NTC-40WV-03

Indoor Industrial Router

December 2012

NTC-40WV-03

Power Input 8 ~ 28 V DC (DC-in Port) Housing Metal Housing with wall mount option CPU ARM9-based 400MHz Processor SIM card reader lockable tray Reader, Push-Button-to-Release, Mini USIM/SIM Format Antenna 2x SMA Cellular (MIMO) 2x Reverse-SMA WLAN (MIMO) Dimension 155mm (L) x 104mm (W) x 30mm (D) Operating temperature -25 ~ 70oC Connectivity 1x RJ-11 voice port Connectivity 1x RJ-45 Ethernet port

SPECIFICATIONS

TECHNICAL SPECIFICATIONS

• Maximum Data Speed
• Downlink: 21Mbps
• Uplink: 5.76Mbps
• UMTS/HSDPA/ HSUPA
• Quad-Band 850/900/2100/1900 MHz
• GSM/ EDGE/ GPRS
• Quad-Band 850/900/1800/1900 MHz
• Telephony
• Circuit-switched voice
• WiFi Network:
• 2.4GHz WiFi network
• Connects up to 16 WiFi devices
• Dimensions
• 155mm (L) x 104mm (W) x 30mm (D)
• Weight
• 300g

INTERFACES

SMA antennas: Connect the WiFi antennas here Power block: Connect the power adapter here Reset: To factory default the device Ethernet port: Connect with RJ45 cable Voice (RJ11): Connect RJ-11 cable to make circuit switched phone calls

INTERFACES

SMA antennas: Connect the 3G antennas here SIM slot: Mobily SIM slot goes in this slot

LEDS EXPLAINED

OVERVIEW

WHY CHOOSE AN NTC-40WV-03?

Fast mobile broadband Connects devices in locations without fixed broadband, stuck on dial-up or in low indoor signal strength locations Leverage a single connection Connect multiple devices to the one 3G connection with the built-in WiFi Industrial rated Rugged aluminium housing, extended temperature tolerance, wall mountable, flexible DC power input Control and monitor from afar Easily control and monitor all connected machines from a remote location. Open software development Configure the routers to perform the functions you want. Customise the type of information that can be collected and analysed from the connected machines

WHO IS IT IDEAL FOR?

• Businesses that want to connect machinery and other devices to the Internet
• Businesses that want to monitor and control devices from a remote location
• Businesses that want to connect multiple devices in a remote location through WiFi
• Businesses who require a connection that can be moved
• Businesses who require a temporary Internet connection for office set-ups or disaster recovery
• Businesses who need to incorporate making phone calls from a remote location

TROUBLESHOOTING

What can be connected to this router? Any device that is Ethernet and/or WiFi enabled. How does this router compare to a standard 3G/4G router? This router is an industrial rated router with rugged hardware features. The configurable software features allow for advanced monitoring and controlling of all connected devices which is particularly important for any remote devices or devices that are in a hard to reach location. Can this router be mounted?

• Yes. This router features holes in the extrusions so it is easy to be wall mounted.

What can be customised on the software? There is a long list of what can be customised using the software development kit. A SDK manual is available for any user who is confident to set customised rules on the software. What antennas are included? The 3G and WiFi antennas are SMA and can both be removed for optional attachment of high powered antennas.

NetComm Wireless M2M

DEVICE BENEFITS

• Remote monitoring, management and control
• Failover – disaster recovery
• Broadband connectivity to remote or mobile sites
• Real time tracking and monitoring
• Fixed line replacement
• Easy installation and integration into existing machines
• Zero provisioning
• Industrial design for durability and long lifespan
• Open embedded Linux platform for customising specific software applications via the Software Development Kit (SDK)

• Conveyor control

monitoring

• Gas detect

communication

• Failover for

Monitoring Systems

• Temperature &

Vibration Reporting

• Traffic

management

• Vehicles, off road

vehicles

• Transportation

infrastructure

• Fleet Management
• Vending Machines
• Recycling/Waste

bin levels

• Gaming Machines
• Digital Signage
• Mobile Health

units

• Emergency

response

• Smart homes
• Remote patient

monitoring

• Metering
• Grid Management
• Smart homes
• Irrigation control
• Remote

troubleshooting

• Supply Chain

Management

• Energy Management
• Building control

NETCOMM’S M2M VERTICAL MARKETS

Opportunity NSW State Government's $1.2 billion electronic ticketing project Application 3G WiFi routers designed to deliver undisrupted 3G connectivity to the integrated ticketing system across the states public ferries, trains and buses to see cash replaced with smartcards that commuters can link to

• nline accounts, or credit and debit cards.

Opportunity A million residential and business customers in Melbourne Application Enable undisrupted remote monitoring and control of pumped sewer systems over the 3G network and manage the delivery of data from sewer stations back to a central host system using a rugged wireless communications router.

CUSTOMER CASE STUDIES

Opportunity Deliver a powerful broadband Internet signal to an online business located in an isolated area with weak 3G signal strength and no available fixed line ADSL or cable infrastructure. Application Install a rugged weatherproof Outdoor Router that creates a strong mobile broadband network connection as well as a fast and secure wired and wireless local network both inside and outside the premise. Issue Monitor and control the waste collection process in real time to increase recycling efficiency, minimise the disposal of dangerous materials and resolve issues. Application Equip waste disposal trucks with rear view camera systems and wireless M2M routers to remotely observe and control the process over 3G networks.

CUSTOMER CASE STUDIES

Business Services Business Services

App development is Easy

NetComm Wireless provide a software development kit containing all the source code, libraries and compilers to enable anyone to develop or customise software applications to run on a NetComm Wireless M2M product.

NetComm Wireless is a leading manufacturer of broadband products. Specialising in the development of industrial-grade mobile-broadband products, NetComm Wireless’ products are designed for machine-to-machine connectivity for applications including remote machine monitoring, control and configuration. NetComm Wireless’ products provide cost effective data-communications for virtually any application using a 3G network.
