SLIDE 1

Physical Design Challenges in the Chip Power Distribution Network

Farid N. Najm Professor & Chair ECE Dept, University of Toronto f.najm@utoronto.ca

SLIDE 2

Outline

■ Introduction

Power grid topology
Physical design challenges

■ Power grid verification

EDA: simulation, vectorless verification
Engineering solution: over-design, and over-kill

■ Constraints-based verification

Voltage variations
Electromigration

■ Constraints generation ■ Conclusion

F. N. Najm

Challenges in Power Grid 2

SLIDE 3

Power Grid Topology

■ ~ a Billion nodes ■ ~ 2,000 C4 pads

1,000 Vdd, 1,000 Vss

■ All levels of metal stack ■ Hundreds of millions of

instances of logic cells

F. N. Najm

Challenges in Power Grid 3

RLC RLC RLC RC Layer RC Layer RC Layer

Vdd Pads Circuit current sources Pkg, PCB

SLIDE 4

Power Grid Topology

■ Package, motherboard, and VRM model; inductance!

F. N. Najm

Challenges in Power Grid 4

SLIDE 5

Power-Managed Chip Grid

■ Gated

supplies

■ Voltage

islands

■ Active

devices!

F. N. Najm

Challenges in Power Grid 5

RLC RLC RLC M7 (RC Layer) M6 (RC Layer) M1 (RC Layer)

Vdd Pads Circuit current sources Pkg, PCB

M5 (RC Layer) M4 (RC Layer) M4 M3 (RC Layer) M3 M2 (RC Layer) M2 M1 Gate FET M1 (RC Layer)

Circuit current sources

M4 (RC Layer) M4 M3 (RC Layer) M3 M2 (RC Layer) M2 M1 Gate FET RLC RLC RLC

Vdd Pads Pkg, PCB

Global (un-gated) Grid Local (gated) Grid

SLIDE 6

Mesh Layer Structure

■ In every layer, the grid is mostly a regular mesh.

F. N. Najm

Challenges in Power Grid 6

M e t a l 3 Metal 4

Vdd

Gnd

■ Note:

Many variations on this central theme
Top layer C4 pads typically on a ~200µm grid
Local non-uniformities make room for signal routing

SLIDE 7

Physical Design

■ With hundreds of millions of instances on die and

clocks running at GHz rates, the total power is high

High performance SOCs might consume over 150 Watts
Very hard to keep supply regulated under such conditions

■ Physical design of the grid can have big impact:

Voltage variations in bottom layers impact circuit timing
Voltage overshoot (inductive kick) impact I/O signal noise
Electromigration damage can be catastrophic throughout

■ Nightmare: ensure circuit is safe from all this while

distributing over 150 Amps to >400 million instances

F. N. Najm

Challenges in Power Grid 7

SLIDE 8

Power Grid Verification

F. N. Najm

Challenges in Power Grid 8

SLIDE 9

Power Grid Verification

■ Verification is needed to check the grid design:

Early high-level grid verification and planning
Incremental verification during redesign cycles
Detailed grid verification at sign-off time

■ Key problem:

The circuit currents are unknown or highly uncertain!

■ Need reliable verification in the face of uncertainty.

F. N. Najm

Challenges in Power Grid 9

SLIDE 10

Existing Commercial Solutions

■ Simulation

Decouple grid from underlying circuit
Simulate the grid for given current source stimulus
Expensive and incomplete; inconclusive

■ Existing solutions for vectorless verification

Voltage variations: timing windows, random scenarios
Electromigration: Black’s model, current density check
Questionable results

■ Engineering solution: over-design, but also over-kill ■ Problem: running out of metal area for signal routing!

F. N. Najm

Challenges in Power Grid 10

SLIDE 11

Constraints-Based Verification

F. N. Najm

Challenges in Power Grid 11

SLIDE 12

Constraints-Based Verification

■ Given:

Power Grid (DC, RC, or RLC netlist)
Tolerance for grid node voltage fluctuations (Vth)
Tolerance for grid branch current densities (EM)
Peak budgets (current constraints) for block currents

■ Find:

Worst-case voltage variations for every grid node
Worst-case current variations in every grid branch

■ Features:

Based on user-provided current constraints (budgets)
Search/optimization (LP) approach for verification
Allows vectorless early high-level power grid verification
F. N. Najm

Challenges in Power Grid 12

SLIDE 13

Current Constraints - Example

■ Local Constraints ■ Global Constraints

F. N. Najm

Challenges in Power Grid 13

1 2 4 5 3 6 9 7 8 +

I3

I5 I2 I7 I9 Vdd Global Constraint 1 Global Constraint 2

SLIDE 14

Voltage Drop: The RC Case

■ Define as the vector of worst-case voltage drops, at

all nodes, over all transient currents in space

■ Define: shorthand notation for element-wise max: ■ Use upper-bound:

F. N. Najm

Challenges in Power Grid 14

emax

i∈F [v(i)] =

       max

i∈F [v1(i)]

max

i∈F [v2(i)]

. . . max

i∈F [vn(i)]

      

SLIDE 15

Performance

F. N. Najm

Challenges in Power Grid 15

SLIDE 16

Voltage Drop/Rise: The RLC Case

F. N. Najm

Challenges in Power Grid 16

SLIDE 17

Electromigration: The Mesh Model

■

Traditional EM model is “series”

But power grid has

much redundancy

■

Vector-based mesh model approach

3-4X lifetime!
Can be 30-40X

■

Vectorless Mesh model approach

F. N. Najm

Challenges in Power Grid 17 Chatterjee 2013, Fawaz 2013

SLIDE 18

Progress Towards Failure

F. N. Najm

Challenges in Power Grid 18

SLIDE 19

Progress towards failure

F. N. Najm

Challenges in Power Grid 19

Series ¡

SLIDE 20

Progress towards failure

F. N. Najm

Challenges in Power Grid 20

Series ¡

SLIDE 21

Progress towards failure

F. N. Najm

Challenges in Power Grid 21

Series ¡

SLIDE 22

Progress towards failure

F. N. Najm

Challenges in Power Grid 22

Series ¡

SLIDE 23

Failure when v(t) > vth

F. N. Najm

Challenges in Power Grid 23

Series ¡ Mesh ¡

SLIDE 24

Results: MTF Comparisons

F. N. Najm

Challenges in Power Grid 24

■ MTF estimation for the largest grid, with 1M nodes

required 97 Monte Carlo iterations and 13.5 hrs.

SLIDE 25

But … there is a Problem

■ Ongoing development:

Electromigration verification

◆ Physical models to further reduce pessimism

Fast hierarchical/modular verification

◆ Boundary conditions to ensure sub-grid safety

■ But there is a fundamental issue with usability of the

constraints-based approach:

F. N. Najm

Challenges in Power Grid 25

The constraints are hard to specify

SLIDE 26

Constraints Generation

F. N. Najm

Challenges in Power Grid 26

SLIDE 27

Alternative Approach

■ Constraints Generation (the “inverse” problem):

Generate circuit current constraints which, if satisfied by the

underlying circuitry, would guarantee grid safety

■ Applications:

Encapsulate much useful information about the grid,

captured in useful quality metrics (peak power, other)

Provides power budgets to drive design process, allowing

rebudgeting, or early hints for grid redesign or new floorplan

During low level physical design, allow local checks for block

compliance with grid safety constraints w/o grid simulation

Local checks in safety “islands” may be enough
F. N. Najm

Challenges in Power Grid 27

SLIDE 28

Voltage Islands (RC case)

■ Typically, we find

the constraints decoupled into “islands”

■ Checking of the

local regions, independently

■ Parallel flow for

verification

F. N. Najm

Challenges in Power Grid 28

SLIDE 29

Container

■ Definition:

F. N. Najm

Challenges in Power Grid 29

SLIDE 30

Safe Container

■ Rewriting the upper-bound on the exact worst-case

voltage drop: where and

■ We want to generate such that , from

which and the grid is safe!

■ Definition: A container is said to be safe if:

F. N. Najm

Challenges in Power Grid 30

SLIDE 31

All Safe Containers

■ Let and define the two sets: ■ Lemma: is safe for any , and:

All possible safe containers may be found as either specific

instances of , or as subsets of such instances.

F. N. Najm

Challenges in Power Grid 31

Vth

SLIDE 32

Maximal Container

■ It’s enough to look at the set of all safe containers: ■ Define a safe container to be maximal if it’s not a

subset of any other safe container.

F. N. Najm

Challenges in Power Grid 32

■ We are interested in

maximal containers!

SLIDE 33

All Maximal Containers

■ Theorem:

F. N. Najm

Challenges in Power Grid 33

Maximal Irreducible Safe Vth

SLIDE 34

Desirable Maximal Containers

■ The space of maximal safe containers represents a

quality assessment for a power grid

What levels of current will this grid safely distribute?

■ Example: suppose the chip is expected to draw a peak

power of 150W at 1V supply

A grid may be deemed unacceptable if no safe container for it

can be found that allows a peak total supply current of 150A

■ Design objectives must drive the choice of container!

F. N. Najm

Challenges in Power Grid 34

SLIDE 35

Container Generation Algorithms

■ Peak Power Problem (P1):

Generate a container that

allows the largest possible peak power dissipation (instantaneous, total)

■ Uniform Current Problem (P2):

Generate a container that does

not severely limit the allowed supply current anywhere on the die

F. N. Najm

Challenges in Power Grid 35

SLIDE 36

Algorithms

■ P1: peak power

One LP

■ P2: uniform budgets

One LP
F. N. Najm

Challenges in Power Grid 36

■ We can prove that both resulting are maximal!

SLIDE 37

Performance (P1)

F. N. Najm

Challenges in Power Grid 37

(Based on 65nm technology parameters and 1.1 Volt supply)

Grid ¡ Nodes ¡ Sources ¡ CPU ¡Time ¡ Peak ¡Power ¡ (mW) ¡ M' ¡ LP ¡ G1 ¡ 8K ¡ 500 ¡ 2 ¡sec ¡ 0.4 ¡sec ¡ 1.7 ¡ G2 ¡ 19K ¡ 1K ¡ 7 ¡sec ¡ 1 ¡sec ¡ 3.7 ¡ G3 ¡ 33K ¡ 2K ¡ 17 ¡sec ¡ 2 ¡sec ¡ 6.8 ¡ G4 ¡ 50K ¡ 3K ¡ 37 ¡sec ¡ 5 ¡sec ¡ 10 ¡ G5 ¡ 113K ¡ 7K ¡ 3 ¡min ¡ 10 ¡sec ¡ 22 ¡ G6 ¡ 201K ¡ 13K ¡ 9 ¡min ¡ 28 ¡sec ¡ 41 ¡ G7 ¡ 312K ¡ 19K ¡ 22 ¡min ¡ 57 ¡sec ¡ 60 ¡ G8 ¡ 449K ¡ 28K ¡ 44 ¡min ¡ 2 ¡min ¡ 85 ¡ G9 ¡ 1M ¡ 63K ¡ 3.6 ¡hr ¡ 9 ¡min ¡ 198 ¡

SLIDE 38

Power Density (P1)

F. N. Najm

Challenges in Power Grid 38

25 50 75 100 125 Number of Windows 0.5 1 1.5 2 2.5 3 3.5 4 4.5

µ = 1.73 mA/cm2 σ = 0.8 mA/cm2

(G4)

SLIDE 39

Performance (P2)

F. N. Najm

Challenges in Power Grid 39

Grid ¡ Nodes ¡ Sources ¡ CPU ¡Time ¡ Radius ¡(uA) ¡ M' ¡ LP ¡ G1 ¡ 8K ¡ 500 ¡ 2 ¡sec ¡ 0.7 ¡sec ¡ 1.8 ¡ G2 ¡ 19K ¡ 1K ¡ 7 ¡sec ¡ 2 ¡sec ¡ 2.1 ¡ G3 ¡ 33K ¡ 2K ¡ 17 ¡sec ¡ 3 ¡sec ¡ 1.5 ¡ G4 ¡ 50K ¡ 3K ¡ 37 ¡sec ¡ 6 ¡sec ¡ 1.8 ¡ G5 ¡ 113K ¡ 7K ¡ 3 ¡min ¡ 20 ¡sec ¡ 1.4 ¡ G6 ¡ 201K ¡ 13K ¡ 9 ¡min ¡ 40 ¡sec ¡ 2.1 ¡ G7 ¡ 312K ¡ 19K ¡ 22 ¡min ¡ 1 ¡min ¡ 2.0 ¡ G8 ¡ 449K ¡ 28K ¡ 44 ¡min ¡ 2 ¡min ¡ 1.6 ¡ G9 ¡ 1M ¡ 63K ¡ 3.6 ¡hr ¡ 5 ¡min ¡ 1.9 ¡

SLIDE 40

Power Density (P2)

F. N. Najm

Challenges in Power Grid 40

25 50 75 100 125 Number of Windows 0.5 1 1.5 2 2.5 3 3.5 4 4.5

µ = 1.3 mA/cm2 σ = 0.2 mA/cm2

(G4)

SLIDE 41

Combined Objective (P3)

■ A combined objective gives the best of both worlds: ■ We can prove that the resulting is maximal!

F. N. Najm

Challenges in Power Grid 41

5 10 15 I1 (mA) 5 10 15 I2 (mA)

SLIDE 42

Performance (P3)

F. N. Najm

Challenges in Power Grid 42

Grid ¡ Nodes ¡ Sources ¡ CPU ¡Time ¡ Peak ¡Power ¡(mW) ¡Radius ¡(uA) ¡ M' ¡ LP ¡ G1 ¡ 8K ¡ 500 ¡ 2 ¡sec ¡ 2 ¡sec ¡ 1.7 ¡ 1.7 ¡ G2 ¡ 19K ¡ 1K ¡ 7 ¡sec ¡ 8 ¡sec ¡ 3.4 ¡ 2.0 ¡ G3 ¡ 33K ¡ 2K ¡ 17 ¡sec ¡ 17 ¡sec ¡ 6.4 ¡ 1.4 ¡ G4 ¡ 50K ¡ 3K ¡ 37 ¡sec ¡ 29 ¡sec ¡ 5.6 ¡ 1.8 ¡ G5 ¡ 113K ¡ 7K ¡ 3 ¡min ¡ 2 ¡min ¡ 22 ¡ 1.4 ¡ G6 ¡ 201K ¡ 13K ¡ 9 ¡min ¡ 5 ¡min ¡ 37 ¡ 2.0 ¡ G7 ¡ 312K ¡ 19K ¡ 22 ¡min ¡ 8 ¡min ¡ 55 ¡ 2.0 ¡ G8 ¡ 449K ¡ 28K ¡ 44 ¡min ¡ 15 ¡min ¡ 84 ¡ 1.6 ¡ G9 ¡ 1M ¡ 63K ¡ 3.6 ¡hr ¡ 56 ¡min ¡ 184 ¡ 1.9 ¡

SLIDE 43

Power Density (P3)

F. N. Najm

Challenges in Power Grid 43

25 50 75 100 125 Number of Windows 0.5 1 1.5 2 2.5 3 3.5 4 4.5

µ = 1.56 mA/cm2 σ = 0.46 mA/cm2

(G4)

SLIDE 44

Conclusion

■ Physical design challenges in the power grid relate to

impact on voltage drop/rise and electromigration

Predicting these effects is hard, due to stimulus uncertainty
Given budgets (constraints), there are ways to overcome the

uncertainty, but still expensive and under development

■ Constraints generation is possible and practical, and

is a rich area of study, previously unexplored

Quality metrics for the power grid provide a rigorous

approach for early grid design/planning

Voltage drop-aware placement and routing?

■ Future work:

Automatic safe grid generation, along with constraints?
F. N. Najm

Challenges in Power Grid 44
