Phosphorus Overview Instrument: Integrated Project under FP6 - - PowerPoint PPT Presentation

· PHOSPHORUS (FP6 IP IST Project) · Web 2.0 & UCLPv2 · Media eInfrastructures

European Future Networking Initiatives TERENA Workshop

February 2007, Amsterdam

Sergi Figuerola

i2CAT Foundation

2

European Future Networking Initiatives Workshop 2007

Phosphorus Overview

Instrument: Integrated Project under FP6 Activity: IST-2005-2.5.6 – research networking test-beds Project duration 30 months Project started 01 October 2006 Project budget 6.868.969 euro (5.125.098 euro EC contribution) Project resources 814 person months http://www.ist-phosphorus.eu

3

European Future Networking Initiatives Workshop 2007

Participants

4

European Future Networking Initiatives Workshop 2007

Phosphorus Project

European and Global alliance of partners to develop advanced solution of application-level middleware and underlying management and control plane technologies Project Vision and Mission

• The project will address some of the key technical challenges in

enabling on-demand end-to-end network services across multiple heterogenous domains

• In the Phosphorus' implementation the underlying network will be

treated as first class Grid resource

• Phosphorus will demonstrate solutions and functionalities across a

test-bed involving European NRENs, GÈANT2, Cross Border Dark Fibre and GLIF

5

European Future Networking Initiatives Workshop 2007

Project key features (I/II)

• Develop integration between application middleware and transport

networks, based on three planes:

• Service plane:

– Middleware extensions and APIs to expose Network and Grid resources and make reservations of those resources

• Network Resource Provisioning plane:

– Adaptation of existing Network Resource Provisioning Systems (NRPS) to support the framework of the project – Interworking of NRPS-based domains with GMPLS-controlled network domains, i.e. interoperability between G[2]MPLS and UCLPv2, DRAC, ARGON and JRA3(GN2).

• Control plane:

– Enhancements of the GMPLS Control Plane (G²MPLS) to provide optical network resources as first-class Grid resource

6

European Future Networking Initiatives Workshop 2007

Project key features (II/II)

Studies to investigate and evaluate further the project

• utcomes :
• Study resource management and job scheduling algorithms

incorporating network-awareness, constraint based routing and advance reservation techniques

• Develop a simulation environment, supporting the Phosphorus network

scenario

Disseminate the project experience and outcomes, toolkits and middleware to NRENs and their users, such as Supercomputing centres

7

European Future Networking Initiatives Workshop 2007

Applications NREN+vendor 1 Service plane 1 Control plane

Equipment

transport+Data

NREN+vendor 2 Service plane 2 NRPS

Equipment

transport+Data

NREN+vendor n Service plane n NRPS+Control plane Equipment

transport+data

Application 1 Application 2 Application n

λ λ

PHOSPHORUS NETWORK SCENARIO

8

European Future Networking Initiatives Workshop 2007

PHOSPHORUS ARCHITECTURE

The different domains of the Phosphorus' test-bed will have:

Two “flavours” of GMPLS standard (Ph. 1) Grid-enabled (Ph. 2) Three types of NRPS: UCLP DRAC ARGON

Grid middleware

UNICORE as a reference point AAA policies

9

European Future Networking Initiatives Workshop 2007

Initial Applications

• WISDOM - Wide In Silica Docking On Malaria (FHG, PSNC):
• Large scale molecular docking on malaria to compute million of compounds with different

software and parameter settings (in silico experimentation)

• KoDaVis – Distributed visualisation (FZJ, PSNC, UESSEX)
• Compute capacity on the data server and the visualisation clients
• Allocate network bandwidth and QoS between server and clients
• TOPS – Technology for Optical Pixel Streaming (FHG, SARA)
• Streaming of Ultra High Resolution Data Sets over Lambda Networks
• Use lossy protocols for long distance connectivity: High performance TCP hard to

achieve, UDP performance trivial

• Light weight application – scalable bandwidth usage
• DDSS - Distributed Data Storage System (PSNC, HEL, FZJ, FHG, UESSEX)
• Possible scenarios of usage:

– Data gathering or data distributing – Backups of large medical data volumes (bandwidth demanding) from one or many clients

10

European Future Networking Initiatives Workshop 2007

Phosphorus Work Packages

• Optical Router

WP3 WP4: Authentication, Authorization and Accounting (AAA) WP4: Authentication, Authorization and Accounting (AAA) Final Demonstrator WP6 WP2 Network Scenario and System Specifications Project Management WP1 Exploitation and Dissemination WP7 Optical Router WP3 Final Demonstrator WP6 WP5 Supporting Studies Project Management WP0 WP7: Dissemination, Contribution to standards, Liaisons WP1: NRPS WP2:Enhancements to GMPLS for Grid Services WP3: Middleware and Applications WP6: Test-bed and Demonstration Activities

11

European Future Networking Initiatives Workshop 2007

WP 1: Network Resource Provisioning Systems (NRPS) for GRID Network Services

Objectives: 1. Definition of NRPS and GMPLS control plane boundaries 2. Development of interfaces and NRPS driver 3. Implementation of the Network Service Plane:

• Implements advance reservations
• AAA Functionalities
• System information management (Topology, users, resource usage, etc.)

Interoperability between NRPS, G2MPLS,Grid middleware and JRA3 (GN2),

TN NRPS

SNMP/CLI/TL1

TN NRPS

SNMP/CLI/TL1

GMPLS NRPS

SNMP/CLI/TL1

NRPS Driver NRPS Driver NRPS Driver

G H F D E B C A

Grid App Network Service Plane NRPS Broker 1st Ph. Architecture:

• Planned delivery date:
• System requirements (D1.1): March 07
• SW prototypes by the end of 2007
• International cooperation:
• EnLIGHTened
• G-Lambda

12

European Future Networking Initiatives Workshop 2007

WP1: Architecture 2nd Ph.

NRPS NSP NRPS NRPS

. . .

NRPS NSP NRPS NRPS

. . .

NRPS NSP NRPS NRPS

. . .

DM G2MPLS TN NRPS NSP NRPS NRPS

. . .

JRA3 IDM TN TN TN TN

. . . . . .

G-Lambda EnLIGHTened ? ?

• Distributed architecture:
• Phosphorus interoperability:

13

European Future Networking Initiatives Workshop 2007

WP2 - Enhancements to the GMPLS Control Plane for Grid Network Services (GNS)

G2 G2 G2 G2

G.I-NNI G.E-NNI G.O-UNI

G2MPLS NRPS

G.O-UNI

VOa VOb VOc Extensions to the GMPLS CP for automatic and single-step setup

• f Grid & network resources
• Grid-GMPLS (G2MPLS) main tracks:
• seamless coexistence with NRPS & Grid MW
• Grid-aware network reference points

(G.O-UNI, G.E-NNI, G.I-NNI)

• CBR algorithms for recovery and TE
• Integration with AAA system
• Planned delivery of G2MPLS CP prototypes
• R1.0 by M12: sw. rel. of G.I-NNI + G.O-UNI
• R2.0 by M24: sys. rel. of full-fledged G2MPLS
• Technical validation
• supporting studies (WP5), demos (WP6)

and disseminations (WP7)

• cooperation with Intl. initiatives (i.e.

EnLIGHTened, G-Lambda) and synergies with GN2-JRA3

14

European Future Networking Initiatives Workshop 2007

WP3: Middleware and Applications

• Integration of network reservation services into existing Grid middleware
• services for user-driven or application-driven set-up of execution environments

with dedicated capabilities & performance

– Compute nodes, storage systems, visualization devices – Network resources with defined QoS

• Integration of applications
• WISDOM: Wide in silicio docking on Malaria
• KoDaVis: collaborative, distributed visualization of huge data sets
• TOPS: Streaming of ultra high resolution data sets over lambda networks
• DDSS: Distributed Data Storage System

Provide application access to PHOSPHORUS services and showcase their benefit via applications

15

European Future Networking Initiatives Workshop 2007

WP4: Authentication, Authorization & Accounting

• Service Plane - AAA will focus on implementing and integrating AAA

solutions for the Phosphorus test-bed. The objectives of WP4 in the first 18 month are:

• To study the applicability of current and emerging AAA related technologies in
• rder to select a suitable set with enough flexibility to create and test the

interoperability of optical network domains. Collaborations with GEANT2 (JRA5), DRAGON and EGEE will be established which and will be used as a base.

• Collaborate with WP1, 2 and 3 to establish their specific needs towards AAA

and describe their needs in a uniform way that allowing a more generalized implementation

• To create prototypes, running in a test-bed which demonstrates authorization

sequences applied in multiple functional layers of the network. The AAI work within GEANT2 and VOMS work within EGEE will be used as starting point and expanded.

16

European Future Networking Initiatives Workshop 2007

WP5: Supporting Studies

Job routing & scheduling algorithms Network & resource management Job routing & scheduling algorithms Network & resource management Simulation environment Simulation environment Control plane design Control plane design

• Job demand models
• QoS resource scheduling
• Grid job routing algorithms
• Physical layer constraints
• Advance reservations
• Optical network
• Advanced control plane
• Network service plane
• Architectural issues
• Integration strategies
• Recommendations

WP1 WP2

17

European Future Networking Initiatives Workshop 2007

WP6: Testbed & Demonstration Activities

18

European Future Networking Initiatives Workshop 2007

WP7: Dissemination, Contribution to Standards, Liaisons

• Disseminate information concerning the technical developments to NRENs and

related projects (MUPBED, GN2, NOBEL, EGEE, DEISA, OpenNet, RING, ONELAB,

PANLAB, UCLP, DRAGON, Enlightened Computing, G-Lambda…)

• Collaboration of 3 Continents (C3C): Phosphorus, Enlightened and G-Lambda
• Meeting between WP1, WP2 and JRA3 (GN2); WP4 and JRA5(GN2) and DRAGON
• Coordinate direct contributions to standards
• Build a collaborative framework for participation to test-bed activities from within

and external to EU

• Questionnaire to collect information about NRENs that would want to deploy

GMPLS & G2MPLS protocol and NRPS systems in their networks and inform about Phosphorus directions of work.

• We want to provide solutions which will expect by our community and could be

deployed in short time as new offered service http://www.ist-phosphorus.eu/documents.php

(http://www.ist-phosphorus.eu/files/press/phosphorus-questionnaire.doc)

UCLPv2: Applying the Web 2.0 UCLPv2: Applying the Web 2.0 phil philosophy to the

• sophy to the networking

networking revolution revolution

Web 2.0:

• Provides tools and applications to empower user

participation, content creation and sharing over the web.

UCLP v2 (I)

• Provides tools to allow users to participate in the process of creating

and setting up their own virtual/logical networking infrastructure

• Virtual networking infrastructure made up of physical resources

(partitions of physical nodes, physical links, sensors, instruments, …) provided by different physical administrators

• Users can use this virtual infrastructure for their own needs and/or

exchange/acquire/sell part of this infrastructure to other users

• Provides a network virtualization framework upon which communities
• f users can build their own services or applications

Physical network administrator creates logical resources by partitioning its network

UCLP v2 (II)

User get resources from the administrator and configures his own network setup

Web 2.0, SOA and UCLPv2

• Web 2.0 tools are a collection of software services (service “mashups”)

whose API is usually publicly accessible trough open standards (XML, REST web services, SOAP web services)

• SOA is about creating modular, secure and reusable services that can be

used to build other services and applications

• UCLPv2 is not an application software but a suite of different application

modules based on SOA. By having these different modules interacting together users can create network behaviors specific to their needs

– Web 2.0 = The Web as a Platform – UCLPv2 = The Network as a Platform

A new Media A new Media eI nfrastructure eI nfrastructure

• Internet is increasingly a media network, but limitations of current network media technology
• The need for a Media eInfrastructure for Future Research on Visualization and Media

Networking: 3/4G, Lambda Networking, GN2.. Digital repositories Media: HD/3D/Visualization Computing: SuperComputing/GRIDS, DEISA

A new Media and Visualization layer to offer experimental media services, that integrates the new digital interfaces European eInfrastructures (2013)

• An environment to enable users to set up the media-network infrastructure under requests

when needed

• Collaboration between:

– Network engineering research community – Media content research community

• These Media eInfrastructure should provide:

– capacity detection: in order to distinguish between users (network and resources) – Transcodification: depending on the capacities the content should dynamically adapt, by means of different codifications schemes – Security, integrity and confidentiality – Balancing/distribution/ load clustering – Content Storage capacity – Detection, publish and new contents service

THANK YOU

Sergi Figuerola

Sergi.figuerola@i2cat.net
