Peter Bandzi, Ahmed Maged @pbandzi @amaged Nov 2015 1 Assembling a - - PowerPoint PPT Presentation

1

Peter Bandzi, Ahmed Maged

@pbandzi @amaged

Nov 2015

• Assembling a VPN in the Cloud Service
• Learning Experience

2

3

• - - - - - - - - - -
• - - - - - - - - -

Application

Home-grown Python Code Front End Back End /User Portal Sharing VPN Meta- Data over Facebook Orchestration/ Dispatching

Bootstrap/Get Started (BGS)

• The main goal of BGS is to assemble and test a base set of infrastructure

components for OPNFV.

• This project achieved that by supporting two deployers for OPNFV Arno, we

used Fuel for building our infrastructure.

5

Virtual Infra Manager

REST API RESTConf

SDN Controller

Application

OpenStack OpenDayLight

Front End Back End Sharing VPN Meta- Data over Facebook Orchestration/ Dispatching BGS/OPNFV Deployer /User Portal

Virtual Infra Manager

REST API RESTConf Netconf/Yang

SDN Controller

VNF

Application

OpenStack OpenDayLight

Front End Back End Sharing VPN Meta- Data over Facebook Orchestration/ Dispatching

VPN Termination

BGS/OPNFV Deployer /User Portal

8

App/ Portal Open Stack OpenDay Light

1 2 3 4 5 6 7 8 9 Request VPN service

VNF/ Router

Instruct ODL to provision VNF

User Facebook

Peer Picking Peer Picked Spin up VNF Provision IPSec Report addressing and preshared key Post addressing and Password IPSec Tunnel Established

9

ü Picking Peer from Facebook for rapid, painless setup *

* Inspired by Cedric Dessez, https://www.ietf.org/proceedings/87/slides/slides-87-homenet-6.pdf

10

App/ Portal Open Stack OpenDay Light

1 2 3 4 5 6 7 8 9 Request VPN service

VNF/ Router

Instruct ODL to provision VNF

User Facebook

Peer Picking Peer Picked Spin up VNF Provision IPSec Report addressing and preshared key Post addressing and Password IPSec Tunnel Established

11

client_manager.compute.servers.create(’router',

image, flavor, key_name=keypair.name, nics=[{'net-id': network.id}]) http://<api-server>/servers

REST Calls Python SDK

Nova Server

Hypervisor (KVM, etc)

VNF

RESTful API Create a VM

12

App/ Portal Open Stack OpenDay Light

1 2 3 4 5 6 7 8 9 Request VPN service

VNF/ Router

Instruct ODL to provision VNF

User Facebook

Peer Picking Peer Picked Spin up VNF Provision IPSec Report addressing and preshared key Post addressing and Password IPSec Tunnel Established

13

Nova Server

Appl/ Portal

ODL

VNF / Router list node-subnets { description "IP and mask behind route"; key "ip inv-mask"; leaf ip {type inet:ipv4-address;} leaf inv-mask {type inet:ipv4-address;} } list shared-key { key shared-key; leaf shared-key {type string;} leaf peer-address {type inet:ip-address;} }

YANG Model

/restconf/data/ipsec-service:ipsec/ <list name>/ <key value(s)>

RESTConf

{ “ipsec-service:node-list” : [ { “node-name”: “vRouter”, “node-ip”: “X.X.X.X” } ] }

JSON

14

App/ Portal Open Stack OpenDay Light

1 2 3 4 5 6 7 8 9 Request VPN service

VNF/ Router

Instruct ODL to provision VNF

User Facebook

Peer Picking Peer Picked Spin up VNF Provision IPSec Report addressing and preshared key Post addressing and Password IPSec Tunnel Established

15

Peer 1

crypto isakmp key KEY address x.x.x.x ! crypto ipsec transform-set TS esp-des esp-md5- hmac ! crypto map CRYPTO 10 ipsec-isakmp set peer y.y.y.y set transform-set TS match address Spoke ! interface TenGig0/0 ip address x.x.x.x 255.255.255.0 crypto map CRYPTO

CLI Config Peer 2

• Assembling a VPN in the Cloud Service
• Learning Experience

16

“Open source propagates to fill all the nooks and crannies that people want it to fill.”

Mitch Kapor Founder of Lotus, Co-Founder EFF

• In 1995, I almost lost my hair, building a Slackware server.
• In 2005, I lost my hair, building/coding a Linux Jumpserver.
• In 2015, We built a VPN in the Cloud server in a few days.

18

Open Source

Made it possible

With BGS :

• Install scripts for automated deployment of

the test setup.

• Comprehensive source-to-tested-

deployment script for running the entire system start to end.

Task Time Installing Infra(Arno/Fuel) 1 Day

• APIs coming to networking, took networking out of its Silo.
• Now Applications can easily control and interact with Networking.
• Opening up the possibility to a wide range of use cases.

20

Task Time Write PoC Code* 3 Days

* Without Facebook App/Front End.

I need REST APIs

Thanks

Q&A

21
