Characterization of a Clamp Band Fastening System MID/BCS Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015 Content Description & Applications of a Clamp Band Load Cases Classical Dimensioning Procedure

slide-1
SLIDE 1

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

Characterization

  • f a

Clamp Band Fastening System

slide-2
SLIDE 2

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

Content

2

Classical Dimensioning Procedure FE-Models (2D & 3D) Conclusions for Design + Dimensioning Description & Applications of a Clamp Band Load Cases Sensitivity Analyses

slide-3
SLIDE 3

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

What is a Clamp Band (CB)?

CB = commonly used fastening mechanism between: spacecraft (S/C) and launch vehicle (LV)

3

Ariane 5 with James Webb Space Telescope (pict. ESA) CB Solar Orbiter

slide-4
SLIDE 4

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

What is a Clamp Band (CB)?

4

S/C Ring Adapter Ring Clamp Band

Tightening Bolt Band Saddles

slide-5
SLIDE 5

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

CB Applications

Mechanical Ground Support Equipment

5

Flight Equipment

Fixation Separation Fixation

Galileo (OHB)

slide-6
SLIDE 6

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

Aim of the study

6

Spacecraft + Load Cases

Classical Dimensioning Procedure Mathematical Formula Clamp Band Preload Clamp Band Design Limitations FE-Analysis Characterization Clamp Band Preload Updated Dimensioning Procedure

slide-7
SLIDE 7

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

Working Principle

7

Section View

S/C Ring LV Adapter Ring Saddles

Top View

F N MTG ! GAP !

slide-8
SLIDE 8

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

Content

8

Classical Dimensioning Procedure FE-Models (2D & 3D) Conclusions for Design + Dimensioning Description & Applications of a Clamp Band Load Cases Sensitivity Analyses

slide-9
SLIDE 9

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

Loading Configurations

Horizontal

9

Vertical

Fixation System:

  • Transport + Handling
  • Thermal Tests
  • Vibrations Tests

CB CB CB

Hoisting

slide-10
SLIDE 10

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

Load Cases in CB joint

10

Clamp Band S/C COG S/C ring Payload adapter ring m h

slide-11
SLIDE 11

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

Content

11

Classical Dimensioning Procedure FE-Models (2D & 3D) Conclusions for Design + Dimensioning Description & Applications of a Clamp Band Load Cases Sensitivity Analyses

slide-12
SLIDE 12

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

ECSS - Dimensioning Procedure

12

Flux from axial force [N/m] Flux from bending moment [N/m]

+ =

Maximal axial Flux:

Conservative !?

Critical load cases Equivalent line force Criterion: No Gaping Band Preload Stress Analysis

slide-13
SLIDE 13

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

ECSS - Dimensioning Procedure

13

T T r z Critical load cases Equivalent line force Criterion: No Gaping Band Preload

slide-14
SLIDE 14

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

ECSS - Dimensioning Procedure

14

Limitations

1- Shear loading 2- Stiffness of the assembled parts 3- Friction between S/C rings 4- Friction between band and saddles FE-MODEL T T

slide-15
SLIDE 15

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

Content

15

Classical Dimensioning Procedure FE-Models (2D & 3D) Conclusions for Design + Dimensioning Description & Applications of a Clamp Band Load Cases Sensitivity Analyses

slide-16
SLIDE 16

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

FE-Models

16

2D Axisymmetric 3D – 180°

+ Solution Time + Implementation + Visualization + Shear + Bending

  • Model size
  • Complexity
  • Simplified geometry
  • Only axial loading

50000 nodes 38000 elements 25-33 contact surfaces

19020 nodes 6120 elements 4 contact surfaces

slide-17
SLIDE 17

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

2D FE – Axial Loading

17

FE Model

Contacts: Band – Clamp Clamp – Rings Between Rings Fixed Ux=0 Negligible tangential stiffness: E-module 0 UY-Coupled

slide-18
SLIDE 18

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

2D FE – Axial Loading

18

FE Post-processing

Averaged Band Hoop Stress Clamp Extension Gaping Edge Distance

slide-19
SLIDE 19

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

2D FE – Axial Loading

19

Kinematics

Comparison T S G U

Sticking Sliding

slide-20
SLIDE 20

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

3D FE – Shear Loading

20

FE Model: 180°

Rigid Beams 180° 0° 2 [m] Remote Point =COG Fixed Thermal Preload

Sentinel 1A (ESA) Planck (ESA)

UY coupled

slide-21
SLIDE 21

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

2D-3D FEM-Correlation (Axial loading)

21

slide-22
SLIDE 22

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

3D FE – Shear Loading

22

FE Post-processing

Gaping angle UY Y X

Gap side 180° Compression side 0°

slide-23
SLIDE 23

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

3D FE – Shear Loading

23

S G

Sticking Sliding

180° 0°

Kinematics

slide-24
SLIDE 24

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

3D FE – Shear Loading

24

Comparison: Pure Bending – Shear Loading

Bending only:

slide-25
SLIDE 25

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

Content

25

Classical Dimensioning Procedure FE-Models (2D & 3D) Conclusions for Design + Dimensioning Description & Applications of a Clamp Band Load Cases Sensitivity Analyses

slide-26
SLIDE 26

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

Clamp Band - Parameters

26

Sensitivity Analyses

Controllable

Parameters

Modifiable – Limited Influence Fixed Band Preload Band Stiffness Clamp Stiffness Friction Coeff. Clamp/Rings Ring Stiffness Friction Coeff. S/C Rings Wedge Angle GAPING

slide-27
SLIDE 27

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

Sensitivity Analysis: Clamps Friction

28

Axial Loading Shear Loading High Friction improves the gaping capability

slide-28
SLIDE 28

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

Sensitivity Analysis: Clamps Friction

29

Wedging effect

Limit of disassembly: r z =0 =0

slide-29
SLIDE 29

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

SA: Shear Loading

30

Band Stiffness Clamp Stiffness Ring Stiffness Friction Clamp Preload [kN] Friction S/C Rings

[GPa]

Shear Load Capability [kN]

[GPa] [GPa]

Wedge Angle Friction Tests Preloading Graph

slide-30
SLIDE 30

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

Content

31

Classical Dimensioning Procedure FE-Models (2D & 3D) Conclusions for Design + Dimensioning Description & Applications of a Clamp Band Load Cases Sensitivity Analyses

slide-31
SLIDE 31

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

Preloading Graph for Axial Loading

32

2SWL =1040 KN 39 KN

Example: MTG SHTCB

slide-32
SLIDE 32

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

Conclusion for CB Design

33

Friction High between clamps and rings, but… High between S/C rings Low between band and clamps Stiffness Design the parts as stiff as possible, but:

  • Clamp stiffness is the important one
  • Band stiffness plays a minor role

Preload Tighten the band with high preloading force Wedge Angle Small to improve gaping, but… Model uncertainty which cannot be modelled with FEM!

slide-33
SLIDE 33

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

Benefits of ANSYS

35

 Non-linear FE analysis (ANSYS Mechanical)

  • Mesh size, element formulation
  • Material parameters
  • Contact Formulation
  • Contact detection method
  • Contact normal stiffness
  • Contact sphere radius

 Easy access to the main parameters, such as:  Convergence and Sensitivity Analyses

(ANSYS Remote Solver Manager) Reality representative FE Model

slide-34
SLIDE 34

MID/BCS – Characterization of a Clamp Band Fastening System, Forum CADFEM 08/09/2015

END

36

Questions?

Alphabus, credit ESA
