Objectives To evaluate the functionality of Rope pump To determine the water quality of water pumped up by Rope pumps especially regarding fecal contamination To get an impression of the social and economic impact of Rope pumps both
To evaluate the functionality of Rope pump To determine the water quality of water pumped up by Rope
pumps especially regarding fecal contamination
To get an impression of the social and economic impact of Rope
pumps both for Communal supply as well as Self supply
To get information on bottle necks and interest by government
and NGOs to use this technology in their water programs
Study areas Karonga Mzuzu Rumphi Mzimba Nkhatabay Kasungu
Purposive sampling was used
DISTRICT NUMBER OF PUMPS VISITED Karonga 4 Kasungu 22 Mzimba 18 Mzuzu 36 Nkhatabay 22 Rumphi 25
Total 127
45 out of 52 working 48 out of 75 working
87% 13%
working not working
64% 36%
working not working
Main reasons not functional
5 10 15 20 25
Rope broken handle broken dry well missing pipes Others
21 1 5 3 4
E.Coli Count
No E.Coli E.Coli
Borehole position vs average distance from contamination source
E.COLI COLONIE S IN SAMPLE (Per 1ml ) AVERAGE DISTANCE FROM POTENTIAL CONTAMINATION SOURCES (m)
Pit Latrine Animal shelter Animal watering point
76 116 154 106 20 52 68 62 56 120 22 20 7 52 140 20 30 30 30 TNTC 20 20 20 100
close to stinky pool close to pit latrine
As the average borehole depth reduces the Coliform count
increases per water sample
E.Coli count (colonies /1ml sample) Average borehole depth(m) 15 >50 10 TNTC 5
Uncovered slab and concrete part. Potential risk of contamination
Children playing around & with the pump
Throw dirt, plastic, Touch the rope
Animals hanging around the surrounding
Animal dung
94% respondents like the technology
42 - easy to maintain 270 – clean water 13 – irrigation 221 – easy to operate 62 – save money 51 - others
50 100 150 200 250 300 Cheap Easy to maintain Produces clean water Used for irrigation easy to
saves money Others Reeks1 Reeks2
Willingness to repair the Rope pump
Communal water points
Despite majority satisfied with the technology, only 11% of respondents
had already started repairing
44% of respondents were doing nothing about repairing the Rope
pump. Private water points
Respondents willing to repair despite having alternative sources
(piped water into dwelling)
2 respondents (28%) willing to repair but couldn’t get in touch with
technician
Socio-economic benefits
1.
Increase access to improved water & sanitation Moving from unprotected wells to protected water source
Used for irrigation Domestic animals
Installation costs lower as compared to other technologies Affordable maintenance costs Affordable spare parts Save money from excessive water bills
easy to maintain
Easy to operate
women fixing the pump
Children operate without hustle
Simple to maintain
Reliable source of water
Water every time all year. No disconnections & 87% of respondents access water at every time of the year as long as the
Rope pump is functional
NGO’s
investment cost is low. Local communities can afford
Greater proportion of rural population still use unprotected sources. Rope pumps can help cover gaps
categorized Rope pumps with shallow well (which the government can
not accept)
Govt policies doesn’t accept Rope pumps (shallow wells). Unless substantiated with water quality results, govt feels the technology
is prone to contamination.
Unable to serve larger communities The technology looks like a temporally solution No plans to promote but support organizations to supply in very needy
areas where
A need to Train users on O&M A self-supply approach regular or periodical monitoring of water points Involvement of government in rope pump technology as key player Dissemination of info in key conference in conjunction with other WASH
players
Need for improvement ( design & method of drilling) to address water
quality concerns
End of presentation Thank you
