Our Mission

CSC-Automation has remained an expert in automation systems and electricity for technological processes for more than 20 years. The company provides its customers with professional and competent engineering as well as modern, high-quality and reliable equipment. But life is an evolving process: information technologies are rapidly developing, there are new directions, industries, standards. A human, his\her life, health, and personality are becoming increasingly valuable. The mission of CSC-Automation is to open the door to the world of modern robotic industries, to take care of the environment, to fulfill energy saving tasks. We strongly hope for a better future for our country and work hard to bring it closer. The customer can get here:

• products for automation and electricity;
• complete solutions for automation and electricity.

CSC-Automation representative offices in Ukraine

• Kyiv - main office
• Vinnytsia
• Kharkiv
• Kremenchuk
• Zaporizhia
• Dnipro
• Kryvyi Rih
• Mykolaiv
• Lviv
• Ivano-Frankivsk
• Poltava

History of the Company

• 1996

Foundation of the company in Kyiv, Ukraine. The company started with several people who wanted to create and implement automated control systems and electrical equipment.

• 1998

First strategic contracts with equipment suppliers have been signed: KROHNE (Germany), JUMO (Germany), InterApp (Austria), Flux (Germany), GSR (Germany). Vinnytsia branch of CSC-Automation was founded. Implementation of the first ambitious project: full reconstruction and modernization of the control system of technological line No.1 at the iron-ore pellet production of Poltava Mining and Processing Plant. The PLC + SCADA architecture was a key element of the new system. It was based on distributed networks connecting more than 80 controllers and several redundant

• perator control stations.
• 2000

The globally known equipment manufacturer Mitsubishi Electric (Japan) becomes a partner of CSC-Automation. The company employs 41 people. Several control systems based on Mitsubishi Electric Q-System OPRH-type controllers, similar in their DCS functionality to distributed control systems, were developed by our department

• f design in Kyiv. The project was created for the Severodonetsk Azot Association, in particular, for

the weak acetic acid department, where it was necessary to manage more than 180 PID control circuits in an explosive environment.

• 2001-2010

Kharkiv, Kremenchuk and Kryvyi Rih regional offices were established. 16 new European equipment suppliers became partners of the company. CSC-Automation developed a system for automated control of gas turbine units for the mechanical engineering company PJSC SPC Energia (Kryvyi Rih). After several unsuccessful attempts to use other control platforms, Energia decided on control systems based on Mitsubishi Electric equipment: logic controllers, frequency converters, HMI-panels and digital servo drives.

• 2011

Mykolaiv and Dnepropetrovsk regional offices were established. Tecfluid (Spain) becomes a new equipment supply partner of CSC-Automation. The control system of the compressor station KS-3 of Nizhnevartovsk gas processing plant was one of the most important projects successfully implemented by our company in 2011. The control system is based on the high-end Allen Bradley Control Logix type-1756 redundant controller and the FactoryTalk View SCADA system. The main unit of this system is the control system of a 66-HZ centrifugal 3-stage compressor driven by a 16 MW gas turbine unit NK-16STD. The device compressed the associated petroleum gas with the natural gas liquids extraction.

• 2012

An increase in the number of engineering projects has led to foundation of a subsidiary company Engineering Center CSC-Automation. The new company focused exclusively

• n integrated automation systems projects.

Its main lines of business are:

• survey of industrial facilities, analysis of existing “raw spots” in technology,

recommendations on equipping the facilities with automation systems to improve product quality, reduce losses and improve energy efficiency;

• design, supply, installation and commissioning of automated process control systems

and emergency shutdown systems;

• design study and selection of the best models of field equipment of EC&I and

actuating mechanisms from the best world manufacturers, equipment supply, commissioning and after-sales service.

• 2012-2018

Zaporizhia, Lviv, Ivano-Frankivsk and Poltava regional branches were established. Another 11 European equipment suppliers companies have become partners of CSC- Automation.

• 2019

The company employs 126 people. CSC-Automation is successfully developing.

CSC-Automation Equipment for Industrial Automation and Electrical Equipment

EQUIPMENT FOR CREATING SCADA AND SECURITY SYSTEMS

Touchscreen operator terminal. Fieldbuses. Compact PLCs. Modular PLCs. Pepperl + Fuchs industrial sensors, proximity sensors, photoelectric sensors, ultrasonic sensors, remote input/output systems, encoders and position control system, RFID identification systems, intrinsic safety barriers and signal converters, explosion-proof electrical equipment, explosion-proof mobile devices.

ELECTRIC DRIVE AND PROTECTIVE ACTION RELAY

Mitsubishi Electric (Japan) frequency converters with a capacity from 02 kW to 630 kW. Mitsubishi Electric servomotor is the perfect solution for machine builders from the world leader in automation. MR-JE and MR-J4 families of products cover the whole range of tasks on the modern market. Mitsubishi Electric (Japan) low-voltage switching equipment: circuit breakers, contactors, network analysers and much more. Frequency converters for average voltage (6, 10 kV) produced by TMEIC (Japan).

The SCM system will let you not only prevent accidents, but also move to a new level when carrying out repairs. Examples of equipment at sites where the SCM system is used: electric motors and gearmotors, fans, pumps, gearboxes, compressors, shafts and hardware platform, separators and decanters. Robotics is the most dynamic part of the automation world in the last few years. Mitsubishi Electric industrial robots will improve quality and speed of work in the important areas of production. Smart Grain Dryer Control is a turnkey solution with algorithms for controlling the moisture and temperature of the grain for most known types of grain dryers. All process parameters and alarm messages are stored in the archive. It also provides the ability to remotely transfer and store data. The Pokayoke Sho-Haisen System is a software and hardware complex that manages the manual assembly process through distributed terminals. Here are some benefits of using SCADA system: it collects data from anywhere — SCADA can integrate various solutions; not only energy monitoring, but also OEE;

• ptimization for the needs of the client; scalability; modular design; integration of
• ther monitoring instruments (openness), setting automatic alerts.

TURNKEY SOLUTIONS FOR AUTOMATION AND ELECTRO SOLUTIONS FROM MITSUBISHI ELECTRIC

CONTROL AND MEASURING DEVICES

Weigh cells, load cells and measuring transducers from the French company

• Scaime. Weight measurement from 1 gram to 200 tons.

Measurement of gas, steam, water, corrosive media, abrasive slurries and sludge, petrochemical products. Nominal diameters DN1 — DN2000. The pressure of the measured medium is up to 50 MPa, the temperature of the measured medium is up to +540 C. Resistance thermometers, thermocouples, thermostats, pH and Redox electrodes, conductivity converters, pressure transducers, humidity sensors, single and multichannel regulators, screen recorders, indicators, thyristor power controllers.

EMERGENCY PROTECTION AND WARNING DEVICES

Light and sound detectors designed by the British company E2S (European Safety Systems) for modern safety systems. Idem Safety Switches Ltd is a machine safety solution. Safety relays. No-contact safety switches. Emergency stop safety switch (E Stop). Safety limit switches. Safety light curtains and security sensors. Belt misalignment sensors and cable safety switches. Measurement of water level and water solutions, products of food and pharmaceutical industry, oil and oil products, liquefied gas, pulps and sludges, corrosive liquids in the chemical industry, bulk materials. The distance measurement range (level) is up to 100 m. The pressure of the measured medium is up to 40 MPa. Temperature of the measured environment is up to +400 C.

PIPE FITTINGS AND PUMPS

Seated control valves are designed to control pressure and flow of liquids, steam and

• gases. Different body materials and different types of drives are available.

Electromagnetic valves are designed to quickly shut off the flow of liquids, steam and

• gases. Various materials of body and connections are available.

Centrifugal sanitary pumps are designed to use with clean media. Pharmaceutical, food and chemical production are the main fields of application. Screw and lobe rotary pumps are primarily intended for use with viscous products. Food production is the main area of application. Stainless steel and carbon steel ball valves. Pneumatic, electric and manual

• control. DN 8 — DN 900.

Rotary valves for cutting off and regulating corrosive and aggressive media. DN 32 — DN 900. Knife gate valves for liquids with high solids, pulp, bulk, abrasive and viscous products

• content. DN 50 — DN 1200.

Rotary valves with elastomer seal for liquids, gases and bulk in various industries. DN 25 — DN 1600.

ANALYTICAL EQUIPMENT FOR MEASURING DENSITY, CONCENTRATION, HUMIDITY EQUIPMENT TO WORK WITH BULK MATERIALS AND DUST

Flow meters for bulk products by HENSE and SWR engineering. Microwave and flow scales. Flow detectors, flow meters for bulk solids. Dust detectors and dust amount sensors by SWR engineering. 4B Braime Elevator Components is a global manufacturer of high-quality and technologically advanced electronic components. Control devices, smart sensors and security monitoring systems are designed to prevent costly downtime and minimize the risks associated with working in explosive

• environment. Control systems for norias and conveyors. Bearing temperature

sensors, speed sensors, belt misalignment sensors. MOLLET level detectors for bulk products: rotational, membrane, vibration, pendulum. MOLLET level gauges for bulk products: reflex-radar, belt level gauges. Moisture meters for bulk materials from IMKO, SWR engineering, Harrer & Kassen. Flow and portable moisture meters. Radar, microwave, infrared moisture meters. Dry matter, fat, protein, collagen and other organic components content meter from Harrer & Kassen. Spectral photometers to measure colour.

PNEUMATICS AND PNEUMATIC SYSTEMS

Pneumatic valve islands. Mounting plates. Mechanically driven valves, panel mounted valves, pilot valves.

VIBRATING MOTORS

Electric: single-phase, three-phase, direct current and pneumatic vibration motors from the Italian company OMV.

MOTOR-REDUCER

Cylindrical, worm, conic-cylindrical. Power from 60 W to 75 kW.

Some examples of implemented solutions

Chemical industry, SC Johnson, Kyiv. Automated control system of production of household chemical goods in aerosol packaging.

Results of commissioning:

• Operational control of the main and auxiliary parameters of the automation object;
• Maximum production safety by using a dedicated emergency shutdown subsystem; prompt

generation of reports for dispatchers on various levels;

• Control over unauthorized or erroneous staff actions;
• Improving technological discipline by improving the quality and ergonomics of the operators

work;

• Timely and accurate notification of pre-emergency situations.

Mnemonic scheme. Control system diagram.

Mining and metallurgical industry, Northern Iron Ore dressing Works, Kryvyi Rih Automated control system for gas-air ducts of the indurating machine OK-36 Results of commissioning:

• Reduction of specific consumption of natural gas from 19.0 to 15.5 — 16 ㎥/t by optimizing and

redistributing gas-air flows;

• Increase in production from 235 to 280 t/h by increasing the thickness of the layer and changing

regimes in the drying1/drying2 zones;

• Automatic control of the contours of gas-air ratio in the technological burners;
• Implementation of various supervisory programs, for example, "slow speed", "overclocking",

"emergency stop", etc.;

• Prompt preparation of reports, improve of technological discipline by monitoring staff actions;
• Improve of the quality and ergonomics of operators, timely providing managers with accurate

current and archival data.

Gas industry, Nizhnevartovsk Gas Processing Plant, Nizhnevartovsk Automated process control system of compressor station KS-3 Results of commissioning:

• The automated process control system of the compressor station KS-3 was commissioned

alongside the launch of the gas pumping unit automatic control system 66GTS as part of the first start-up complex;

• Possibility of remote control and monitoring of remote technological objects;
• Possibility of preliminary preparation of associated petroleum gas (filtration, separation, heating)

before its compression;

• Possibility of collecting, storing and automatically transporting condensate;
• The use of heat energy of exhaust gases of the gas pumping unit in the heat supply system at the

plant; redundant control circuit of the pump coolant;

• Organisation of internal self-accounting for the amount of gases discharged into the flare system
• f the plant;
• Preparation of summary data on the operation of compressor station.

Our Advantages

• Over 20 years of experience;
• Full range of high quality equipment;
• Warranty, repair and service centre;
• Most equipment is in stock;
• Case-by-case approach;
• Training and workshops for our clients, technical support;
• We are located near you.

Contact us

Telephone: +38 (044) 494 33 55 E-mail: kck@kck.ua Main office: 4-В, Yevhena Sverstyuka st., Kyiv, Ukraine www.kck.ua
