1 EE 457 Unit 7d Virtual Memory 2 Virtual Memory Concept A mechanism for hiding the details of how much physical memory exists and how its being shared Allows the OS to Efficiently share the physical memory between several


slide-1
SLIDE 1

1

EE 457 Unit 7d

Virtual Memory

slide-2
SLIDE 2

2

Virtual Memory Concept

  • A mechanism for hiding the details of how much physical

memory exists and how it’s being shared

  • Allows the OS to

– Efficiently share the physical memory between several running programs/processes and provide protection against each other – Remove the need of the programmer to know how much memory is physically present and/or give the illusion of more or less physical memory than is present

  • Use MM as a cache for multiple programs and their data as they

run using secondary storage (hard-drive) as the home location

slide-3
SLIDE 3

3

Memory Hierarchy & Caching

  • Lower levels act as a cache for upper levels

Disk / Secondary Storage ~1-10 ms Main Memory ~ 100 ns L2 Cache ~ 10ns L1 Cache ~ 1ns Registers L1/L2 is a “cache” for main memory Virtual memory provides each process its own address space in secondary storage and uses main memory as a cache

slide-4
SLIDE 4

4

Virtual Memory Motivation

  • Virtual memory is largely discussed in operating systems

courses

– We will focus on HW support for VM

  • Magnetic hard drive consists of

– Double sided surfaces/platters (with R/W head) – Each platter is divided into concentric tracks of small sectors that each store several thousand bits

Surfaces

Read/Write Head 0 Read/Write Head 7 Read/Write Head 1 … Track 0 Track 1 Sector 0 Sector 1 Sector 2

  • Seek Time: Time needed to

position the read-head above the proper track

  • Rotational delay: Time needed

to bring the right sector under the read-head

  • Depends on rotation

speed (e.g. 5400 RPM)

  • Transfer Time:
  • Disk Controller Overhead:

3-12 ms 5-6 ms 0.1 ms + 2.0 ms ~20 ms

slide-5
SLIDE 5

5

Address Spaces

  • Physical address spaces corresponds

to the actual system address range (based on the width of the address bus) of the processor and how much main memory is physically present

  • Each process/program runs in its own

private "virtual" address space

– Virtual address space can be larger (or smaller) than physical memory – Virtual address spaces are protected from each other

32-bit Physical Address Space w/

  • nly 1 GB of Mem

0x00000000 0xffff ffff

Mem. I/O Not used

0x3fffffff

Not used

0x80000000 0xbfffffff

Code

0x00000000 0xffff ffff

32-bit Fictitious Virtual Address Spaces ( > 1GB Mem)

Mapped I/O

  • Program/Process

1,2,3,…

  • Data
  • Heap
  • Stack
  • 0xc0000000

0x10000000

slide-6
SLIDE 6

6

Processes

  • Process

– (def 1.) Address Space + Threads

  • (Virtual) Address Space = Protected view of memory
  • 1 or more threads

– (def 2.) : Running instance of a program that has limited rights

  • Memory is protected: Address translation (VM) ensures no

access to any other processes' memory

  • I/O is protected: Processes execute in user-mode (not

kernel mode) which generally means direct I/O access is disallowed instead requiring system calls into the kernel

  • OS Kernel is not considered a "process"

– Has access to all resources and much of its code is invoked under the execution of a user process thread

Code

0x00000000 0xffff ffff

Address Spaces

Mapped I/O

  • Program/Process

1,2,3,…

  • Data
  • Heap
  • Stack
  • 0xc0000000

0x10000000 = Thread

slide-7
SLIDE 7

7

Virtual Address Spaces (VAS)

  • Virtual address spaces

(VASs) are broken into blocks called "pages"

  • Depending on the

program, much of the virtual address space will be unused

  • Pages can be allocated

"on demand" (i.e. when the stack grows, etc.)

  • All allocated pages can be

stored in secondary storage (hard drive)

1 2 3 Unalloc 1 2 Unalloc

Secondary Storage

… Unalloc … 1 2 3 1 2

Used/Unused Blocks in Virtual Address Space

Code

0x00000000 0xffff ffff

Mapped I/O

  • Program/Process

1,2,3,…

  • Data
  • Heap
  • Stack
  • 0xc0000000

0x10000000

0 - Code 1 - Code 2 - Data 4 - Heap … 3 - Stack 0 - Code 1 - Code 2 - Data 4 - Heap 3 - Stack

slide-8
SLIDE 8

8

1 2 3 Unalloc 1 2 Unalloc … Unalloc … 1 2 3 1 2 0 - Code 1 - Code 2 - Data 4 - Heap … 3 - Stack 0 - Code 1 - Code 2 - Data 4 - Heap 3 - Stack

Physical Address Space (PAS)

  • Physical memory is broken into

page-size blocks called "frames"

  • Multiple programs can be running

and their pages can share the physical memory

  • Physical memory acts as a cache

for pages with secondary storage acting as the backing store (next lower level in the hierarchy)

  • A page can be:

– Unallocated (not needed yet…stack/heap) – Allocated and residing in secondary storage (Uncached) – Allocated and residing in main memory (Cached)

0x00000000 0x3fffffff

1GB Physical Memory and 32-bit Address Space

0xffffffff

Secondary Storage Fictitious Virtual Address Spaces

frame

0-Code

  • Pg. 0
  • Pg. 2

2-Data

  • Pg. 0

frame I/O and un- used area

slide-9
SLIDE 9

9

Paging

  • Virtual address space is divided into equal

size "pages" (often around 4KB)

  • Physical memory is broken into page

frames (which can hold any page of virtual memory and then be swapped for another page)

  • Virtual address spaces can be contiguous

while physical layout is not

Physical Frame of memory can hold data from any virtual page. Since all pages are the same size any page can go in any frame (and be swapped at our desire).

0x00000000 0x3fffffff

frame

0-Code

  • Pg. 0
  • Pg. 2

2-Data

  • Pg. 0

frame I/O and un- used area

0xffffffff

  • Pg. 0
  • Pg. 1
  • Pg. 2
  • Pg. 3

unused …

  • Pg. 0
  • Pg. 1
  • Pg. 2

unused unused …

  • Phys. Addr.

Space

  • Proc. 1 VAS Proc. 2 VAS
slide-10
SLIDE 10

10

Virtual vs. Physical Addresses

  • Key: Programs are written using virtual

addresses

  • HW & the OS will translate the virtual

addresses used by the program to the physical address where that page resides

  • If an attempt is made to access a page

that is not in physical memory, HW generates a "page fault exception" and the OS is invoked to bring in the page to physical memory (possibly evicting another page)

  • Notice: Virtual addresses are not unique

– Each program/process has VA: 0x00000000

Translation Unit / MMU (Mem. Mgmt. Unit)

Proc. Core

Memory

Data PA: 0x0 PA:0x3fffffff

frame

0-Code

Physical Memory and Address Space

  • Pg. 0
  • Pg. 2

2-Data

  • Pg. 0

frame I/O and un- used area

0xffffffff

Secondary Storage Fictitious Virtual Address Spaces

1 2 3 Unalloc 1 2 Unalloc … Unalloc … 1 2 3 1 2 0 - Code 1 - Code 2 - Data 4 - Heap … 3 - Stack 0 - Code 1 - Code 2 - Data 4 - Heap 3 - Stack

PA: 0x11f000 PA: 0x21b000 VA: 0x040000 VA: 0x100080 Virtual Addr Physical Addr VA: 0x040000 PA: 0x21b000

slide-11
SLIDE 11

11

Summary

  • Program takes an abstract (virtual) view of

memory and uses virtual addresses and necessary data is broken into large chunks called pages

  • HW and OS work together to bring pages into

main memory acting as a cache and allowing sharing

  • HW and OS work together to perform

translation between:

– Virtual address: Address used by the process (programmer) – Physical address: Physical memory location of the desired data

  • Translation allows protection against other

programs

Translation Unit / MMU (Mem. Mgmt. Unit)

Proc. Core

Virtual Addr

Memory

Physical Addr Data PA: 0x0 PA:0x3fffffff

frame

0-Code

Physical Memory and Address Space

  • Pg. 0
  • Pg. 2

2-Data

  • Pg. 0

frame I/O and un- used area

0xffffffff

Secondary Storage Fictitious Virtual Address Spaces

1 2 3 Unalloc 1 2 Unalloc … Unalloc … 1 2 3 1 2 0 - Code 1 - Code 2 - Data 4 - Heap … 3 - Stack 0 - Code 1 - Code 2 - Data 4 - Heap 3 - Stack

PA: 0x11f000 PA: 0x21b000 VA: 0x040000 VA: 0x100080

slide-12
SLIDE 12

12

VM Design Implications

  • SLOW secondary storage access on page faults (10 ms)

– Implies page size should be fairly large (i.e. once we’ve taken the time to find data on disk, make it worthwhile by accessing a reasonably large amount of data) – Implies the placement of pages in main memory should be fully associative to reduce conflicts and maximize page hit rates – Implies a "page fault" is going to take so much time to even access the data that we can handle them in software (via an exception) rather than using HW like typical cache misses – Implies eviction algorithms like LRU can be used since reducing page miss rates will pay off greatly – Implies write-back (write-through would be too expensive)

slide-13
SLIDE 13

13

ADDRESS TRANSLATION

Page Tables

slide-14
SLIDE 14

14

Page Size and Address Translation

  • Since pages are usually retrieved from disk, we size them to be fairly large

(several KB) to amortize the large access time

  • Virtual page number to physical page frame translation performed by HW

unit = MMU (Mem. Management Unit)

  • Page table is an in-memory data structure that the HW MMU will use to look

up translations from VPN to PPFN

Offset within page

Virtual Address

Virtual Page Number

31 12 11

Offset within page

Physical Address

  • Phys. Page Frame

Number

31 30 12 11

00

Copied

12

Translation Process (MMU + Page Table)

29 20 18

2 2 1 b

Lookup VPN 0x00040 to it lives in PPFN: 0x0021b

slide-15
SLIDE 15

15

Address Translation Issues

  • We want to take advantage of all the physical memory so page placement

should be fully associative

– For 1GB of physical memory, a 4KB page can be anywhere in the 256K = 218 page frames

  • We could potentially track the contents of physical memory using similar

techniques to cache

– TAG = VPN that is currently stored in the frame

– TAG = 20 + 1 = 21 bits, 218 comparators…TOO MUCH

  • Instead, most systems implement full associativity using a look-up table =

PAGE TABLE

Frame 2 Frame 1 Frame 0 … Frame 218-1 VPN

Page Frame # Virtual Address

  • ffset

= = = = = Physical Memory Processor

Tag (VPN) V M Tag (VPN) V M Tag (VPN) V M … Tag (VPN) V M 218-1 2 1

slide-16
SLIDE 16

16

Analogy for Page Tables

  • Suppose we want to build a caller-ID mechanism for your

contacts on your cell phone

– Let us assume 1000 contacts represented by a 3-digit integer (0-999) in the cell phone (this ID can be used to look up their names) – We want to use a simple array (or Look-Up Table (LUT)) to translate phone numbers to contact ID’s, how shall we organize/index our LUT

213-745-9823

LUT indexed w/ contact ID

000

LUT indexed w/ all possible phone #’s

626-454-9985 … 323-823-7104 818-329-1980 001 002 999 null 000-000-0000 .. … null 000 213-745-9823 999-999-9999

Sorted LUT indexed w/ used phone #’s

436 213-745-9823 000 … 002 999 323-823-7104 213-730-2198 818-329-1980

O(n) - Doesn’t Work We are given phone # and need to translate to ID (1000 accesses) O(log n) - Could Work Since its in sorted order we could use a binary search (log21000 accesses) O(1) - Could Work Easy to index & find but LARGE (1 access) 1 2 3

slide-17
SLIDE 17

17

Page Tables

  • VA is broken into:

– VPN (upper bits) + Page offset: Based on page size (i.e. 0 to 4K-1 for 4KB page)

  • MMU uses VPN & PTBR to access the page table in memory and lookup physical frame

(i.e. like an array access where VPN is the index: PTBR[VPN] )

– Each entry is referred to as a Page Table Entry (PTE) and holds the physical frame number & bookkeeping info

  • Physical frame is combined with offset to form physical address
  • For 20-bit VPN, how big is the page table? (See below)

VA

Offset w/in page Virtual Page Number

31 12 11

Page Table Size = 220 entries * 18 bits = approx. 220*4bytes = 4MB

PTBR = Page Table Base Reg. Offset w/in page

PA

  • Phys. Frame #

31 12 11

00

PTE Page Frame Number PTE …

Other flags 20

Page Table in Main Memory

18

Processor

0xc0008000 0xc0008000 PTBR[2] PTBR[1] PTBR[0] … 0x0021b 0x0021b 0x00002 0x2d8 0x2d8

slide-18
SLIDE 18

18

Page Table Example

  • Suppose a system with 8-bit VAs, 10-bit PAs, and 32-byte pages.

VPN P1-VAS 1 2 3 4 5 6 7

Page Table VA

Offset VPN

7

Offset

PA

PFN

4 4 9

Page Table

0x00 0x1F 0x20 0x3F 0x40 0x5F 0xE0 0xFF

PFN

Phys Mem

VP 3 1 2 VP 1 3

PT for P1 (OS Owns)

31 VP 5

0x000 0x01F 0x020 0x03F 0x040 0x05F 0x3E0 0x3FF

V Entry 0x1a 1 1 0x02 2 1 0x18 3 1 0x00 4 0x10 5 1 0x1F 6 0x15 7 0x0A

slide-19
SLIDE 19

19

Page Table Exercise

  • Suppose a system with 8-bit VAs, 10-bit

PAs, and 32-byte pages.

  • Fill in the table below showing the

corresponding physical or virtual address based on the other. If no translation can be made, indicate "INVALID"

V Entry 0x0E 1 1 0x1E 2 1 0x16 3 1 0x06 4 0x0B 5 1 0x1F 6 0x15 7 0x0A

Page Table

VA PA 0x2D = 0010 1101 0x3CD 0x7A = 0111 1010 0x0DA 0xEF = 1110 1111 INVALID 0xA8 = 1010 1000 0x3E8

VA

Offset VPN

7

Offset

PA

PFN

4 4 9

Page Table

slide-20
SLIDE 20

20

Analogy for Page Tables

  • Can we use the table indexed using all possible phone numbers (because it only

requires 1 access) but somehow reduce the size especially since much of it is unused?

  • Do you have friends from every area code? Likely contacts are clustered in only a few

area codes.

  • Use a 2-level organization

– 1st level LUT is indexed on area code and contains pointers to 2nd level tables – 2nd level LUT’s indexed on local phone numbers and contains contact ID entries LUT indexed w/ all possible phone #’s

null … … 000 213 323

1st Level Index = Area Code

Area Code null 000-000-0000 .. … null 000 213-745-9823 999-999-9999 … 213 Table

2nd Level Index = Local Phone #

000-0000 999-9999 323 Table 000-0000 999-9999

If only 2 used area codes then only 1000 + 2(107) entries rather than 1010 entries

slide-21
SLIDE 21

21

Analogy for Page Tables

  • Could extend to 3 levels if desired

– 1st Level = Area code and pointers to 2nd level tables – 2nd Level = First 3-digits of local phone and pointers to 3rd level tables – 3rd Level = Contact ID’s

null … … 000 213 323

1st Level Index = Area Code

Area Code …

2nd Level Index = Local Phone #

000 999 000 999 323 Table 213 Table null null 745 823 null null

3rd Level Index = Local Phone #

000 999 213-745 Table null 000 null 9823 000 999 323-823 Table null 999 null 7104

slide-22
SLIDE 22

22

Analogy for Page Tables

  • If we add a friend from area code 408 we would have to add a second and

third level table for just this entry

null … … 000 213 323

1st Level Index = Area Code

Area Code …

2nd Level Index = Local Phone #

000 999 000 999 323 Table 213 Table null null 745 823 null null

3rd Level Index = Local Phone #

000 999 213-745 Table null 000 null 9823 000 999 323-823 Table null 999 null 7104

slide-23
SLIDE 23

23

Multi-level Page Tables

  • VPN is broken into fields to index each level of the page table
  • Think of a multi-level page table as a tree

– Internal nodes contain pointers to other page tables – Leaves hold actual translations

0x40 0x040 0x35 Virtual Addr VPN

  • ffset

Idx1 Idx2 7 bits 7 bits 12 bits 0xd0000 PDBR/CR3 … … 0x3f 6 bits Idx3 [0x40] PT2[] = start addr PD start addr [0x3f] [0x35] PT3[] = start addr Level 1 Level 2 Level 3

  • Phys. Frame Addr

Translations live in this level

Processor

  • Unused entries in one

level mean no table at the next (saving space)

Page Directory

slide-24
SLIDE 24

24

Page Faults

Uncached Page Uncached Page Uncached Page Uncached Page Uncached Page Uncached Page

1 2 1023 1 2 1023 1 2 1023 1 2 1023

Offset w/in page Level Index 1

31 12 11 22 21

Level Index 2

10 10

Pointer to start of 2nd Level Table PPFN’s

frame I/O and un- used area frame

0x0

When HW encounters a PTE whose page is not in physical memory, it will generate a page fault exception and the OS will take over and retrieve the page before resuming the program.

slide-25
SLIDE 25

25

SPARC VM Implementation

Offset w/in page

Index 1

8 11 6

Index 2 Process ID Index 3

6

4095 MMU hold 4096 entry table (one entry per context/process) [Essentially, PTBR for each process] Context Table First Level Second Level Third Level 4K Page Desired word PPFN 28 * 4 bytes 26 * 4 bytes 26 * 4 bytes

How many accesses to memory does it take to get the desired word that corresponds to the given virtual address? Would that change for a 1- or 2- level table?

Virtual Address:

slide-26
SLIDE 26

26

Page Table Entries

  • Valid bit (1 = desired page in memory / 0 = page not present / page fault)
  • Referenced = To implement pseudo-LRU replacement
  • Protection: Read/Write/eXecute

Page Frame Number Valid / Present Modified / Dirty Referenced Protection Cacheable

slide-27
SLIDE 27

27

Page Fault Steps

  • HW will…

– Record the offending address, the EPC, and cause (page fault)

  • SW will…

– Pick an empty frame or select a page to evict – Writeback the evicted page if it has been modified

  • May block process while waiting and yield processor

– Bring in the desired page and update the page table

  • May block process while waiting and yield processor

– Restart the offending instruction

slide-28
SLIDE 28

28

Page Replacement Policies

  • Possible algorithms: LRU, FIFO, Random
  • Since page misses are so costly (slow) we can afford to spend sometime

keeping statistics to implement LRU

  • Implementing exact LRU would require updating statistics every access (using

some kind of timestamp). This is too much to do in HW and we don’t want to use SW when we have hits

  • HW will implement simple mechanism that allows SW to implement a

pseudo-LRU algorithm

– HW will set the “Referenced” bit when a page is used – At certain intervals, SW will use these reference bits to keep statistics on which pages have been used in that interval and then clear the reference bits – On replacement, these statistics can be used to find the pseudo-LRU page

slide-29
SLIDE 29

29

Cache & VM Comparison

Cache Virtual Memory Block Size 16-64B 4 KB – 64 MB Mapping Schemes Direct or Set Associative Fully Associative Miss handling and replacement HW SW Replacement Policy Full LRU if low associativity / Random is also used Pseudo-LRU can be implemented

slide-30
SLIDE 30

30

Performance Issues

  • Let cache hits = 10ns, memory accesses=100ns
  • Assume a program makes an access to data located in cache…

– Without VM, only requires 10ns cache access time – With VM, address must first be translated via the page table (recall page table is in memory)

  • If a single-level, one access to the page table (MM) = 100ns
  • If two-levels, two access to the page tables = 200ns
  • If three-levels, three access to the page tables = 300ns
  • Finally, physical address can access cache = 10 ns (if hit)
  • Total time equals 100*L+10 (where L=# of Level of Page Table)
  • Translation is extremely costly as currently implemented!!!
slide-31
SLIDE 31

31

Translation Unit / MMU

Translation Lookaside Buffer (TLB)

  • Solution: Let’s create a cache for translations = Translation

Lookaside Buffer (TLB)

  • Needs to be small (64-128 entries) so it can be fast, with high degree of

associativity (at least 4-way and many times fully associative) to avoid conflicts – On hit, the PPFN is produced and concatenated with the offset – On miss, a page table walk is needed

TLB I or D Cache

CPU

VA VPN Page Offset PPFN PA data 10 ns 10 ns

Memory Memory (Page Table)

Hit Miss Miss Hit

Processor

slide-32
SLIDE 32

32

TLB + Data Cache

Offset w/in page

Virtual Address

Virtual Page Number

31 12 11

Page Frame #

Offset w/in page

Physical Address

  • Phys. Frame #

31 12 11

V M Tag = VPN

= = = =

TLB Fully Direct Set-Assoc.

20 12

  • Phys. Tag

Index

Byte Offset

Data Data Data Data Tag V

= Hit

Desired Data 14 16

TLB Data Cache Fully Direct Set-Assoc. MMU Cache If data cache is tagged with physical addresses, then we must translate the VA before we can access the data cache.

TLB only has a few entries so now we need to store tags.

slide-33
SLIDE 33

33

Differences of TLB & Data Cache

  • Data cache

– 1 tag (to identify the block) corresponds to MANY bytes (16-64 bytes)

  • TLB

– 1 tag (VPN) corresponds to 1 translation (PTE/PPFN) which is good for 4KB

  • Main Point: TLBs are smaller than normal data caches and faster

to access

TLB

(1 tag = 1 translation. No Offset needed)

Instruc./Data Cache

(Offset needed since one tag corresponds to many values)

slide-34
SLIDE 34

34

TLB Block Size

  • A block in cache may be

– 1 word – 2 words – 4 words

  • Consider a direct mapped cache mapping can the

word field be 0-bits?

  • But an entry in the TLB is 1 value

– Log2(1) = 0…TLB mappings have no word field

Tag Block

Word Byte Offset

18 10 2 2

slide-35
SLIDE 35

35

A 4-Way Set Associative TLB

  • 64 entry 4-way SA TLB (set field indexes each “way”)

– On hit, page frame # supplied quickly w/o page table access

Offset w/in page

Virtual Address

VPN

31 12 11

Offset w/in page

Physical Address

  • Phys. Frame #

31 12 11

Set Tag

308ac 7ffe Tag PF# Tag PF# Tag PF# Tag PF#

= = = =

Way 1 Way 0 Way 2 Way 3

4 16

7 f f e 1 6 d 8 3 8 a c 6 d 8 7 f f e 1

What is the page size? 4KB Tag size? 16 bits Comparator Width? 5-bits (4+V)

slide-36
SLIDE 36

36

Processor Chip Translation Unit / MMU

Page Fault Steps

  • On page fault, handler will access

disk to evict old page (if dirty) and to bring in desired page

– Likely context switch on each access since disk is slow

  • Make sure PT & TLB are updated

appropriately

TLB Cache

CPU

VA VPN Page Offset PPFN PA data 10 ns

Miss Miss Hit

VA Miss Invalid / Not Present OS Exception (Page Fault) Handler

Memory

1 2 3 3 4

  • 3. Evict (writeback) page if no

frame free (update PT & TLB)

  • 4. then bring in needed page

and update PT

4 5

Restart faulting instruction

3 4

Page Table

4 3 Disk Driver (Interrupt) 6

TLB Miss / PT walk / Update TLB

6

slide-37
SLIDE 37

37

Virtual Memory System Examples

Microprocessor AMD Opteron P4 PPC 7447a Virtual Address 48-bit 32- or 48-bit 52-bit Physical Address 40-bit 36-bit 32- or 36-bit TLB Entries (I/D/L2 TLB) L1: 40/40 L2: 512/512 L1: 128/128 L1: 128 / 128 TLB Mapping L1: Fully L2: 4-way SA Fully (? 4-way) 2-way set associative

  • Min. Page Size

4 KB 4 KB 4 KB

Notes: Large VA’s include ASID (process ID’s) and other segment information Sources: H&P, “CO&D”, 3rd ed., Freescale.com,

slide-38
SLIDE 38

38

TLB Issues

  • Because of high degree of associativity and limited working set
  • f pages (usually) we can get VERY HIGH hit rates for the TLB

– Variable page size settable by OS to allow for different working set sizes – Example: 64 TLB entries and 4 KB pages = 256KB

  • Often times, separate TLB’s for instruction and data address

translation

slide-39
SLIDE 39

39

TLB Miss Process

  • On a TLB miss, there is some division of work between the hardware (MMU) and

OS

  • Option 1

– MMU can perform the TLB search followed by a page table walk if needed – If page fault occurs, OS takes over to bring in the page

  • Option 2

– MMU performs TLB Search – If TLB miss, OS can perform page table walk and bring in page if necessary

  • When we want to remove a page from MM

– First flush out blocks belong to that page from cache (writing back if necessary) – Invalidate tags of those blocks – Invalidate TLB entry (if any) corresponding to that page

  • If D=1, set dirty bit in page table

– If page is dirty, copy page back to the disk – Simple way to remember this…

  • If parents (page) leave a party then the children (cache blocks & TLB entries) must leave too
slide-40
SLIDE 40

40

Other Issues

  • Property of Inclusion

– Cache contents are a (subset / superset) of main memory contents – Main memory contents are a (subset / superset) of page/swap file on disk – TLB contents are a (subset / superset) of page table contents

slide-41
SLIDE 41

41

Cache, VM, and Main Memory

TLB VM Cache Possible Y/N & Description Hit Hit Hit Possible: best-case scenario Hit Hit Miss Possible: TLB hits (hit in VM is implied), then cache miss Miss Hit Hit TLB misses, then hits in page table, then cache hit Miss Hit Miss TLB misses, then hits in page table, then cache miss Miss Miss Miss TLB misses, then page fault, then miss in cache Hit Miss Miss Impossible: cannot hit in TLB if page not present Hit Miss Hit Impossible: cannot hit in TLB if page not present Miss Miss Hit Impossible: data cannot be in cache if page not present

Taken from H & P, “Computer Organization” 3rd, Ed.

slide-42
SLIDE 42

42

Cache Addressing with VM

  • Cache review

– Set or block field indexes LUT holding tags – 2 steps to determine hit:

  • Index (lookup) to find tags (using block or set bits)
  • Compare tags to determine hit
  • Sequential connection between indexing and tag comparison
  • Rather than waiting for address translation and then

performing this two step hit process, can we overlap the translation and portions of the hit sequence?

– Yes if we choose page size, block size, and set/direct mapping carefully

slide-43
SLIDE 43

43

Cache Index/Tag Options

  • Physically indexed, physically tagged (PIPT)

– Wait for full address translation – Then use physical address for both indexing and tag comparison

  • Virtually indexed, physically tagged (VIPT)

– Use portion of the virtual address for indexing then wait for address translation and use physical address for tag comparisons – Easiest when index portion of virtual address w/in offset (page size) address bits, otherwise aliasing may occur

  • Virtually indexed, virtually tagged (VIVT)

– Use virtual address for both indexing and tagging…No TLB access unless cache miss – Requires invalidation of cache lines on context switch or use of process ID as part of tags

Offset

VA

VPN

31 12 11

Offset

PA

PFN

31 12 11

Set/Blk Tag

PIPT

Offset

VA

VPN

31 12 11

Offset

PA

PFN

31 12 11

Tag Set/Blk Offset

VA

VPN

31 12 11

Offset

PA

PFN

31 12 11

Set/Blk Tag

VIPT VIVT

slide-44
SLIDE 44

44

Multiple Processes

  • Recall each process has its own virtual address space, page

table, and translations

  • How does TLB handle context switch

– Can choose to only hold translations for current process and thus invalidate all entries on context switch – Can hold translations for multiple processes concurrently by concatenating a process or address space ID (PID or ASID) to the VPN tag

Offset

VA

VPN

31 12 11

ASID

Unique ID for each process

Page Frame # V M Tag

= = = =

ASID

slide-45
SLIDE 45

45

Shared Memory

  • In current system, all memory is

private to each process

  • To share memory between two

processes, the OS can allocate an entry in each process’ page table to point to the same physical page

  • Can use different protection

bits for each page table entry (e.g. P1 can be R/W while P2 can be read only)

1 2 3 1 2

… …

1 2

Physical Memory Virtual Address Spaces P1 P2

slide-46
SLIDE 46

46

8-Stage Pipeline

  • In 5-stage pipeline, we place the I-Cache and

D-Cache in one stage each

  • When we add VM translation (i.e. TLB), cache

tag check, and data access we need more stages to balance the delay

D-Cache D-TLB

Cache Data Cache Tag Lookup

Tag Check

Single Memory Stage in 5- Stage Pipeline Expand to three stages when TLB and Cache access is balanced

slide-47
SLIDE 47

47

8-Stage Pipeline

  • MIPS R4000 uses pipelined instruction and data caches
  • The instruction is available at the end of the IS stage but the

tag check is done in RF

– This is harmless since it’s fine to start the decode and read registers even if it’s an invalid tag so long as we know by the end of the clock

  • For the data cache we must perform the tag check before we

can start writing into the register file

IM

Reg

ALU

DM

Reg

IF IS RF EX DF DS TC WB TLB Data/Tag Access Tag Check TLB Data/Tag Access Tag Check

slide-48
SLIDE 48

48

Load Dependency Issue Latency

  • 8-stage pipeline has a two-cycle load delay

– Possible since data is available at end of DS and can be forwarded – If tag check indicates a miss the pipeline can be “backed up” (re-execute the instruction when the data is available

IM

Reg

ALU

DM

Reg

IM

Reg

ALU

DM

Reg

IM

Reg

ALU

DM

Reg

IM

Reg

ALU

DM

Reg

LW $5,0($2) ADD $1,$1,$5

slide-49
SLIDE 49

49

A Complete VM / Cache Example

  • Use the following specification for the following questions

– 64-bit data, 32-bit virtual/physical address – Page Size: 128KB – TLB Size: 256 entry 4-way set associative – Page Table Org.: 3-levels

  • A 64 entry A-Table (page directory) followed by several 32 entry B-Tables

(2nd level tables) followed by some number of C-Tables (3rd level)

– Cache Organization

  • Cache Size: 512KB
  • 8-way set associative
  • Block size: 2 words [Word = 64-bits = 8 bytes]
slide-50
SLIDE 50

50

Address Bus and Interleaving

  • Use the following specification for the following questions

– 64-bit data, 32-bit virtual/physical address – Cache Organization: Block size: 2 words [1 Word = 64-bits = 8 bytes]

  • How many banks would you suggest for interleaving purposes?

2 Banks so we can quickly get two words to the data cache when a block is transferred

Physical Address

Word 31 Byte

Proc.

Bank 0 (A3=0) Bank 1 (A3=1)

/BE7…/BE0 64 29 A31-A3

Block ID 8 8 31 3 2 1 0 Byte

31

Logical Address Bus Logical Address Bus

3 4 2 1 0

64-bit Data bus = 8 bytes = 8 Byte enables (/BE7…/BE0)

28 28

slide-51
SLIDE 51

51

TLB Mapping

  • Use the following specification for the following questions

– 64-bit data, 32-bit virtual/physical address – Page Size: 128KB – TLB Size: 256 entry 4-way set associative

Logical Address Bus

Page Size = 128KB => Offset Field Size = 17-bits # of TLB Sets: 256 entries / 4 entries per set = 64 sets => 6 set bits Offset VPN

31 17 16

Tag Set

17 23 31 22

slide-52
SLIDE 52

52

Page Table Mapping

  • Use the following specification for the following questions

– Page Size: 128KB – Page Table Org.: 3-levels

  • A 64 entry A-Table (page directory)

32 entry B-Tables (2nd level tables) some number of C-Tables (3rd level)

Virtual Address

VPN = 15-bits Level 1 Page Table = 64 (26) entries => 6-bits Level 2 Page Table = 32 (25) entries => 5-bits Level 3 Page Table = 15-6-5= 4-bits => 16 (24) entries Offset=17-bits VPN=15-bits

31 17 16 Level 1 4 5 6 Level 2 Level 3

slide-53
SLIDE 53

53

Data Cache Design

  • Use the following specification for the following questions

– Cache Organization

  • Cache Size: 512KB
  • 8-way set associative
  • Block size: 2 words [Word = 64-bits = 8 bytes]

64-bit data = 8 (23) bytes per word Block Size = 2 (21) words = 1 word bit # of Cache blocks = 512KB / 16 bytes per block = 219 / 24 = 215 # of Sets = 215 / 23 ways per set = 212 sets => 12 set bits # of Tag bits = 32 – 12 – 1 – 3 bits = 16-bits

Logical Address Bus

Word

3 Tag Set 1 16

31

12

Byte

slide-54
SLIDE 54

54

Data Cache Implementation

  • How many comparators and of what size are needed to

determine cache hit or miss?

  • What is the size of the TAG RAM’s?

8 comparators of 17-bits Tag RAM Size = 4K x 17

Logical Address Bus

Word

3 Tag Set 1 16

31

12

Byte

Set Tag RAM DI[16:0]

DO[16:0]

A15-A4 A31-A16 + V-bit A[11:0]

=

Hit/Miss Tag

x 8

12 17 17
