Persistent Groundwater Contaminant Plumes: Processes, Characterization, and Case Studies

UA-SRP & USEPA Seminar Series- Webinar February 24, 2014

Mark L. Brusseau School of Earth & Environmental Sciences University of Arizona

1

Constrained Mass Removal & Plume Persistence

“significant limitations with currently available remedial technologies persist that make achievement of MCLs throughout the aquifer unlikely at most complex groundwater sites in a time frame of 50-100 years.”* “Complex” groundwater sites are defined as those that have DNAPL present (e.g., chlorinated solvents) and that have substantial subsurface heterogeneity, including the presence of extensive lower-permeability units or fractured media.

• Why does this situation exist?
• What options are available?

*National Research Council (NRC). 2013. Alternatives for

Managing the Nation's Complex Contaminated Groundwater

• Sites. Wash., DC

2

Outline

• Chlorinated-solvent sites- prevalence and issues
• Constrained mass removal and plume persistence: Impact of

DNAPL source zones

• Constrained mass removal and plume persistence: Impact of

mass storage in lower-K zones & hydraulic factors

• Constrained mass removal and plume persistence: Impact of

sorbed mass

• Summary

3

~1600 SUPERFUND Sites ~80% have Chlorinated-Solvent Contaminants

4

Arizona Sites

Chlorinated- Solvents Presence: State: 31/35 Federal: 13/15

5

Groundwater Contamination Sites in Tucson

Chlorinated-Solvent Contaminants are Primary Concern

6

at all 9 Sites

Groundwater Remediation

Standard Method = Pump and Treat Very effective for plume containment

7

Impact of P&T on Water Resources

• Analysis for Tucson [Brusseau & Narter, 2013]- year 2010
• Compare aggregate volume of groundwater extracted for all P&T

systems to total metropolitan groundwater withdrawal

• Total groundwater withdrawal for all P&T systems = 16.6 M m3
• This is ~20% of the total groundwater withdrawal in Tucson
• Treated water used primarily for potable water or re-injection
• Represents ~6% of total potable water supply

8

Three Chlorinated-Solvent Sites in Arizona

• TCE is Primary COC
• Very Low Retardation (R<2)
• No Measurable Transformation Processes
• V. Low Biogeochemical Attenuation Capacity

Large Plumes

(several km long)

11 KM 4.5 KM

9

9 KM

Pump & Treat CMD Data

Composite Measure:

CMD = Q * C

• OU1

Q = pumping rate C = concentration ~90% Reduction Currently ~ 1 kg/d Asymptotic conditions

~2 equivalent pore volumes displaced 10

Constrained Mass Removal & Plume Persistence

Potential Factors:

• Uncontrolled DNAPL Sources
• Plume-scale Lower-K Zones and Mass Storage (diffusive mass

transfer- “back diffusion”)

• Plume-scale Sorbed-phase Mass Storage

(sorption/desorption processes)

• Hydraulic Factors (P&T well-field, etc)
• Low Attenuation Capacity
• Other (Institutional, Analytical, etc)

11

Constrained Mass Removal & Plume Persistence

Need to Determine Relative Significance of Each Factor, and Site-dependent Functionality Long Known:

12

1989

Tucson International Airport Area Superfund Site

• TCE/DCE Contamination

Identified in 1981

• Site Placed on Superfund

NPL in 1983

• Pump and Treat started in

1987 (south plume)

• Source-zone Remediation

efforts [SVE, ISCO]

• UA Collaboration since 1993

13

Composite CMD: AFP44

1987

High-resolution Temporal Data set

Asymptotic conditions Start Pump & Treat

14

Constrained Mass Removal & Plume Persistence

Question: What is the relative significance of each of the various Persistence/Attenuation factors for this site? Conducted an integrated Laboratory, Field, and Modeling study

15

Plume-scale Modeling Effort ~50 km2

Known Inputs Conduct series of scenario-testing sensitivity analyses

16

17

Impact of Transport Processes

K Variability & Diffusive Mass Transfer (back diffusion)

18

Impact of Transport Processes

Sorption-desorption (nonlinear, rate limited)

[Sims include physical heterogeneity] 19

Impact of Transport Processes

Controlling Factor for Early Phase

DNAPL in Source zones

20

Source-zone Architecture, DNAPL Dissolution, and Mass Removal

Multi-scale Investigations of Systems

21

APS ~6 mm ~10 cm ~2 m

Pore Core Intermediate

DNAPL Source Behavior

Pore-scale Imaging: 10 um resolution 1 2 3 4 1 2 3 4

Desorption Control NAPL Dissolution Control [1-4]: Non-uniform accessibility No-NAPL Expt

2 3 4 2 3 4 Column Experiments

Relative Concentration

22

DNAPL Source Behavior

Flow-cell Experiments DNAPL Sn Imaging

1 10 100 1000 10000 100000 20 40 60 80 100 120 140 160 180

Concentration (mg/L) Pore Volume

Control- Homogeneous Mixed Source Heterogeneous Heterogeneous-2

Laboratory Experiments

• Known DNAPL distributions
• Permeability variability
• Measure DNAPL in situ

23

DNAPL Source Behavior

Variables:

• Domain size

[20 vs 10,000 m2]

• Gradient & Q

[natural vs induced]

• Initial DNAPL Mass

Field Data

0.0001 0.001 0.01 0.1 1 10 50 100 150 200 CMD (Kg/d) Time (month) AFP44- 3 3 Hangers Dover- Surf

24

Difficult to conduct comparative analysis

Data Analysis & Interpretation

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1

Fractional Mass Discharge Reduction Fractional Mass Reduction

1:1 (First order) Minimal Reduction (efficient mass removal) Maximal Reduction (inefficient mass removal)

0.001 0.01 0.1 1 5 10 15 20

Relative Concentration or Relative CMD Relative Time

1:1 Minimal Reduction Maximal Reduction

• Employ contaminant mass discharge (CMD)

metric

• Determine relationship between reduction in

mass discharge and reduction in mass

• Enhances comparative analysis

25

DNAPL Source Behavior

Contaminant Mass Distribution [Accessibility] {source architecture, site age (mass removed)} Field Data Flow-cell Experiments

0.2 0.4 0.6 0.8 1 0.2 0.4 0.6 0.8 1

Fraction Reduction in CMD Fraction Reduction in Mass

TIAA-1 TIAA-2 Visualiz. Dover-CSF Dover-Surf Borden-1 Borden-2

Increasing fraction

• f poorly accessible

mass)

0.2 0.4 0.6 0.8 1 0.2 0.4 0.6 0.8 1

Fractional Reduction in CMD Fractional Reduction in Mass

Control-homogeneous Mixed Source Heterogeneous-1 Heterogeneous-2

26

Post Source-zone Remediation

Persistence Factors:

• Residual DNAPL Sources (incomplete removal/containment)
• Plume-scale Lower-K Zones and Mass Storage (diffusive mass

transfer- “back diffusion”)

• Plume-scale Sorbed-phase Mass Storage

(sorption/desorption processes)

• Hydraulic Factors (P&T well-field, etc)
• Other (Institutional, Analytical, etc)

27

Composite CMD: AFP44

SVE Start ISCO Start

1987

Impacts from Source Remediation efforts

Current CMD = 0.2 kg/d Pre SZR CMD = 2 kg/d ~90% Reduction

ISCO End SVE End

28

Plume Persistence after Source Remediation

0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0

Contaminant Mass Discharge (Kg/d)

Simulated- Remediation Simulated- No Remediation Measured

Non-source Factors: *Plume-scale*

• 1. Mass in Lower-K Zones
• 2. Sorbed Mass
• 3. Hydraulic Factors (well field)

*Ideal case- all source mass removed

Predictions for AFP44 Site

2 4 6 8 10 12 14

Time (Y)

29

Lower-permeability Zones & Diffusion

0.001 0.01 0.1 1 10 100 5 10 15 20 25

Mass Remaining (%) Relative Time

1 3.5 Modflow: Clay-Sand-Clay

Mass Removed (%)

90 99 99.9 99.99

0.2 0.4 0.6 0.8 1 0.2 0.4 0.6 0.8 1

Fraction Reduction in Mass Discharge Fraction Mass Reduction

Model Simulations

Stochastic (random K fields) vs. Discrete (homogeneous, orthogonal) layers (MODFLOW)

30

1 3.5 Modflow: Clay-Sand-Clay

Variance of lnK

Well-field Configuration

0.001 0.01 0.1 1 5 10 15 20 25

Relative Concentration Relative Time

3 longitudinal wells 3 downgradient (transverse) wells 9 uniform-dist wells Natural gradient (equiv Q)

Model Simulations

3–Layer system (Clay-Sand-Clay) [MODFLOW]

31

Sorption-Desorption Processes

Extensive Elution Tailing

• Observed for all media
• Occurs with short contact times
• Need continuous-distribution

domain model Causative Mechanisms?

0.0000001 0.000001 0.00001 0.0001 0.001 0.01 0.1 1 500 1000 1500 2000 2500 3000 3500 4000

Relative Concentration Pore Volumes

Non-Linear, Rate-Limited Sorption Linear, Rate-Limited Sorption Non-Linear, Equilibrium Sorption Measured

RLS >> NLS Column Experiments

32

Sorption-Desorption Processes

1

Eustis

0.1 0.01

Progressive increase

0.001

in resistance with increasing contact

0.0001

time

0.00001 0.000001 0.0000001 2 PV 4 PV 8 PV 20 PV 100 PV 1000 PV Aged 30 days Aged 420 days Aged 4 years

Interaction with Hard Carbon [sorbate permeation within, and sorbate-induced deformation of, the HC matrix]

1 0.1

Replication

Exp 1 Exp 2 Exp 3

Relative Concentration

1000 2000 3000 4000 5000 6000 7000 8000 9000

Pore Volumes

98% quartz sand 2% clay (kaolinite- non-expanding) 0.38% organic carbon 0.14% hard carbon (kerogen, bc)

Relative Concentration

Exp 4

0.01

Simulation

0.001 0.0001 0.00001 0.000001

Non-linear sorption Competitive sorption

0.0000001 500 1000 1500 2000 2500 3000 3500 4000

Pore Volumes

33

Sorption-Desorption Processes

98-80% quartz, feldspars 2-20% clay (montmorillonite- expanding) 0.03% organic carbon 0.02% hard carbon (kerogen, bc) Non-linear sorption

Peak Shift = change in d-spacing

AFP 44 Sediment XRD Analysis: several AFP44 samples and 2 (mont) specimen controls Clay inter-layer d-spacing = ~0.3-0.6 nm TCE thickness = ~0.3 nm Increase in d-spacing for TCE treatment = ~0.4 nm TCE Intercalation [+ HCI]

No apparent aging effect 34

Summary: 3 Hanger Site at TIAA

0.00 0.05 0.10 0.15 0.20 0.25 0.30 0.35 0.40 10 20 30 40 50 60 Contaminant Mass Discharge (kg/d) Elapsed Time (month)

Hydraulic Source Control

Plume Reduction = ~50% Identify Relevant Factors:

• 1. Low-K Zones and DMT
• 2. Source Residual
• 3. Well-field Configuration

[~2-3 pore volumes]

35

Measured Model Simulation

Summary: continued

• Source Zones- incomplete removal/containment of

contamination, continuing source

• Large, Persistent Plumes- contributing factors
• Site “Architecture” and “Age” key factors

– Subsurface properties (permeability field, flow field) – Contaminant distribution (phases, relative accessibility) – Change in contaminant distributions and accessibility as sites age

• Alternatives to P&T ?
• Long-term Site Management

36

Acknowledgements

• The many students and post-docs who have contributed

to this research; our collaborators and partners with EPA, AECOM, US Air Force, CRA, Tucson Airport Authority, ADEQ.

• Financial support provided by the National Institute of

Environmental Health Sciences Superfund Research Program (ES04940), the US Department of Defense Strategic Environmental Research and Development Program (ER-1614), the US Air Force, and the Tucson Airport Authority

37

References

• Brusseau, M.L.; Nelson, N.T.; Zhang, Z.; Blue, J.E.; Rohrer, J.; Allen, T. 2007. Source-Zone Characterization of a Chlorinated-Solvent Contaminated Superfund Site

in Tucson, AZ. J. Contam. Hydrol., 90:21-40.

• Brusseau, M.L., Hatton, J., and DiGuiseppi, W. 2011. Assessing the Impact of Source-Zone Remediation Efforts at the Contaminant-Plume Scale: Application to a

Chlorinated-Solvent Site. J. Contam. Hydrol., 126:130-139.

• Brusseau, M.L., Carroll, K.C., Allen, T., Baker, J., DiGuiseppi, W., Hatton, J., Morrison, C., Russo, A., and Berkompas, J. 2011. The Impact of In-situ Chemical

Oxidation on Contaminant Mass Discharge: Linking Source-zone and Plume-scale Characterizations of Remediation Performance. Environ. Sci. Technol., 45:5352- 5358.

• Brusseau, M.L., Russo, A.E., and Schnaar, G. 2012. Nonideal Transport of Contaminants in Heterogeneous Porous Media: 9- Impact of Contact Time on Desorption

and Elution Tailing. Chemosphere, 89:287-292.

• Brusseau, M.L. 2013. Use of Historical Pump-and-Treat Data to Enhance Site Characterization and Remediation Performance Assessment. Water Air Soil Poll., 224:

article 1741.

• Brusseau, M.L. and Narter, M. 2013. Assessing the Impact of Chlorinated-Solvent Sites on Metropolitan Groundwater Resources. Groundwater, 51(6): 828-832.
• Brusseau, M.L.; Matthieu III, D.E.; Carroll, K.C.; Mainhagu, J.; Morrison, C.; McMillan, A.; Russo, A.; Plaschke, M. 2013. Characterizing Long-term Contaminant

Mass Discharge and the Relationship Between Reductions in Discharge and Reductions in Mass for DNAPL Source Areas. J. Contam. Hydrol., 149: 1-12.

• Chorover, J. and Brusseau, M.L. 2008. Kinetics of Sorption-Desorption, pgs 109-149 in Kinetics of Water-Rock Interaction, S.L. Brantley, J. Kubicki, and A.F. White,

Editors, Springer, New York, NY.

• DiFilippo, E.L. and Brusseau, M.L. 2008. Relationship Between Mass Flux Reduction and Source-zone Mass Removal: Analysis of Field Data. J. Contam. Hydrol.,

98:22-35.

• DiFilippo, E.L., Carroll, K.C., and Brusseau, M.L. 2010. Impact of Organic-Liquid Distribution and Flow-Field Heterogeneity on Reductions in Mass Flux. J. Contam.

Hydrol., 115:14-25.

• Johnson, G.R., Norris, D.K., and Brusseau, M.L. 2009. Mass Removal and Low-concentration Tailing of Trichloroethene in Freshly-amended, Synthetically-aged,

and Field-contaminated Aquifer Material. Chemosphere, 75:542–548.

• Matthieu III, D.E., Brusseau, M.L., Johnson, G.R., Artiola, J.L., Bowden, M.L., Curry, J.E. 2013. Intercalation of Trichloroethene by Sediment-Associated Clay
• Minerals. Chemosphere, 90:459-463.
• Russo, A., Johnson, G.R., Schnaar, G., and Brusseau, M.L. 2010. Nonideal Transport of Contaminants in Heterogeneous Porous Media: 8. Characterizing and

Modeling Asymptotic Contaminant-Elution Tailing for Several Soils and Aquifer Sediments. Chemosphere, 81:366-371.

• Schnaar, G. and Brusseau, M.L. 2006. Characterizing pore-scale dissolution of organic immiscible liquid in natural porous media using synchrotron X-ray
• microtomography. Environ. Sci. Technol., 40:6622-6629.
• Zhang, Z. and Brusseau, M.L. 1999. Nonideal Transport of Reactive Solutes in Heterogeneous Porous Media: 5. Simulating Regional-Scale Behavior of a

Trichloroethene Plume During Pump-and-Treat Remediation. Water Resour. Res., 35: 2921-2935.

38
