Open Data Detector - Status & Release
- A. Salzburger (CERN)
Open Data Detector - Status & Release A. Salzburger (CERN) From - - PowerPoint PPT Presentation
Open Data Detector - Status & Release A. Salzburger (CERN) From - - PowerPoint PPT Presentation
Open Data Detector - Status & Release A. Salzburger (CERN) From this workshop only CHEP2018 - announcement Wheres the right working point? real ideal Simulation Reconstruction 4 r[mm] =0 0.5 1 1.5 2.0 Long Strips Short
SLIDE 2
SLIDE 3
CHEP2018 - announcement
SLIDE 4
4
ideal real
Where’s the right working point?
Simulation Reconstruction
SLIDE 5
η=0 1 0.5 1.5 2.0 2.5 3.0
z [mm] r[mm]
Pixels Long Strips Short Strips 5
SLIDE 6
6
Full tracker view
SLIDE 7
Layer 0 Layer 1 Layer 2 Layer 3 ~1000 mm 7
Pixel barrel system
SLIDE 8
Silicon sensor Module board Carbon foam Cooling pipe Connector Cable bundle
x y
tilt angle Support cylinder Stave 8
Innermost layer definition
SLIDE 9
Negative Endcap Positive Endcap Positive Endplate Negative Endplate Cable and cooling pipe routing 9
Full pixel system
SLIDE 10
Inner ring Outer ring Support disk with cooling rings Overlapping modules 10
Pixel end cap example
SLIDE 11
11
Pixel support tube
SLIDE 12
12
Short strip system
SLIDE 13
13
Long strip system
SLIDE 14
axial side: stereo side: stereo angle module gap 14
Stereo angle in outermost strip system
SLIDE 15
2 Long strip rings 3 short strip rings 15
SLIDE 16
4 − 3 − 2 − 1 − 1 2 3 4 η 0.2 0.4 0.6 0.8 1 1.2 1.4 X/X 4 − 3 − 2 − 1 − 1 2 3 4 η 0.2 0.4 0.6 0.8 1 1.2 X/X Material Composition Beam pipe Module board Support structure Connectors Active sensors Cooling pipes Cables 4 − 3 − 2 − 1 − 1 2 3 4 η 0.5 1 1.5 2 2.5 3 3.5 X/X 4 − 3 − 2 − 1 − 1 2 3 4 η 0.2 0.4 0.6 0.8 1 1.2 1.4 X/X
Current material model
SLIDE 17
17
