NWMP Target Compilation

slide-2
SLIDE 2
  • Provide awareness of previously developed targets
  • What was their basis?
  • More broadly applicable?
  • Consider limits to applicability
  • What else could be done
  • Potential to rank or consider your own areas
  • To what extent do they agree or disagree?
  • Target Types
  • Empirical
  • Conceptual
  • Prospectivity

Aims

slide-3
SLIDE 3

CRICOS code 00025B Presentation Title | Date 3

Geochemical Anomalies

slide-4
SLIDE 4

CRICOS code 00025B Presentation Title | Date 4

Geophysical Anomalies

>10ppm U from Radiometrics 99.5th percentile bouguer gravity high Magnetics RTP greater than 2000nT

Lots more could be done with this!!

slide-5
SLIDE 5

Mineral Occurrence density

  • From GSQ Mineral Occurrence database
  • Classified according to the terms in that

database

  • 1km grid over entire inlier
  • Counting number of deposits within a 5km

radius of each point

Mineral Occurrence Densities

CRICOS code 00025B Presentation Title | Date 5

slide-6
SLIDE 6

Pmd*CRC Conceptual – Lawn Hill

CRICOS code 00025B Presentation Title | Date 6

slide-7
SLIDE 7

Pmd*CRC Conceptual – Lawn Hill

CRICOS code 00025B Presentation Title | Date 7

Inter Interp F Faul ault t Archi hitec ectur ure

Sei Seismic da data Potential al field d data Cr Cross ss sect ctions

3D 3D Map ap

2D/3 D/3D geophys modellin lling WORMS MS

Proj

  • jec

ect Gener neration

  • n

Modelling g Major

  • r

Lithostrat at & Intrusive boundaries es and Faults Solid G Geol Mineral Depos

  • sits

Commo modity Groups Size Ranking Spatia ial A l Analy lysis is Len Length Tren end Hi Histo story Nume merica cal Modellin lling

slide-8
SLIDE 8

Pmd*CRC Conceptual – Lawn Hill

CRICOS code 00025B Presentation Title | Date 8

Intersections Red or Blue Min > 50km Max > 80km Blue – NW trends Red – ENE trends Century

slide-9
SLIDE 9

Century region – supervised/unsupervised

CRICOS code 00025B Presentation Title | Date 9

slide-10
SLIDE 10

Knowledge-driven model

CRICOS code 00025B Presentation Title | Date 10

SEDEX VEIN-STYLE

slide-11
SLIDE 11

Data-driven model

CRICOS code 00025B Presentation Title | Date 11

SEDEX VS DIFFERENCE 11 layers – not clearly specified

slide-12
SLIDE 12
  • 1. Deposits Hosted Within the Upper Staveley/Lower Kuridala Stratigraphy.
  • Rheological contrast between Calc-silicates, Roxmere Quartzite, and Kuridala schists seen as a focus for

deformation and exploited during mineralization in late D3.

  • ‘Other’ rigid bodies at this stratigraphic position, e.g. SWAN Diorite, offer further rheological contrast and

focusses brecciation/secondary permeability and potential to host mineralization if within a fluid cell.

  • Redox potential of Staveley in contact with overlying reduced rocks (Figure 5.2) inferred as an important

ingredient.

  • Presence of ironstones yields discrete targets within this broader stratigraphic package.
  • E.g. Osborne-Kulthor, Mt Elliott-SWAN, and Merlin-Mt Dore deposits.
  • 2. Structural juxtaposition of Staveley with Other (Reduced) Packages.
  • Likely to be evidently structurally-controlled/hosted
  • Greater potential expected where Staveley is in structural contact with reduced packages such as Answer

Slate/ Toole Creek Formation.

  • Focussing relationship of early structural features, likely reactivated basement structures.
  • E.g. Starra line of deposits.
  • 3. Deposits hosted in Overlying Sequences, but Related to

Staveley:Granite:Fault Association at Depth.

  • Highly variable deposit-style possible.
  • Deposits may be structurally-focussed or within broader breccia bodies.
  • Intrusion of granite into the Staveley calcareous sequence inferred as driver for brecciation (CO2 release).
  • E.g. EH, Eloise

DMQ Targets – 3 styles

slide-13
SLIDE 13

Swan-style

slide-14
SLIDE 14

Starra-style

slide-15
SLIDE 15

Osborne/Kulthor - style

slide-16
SLIDE 16

NWQMP Targets

slide-17
SLIDE 17

NWQMP

CRICOS code 00025B Presentation Title | Date 17

slide-18
SLIDE 18

NWQMP

CRICOS code 00025B Presentation Title | Date 18

slide-19
SLIDE 19

NWQMP

CRICOS code 00025B Presentation Title | Date 19

slide-20
SLIDE 20

NWQMP

CRICOS code 00025B Presentation Title | Date 20

slide-21
SLIDE 21

NWQMP

CRICOS code 00025B Presentation Title | Date 21

slide-22
SLIDE 22

GSQ Quamby Project

CRICOS code 00025B Presentation Title | Date 22

slide-23
SLIDE 23

GSQ Quamby Project

CRICOS code 00025B Presentation Title | Date 23

slide-24
SLIDE 24

GSQ Quamby Project

CRICOS code 00025B Presentation Title | Date 24

Full Model Subset Model

slide-25
SLIDE 25

Mira Geoscience Mt Dore

CRICOS code 00025B Presentation Title | Date 25

slide-26
SLIDE 26

Mira Geoscience Mt Dore

CRICOS code 00025B Presentation Title | Date 26

slide-27
SLIDE 27

Pmd*CRC i2 Prospectivity

CRICOS code 00025B Presentation Title | Date 27

slide-28
SLIDE 28

Pmd*CRC i2 Prospectivity – 12 layer

CRICOS code 00025B Presentation Title | Date 28

slide-29
SLIDE 29

Pmd*CRC i2 Prospectivity – 9 layer

CRICOS code 00025B Presentation Title | Date 29

X X X

slide-30
SLIDE 30

GMEX Geomechanical models

CRICOS code 00025B Presentation Title | Date 30

slide-31
SLIDE 31

GMEX Geomechanical models

CRICOS code 00025B Presentation Title | Date 31

slide-32
SLIDE 32

GMEX Geomechanical models

CRICOS code 00025B Presentation Title | Date 32

slide-33
SLIDE 33

Available target layers

  • Empirical

 Geochem/Geophys/Occurrence anomalies

  • Conceptual

 NWQMP, DMQ Conceptual

  • Prospectivity/modelling

 Pmd*CRC, Quamby, Mt Dore, Geomechanical Find 3 prospect-scale areas that have some support from each of the above categories Why did you pick them and what would you do next?

Eastern Succession exercise

CRICOS code 00025B Presentation Title | Date 33

slide-34
SLIDE 34

G14 Lawn Hill model

CRICOS code 00025B Presentation Title | Date 34

slide-35
SLIDE 35

G14 surfaces modelled

CRICOS code 00025B Presentation Title | Date 35

https://nwmp-data.s3-ap-southeast-2.amazonaws.com/NWMP+Timeslices.zip https://nwmp-data.s3-ap-southeast-2.amazonaws.com/NWMP_Timeslices_MI.zip

slide-36
SLIDE 36

Pick three areas which meet the following criteria

  • Isa/Century host rocks with 1000m of surface
  • One other characteristic which provides support, eg

 Previously targeted  Structural Justification  Stratigraphic justification (eg thickness change)  Empirical support Why did you pick them and what would you do next?

Lawn Hill area exercise

CRICOS code 00025B Presentation Title | Date 36

slide-37
