SLIDE 1

A Dialogue on Phosphorus Measurements

4/8/2014 Upstate Freshwater Institute 1

SLIDE 2

Outline

1. review of forms of phosphorus (P) 2. triplicate sample performance, Cayuga Lake 2013 study 3. phosphorus fraction comparisons among different systems 4. phosphorus fraction comparisons: different certified labs 5. consistency of P forms with limnological paradigms 6. UFI’s P resume 7. evaluation of two SRP methods (selected features)

4/8/2014 Upstate Freshwater Institute 2

SLIDE 3

Partitioning P Fractions

 contemporary methods for large sample number studies remain operationally-based  particulate vs. dissolved partitioning – 0.45 µm pore size filtration – imperfect – colloidal and ruptured cell passage – convenient and replicable  total P fractions – following digestion – without filtration – total P (TP) – following filtration – total “dissolved” P (TDP) – particulate P (PP) usually by calculation

4/8/2014 Upstate Freshwater Institute 3

𝑄𝑄 = 𝑈𝑄 − 𝑈𝐸𝑄

SLIDE 4

Partitioning Dissolved P Fractions

 nomenclature

– soluble reactive P (SRP)

operationally defined – responsive to “mixed” reagent
also MRP – molybdate reactive; PO4

3-—P (not good alternative)

PO4

3- actually a small fraction of SRP

– soluble unreactive P (SUP)

commonly and heretofore, dissolved organic P (DOP)
henceforth SUP

 wide array of P-containing chemical entities contribute to fractions

– system specific differences and temporal variation reasonable expectations – variations in relative contributions of SRP and SUP to be expected

TDP SRP SUP

PO4

3-

heterogeneous array of forms

condensed phosphates

rganic P

colloidal particles

4/8/2014 Upstate Freshwater Institute 4

SLIDE 5

References for P: Limitations of Common Operative Measurements

 selective

– Lean, D.R.S. 1973. Science. 179:678-680 – Fisher, T.R. and Lean, D.R.S. 1992. Can. J. Fish. Aquat. Sci. 49:252-259 – Baldwin, D.S. 1998. Wat. Res. 2265-2270 – Hudson, J.J., Taylor W.D., and Schindler, D.W. 2000. Nature. 406:54-56 – Dodds, W.K. 2003. J. N. Am. Benthol. Soc. 22:171-181 – Hudson, J.J. and Taylor, W.D. 2005. Aquat. Sci. 67:316-325

 UFI’s synthesis

– see Introduction of Effler and O’Donnell (2010). Fundam. Appl.

Limnol. 177:1-18

4/8/2014 Upstate Freshwater Institute 5

SLIDE 6

References for P: SUP(DOP) – Characterizations, Etc.

 Turner, B.L., E. Frossard, and D.S. Baldwin. (2005) Organic Phosphorus in the

Environment. CABI, Oxfordshire UK, 399pp.

– various examples of elegant isolations of specific groups

 selected articles

– Francko, D.A. and Heath, R.T. 1979. Limnol.

Oceanogr. 24: 463-473

– Cotner, J.B. and Wetzel, R.G. 1992. Limnol.

Oceanogr. 37: 232-243

– Betzen, E. and Taylor, W.D. 1992. Limnol. Oceanogr. 37: 217-231 – Baldwin, D.S. 1998. Wat. Res. 32:2265-2270 – Bjorkman, K.M. and Karl, D.M. 2003. Limnol.

Oceanogr. 48: 1049-1057

– Stets, E.G. and Cotner, J.B. 2008. Limnol. Oceanogr. 53: 137-147

4/8/2014 Upstate Freshwater Institute 6

SLIDE 7

Outline

1. review of forms of phosphorus (P) 2. triplicate sample performance, Cayuga Lake 2013 study 3. phosphorus fraction comparisons among different systems 4. phosphorus fraction comparisons: different certified labs 5. consistency of P forms with limnological paradigms 6. UFI’s P resume 7. evaluation of two SRP methods (selected features)

4/8/2014 Upstate Freshwater Institute 7

SLIDE 8

Analysis of Field Triplicate Samples

 3 discrete samples collected over a short time interval  combined test of – representativeness of individual samples – laboratory performance  not a NELAC requirement  conducted in addition to lab QA protocols  UFI policy to include – limnological QA – included in Cayuga L. QAPP  coefficient of variation (CV=stand. dev. ÷ mean) adopted as a summary statistic  acceptable thresholds rarely set – one example, CV ≤ 20% for Onondaga L. Superfund site – some guidance in the literature

4/8/2014 Upstate Freshwater Institute 8

SLIDE 9

Analysis of Field Triplicate Samples: Salmon Creek, P

 based on UFI’s experience a case of good performance

– low variability

4/8/2014 Upstate Freshwater Institute 9

SLIDE 10

Analysis of Field Triplicate Samples: Onondaga Creek, P

example year, 2006, TP,

TDP, and SRP

generally consistent with

Salmon Creek

bservations, 2013

4/8/2014 Upstate Freshwater Institute 10

Count

4 8 12

Count

4 8

CV (%)

4 8 12 16 20

Count

4 8

(a) TP (b) TDP (c) SRP

>20

n=27 mean=10% n=27 mean=10% n=27 mean=8%

SLIDE 11

Peer-Reviewed Literature Support for Field Triplicate Performance

UFI reported average CV =

10% for TP, biweekly collection for 19 years (supported as appropriate in the peer-reviewed literature)

Effler, S.W., Prestigiacomo,

A.R., Matthews, D.A., Michalenko, E.M., and Hughes, D.J. 2009. Partitioning phosphorus concentrations and loads in tributaries of a recovering urban lake. Lake Reservoir

Manag. 25: 225-239.

4/8/2014 Upstate Freshwater Institute 11

SLIDE 12

Peer-Reviewed Literature Support for UFI Performance on Field Triplicates P Analyses: Onondaga Lake

 note CV higher for SRP because many samples approached detection limit  Effler, S.W. and S.M. O’Donnell. 2010. A long-term record of epilimnetic phosphorus patterns in recovering Onondaga Lake, New

York. Fundam. Appl. Limnol. Vol. 177/1, 1–18.

4/8/2014 Upstate Freshwater Institute 12

Phosphorus Concentration (µg·L-1) Forms of Phosphorus SRP TDP TP n median CV % n median CV % n median CV % 1-5 157 15.5 56 7.3

5-20

83 2.7 263 7.5 49 3.1 20-50 86 1.6 148 6.3 220 3.4 50-100 39 1.0 99 2.8 231 3.1

SLIDE 13

Comparison of Cayuga Lake Field Triplicate Performance to Onondaga Lake Performance

 consistent, good, performance

4/8/2014 Upstate Freshwater Institute 13

Phosphorus Concentration (µg·L-1) Forms of Phosphorus SRP TDP TP n median CV % n median CV % n median CV % 1-5 On.Lk. 157 15.5 56 7.3

1-5 Cay. Lk. 2013

9 8.5 5 8.4

1-5 Cay. Lk. 98-06

90 4.5 144 12.4 1

5-20 On. Lk.

83 2.7 263 7.5 49 3.1 5-20 Cay. Lk. 2013 2 3.2 11 5.7 16 3.9 5-20 Cay. Lk. 98-06

48 3.2

113 9.6 171 5.2 20-50 On. Lk. 86 1.6 148 6.3 220 3.4 20-50 Cay. Lk. 2013

20-50 Cay. Lk. 98-06
4

3.1 99 7.4 50-100 On. Lk. 39 1.0 99 2.8 231 3.1 50-100 Cay. Lk. 2013

50-100 Cay. Lk. 98-06
6

6.9

general consistency in performance between lake programs

SLIDE 14

Analysis of Field Triplicate Samples: Salmon Creek, Other Constituents

low variability for these other constituents

4/8/2014 Upstate Freshwater Institute 14

SLIDE 15

Outline

1. review of forms of phosphorus (P) 2. triplicate sample performance, Cayuga Lake 2013 study 3. phosphorus fraction comparisons among different systems 4. phosphorus fraction comparisons: different certified labs 5. consistency of P forms with limnological paradigms 6. UFI’s P resume 7. evaluation of two SRP methods (selected features)

4/8/2014 Upstate Freshwater Institute 15

SLIDE 16

Phosphorus Fractions

where : TP = total phosphorus PP = particulate phosphorus TDP = total dissolved phosphorus

𝑈𝑄 = 𝑄𝑄 + 𝑈𝐸𝑄

where : SRP = soluble reactive phosphorus SUP = soluble unreactive phosphorus

𝑈𝐸𝑄 = 𝑇𝑆𝑄 + 𝑇𝑉𝑄

4/8/2014 Upstate Freshwater Institute 16

SLIDE 17

Phosphorus Ratios as Diagnostics Supporting Data Analysis 𝑈𝑄 = 𝑄𝑄 + 𝑈𝐸𝑄 𝑈𝐸𝑄 = 𝑇𝑆𝑄 + 𝑇𝑉𝑄 𝑄𝑄 𝑈𝑄 𝑇𝑆𝑄 𝑈𝐸𝑄 𝑇𝑉𝑄 𝑈𝐸𝑄

 to represent contributions of fractions

4/8/2014 Upstate Freshwater Institute 17

SLIDE 18

SRP/TDP : Tributary Cross System Comparison

 tributaries, averages and variability bars (1 std. dev.)  UFI measurements

4/8/2014 Upstate Freshwater Institute 18 C-WBDR95 C-WBDR98 AW-ESO97 P-EBDR97 S-Sch98 N-NevR98

SRP/TDP (%)

20 40 60 80 100 A-MR 99 Cr-Cross99 M-AngFly99 M-AngFly00 M-Plum99 M-Plum00 M-Stone99 M-Stone00 N-Hunt99 N-Hunt00 N-Kiscot99 N-Kisco00 O-Nm06 O-Nm07 O-Nm08 O-Nm09 O-Nm10 O-Ock06 O-Ock07 O-Ock08 O-Ock09 O-Ock10

Onon. L.

NYC WOH NYC EOH

SLIDE 19

SRP/TDP : Tributary Cross System Comparison Including Cayuga Lake

 tributaries, averages and variability bars (1 std. dev.)  UFI measurements  Cayuga tribs not widely different – similar temporal variability

4/8/2014 Upstate Freshwater Institute 19 C-WBDR95 C-WBDR98 AW-ESO97 P-EBDR97 S-Sch98 N-NevR98

SRP/TDP (%)

20 40 60 80 100 A-MR 99 Cr-Cross99 M-AngFly99 M-AngFly00 M-Plum99 M-Plum00 M-Stone99 M-Stone00 N-Hunt99 N-Hunt00 N-Kiscot99 N-Kisco00 O-Nm06 O-Nm07 O-Nm08 O-Nm09 O-Nm10 O-Ock06 O-Ock07 O-Ock08 O-Ock09 O-Ock10 Cay-FallCk Cay-CayInlet Cay-Salmon Cay-SixMile Cay-TaughCk

Onon. L.

NYC WOH NYC EOH Cayuga Tribs

SLIDE 20

PP/TP : Tributary Cross System Comparison

 tributaries, averages and variability bars (1 std. dev.)  UFI measurements

C-WBDR95 C-WBDR98 AW-ESO97 P-EBDR97 S-Sch98 N-NevR98

PP/TP (%)

20 40 60 80 100 A-MR 99 Cr-Cross99 M-AngFly99 M-AngFly00 M-Plum99 M-Plum00 M-Stone99 M-Stone00 N-Hunt99 N-Hunt00 N-Kiscot99 N-Kisco00 O-Nm06 O-Nm07 O-Nm08 O-Nm09 O-Nm10 O-Ock06 O-Ock07 O-Ock08 O-Ock09 O-Ock10

Onon. L.

NYC WOH NYC EOH

4/8/2014 Upstate Freshwater Institute 20

SLIDE 21

PP/TP: Tributary Cross System Comparison, Including Cayuga Lake

 tributaries, averages and variability bars (1 std. dev.)  UFI measurements  Cayuga tributaries not widely different – similar to sediment-rich Onondaga Lake tributaries – similar temporal variability

C-WBDR95 C-WBDR98 AW-ESO97 P-EBDR97 S-Sch98 N-NevR98

PP/TP (%)

20 40 60 80 100 A-MR 99 Cr-Cross99 M-AngFly99 M-AngFly00 M-Plum99 M-Plum00 M-Stone99 M-Stone00 N-Hunt99 N-Hunt00 N-Kiscot99 N-Kisco00 O-Nm06 O-Nm07 O-Nm08 O-Nm09 O-Nm10 O-Ock06 O-Ock07 O-Ock08 O-Ock09 O-Ock10 Cay-FallCk Cay-CayInlet Cay-Salmon Cay-SixMile Cay-TaughCk

Onon. L.

NYC WOH NYC EOH Cayuga Tribs

4/8/2014 Upstate Freshwater Institute 21

SLIDE 22

SUP/TDP: Upper Waters Cross System Comparison

 epilimnion, averages (spring-fall) and variability bars (1

std. dev.)

 UFI measurements

ASE-97 ASW-97 PEP-97 RON-97 CAN-95 CAN-98 NEV-98 SCH-98 WBR-98

SUPe/TDPe (%)

20 40 60 80 100

Onondaga Cat/Del EOH

AWR-99 CRR-99 CFR-99 DVR-99 TCR-99 MCR-99 MCR-00 NCR-99 NCR-00 ONL-06 ONL-07 ONL-08 ONL-09 ONL-10 ONL-11 ONL-12 4/8/2014 Upstate Freshwater Institute 22

SLIDE 23

SUP/TDP: Upper Waters Cross System Comparison, Including Cayuga Lake

 epilimnion, averages (spring-fall) and variability bars (1 std. dev.)  Cayuga Lake 0-4m composite sample (1999 -2006), site LSC8 or site 3  UFI measurements  Cayuga Lake generally consistent, SUP dominates

ASE-97 ASW-97 PEP-97 RON-97 CAN-95 CAN-98 NEV-98 SCH-98 WBR-98

SUPe/TDPe (%)

20 40 60 80 100

Onondaga Cat/Del EOH

AWR-99 CRR-99 CFR-99 DVR-99 TCR-99 MCR-99 MCR-00 NCR-99 NCR-00 ONL-06 ONL-07 ONL-08 ONL-09 ONL-10 ONL-11 ONL-12 CAY-99 CAY-00 CAY-01 CAY-02 CAY-03 CAY-04 CAY-05 CAY-06

Cayuga

4/8/2014 Upstate Freshwater Institute 23

SLIDE 24

PP/TP: Upper Waters Cross System Comparison

 epilimnion, averages (spring-fall) and variability bars (1

std. dev.)

 UFI measurements

ASE-97 ASW-97 PEP-97 RON-97 CAN-95 CAN-98 NEV-98 SCH-98 WBR-98

PPe/TPe (%)

20 40 60 80 100

Onondaga Cat/Del EOH

AWR-99 CRR-99 CFR-99 DVR-99 TCR-99 MCR-99 MCR-00 NCR-99 NCR-00 ONL-06 ONL-07 ONL-08 ONL-09 ONL-10 ONL-11 ONL-12 4/8/2014 Upstate Freshwater Institute 24

SLIDE 25

PP/TP: Upper Waters Cross System Comparison, Including Cayuga Lake

 epilimnion, averages (spring-fall) and variability bars (1 std. dev.)  Cayuga Lake 0-4m composite sample (1999 -2006), site LSC8 or site 3  Cayuga Lake generally consistent

ASE-97 ASW-97 PEP-97 RON-97 CAN-95 CAN-98 NEV-98 SCH-98 WBR-98

PPe/TPe (%)

20 40 60 80 100

Onondaga Cat/Del EOH

AWR-99 CRR-99 CFR-99 DVR-99 TCR-99 MCR-99 MCR-00 NCR-99 NCR-00 ONL-06 ONL-07 ONL-08 ONL-09 ONL-10 ONL-11 ONL-12 CAY-99 CAY-00 CAY-01 CAY-02 CAY-03 CAY-04 CAY-05 CAY-06

Cayuga

4/8/2014 Upstate Freshwater Institute 25

SLIDE 26

Outline

1. review of forms of phosphorus (P) 2. triplicate sample performance, Cayuga Lake 2013 study 3. phosphorus fraction comparisons among different systems 4. phosphorus fraction comparisons: different certified labs 5. consistency of P forms with limnological paradigms 6. UFI’s P resume 7. evaluation of two SRP methods (selected features)

4/8/2014 Upstate Freshwater Institute 26

SLIDE 27

SRP/TDP Ratio: Comparison Between Labs

 West Branch Delaware River  2002  UFI versus NYSDEP lab  samples not paired  similar distribution

(a) UFI n = 17

med. = 0.80

% Occurrence

10 20 30 40 50 (b) DEP n = 24

med. = 0.72

SRP/TDP

0.0 0.2 0.4 0.6 0.8 1.0 10 20 30 40

4/8/2014 Upstate Freshwater Institute 27

SLIDE 28

SRP/TDP Ratio: Comparison Between Labs

 Onondaga Creek @ Kirkpatrick St.  2006-2012  UFI versus WEP lab  samples not paired  similar distributions

(a) UFI n = 271

med. = 0.67

% Occurrence

10 20 30 40 50 (b) WEP n = 185

med. = 0.64

SRP/TDP

0.0 0.2 0.4 0.6 0.8 1.0 10 20 30 40

4/8/2014 Upstate Freshwater Institute 28

SLIDE 29

SRP/TDP Ratio: Comparison Between Labs

 Ninemile Creek @ Route 48  2006-2012  UFI versus WEP lab  samples not paired  similar distribution

(b) WEP n = 261

med. = 0.53

SRP/TDP

0.0 0.2 0.4 0.6 0.8 1.0 5 10 15 20 25 (a) UFI n = 179

med. = 0.53

% Occurrence

5 10 15 20 25 30

4/8/2014 Upstate Freshwater Institute 29

SLIDE 30

SRP/TDP Ratio: Comparison Between Labs

 Ley Creek @ Park Street  2006-2012  UFI versus WEP lab  samples not paired  similar distribution

(b) WEP n = 180

med. = 0.57

SRP/TDP

0.0 0.2 0.4 0.6 0.8 1.0 5 10 15 20 25 (a) UFI n = 177

med. = 0.60

% Occurrence

5 10 15 20 25 30

4/8/2014 Upstate Freshwater Institute 30

SLIDE 31

Outline

1. review of forms of phosphorus (P) 2. triplicate sample performance, Cayuga Lake 2013 study 3. phosphorus fraction comparisons among different systems 4. phosphorus fraction comparisons: different certified labs 5. consistency of P forms with limnological paradigms 6. UFI’s P resume 7. evaluation of two SRP methods (selected features)

4/8/2014 Upstate Freshwater Institute 31

SLIDE 32

Utility of Monitoring Operationally Defined Forms of P: The Onondaga Lake Example

 demonstrated widely as an effective basis of management  long-term trends for Onondaga Lake (a UFI product) a good example (Effler and O’Donnell 2010)

TPL (kg·d-1)

100 200 300 400

TPMetro (µgP·L-1)

500 1000 1500

(a)

(µgP·L (µgP·L (µgP·L

TPL TPMetro

70 75 80 85

TPMetro

6 12

87 88 89 90 91 92 93 94 95 96 97 98 99 00 01 02 03 04 05 06 07 08 09

decreasing loads (WEP data) severe eutrophy upper mesotrophy

4/8/2014 Upstate Freshwater Institute 32

SLIDE 33

Utility of Monitoring Operationally Defined Forms of P: The Onondaga Lake Example

 demonstrated widely as an effective basis of management  long-term trends for Onondaga Lake (a UFI product) a good example (Effler and O’Donnell 2010)

TPL (kg·d-1)

100 200 300 400

TPMetro (µgP·L-1)

500 1000 1500

(a) (b)

TPe (µgP·L-1)

50 100 150

(µgP·L (µgP·L

TPL TPMetro

70 75 80 85

TPMetro

6 12

87 88 89 90 91 92 93 94 95 96 97 98 99 00 01 02 03 04 05 06 07 08 09

decreasing loads (WEP data) decreasing epilimnetic concentrations severe eutrophy upper mesotrophy

4/8/2014 Upstate Freshwater Institute 33

SLIDE 34

Utility of Monitoring Operationally Defined Forms of P: The Onondaga Lake Example

 demonstrated widely as an effective basis of management  long-term trends for Onondaga Lake (a UFI product) a good example (Effler and O’Donnell 2010)

TPL (kg·d-1)

100 200 300 400

TPMetro (µgP·L-1)

500 1000 1500

(a) (b) (c)

TPe (µgP·L-1)

50 100 150

(µgP·L SRPe (µgP·L-1)

0.0 12.5 25.0 37.5 50.0

TPL TPMetro

70 75 80 85

TPMetro

6 12

87 88 89 90 91 92 93 94 95 96 97 98 99 00 01 02 03 04 05 06 07 08 09

decreasing loads (WEP data) decreasing epilimnetic concentrations shift to distinct P-limitation severe eutrophy upper mesotrophy

4/8/2014 Upstate Freshwater Institute 34

SLIDE 35

Utility of Monitoring Operationally Defined Forms of P: The Onondaga Lake Example

 demonstrated widely as an effective basis of management  long-term trends for Onondaga Lake (a UFI product) a good example (Effler and O’Donnell 2010)

TPL (kg·d-1)

100 200 300 400

TPMetro (µgP·L-1)

500 1000 1500

(a) (b) (c) (d)

TPe (µgP·L-1)

50 100 150

SUPe (µgP·L-1)

0.0 12.5 25.0 37.5 50.0

% of TDPe

25 50 75 100

SRPe (µgP·L-1)

0.0 12.5 25.0 37.5 50.0

SUPe %SUPe of TDPe TPL TPMetro

70 75 80 85

TPMetro

6 12

87 88 89 90 91 92 93 94 95 96 97 98 99 00 01 02 03 04 05 06 07 08 09

decreasing loads (WEP data) decreasing epilimnetic concentrations shift to distinct P-limitation decreases reflect increased enzymatic uptake severe eutrophy upper mesotrophy

4/8/2014 Upstate Freshwater Institute 35

SLIDE 36

Limnological Consistency Checks: SUP to DOC Ratio, Hypolimnion, Cayuga Lake

4/8/2014 Upstate Freshwater Institute 36

 dissolved organic material (DOM) pool

– primary proxy – dissolved organic carbon (DOC) – expected to have associated dissolved

rganic phosphorus

(DOP) - e.g. SUP

 hypolimnetic temporal pattern  lack of noteworthy trend, consistent 2013

Apr May Jun Jul Aug Sep Oct

SUP/DOC (µgP/mgC)

0.0 0.5 1.0 1.5 2.0 2.5

95 5 90 10 75 25 50 key

SLIDE 37

Limnological Consistency Checks: Hypolimnetic Pools of SUP, SRP and DOC, in the Vertical

4/8/2014 Upstate Freshwater Institute 37

profiles mid-lake early May profiles mid-lake Sept.

T (°C)

10 20

Depth (m)

20 40 60 80 100 120

P (µgP/L)

5 10 15

DOC (mg/L)

1 2 3 4

T (°C)

0 5 101520

Depth (m)

20 40 60 80 100 120

P (µgP/L)

5 10 15

DOC (mg/L)

1 2 3 4

SRP SUP

little vertical structure DOC and SUP
SRP seasonally variable structure – source

and sink processes

SLIDE 38

Limnological Consistency Checks: Hypolimnetic Pools of SUP, SRP, and DOC Temporally

4/8/2014 Upstate Freshwater Institute 38

 as mass estimates – volumes for depth interval from hypsographic data 𝑛𝑏𝑡𝑡 = 𝑑𝑝𝑜𝑑 𝑛𝑕 𝑛3 · 𝑤𝑝𝑚(𝑛3) 𝑢𝑝𝑢𝑏𝑚 𝑛𝑏𝑡𝑡 =

𝑗=1 𝑜

𝑤𝑗 · 𝑑𝑝𝑜𝑑.𝑗  temporal patterns of mass

2013

Apr May Jun Jul Aug Sep Oct

Hypolimnion Mass (mgP)

1e+10 2e+10 3e+10 4e+10

Hypolimnion Mass (gC)

1e+10 2e+10 3e+10 4e+10

SRP SUP DOC

SLIDE 39

Cayuga vs. Finger Lakes

 2004 Finger Lakes survey  Chl and TP, TDP, PP  average measurements, bars are 1

std. dev. (temporal variations)

 UFI lake data – collected 1/month – May – Sept. 2004 – samples 0-2m composite – laboratory fluorometric Chl  Cayuga LSC8 (presently Site 3) – collected 2/month – 2 cases

May-Sept. 2004
May-Sept. 1998-2006

– samples 0-4m composite – laboratory spectrophotometric Chl

4/8/2014 Upstate Freshwater Institute 39

Chl a (µg/L)

5 10 15 20

TP (µgP/L)

10 20 30

TDP (µg/L)

10 20 30

System

Conesus Hemlock Canadice Honeoye Canandaigua Keuka Seneca Cayuga Cayuga LSC8 CayugaLSCl98-06 Owasco Skaneateles Otisco

PP (µg/L)

10 20 30

SLIDE 40

TDP (µgP/L)

5 10 15

SUP (µgP/L)

5 10

System

Conesus Hemlock Canadice Honeoye Canandaigua Keuka Seneca Cayuga Cayuga LSC8 CayugaLSC98-06 Owasco Skaneateles Otisco

SRP (µgP/L)

5 10

Cayuga vs. Finger Lakes

 2004 Finger Lakes survey  TDP, SUP, SRP  average measurements, bars are 1 std. dev. (temporal variations)  UFI lake data – collected 1/month – May – Sept. 2004 – samples 0-2m composite  Cayuga LSC8 (presently Site 3) – collected 2/month – 2 cases

May-Sept. 2004
May-Sept. 1998-2006

samples 0-4m composite

4/8/2014 Upstate Freshwater Institute 40

SLIDE 41

Cayuga vs. Finger Lakes

 2004 Finger Lakes survey  Chl and SD  average measurements, bars are 1

std. dev. (temporal variations)

 UFI lake data – collected 1/month – May – Sept. 2004 – samples 0-2m composite – Chl fluorometric  Cayuga LSC8 (presently Site 3) – collected 2/month – 2 cases

May-Sept. 2004
May-Sept. 1998-2006 samples

0-4m composite – samples 0-4m composite – Chl spectrophotometric

4/8/2014 Upstate Freshwater Institute 41

Chl a (µg/L)

5 10 15 20

System

Conesus Hemlock Canadice Honeoye Canandaigua Keuka Seneca Cayuga Cayuga LSC8 CayugaLSC98-06 Owasco Skaneateles Otisco

SD (m)

2 4 6 8 10

SLIDE 42

Outline

1. review of forms of phosphorus (P) 2. triplicate sample performance, Cayuga Lake 2013 study 3. phosphorus fraction comparisons among different systems 4. phosphorus fraction comparisons: different certified labs 5. consistency of P forms with limnological paradigms 6. UFI’s P resume 7. evaluation of two SRP methods (selected features)

4/8/2014 Upstate Freshwater Institute 42

SLIDE 43

UFI’s Phosphorus Resume

 years making P measurements: 1980 - 2013 (34 years)  years certified by NYS DOH for TP and SRP: 1994 – 2014 (20 years)  measurements in the limnological range of interest  estimated number of samples analyzed for P: a conservative estimate – TP ~ 31,400 – TDP ~ 13,930 – SRP ~ 20,810 total analyses run > 67,000

4/8/2014 Upstate Freshwater Institute 43

SLIDE 44

UFI Phosphorus Resume: Analyses Supporting Research and Long-term Monitoring

Key Studies/Systems  CSLAP program - 14 years; NYSDEC  NYC Reservoirs - 19 years; FAD work

(Cannonsville, Pepacton, Rondout, Neversink, Ashokan, Schoharie, West Branch, Middle Branch, East Branch, Diverting, Titicus, Amawalk, Bog Brook, Cross River, Croton, Muscoot, Boyds Corners, Kensico)

 Onondaga Lake - 34 years; Phosphorus TMDL  Finger Lakes Surveys (11 lakes) – 1996 & 1997; 2001 & 2002 (in collaboration with NYSDEC)  Lake Source Cooling (Cornell) monitoring (facility & in- lake) - 18 years  Cornell Shackelton Point - 8 years; Oneida Lake  ESF Thousand Islands Biological Station - 5 years

4/8/2014 Upstate Freshwater Institute 44

SLIDE 45

UFI-Phosphorus Resume: Publications in the Peer-Reviewed Literature

 based on UFI P analyses  papers for which UFI P data are central – 43  national and international peer-reviewed journals – 20  aspects of phosphorus (P) assessed with UFI P data – vertical transport from enriched hypolimnia to productive epilimnia – deposition – effects of pollution on cycling – sediment-water exchange (e.g., release) – sediment diagenesis (legacy effects) – limitation of algae growth

4/8/2014 Upstate Freshwater Institute 45

SLIDE 46

UFI-Phosphorus Resume: Publications in the Peer-Reviewed Literature

 aspects of phosphorus (P) assessed with UFI P data – models

water column P
nutrient-eutropication
sediments

– effects of dreissenid mussels on cycling – eutrophication effects on other constituents – bioavailability assessments – effects of minerogenic particles – external loading calculations – long-term trend analysis – Cayuga Lake – specific analyses

4/8/2014 Upstate Freshwater Institute 46

SLIDE 47

Outline

1. review of forms of phosphorus (P) 2. triplicate sample performance, Cayuga Lake 2013 study 3. phosphorus fraction comparisons among different systems 4. phosphorus fraction comparisons: different certified labs 5. consistency of P forms with limnological paradigms 6. UFI’s P resume 7. evaluation of two SRP methods (selected features)

4/8/2014 Upstate Freshwater Institute 47

SLIDE 48

Approved Methods for NELAC Certification for SRP

Process SM 4500 P E & 4500 P b.5 EPA 1978 (365.3) Container acid washed glass

r plastic

Acid washed pyrex

r plastic

Filtering 0.45 um membrane 0.45 um membrane Colormetric method ascorbic acid ascorbic acid Filtration immediately after collection, store at 4C, analyze within 48 hrs day of collection

4/8/2014 Upstate Freshwater Institute 48

 UFI uses SM 4500 P E & 4500 P b.5

SLIDE 49

Process SM 4500 P E & 4500 P b.5 EPA 1978 (365.3) Reagents 5N H2SO4 (50 ml) + potassium antimonyl tartrate (PAT) (5 ml) + ammonium molybdate (15 ml) + ascorbic acid (30 ml) = “mixed reagent” (8 mls added to sample) 11 N H2SO4 (1 ml) + PAT + ammonium molybdate (4 ml) + ascorbic acid (2 ml) Reagents added sequentially to sample Sample volume 50 ml 50 ml

Approved Methods for NELAC Certification for SRP (continued)

4/8/2014 Upstate Freshwater Institute 49

SLIDE 50

Process SM 4500 P E & 4500 P b.5 EPA 1978 (365.3) Calibration curve(s) Prepared weekly; verified daily Prepared with each run pH adjustment yes Color development 10 minutes 5 minutes Read sample 10 – 30 minutes after adding “mixed reagent” 5 - 60 minutes after sequential addition

f reagents

Wavelength 880 nm 650 nm (660/880) Glassware cleaning 1:1 Nitric acid 1:1 HCL & all reagents Precision & Bias (DI water) 100 ug/L, 3 labs RSD = 9.1%, RE = 10.0%

Approved Methods for NELAC Certification for SRP (continued)

4/8/2014 Upstate Freshwater Institute 50

SLIDE 51

Color Development Experiment Sample Results

 comparison of Methods (Feb 2014) – Standard Methods 18-21; 4500-P E – EPA 1978  Cayuga Lake system samples  EPA method consistently reads higher but both methods are relatively close (RPD 4 – 23%) at 15 minutes  divergence with time

4/8/2014 Upstate Freshwater Institute 51

a) Inlet 2 4 6 8 Standard Methods EPA 1978 b) Cayuga near LSC

SRP (µg·L-1)

17 19 21 23 c) Salmon Cr

Time (minutes)

20 40 60 80 100 8 10 12 14

RPD = 23% RPD = 4% RPD = 7%

SLIDE 52

Color Development Experiment: Quality Control

 both methods had continuing calibration blanks (CCB) that were below UFI’s Level of Detection (LOD)  the continuing calibration verification (CCV; 25 µg·L-1) is phosphorus in DI water and should remain relatively constant over time. – EPA method increases

4/8/2014 Upstate Freshwater Institute 52

a) CCB

0.25

0.00 0.25 0.50 b) CCV

Time (minutes)

20 40 60 80 100

SRP (µg·L-1)

24 25 26 Standard Methods EPA 1978

UFI LOD

SLIDE 53

Color Development Experiment

for Onondaga Lake and Tributaries Standard Methods 18-21 4500-P E

4/8/2014 Upstate Freshwater Institute 53

 color stability over time  dissolved phosphorus components stable

Time after adding mixed reagent (min)

20 40 60 80 100

SRP ( g·L-1)

2 4 6 8 10 Ninemile Cr Onon Cr Ley Cr Onon Lk Marina

SLIDE 54

Color Development Experiment

for Onondaga Lake and Tributaries

initial sample values for SM and USEPA had a RPD ranging from 6 to 11%

4/8/2014 Upstate Freshwater Institute 54

Time after adding mixed reagent (min)

20 40 60 80 100

SRP (g·L-1)

2 4 6 8 10 SM 18-21 4500 PE Ninemile Cr (EPA 1978) Onon Cr (EPA 1978) Ley Cr (EPA 1978) Onon Lk Marina (EPA 1978)

 USEPA 1978, with time  initial Standard Methods results also

SLIDE 55

Summary

 UFI presented – a review of P forms, according to the operationally based methods, and presented related literature citations – a description of UFI’s triplicate sample program, and a review of performance for Cayuga Lake in a comparative context – a selective review of P fractions for different systems in New York

4/8/2014 Upstate Freshwater Institute 55

SLIDE 56

Summary

 UFI presented – a selective comparison of P fractions according to UFI

vs. other certified labs

– examples of consistent patterns of forms of P in multiple lakes – a review of UFI’s P resume

durations, lake programs
P related topics in peer-reviewed literature

– an evaluation of selected features of the NELAC- approved SRP methods

4/8/2014 Upstate Freshwater Institute 56
