Jason Manley, Aaron Parsons, Don Backer, Henry Chen, Terry Filiba, David MacMahon, Peter McMahon, Arash Parsa, Andrew Siemion, Dan Werthimer, Mel Wright

Outline

• What is a correlator?
• Scalable packetized correlators:

– The architecture – The hardware – The software – The cost

• Closing thoughts
• Walk through actual design
• Questions and comments

Interferometry…

Basic idea

Amplitude Time

90°

Vij  Vij Vi Vj

∑ ∑

Z-n 90°

Vij  Vij Vi Vj

∑ ∑

Z-n Z-n 90°

Vik  Vik Vk

∑ ∑

Vii

∑

Vjj

∑

Vjk

∑

 Vjk

∑

Vkk

∑

Amplitude Time

“Actual” FX Correlator

∑ FFT Z-n FFT Z-n FFT Z-n ∑ ∑

CASPER DSP backend concept

Commercial off-the-shelf Multicast 10 Gbps (10GE

• r InfiniBand) Switch

PFB

ADC

FPGA DSP Module FPGA DSP Module FPGA DSP Module FPGA DSP Module FPGA DSP Module FPGA DSP Module

General-purpose CPUs

PFB PFB

. . .

Correlator Beamformers/ Spectrometers Pulsar timer

. . .

Reconfigurable Compute Cluster

ADC ADC

Polyphase Filter Banks

. . . . . .

Design Philosophy

• Standardized processing hardware
• Commercial interconnect
• Asynchronous compute engines
• Synchronization using common 1PPS
• UDP output delivery over ethernet

network

• Correlator scales with your array

F Engine 0 10GbE Switch F Engine 1 F Engine N-1 X Engine 0 X Engine 1 X Engine N-1

. . . . . . . . .

CASPER FX Architecture

Implementation

F Engine 0 10GbE Switch F Engine 1 F Engine N-1 X Engine 0 X Engine 1 X Engine N-1 . . . . . . . . .

Architecture to hardware mapping

Example 8 Antenna system

BEE2 10GbE Switch X Eng X Eng BEE2 user FPGA X Eng X Eng BEE2 user FPGA X Eng X Eng BEE2 user FPGA X Eng X Eng BEE2 user FPGA F Eng F Eng iBOB F Eng F Eng iBOB F Eng F Eng iBOB F Eng F Eng iBOB

F Engine Operations

Reformat

DDC Quantize

Channelize

X Engine

ADC

• Two F engines per iBOB
• Dual polarization design
• Currently uses ASTRO library
• Currently processes data at native clock

rate (<200MHz IBOB or < 400MHz ROACH)

Setup and Control

• Clocks:

– X engines each run off independent clock – Sampling synchronized at F engines, but clock not distributed to X engines

• Synchronized using global 1pps signal at ADCs

– Propagated to X engines using out-of-band signaling on XAUI links – Headers labeling 10GbE Ethernet packet data

• System control: separate 100Mbps Ethernet network on BEE2
• F engines configured from BEEs through XAUI links
• Control packets: CASPER UDP framework on BEE2 control FPGA
• Execute Python scripts for configuration, control and debugging

F engine development

• 2008:

– Coarse delays (cable length compensation) – Fringe-stopping & fine delays – Walsh code generation and phase switching – Real sampling (low bandwidth) – Parallel streams (high bandwidth)

• Future:

– Ability to output subset of band – Spectral zoom modes

X Engine Operations

• Using CASPER library
• Scales with 2^N antennas
• Fit as many X engines on an FPGA as

possible (2x 16 ant on BEE2 usr)

10GbE Buffer X Eng Accum

F Engine

Backend Software

• UDP packets received
• Currently received, parsed and saved in

MIRIAD file format by single computer.

• Computing requirements dependant on

experiment;

• Usually single computer ok: 128

antennas, 1 sec integrations, 2k chan = 512MB/s

Pending systems

• Bench sys: 8ant, DP, 200MHz, 2k ch
• PAPER: 128ant, DP, 100MHz, 2k ch
• KAT-7: 8ant, DP, 256MHz, 2k ch
• meerKAT: 80ant, DP, 1GHz, 16k ch
• Bologna: 32ant, SP, 32MHz, 1k ch
• GMRT: 32ant, DP, 400MHz, 4k-8k ch

How does it scale

1 10 100 1000 10000 100000 1000000 F Engines X Engines

FPGA Roadmap

• Processing power doubling every two years
• V4 = ½ power requirements of V2Pro*

* Manufacturers claim - Xilinx Inc.

100 200 300 400 2000 2002 2004 2006 43 100 200 330 Logic Cells Thousands

Xilinx Virtex Family

Coming soon…

• 10Gbps output optionally gives integrations ~10ms
• More efficient use of hardware DSP slices
• High speed, scalable, distributed data capture software
• Walsh codes and phase switching
• Phase rotation
• 64 antenna design
• Upgrade to 4096 channels
• ROACH hardware:

– <400MHz bandwidth – 16 384 channels – 128 antennas – no architectural changes

Questions and Comments

Visit the CASPER correlator page:

http://casper.berkeley.edu/wiki/index.php?title=Correlator

Add your own requirements:

http://casper.berkeley.edu/wiki/index.php?title=International_ Correlator_Collaboration

Email me: jason_manley@hotmail.com

PFB-FFT response

Current uses Pocket Spectrometer

• Using ATMEL ADC’s at 2

Gsamples/sec

• Performing 4 real FFT’s in 1

(complex) biplex pipelined FFT module.

• 2048 channels
• Uses just 1 ADC, 1 IBOB, and your

laptop.

ROACH block diagram
