Vi VioStor oStor NVR VR + Tu + Turbo bo NAS AS Surveillance Storage Expansion NVR NAS Agenda Intro trodu ductio ction Background Challenges Solution Features Advantages Benefits Limitations Stora orage ge Expan pansio ion

slide-1
SLIDE 1

Vi VioStor

  • Stor NVR

VR + Tu + Turbo bo NAS AS

Surveillance Storage Expansion

NVR NAS

slide-2
SLIDE 2

Agenda

Intro trodu ductio ction

Background Challenges

Solution

Features Advantages Benefits Limitations

slide-3
SLIDE 3

Stora

  • rage

ge Expan pansio ion

Background

IP surveillance trends

 Latest technologies, including 4K, 60/120 fps gradually entering the market  Higher resolution, quality, and frames per second needs higher BIT RA RATES thus much more storage is required

slide-4
SLIDE 4

Agenda

Intro trodu ductio ction

Background Challenges

Solution

Features Advantages Benefits Limitations

slide-5
SLIDE 5

Stora

  • rage

ge Expan pansio ion

Challenges

An example from a bank:

 A retention period of at least 6 months is demanded by the Financial Supervisory Commission  16 TB is required for one standard Full HD IP camera  How much storage will be necessary for a 10, 20, or even 100 similar cameras?

160TB

slide-6
SLIDE 6

Stora

  • rage

ge Expan pansio ion

Considerations

Storage selection

Software NVR? Windows-based RAID? Unreliable and complicated. Pure NVR with third-party storage? Compatibility. Troubleshooting. Performance. DAS? SAN? NAS? Scalability. Expensive. Accountability.

And need a Market t Va Validate ated storage brand?

slide-7
SLIDE 7

Agenda

Introduction

Background Challenges

So Solutio tions ns

Features Advantages Benefits Limitations

slide-8
SLIDE 8

So how about QNAP VioStor NVR + Turbo NAS?

Stora

  • rage

ge Expan pansio ion

slide-9
SLIDE 9

Stora

  • rage

ge Expan pansio ion

World-class Storage:

 Top 8 storage brand*  Top 3 SMB NAS brand (below MSRP $24,999)*  Linux-embedded NAS with multiple RAID support  Global support infrastructure and free software updates  Countless awards for performance and reliability  3 million worldwide sales

Note: Ranked by Gartner report 2012

QNAP Turbo NAS

slide-10
SLIDE 10

How Surveillance Storage Expansion (SSE) Works?

IP camera Video Server Analog camera

VioStor NVR Turbo NAS Storage Expansion

IP camera Video Server Analog camera

SSE QPKG Stora

  • rage

ge Expan pansio ion

slide-11
SLIDE 11

Case Study: Banking

 Locatio tion: n: Leading Georgian commercial bank  Soluti tion:

  • n: 4-bay tower NVR

(VS-4116 Pro+)& 6-bay tower NAS (TS-669 Pro)  Quantity ntity: 37 branches  Feature ture:

  • 1. Full-HD video recording
  • 2. Flexibly enlarged storage
  • 3. 180-day video retention

Stora

  • rage

ge Expan pansio ion

slide-12
SLIDE 12

Stora

  • rage

ge Expan pansio ion

Architecture

slide-13
SLIDE 13

Agenda

Introduction

Background Challenges

So Solutio tions ns

Features Advantages Benefits Limitations

slide-14
SLIDE 14

Balanced Workload: Reduce NVR CPU load

 Typical problem: Integrating third-party storage often

  • verloads the NVR as it both records and “pushes”

files to storage  QNAP does it smarter, the Turbo NAS “pulls” files from the NVR (with the SSE app on the Turbo NAS)

Stora

  • rage

ge Expan pansio ion

Recording rding+Archi +Archivin ving= g= Overload rload

PUSH PUSH

Receiver iver (Idle)

PUL ULL

Recording rding Archivin ving

Advantages

slide-15
SLIDE 15

Stora

  • rage

ge Expan pansio ion

Cost-effective

 Surveillance Storage Expansion is your best choice and solution if you think…

 iSCSI SAN is too expensive and unnecessary  You don’t want some lousy storage solution to ruin your business  But you still need a well-known storage vendor providing reliable storage, powerful backup, and trusty service

Advantages

slide-16
SLIDE 16

Agenda

Introduction

Background Challenges

So Solutio tions ns

Features Advantages Benefits Limitations

slide-17
SLIDE 17

Customize storage

 Grow capacity to meet the need for higher resolution (bit rate) videos or longer retention periods  Flexible system structure  Leverage QNAP storage power

 Product (wide range NAS/JBOD solution)  Latest technology (10GbE, SAS 6G..etc)  Performance benchmarking & testing  RAID fundamentals and innovative storage applications (SSD Cache, hot spare drive, etc…)

Stora

  • rage

ge Expan pansio ion

Benefits

slide-18
SLIDE 18

Reducing Investment

 Buy only to meet your current needs and expand the system later to meet future requirements  Free software updates & performance enhancements  Less maintenance costs and rich support resources  QNAP holds all accountable for backend storage (NAS + NVR)

Stora

  • rage

ge Expan pansio ion

Benefits

slide-19
SLIDE 19

Highly Scalable

 Scalable design supports more than 912 TB raw capacity for one NVR  Not only scalable capacity, but scalable design and architecture (e.g. online RAID migration/expansion)

Stora

  • rage

ge Expan pansio ion

Benefits

slide-20
SLIDE 20

Agenda

Introduction

Background Challenges

So Solutio tions ns

Features Advantages Benefits Limitations

slide-21
SLIDE 21

Stora

  • rage

ge Expan pansio ion Expanded to 912TB Turbo rbo NAS (Max. 144TB) VioSt Stor

  • r NVR

(Max. 64ch)

Notes: Design and specifications are subject to change without notice

How to Connect

REXP (Max. 768TB)

slide-22
SLIDE 22

Stora

  • rage

ge Expan pansio ion

Reserve Throughput

  • Suggested recording network

throughput limit: 90 Mbps

VS VS-2000/4000/ 2000/4000/6000 6000 Pro series es

  • Suggested recording network

throughput limit: 160 Mbps

VS VS-2100/4100/ 2100/4100/6100 6100 Pro+

  • + series

es

  • Suggested recording network

throughput limit: 360 Mbps

VS VS-8100U/ 8100U/12100U 12100U- RP Pro(+) +) series es

 To ensure the NVR CPU works well with the recording and storage expansion, we strongly suggest reserving the recording network throughput.

slide-23
SLIDE 23

Maximum Connected NAS

  • Only 1 NAS is recommended for

storage expansion.

VS VS-2000/ 000/ 4000/ / 6000/ 4000U 4000U-RP RP Pro series es

  • Up to 2 NAS is recommended for

storage expansion.

VS VS-2100/ 100/ 4100/ / 6100/ 4100U 4100U-RP RP Pro+ series es

  • Up to 3 NAS is recommended for

storage expansion.

VS VS-8100U 100U/ / 12100U 0U-RP RP Pro(+) +) series es

 To ensure the NVR CPU works well with the recording and storage expansion, please follow the suggested limit

  • f connected NAS.
slide-24
SLIDE 24

Stora

  • rage

ge Expan pansio ion

Important Reminders

 Applicable Models:

 VioStor NVR Pro(+) series: Firmware v5.0.3 or above  QNAP NAS TVS-x63, x71 series and TS-x51, x53, x69, x79, x70, x80 series: Firmware v4.1.2

 NAS must be solely used for surveillance storage expansion.  All NVR and NAS must adopt static IP address.  A Gigabit switch is required for this application.

slide-25
SLIDE 25

QN QNAP AP Sec Securi urity ty

Ma Maxi ximi mize ze yo your ur sy syst stem em sc scal alabi abilit lity

www.qnapsecurity.com

Stora

  • rage

ge Expan pansio ion
