> Philip Lawrence Senior Solution Architect Sun Microsystems UK - - PowerPoint PPT Presentation

1

>

Philip Lawrence

Senior Solution Architect Sun Microsystems UK & Ireland

1

• Term coined by Clayton Christensen in his book The

Innovator's Dilemma to denote a technology that – aside (or because of) its technical merit has revolutionary economics

• Classic examples:

> Digital photography disrupted film

Disruptive Innovation

Sun Confidential: Internal Only

2

> Steamships disrupted sailing ships > Minicomputers disrupted mainframes > EMC (with RAID- & cache-based storage) disrupted IBM in DASD > Linux/x86 disrupted UNIX/RISC

• Often involve a redistribution of margin: lower overall margin

but much higher volume and broader market

• Over time, the value in a storage product has trended from hardware to

software...

• ...but storage hardware has remained unnecessarily custom (i.e.,

expensive and slow)

• Sun has built an appliance out of industry standard components

(servers + JBODs): higher performing, cheaper

Why is the S7000 Series disruptive?

Sun Confidential: Internal Only

3

(servers + JBODs): higher performing, cheaper

• ...and because COGS of software is $0.00, Sun need not monetize the

software directly – software development costs can be paid with marginal increase in revenue

• Adds up to disruption: 2X performance at ½ cost
• The 7000 Series would have been disruptive based on these

economics alone, but along came flash memory...

• Flash memory now sits between DRAM and 15K RPM disk in terms of

performance and price:

> Flash is microseconds per op, where DRAM is nanoseconds and disk is

milliseconds

> Flash is tens of dollars per GB, where DRAM is hundreds of dollars per GB and

disk is dollars per GB

The disruptive effects of Flash

Sun Confidential: Internal Only

4

• Seeing this trend, we integrated flash into a hybrid storage pool, where

read-optimized flash is used as a cache

• Cache is up to 600GB in currently shipping products, but curves are

steep: headed much higher (and much cheaper!)

• For random-read workloads, flash + 7200 RPM drives yields 4X

performance of 15K RPM drives at ¼ cost!

Sun’s Open Strategy

General Purpose Systems + Open Source Software = Lower Costs

Sun Confidential: Internal Only

5

• Open Source reduced costs

Open Source reduced costs and vendor lock and vendor lock-in in

• Scale out architectures brought

Scale out architectures brought new economics new economics

• Commoditisation

Commoditisation brought brought increased competition increased competition

• Differentiation from innovative

Differentiation from innovative product design and packaging product design and packaging

• Follows same server trend

Follows same server trend

• General purpose systems will

General purpose systems will drive storage costs down drive storage costs down

• Robust Open Source soft

Robust Open Source soft-ware ware will further reduce costs will further reduce costs

• Simple data administration

Simple data administration

• Revolutionary analytics

Revolutionary analytics

• Open architectures will free

Open architectures will free users from vendor lock users from vendor lock-in in

• Archive products built from open

Archive products built from open architectures architectures

• Using general purpose systems

Using general purpose systems that drive down costs that drive down costs

• Seamless integration

Seamless integration with existing environments with existing environments

• Leading Sun Archive software

Leading Sun Archive software now open sourced now open sourced

Open Servers Open Servers Open Storage Open Storage Open Archive Open Archive

Sun Storage 7000 Unified Storage Systems

nce

Bringing Simplicity to Enterprise Storage

Sun Confidential: Internal Only

6

Capacity Performanc Sun Storage 7110

8GB RAM 14x146GB SAS 10K

RPM Drives

Up to 2 TB 2RU package

Sun Storage 7210

32GB and 64GB options Up to 44 TB Hybrid Storage Pool I/O

Acceleration

Write Flash/SSD options

for higher performance

Sun Storage 7410

16GB, 64GB and 128 GB

• ptions

Up to 288 TB* Hybrid Storage Pool I/O

Acceleration

Read/Write Flash/SSD options

for higher performance

Provides support for unified file and block data protocols, Provides support for unified file and block data protocols, including a rich set of data services including a rich set of data services

* Up to 576 TB coming soon.

Sun Storage 7410 Cluster

32GB, 128GB and 256 GB options Up to 288 TB* Includes cluster software Hybrid Storage Pool I/O Acceleration Read/Write Flash/SSD options for

higher performance (2x 7410)

Sun Storage 7110 Unified Storage System

Unified Storage Systems for Departmental/Workgroups

• Hybrid Storage Pool
• RAM 8G
• 6 PCI-E slots
• 14 146GB SAS 10K RPM Drives
• Network Connectivity
• Standard 4 x 1Gb Ethernet Ports

Optional Dual Copper or Optical Port

Sun Confidential: Internal Only

7

• Optional Dual Copper or Optical Port

10Gb Ethernet

• Optional Quad Port 1Gb Ethernet
• Tape Backup Connectivity
• Optional Dual Port Fibre Channel HBA
• Optional Dual Port SCSI HBA

Sun Storage 7210 Unified Storage System

High-density Open Unified Storage Systems

• Hybrid Storage Pool
• RAM 32GB or 64GB
• 3 PCI-E slots
• SSD Write Optimized Up to 2 x 18GB
• SATA up to 46 250GB,500GB or 1TB

Drives

• Network Connectivity

Sun Confidential: Internal Only

8

• Network Connectivity
• Standard 4 x 1Gb Ethernet Ports
• Optional Dual Copper or Optical Port

10Gb Ethernet

• Optional Quad Port 1Gb Ethernet
• Tape Backup Connectivity
• Optional Dual Port Fibre Channel HBA
• Optional Dual Port SCSI HBA

Sun Storage 7410 Unified Storage System

High Availability, massive scale Unified Open Storage Server

• Hybrid Storage Pool
• RAM 16GB, 64GB or 128GB
• 6 PCI-E slots per node
• SSD Write Optimized Up to 8 x 18GB
• SSD Read Optimized Up to 6 x 100GB

per node

• SATA up to 287* 1TB Drives

Sun Confidential: Internal Only

9

• Arrays up to 12 @ 24 HDDs
• Network Connectivity
• Standard 4 x 1Gb Ethernet Ports
• Optional Dual Copper or Optical Port

10Gb Ethernet

• Optional Quad Port 1Gb Ethernet
• Tape Backup Connectivity
• Optional Dual Port Fibre Channel HBA
• Optional Dual Port SCSI HBA
• Clustering for High Availability

*Up to 576TB soon after release *Up to 576TB soon after release

Storage Appliance Arrays

7410 Expansion Array Options

• Seamless Expansion
• J4400 Expansion Array
• 24 X 3.5” SATA devices in 4u
• Front-accessible
• Half-full or full of 1TB HDDs
• 0-4 write optimized SSDs

Sun Confidential: Internal Only

10

• Dual SAS controller FRUs, independent

hot-swap

• Fans in power supplies

Most Scalable Storage System Design

• Hybrid Flash Storage Pools

Hybrid Flash Storage Pools

> Data is intelligently placed in DRAM,

Data is intelligently placed in DRAM, Flash or Disk Flash or Disk

> Transparently Managed as one

Transparently Managed as one storage pool storage pool

Read/ L2ARC SSDs Write/ ZIL SSDs

Sun Confidential: Internal Only

11

storage pool storage pool

> Optimizes £/GB and £/IOP

Optimizes £/GB and £/IOP performance performance

• Enterprise Grade Flash

Enterprise Grade Flash

> 3-5 year lifetime

5 year lifetime

HDD Pool (SATA)

ZFS Hybrid Storage Pool Architecture

Performance Tuning Without the Guess Work

Sun Confidential: Internal Only

12

• ARC – Adaptive Replacement Cache, the main ZFS memory cache in DRAM
• L2ARC – Level Two Adaptive Replacement Cache, extends the ARC into Read

Optimized Solid State Disk Devices to provide a large read cache to accelerate reads

• ZIL – ZFS Intent Log is transactional, using Write Optimized Solid State Disk Devices

provides a large cache to accelerate writes

• Disk Storage Pool – 7200 RPM SATA Drives, high speed drives no longer relevant

Old Model Storage Pool New Model Storage Pool Hybrid Storage Pool (ZFS)

ZFS Hybrid Storage Pool

Sun X4250 Storage Server Example

Configuration B Configuration A Configuration A

• 4 Xeon 7350 Processors
• 32GB FB DDR2 ECC DRAM

OpenSolaris with ZFS

Sun Confidential: Internal Only

13

(5) 400GB 4200 RPM SATA Drives

(7) (7) 146GB 10,000 RPM SAS Drives 146GB 10,000 RPM SAS Drives

(1) 32G SSD ZIL Device (1) 80G SSD Cache Device

• OpenSolaris with ZFS

ZFS Hybrid Pool Example

3.2x 11% 4% 4.9x 2x

Based on Actual Benchmark Results

Sun Confidential: Internal Only

14

Hybrid Storage Pool (DRAM + Read SSD + Write SSD + 5x 4200 RPM SATA) Traditional Storage Pool (DRAM + 7 x 10K RPM 2.5”)

Read IOPs Write IOPs Cost Storage Power (Watts) Raw Capacity (TB)

Storage Analytics

Unprecedented Real-Time Observability, First and Only in Market

Sun Confidential: Internal Only

15

Unprecedented DTrace Analytics

Analyse Performance Bottlenecks Down to the User Level

• Real-time monitoring of the

complete storage system

• Built on DTrace instrumentation

for key subsystems

>

NFSv3, NFSv4, CIFS, iSCSI

>

ZFS and the Solaris i/o path

Sun Confidential: Internal Only

16

>

ZFS and the Solaris i/o path

>

CPU and Memory Utilization

>

Networking (TCP, UDP, IP)

• Real-time graphical business analytics

>

“What files are hot right now?”

>

“What is the distribution of reads and writes?”

>

“Which CIFS clients are hot right now?”

>

“How much networking bandwidth do I use?”

• Group into worksheets, can be made persistent
• Data can be exported for further number crunching

• Real-time system performance visualization supporting ad hoc,

high-level queries:

The Analytics Advantage

Sun Confidential: Internal Only

17

c

“Point & Click” Storage Configuration

Sun Confidential: Internal Only

18

Breakthrough Enterprise Storage Economics

Sun Unified Sun Unified Storage 7410 Storage 7410

Sun Confidential: Internal Only

19

4X 4X 2.6X 2.6X £593,000 £593,000 £368,000 £368,000

Price Price NetApp 3170

154 x 300 x15K RPM drives Data OnTAP 7.3G

EMC NS80

154 x 300 x10K RPM drives

£147,000 £147,000

Best Eco Efficiency

Energy Efficient, Less Datacentre Space

Sun Unified Sun Unified Storage 7410 Storage 7410

Sun Confidential: Internal Only

20

3.3x 3.6x 2.8x 3.6x

NetApp 3170

154 x 300 x15K RPM drives Data OnTAP 7.3G

EMC NS80

154 x 300 x10K RPM drives

Space Space Power Power

Everything You Need - Included

Data Protocols Data Protocols Data Services Data Services Management Management

NFS NFS CIFS CIFS iSCSI iSCSI Flash Hybrid Flash Hybrid Storage Pool Storage Pool Mirroring Mirroring Snapshots Dashboard Dashboard SNMP SNMP Scripting Scripting Upgrade Upgrade DTrace DTrace Analytics Analytics Clones

Sun Confidential: Internal Only

21

iSCSI iSCSI HTTP HTTP WebDAV WebDAV FTP FTP NDMP NDMP RAID RAID-Z DP (6) Z DP (6) Striping Striping Active-Active Clustering Remote Replication Antivirus Antivirus Role Role-Based Based Access Control Access Control Advanced Advanced Networking Networking NIS, LDAP NIS, LDAP and AD and AD Hardware View Hardware View Alerts Alerts Phone Home Phone Home Upgrade Upgrade Thin Thin Provisioning Provisioning RAID RAID-Z (5) Z (5) Compression Compression End End-to to-End End Data Integrity Data Integrity Fault Fault Management Management Multi Multi-Path I/O Path I/O

Everything You Need - Included

Data Protocols Data Protocols Data Services Data Services Management Management

NFS NFS CIFS CIFS iSCSI iSCSI Flash Hybrid Flash Hybrid Storage Pool Storage Pool Mirroring Mirroring Snapshots Dashboard Dashboard SNMP SNMP Scripting Scripting Upgrade Upgrade DTrace DTrace Analytics Analytics Clones

Active-Active

Snapshots

Sun Confidential: Internal Only

22

iSCSI iSCSI HTTP HTTP WebDAV WebDAV FTP FTP NDMP NDMP RAID RAID-Z DP (6) Z DP (6) Striping Striping Active-Active Clustering Remote Replication Antivirus Antivirus Role Role-Based Based Access Control Access Control Advanced Advanced Networking Networking NIS, LDAP NIS, LDAP and AD and AD Hardware View Hardware View Alerts Alerts Phone Home Phone Home Upgrade Upgrade Thin Thin Provisioning Provisioning RAID RAID-Z (5) Z (5) Compression Compression End End-to to-End End Data Integrity Data Integrity Fault Fault Management Management Multi Multi-Path I/O Path I/O

Remote Replication Active-Active Clustering

Clones

Customers who are struggling to keep pace with rapid storage growth, looking for a radically

Who will use the... Sun Unified 7000 Storage System?

Sun Confidential: Internal Only

23

rapid storage growth, looking for a radically easier and faster way to manage storage at a substantially better ROI

Where should you use this product?

New and fast growing storage build-outs where you want to simplify and speed up their administration

Sun Confidential: Internal Only

24

their administration Application areas include; Web, HPC, data farms for server virtualisation, file sharing and database DW/BI

Why is this a good time to bring this product to market?

“Crisis loves an innovation” “Crisis loves an innovation”

With flat to decline storage budgets customers look at

Sun Confidential: Internal Only

25

With flat to decline storage budgets customers look at best in class and innovative alternatives to meet their huge data growth challenges. The 7000 series offers a new way to provide enterprise class, unified storage at a fraction of the cost of comparable solutions.

Sun Storage 7000 Unified Storage Systems vs. the Competition

Sun 7410 Sun 7410 NetApp FAS 3170 NetApp FAS 3170 EMC NS80 EMC NS80 Data Services * Included Fee Based Fee Based Flash Optimised Yes Not Available Not Available

Sun Confidential: Internal Only

26

DTrace Analytics Yes Not Available Not Available Power Consumption 2524w 6426w 6975w RAID Rebuild Minutes Hours Hours Space 12RU 45RU 43RU Grand Grand Total Total £148k £599k £599k £371k £371k

* Sun’s Data Services include: San/Clone, Restore, Mirroring, Replication, Compression, Thin Provisioning, CIFS, NFS, HTTP/FTP and WebDAV

Competitive

We provide basic features...

Feature Amber Road EMC Basic features

• NFS, CIFS, iSCSI, HTTP/WebDAV, FTP

Y Y Y

• Snapshots, read and writable, restore

Y Y Y

• High availability 2-node cluster

Y Y Y

• Replication capabilities

Y Y Y Y Y Y NetApp

• AntiVirus support

Sun Confidential: Internal Only

27

• NDMP v3/v4

Y Y Y

• Thin Provisioning

Y Y Y

• Call-Home support

Y Y Y

• RAID single and dual parity protection

Y Y Y

• NAS Filer Shell with Scripting

Y Y Y

• Phone home

Y Y Y

• Simple upgrade process

Y Y Y

• RBAC

Y Y Y

Competitive

Work in progress, improving our platform...

Feature Amber Road EMC What we are missing...Coming future release Microsoft VSS Snapshots Future Y Y Gateway Future Y Y Compliance Future Y Y De-duplication Future Y Y Global Namespace Future Y Y Encryption (integrated) Future Y (ext) Y (ext) NetApp

Sun Confidential: Internal Only

28

ILM based – HSM Future Y Y N-way Management Future Y Y Future Y Y N+1 Cluster Storage Future Y N Future Y Y User and Group Quota (reporting only) Future Y Y Future Y Y Automated Migration (monarch) Future N N Hosted Applications Future N N Future N N Application Integration (Exchange, Oracle, VMWare, etc.) Fibre Channel Target IPSec FcoE

Big Take Away...

A radically simple way to use storage, at a fraction of the cost of traditional storage systems. The Sun Storage 7000 Unified Storage System, the

Sun Confidential: Internal Only

29

The Sun Storage 7000 Unified Storage System, the worlds first open storage appliance, forever changes the way businesses and enterprises experience storage.

30

Phil Lawrence

phil.lawrence@sun.com Tel – 07793 314 666

30
