OCPP Smart Charging 12 September 2019 1 Agenda Introduction to OCPP: What is OCPP Why OCPP OCA organisation OCPP Basics OCPP 1.5/1.6/2.0 OCPP security OCPP Smart Charging Supported use cases Different

slide-1
SLIDE 1

OCPP Smart Charging

12 September 2019

1

slide-2
SLIDE 2

Agenda

Introduction to OCPP:

  • What is OCPP
  • Why OCPP
  • OCA organisation
  • OCPP Basics
  • OCPP 1.5/1.6/2.0
  • OCPP security

OCPP Smart Charging

  • Supported use cases
  • Different profiles
  • Difference OCPP 1.6/2.0
  • V2G

2

slide-3
SLIDE 3

Robert de Leeuw Software Architect @ ihomer 6 years experience EV Charging 5 years chair OCA TWG robert.de.leeuw@ihomer.nl

3

slide-4
SLIDE 4

Open Source Protocol for managing Charge Points What is OCPP

4

Charge Point Central System EV OCPP

slide-5
SLIDE 5

Why OCPP

5

  • Open/free protocol
  • Prevents vendor lock-in
  • Reduce integration time/issues
  • The de-facto standard for Charge Point to CPO communication

20.000+ downloads of OCPP 1.6 alone

  • Based on experience and knowledge of the OCA participants
slide-6
SLIDE 6

History

6

  • Start in 2009 by E-Laad (now ElaadNL)
  • The aim was to create an open communication standard that

would allow the Dutch Charging Stations (CS) and Charing Station Management Systems (CSMS) from different vendors to easily communicate with each other.

  • Versions:

○ OCPP 1.2 (2011) ○ OCPP 1.5 (2012) ○ OCPP 1.6 (2015) ○ OCPP 2.0 (2018)

slide-7
SLIDE 7

OCA

7

  • OCA = Open Charge Alliance
  • Free to use protocols:

no constraints on the use of the standards

  • 120+ Participants
  • OCPP and OSCP
slide-8
SLIDE 8

OCA: Participants (2018)

8

slide-9
SLIDE 9

OCA organization

9

slide-10
SLIDE 10

OCA TWG

10

  • Technology Working Group
  • Responsible for development and maintenance of the OCPP

and OSCP specification

  • Whitepapers and application notes
  • Bi-weekly calls
slide-11
SLIDE 11

OCA CWG

11

  • Compliance Working Group
  • Responsible for development and maintenance of test cases,

compliance toolkits and certification programs.

  • Monthly calls
  • Plugfests

○ Goal: twice a year ○ Safe testing environment

slide-12
SLIDE 12

OCTT

12

  • Validation of OCPP 1.6 implementations
  • Test automation/continuous integration
  • Conformance testing
  • Will also be used in the future certification program
slide-13
SLIDE 13

OCA Membership

13

Want to known more? info@openchargealliance.org

slide-14
SLIDE 14

OCPP Design principles

14

  • Designed for wireless, unreliable, connections
  • Guarantee delivery of information needed for billing purposes
  • Only the Charge Point knows it current true state
  • Essential to known what has happened and why
slide-15
SLIDE 15

OCPP Basic functionality

15

  • Authorization (Cache)
  • Transactions Start/Stop & Metervalues
  • Charge Point configuration
  • Status information
  • Remote Commands: Start/Stop/Unlock
  • OTA Firmware updates
slide-16
SLIDE 16

OCPP: 1.5 2012 New:

  • Local Authorization List
  • Reservation
  • Get Configuration
  • DataTransfer (Custom messages)

SOAP Only

16

slide-17
SLIDE 17

OCPP 1.6 2015 New:

  • Smart Charging
  • JSON over WebSockets
  • Trigger Message
  • Lot of minor improvements (extra statuses)

2017: 1.6 edition 2 (contains a lot of errata) 2019: 1.6 edition 3, planned for later this year.

17

slide-18
SLIDE 18

OCPP 2.0 2018 New:

  • Improved security
  • ISO 15118 support
  • Improved charge point management (monitoring)
  • Improved transaction handling
  • Extended Smart Charging

2019: 2.0.1 (or 2.1) planned for later this year.

18

slide-19
SLIDE 19

OCPP 2.0: Documents Part 0: Introduction Part 1: Architecture & Topology Part 2: Specification Part 2: Appendices Part 3: Schemas Part 4: JSON over WebSockets implementation guide Part 5: Certification Profiles (not yet released) Part 6: Test Cases (not yet released)

19

slide-20
SLIDE 20

OCPP 2.0: Functional Blocks A. Security B. Provisioning C. Authorization D. Local Authorization List Mgmt. E. Transactions F. Remote Control G. Availability H. Reservation

20

  • I. Tariff and Cost
  • J. Metering
  • K. Smart Charging
  • L. Firmware Management
  • M. ISO 15118 Certificate Mgmt.
  • N. Diagnostics
  • O. Display Message
  • P. Data Transfer
slide-21
SLIDE 21

OCPP 2.0: Functional Blocks Use Cases: Name Description Pre/Post conditions Detail sequence diagram Number requirement

21

slide-22
SLIDE 22

OCPP 2.0: In numbers

22

OCPP 1.6 OCPP 2.0 Messages: 28 67 Pages: 143 476

slide-23
SLIDE 23

OCPP Security Added in 2.0 Input and review by ENCS* & Radboud University Secure connection profiles 1. Unsecured Transport with Basic Authentication 2. TLS with Basic Authentication 3. TLS with Client Side Certificates OCPP 1.6 Security whitepaper (JSON only)

23

*European Network for Cyber Security

slide-24
SLIDE 24

OCPP Security Functionality

  • Certificate Management
  • Security Events/Log
  • Secure Firmware Update

24

slide-25
SLIDE 25

Agenda

Introduction to OCPP:

  • What is OCPP
  • Why OCPP
  • OCA organisation
  • OCPP Basics
  • OCPP 1.5/1.6/2.0
  • OCPP security

OCPP Smart Charging

  • Supported use cases
  • Different profiles
  • Difference OCPP 1.6/2.0
  • V2G

25

slide-26
SLIDE 26

OCPP Smart Charging Supported Use Cases:

  • Internal Load Balancing
  • Central Smart Charging
  • Local Smart Charging
  • External Smart Charging Control Signals (OCPP 2.0)

OCPP 2.0 also supported 15118 Smart Charging All can be combined

26

slide-27
SLIDE 27

OCPP Smart Charging: Internal Load Balancing

27

slide-28
SLIDE 28

OCPP Smart Charging: Central Smart Charging

28

slide-29
SLIDE 29

OCPP Smart Charging: Local Smart Charging

29

slide-30
SLIDE 30

OCPP Smart Charging: External Smart Charging Control Signals (OCPP 2.0)

30

slide-31
SLIDE 31

OCPP Smart Charging: Profiles

31

  • ChargePointMaxProfile

○

Limit the power or current taken from the grid (shared by all EVSEs of the Charging Station.)

  • TxDefaultProfile

○ Pre-installed profile, to be used for all transactions, started or not started. ○ Also works when offline

  • TxProfile

○ Charging Profile set on one specific transaction ○ Overrules TxDefaultProfiles

  • ChargingStationExternalConstraints

○ Used to report limit set by an external system (not the CSMS)

slide-32
SLIDE 32

OCPP Smart Charging: Profile Content

32

slide-33
SLIDE 33

OCPP Smart Charging: Stacking

33

  • Multiple profiles with same purpose (TxProfile, TxDefaultProfile

etc.) can be installed with different StackLevels.

  • Highest StackLevel prevails over lower.
  • Uses:

○ Complex calendars: daily 17:00 - 21:00 and on friday: 18:00 - 22:00. ○ Multi system providing inputs: DSO profiles higher stack level then eMSP profiles.

slide-34
SLIDE 34

OCPP Smart Charging: Messages

34

  • since OCPP 1.6:

○

SetChargingProfile ○ ClearChargingProfile ○ GetCompositeSchedule ○ RemoteStart with TxProfile

  • since OCPP 2.0

○ GetChargingProfile ○ NotifyChargingLimitRequest ○ ClearedChargingLimit ○ NotifyEVChargingNeedsRequest (ISO 15118) ○ NotifyCentralChargingNeedsRequest (ISO 15118)

slide-35
SLIDE 35

OCPP Smart Charging: V2G

35

  • Charging Profiles can be negative
  • Extra parameters could be configured via

○ Configuration Keys (1.6) ○ Device Management (2.0)

  • OCA V2X workgroup

○ Input for future version of OCPP.

slide-36
SLIDE 36

Questions? robert.de.leeuw@ihomer.nl

36
