Patterns for High Performance C# Federico Lois Twitter: - - PowerPoint PPT Presentation

Patterns for High Performance C#

Federico Lois

Twitter: @federicolois Github: redknightlois Repo: performance-course

c o r v a l i u s . c o m

“The best programs are written so that computing machines can perform them quickly and so that human beings can understand them clearly.”

Donald Knuth

c o r v a l i u s . c o m

Asymptotic Notation

“Big-O notation is a mathematical notation that describes the limiting behavior of a function when the argument tends towards a particular value or infinity.” Bachmann–Landau notation

c o r v a l i u s . c o m

BigO notation

• Instruction Counting. (Turing model)
• Simple, effective for most problems.
• Cache-Oblivious (based on RAM model)
• Incorporates a simple cache to the model.
• Doesn’t explicitly model it’s size.
• It can include the tall-cache assumption.
• Cache-Aware (based on RAM model)
• It models explicitely size, structuction, eviction policy.
• Theoretical analysis is pretty complex.

c o r v a l i u s . c o m

Big O in practice

• Useful to evaluate general behavior.
• Not necessarily a deal-breaker
• Guides your hypothesis.
• Usually will not represent the behavior
• Until sizes are big enough to dominate
• Which may never happen
• Simple models add uncertainty.
• Our job is to adjust those variables.

c o r v a l i u s . c o m

Performance Bounds

• Compute Bound
• Memory Bound.
• Input/Output Bound

c o r v a l i u s . c o m

20% of the code consumes 80% of the resources

Pareto Rule (80-20)

…especially bad when they are in the critical path

c o r v a l i u s . c o m

Pareto

20% of the code consumes 80% of the CPU/Memory/IO

c o r v a l i u s . c o m

Pareto

20% of the code consumes 80% of the resources

c o r v a l i u s . c o m

20% of the 20% of the code consumes 64% of the resources

Pareto

2

…around of 4% of the code.

c o r v a l i u s . c o m

20% of the 20% of the 20% of the code consumes 51% of the resources

Pareto

3

…roughly 0,8% of the code.

c o r v a l i u s . c o m

Pareto

Architecture/Network/Algorithm

Optimization Land

c o r v a l i u s . c o m

Pareto

• Choosing the wrong algorithm/data structure.
• Systems outgrowing design parameters.
• Chatty network interfaces: nano-services
• Physical (and not so physical) distance.
• CPU is doing nothing, nichts, nada!

c o r v a l i u s . c o m

Pareto

2

Algorithm Time Optimization Land

c o r v a l i u s . c o m

Pareto

2

• Doing things more than once.
• CPU is doing stuff, just nothing useful (for you)!
• Memory pressure on GC or allocators
• Thread state hand-off
• Using data structures wrong
• I’m watching at you int.GetHashCode() & long.GetHashCode()

c o r v a l i u s . c o m

Pareto

3

Micro Optimization Land

c o r v a l i u s . c o m

Pareto

3

Voodoo Land

c o r v a l i u s . c o m

Pareto

3

... function calls will hurt you ... code alignment will hurt you ... useless instructions will hurt you You get the idea  … false sharing will hurt you … cache line pollution will hurt you … memory layout will hurt you …loop size in bytes will hurt you

c o r v a l i u s . c o m

Secret Sauce for High Performance (???)

• Adopt laziness as a way of life.
• Why do things twice when you can do them once.
• Choose the right data structures/algorithms
• Avoid being chatty over the network (aka IO)
• Design for no less than 20x your expected requirements
• Diminish allocations (like the plague)

Measure, Measure and when you are sure,

Measure Again!!

(just in case, you know!)

The End!

…of not talking about C#

High Performance C#

(even though most would apply to other platforms / frameworks / languages out there…)

c o r v a l i u s . c o m

IF-Switch

c o r v a l i u s . c o m

IF-Switch

• If you know the statistical distribution
• IF tends to be more efficient, except when
• You face a uniform distribution.
• You face a non tail distribution.
• Switch builds a perfect hash
• Unless values are consecutive.

c o r v a l i u s . c o m

Try-Catch

c o r v a l i u s . c o m

Try-Catch

CanThrow

c o r v a l i u s . c o m

Try-Catch

c o r v a l i u s . c o m

Try-Catch

Without Try-Catch

c o r v a l i u s . c o m

Interfaces vs Class vs Struct

• Stack Allocation vs Heap Allocation
• At least in C#, etc.
• Accessing an struct via interface will allocate on the Heap.
• Aka Boxing
• Struct is subject to special optimization.
• You can abuse the Dead Code Elimination mechanism to do

simple metaprogramming.

Allocations

• Pooling
• Generalized
• Contextual
• Per operation
• Stack Allocations
• Fixed
• Structs
• Ref/Out Trick
• Ref Return (C# 7)

Allocations

c o r v a l i u s . c o m

Inlining

• Compilers do it, and allow you to suggest them targets
• Avoiding the call helps you because it diminishes:
• Instruction Cache Misses
• Push/Pop en el stack
• Number of retired instructions
• Call context changes at the processor
• Avoiding the call increments
• Caller size in bytes.
• Locality of reference
• Collateral effects (among others)
• Dead code elimination
• Contant propagation

c o r v a l i u s . c o m

Inlining – Call Cost

c o r v a l i u s . c o m

Inlining – Call Cost

c o r v a l i u s . c o m

Inlining - Virtual Calls

• They cant be removed without devirtualization.
• The cost of a virtual call is higher than static ones.

c o r v a l i u s . c o m

Constant Propagation

c o r v a l i u s . c o m

Constant Propagation

c o r v a l i u s . c o m

Constant Propagation

c o r v a l i u s . c o m

Simple Metaprogramming

c o r v a l i u s . c o m

Comparers

c o r v a l i u s . c o m

Comparers

c o r v a l i u s . c o m

Comparers

c o r v a l i u s . c o m

Code Flow

c o r v a l i u s . c o m

c o r v a l i u s . c o m

But is it really all this work worth the trouble?

c o r v a l i u s . c o m

Thanks for coming!
