Permanent Erosion Protection and Prevention

Talk to us… 0414 280 009 info@concretemats.com.au www.ConcreteMats.com.au

 Simple and easy to install  Flexible design easily contours to landscape  Offers permanent erosion protection  Cost saving - reduced time, labour and equipment  Environmentally friendly and sustainable solution  Aesthetically tidy, can be vegetated or unvegetated  Low maintenance, capable of being mowed  Minimized public risks, blocks cannot be dislodged

• r thrown like rocks

 Safe for pedestrians or wildlife to walk across  Durable long-term erosion protection Talk to us… Call 02 6682 8614

• r 0414 280 009

info@concretemats.com.au

www.ConcreteMats.com.au Benefits of the concrete mat…

ACM = Quick Unroll Erosion Control

What is the concrete mat?

 Australian Concrete Mats consists of concrete

shapes, locked and embedded into a high strength, polypropylene geogrid.

 Used to control erosion in any area where soil

sediment can be moved by water runoff.

Talk to us… Call 02 6682 8614

• r 0414 280 009

info@concretemats.com.au

www.ConcreteMats.com.au

 Spacings around each concrete

shape that gives the concrete mat flexibility to be packaged in rolls.

 Openings around the concrete

shapes also allow vegetation to grow through the mat.

 Eventually, vegetation will

completely cover Australian Concrete Mat.

ACM = Quick Unroll Erosion Control

Physical Properties

 CONCRETE:

 40 MPA Concrete. Wet cast portland cement  6% air entrained. 8mm aggregate

 INTERLOCKING GEOGRID:

 50KN/m PVC coated polyester woven geogrid

 UNDERLAYMENT:

 As per selection to suit conditions and environment

 WEIGHT PER M2:

 40KG

Talk to us… Call 02 6682 8614

• r 0414 280 009

info@concretemats.com.au

www.ConcreteMats.com.au

ACM = Quick Unroll Erosion Control

Physical Properties

 Australian Concrete Mats

are packaged in rolls, making handling and installing the mat simple and efficient.

Talk to us… Call 02 6682 8614 or 0414 280 009 info@concretemats.com.au

www.ConcreteMats.com.au

 Cost saving

installation- reduced time, labour and equipment

Quick Unroll Erosion Control

 Australian Concrete Mats offer a permanent, hard

armour protection to the ground surface, whilst supporting natural vegetation to grow through

 Mats can be supplied with non-woven fabrics, as

well as various turf reinforced mats on the underside

 Site conditions determine the underlayment

material

Talk to us… Call 02 6682 8614

• r 0414 280 009

info@concretemats.com.au

www.ConcreteMats.com.au Concrete + Vegetation = Permanent Erosion Protection

Various Lengths

 Australian Concrete Mats are

available in standard widths

• f 1.2m or 2.4m wide rolls

Talk to us… Call 02 6682 8614

• r 0414 280 009

info@concretemats.com.au

www.ConcreteMats.com.au

 Lengths can be custom cut up to 15m

ACM = Quick Unroll Erosion Control

Where does the concrete mat work?

Talk to us… Call 02 6682 8614

• r 0414 280 009

info@concretemats.com.au

www.ConcreteMats.com.au

ACM = Quick Unroll Erosion Control Australian Concrete Mats are bio-engineering at its best! Concrete mats offers protection and support for the environment.

 Shoreline Protection  Roadside Shoulder Protection  Bridge Slope Support  Inlet / Outlet Protection  Culvert and Apron Protection  Reservoir and Settlement Ponds  Drainage Channels

Where does the concrete mat work?

Talk to us… Call 02 6682 8614

• r 0414 280 009

info@concretemats.com.au

www.ConcreteMats.com.au

ACM = Quick Unroll Erosion Control Australian Concrete Mats are bio-engineering at its best! Concrete mats offers protection and support for the environment.

 Channel Lining  Dam and Spillway Protection  Canal and River banks  Low Water Crossings  Access Roads  Tyre Wash points  Weirs and Boat Ramps  … the list goes on!

Replaces other erosion control methods

Talk to us… Call 02 6682 8614

• r 0414 280 009

info@concretemats.com.au

www.ConcreteMats.com.au

Concrete mats can handle a wide range

• f erosion control applications where

many other applications fall short.

 Replaces Articulated Concrete Blocks  Replaces Rip Rap Rock  Replaces Gabion Mattresses  Replaces Poured Concrete Gutters or

Channels

 Replaces Fabric Form

All round Australian Concrete Mats offer significant cost savings. Low material costs, less labour and faster installation for project completion

ACM - Replaces Articulated Blocks

Talk to us… Call 02 6682 8614

• r 0414 280 009

info@concretemats.com.au

www.ConcreteMats.com.au

ACM = Quick Unroll Erosion Control

 Vegetated armour protects and

supports ground underneath

 Flexible roll easily contours to

landscape

 Will not break apart with wet-dry /

hot-cold cycles

 Settling will not pull apart concrete

mat – it flexes with ground movement

 Significant cost savings – low

material costs, less labour and faster installation and project completion

ACM - Replaces Rock Rip Rap www.ConcreteMats.com.au

ACM = Quick Unroll Erosion Control

 Concrete Mat can be maintained

with commercial mowers

 Armor is locked in place, will not

move like rock

 Supports and protects soils to

promote vegetation growth underneath

 Vegetated concrete mat

will not heat water like rocks which absorb heat

Failed rip rap erosion control Replaced with flexible Concrete Erosion Mats & seeded underlay.

ACM - Replaces Poured Concrete Channels

 Will not crack with

weather extremes

 Has longer lifespan  Contaminants are

filtered through vegetated channels

 Eliminates need for

labour intensive formwork

 Less expensive with

faster installation

Talk to us… Call 02 6682 8614

• r 0414 280 009

info@concretemats.com.au

www.ConcreteMats.com.au

Quick Unroll Erosion Control

Failed poured concrete erosion control Replaced with flexible Concrete Erosion Mats

ACM - Replaces other erosion control methods

 Replaces Gabion Mattresses

 Can be driven over and

maintained with mowers

 Less expensive and

faster to install

 Replaces Fabric Form

 Australian Concrete Mats

articulates and will not crack

Talk to us… 02 02 6682 8614 or 0414 280 009 info@concretemats.com.au

www.ConcreteMats.com.au

ACM = Quick Unroll Erosion Control

Choose ACM… Everyone Wins!

 When all factors are considered for selecting erosion

control for your project, Australian Concrete Mat

• ffers an all-round efficient solution.

 ACM offers significant cost savings, lower material

costs, less labour and faster installation than the alternative erosion control methods.

 Results are a permanent durable erosion solution with

faster and more efficient project completion.

 Consider our concrete erosion mat for your projects

that require efficient permanent erosion protection and prevention…

 Choose Australian Concrete Mats - everyone wins! Talk to us… Call 02 6682 8614

• r 0414 280 009

info@concretemats.com.au

www.ConcreteMats.com.au

Permanent Erosion Protection & Prevention

The easy choice… Australian Concrete Mats

Call: 02 6682 8614 or 0414 280 009 Email: info@concretemats.com.au

www.ConcreteMats.com.au

www.ConcreteMats.com.au

Quick to Install Permanent Erosion Protection Friendly for Environment Sustainable Solution
