Normalization

Cs386 - Introduction to Database Systems Jay Urbain, PhD

Credits: Data Management, Richard Watson Database Management Systems, Raghu Ramkrishnan, Johannes Gehrke

Normalization

n An alternative/adjunct database design tool to data

modeling.

n Schema refinement. n A theoretical foundation for the relational model. n Application of a series of rules that gradually improve the

design.

Functional dependency

n A relationship between the attributes of an entity where:

¨ One or more attributes determine the value of another attribute

n An identifier can functionally determine all of the

attributes of an entity

¨ stock code -> firm name, stock price, stock quantity, stock

dividend

¨ If we know stock code, we know the value of firm name, etc.

n Multi-valued dependency

¨ Formula

n (stock dividend, stock price) -> yield

Full functional dependency

n Yield is fully functionally dependent on stock dividend

and stock price because both of these attributes are required to determine the value of yield

¨ (stock dividend, stock price) -> yield

n Determinant

¨ An attribute that fully functionally determines another

attribute

n e.g., stock code determines stock PE

Multidetermination

n A given value can determine multiple values

¨ A multidetermines B ¨ A -> B ¨ E.g., Department multidetermines course

Attribute relationships

n One-to-one

¨ A value of an attribute determines the value of

another attribute and vice versa

¨ A -> B and B -> A ¨ e.g.:

n CH -> Switzerland n Switzerland -> CH

Attribute relationships

n One-to-many

¨ A value of one attribute determines the value of

another attribute but not vice versa

¨ A -> B ¨ e.g.:

n country name -> currency unit n currency unit NOT-> country name

Attribute relationships

n Many-to-many

¨ Neither attribute determines the other ¨ A not -> B ¨ B not -> A

n country name not -> language n language not -> country name

¨ French and Flemish is spoken in Belgium ¨ French is spoken in many countries

Normal forms

n A classification of relations n Innermost is first normal form

¨ I.e. each normal form is a prerequisite for the next higher

normal form.

First normal form (1NF)

n Only scalar attributes

¨ All rows must have the same number of columns ¨ Single valued attributes only ¨ "A relation is in first normal form if it has the

property that none of its domains has elements which are themselves sets.”

n E. F. Codd (Oct 1972). "Further normalization of the

database relational model”.

Second normal form (2NF)

n All columns are fully functionally dependent on the

primary key

¨ Violated when a nonkey column is a fact about part of the

primary key

¨ customer-credit in this case is not dependent on itemno

• rder

itemno customerid quantity customer-credit 12 57 25 OK 34 679 3 POOR

Third normal form (3NF)

n No Transitive dependencies

¨ Violated when a nonkey column is a fact about another nonkey

column

¨ A column is not fully functionally dependent on the primary key ¨ exchange rate in this case is a fact about nation

stock stock code nation exchange rate MG USA 0.67 IR AUS 0.46

Boyce-Codd normal form (BCNF)

n Violation of BCNF arises when a table

¨ has multiple candidate keys ¨ the candidate keys are composite ¨ the candidate keys overlap

advisor client probtype consultant Alpha Marketing Gomez Alpha Production Raginiski

Fourth normal form (4NF)

n A row should not contain two or more multivalued

independent facts

student studentid sport subject … 50 Football English … 50 Football Music … 50 Tennis Botany … 50 Karate Botany …

Fifth normal form (5NF)

n 5NF if decomposition would not remove any redundancies. n Not 5NF if a table can be reconstructed from other tables

¨ There exists some rule that enables a relation to be inferred

n Base case

¨ Consultants provide skills to one or more firms, and firms can use many

consultants; a consultant has many skills and a skill can be used by many firms; and a firm can have a need for many skills and the same skill can be required by many firms

advisor client probtype consultant Alpha Marketing Gomez Alpha Production Raginiski

Fifth normal form (5NF)

n Designed to reduce redundancy in databases recording multi-valued

facts by isolating semantically related multiple relationships.

n The rule - If a consultant has a certain skill (e.g., database) and has a

contract with the firm that requires that skill (e.g., IBM), then the consultant advises the firm on that skill (i.e., he advises IBM on database).

Domain key/ normal form (DK/NF)

n Every constraint on the table is a logical consequence of

the table's domain constraints and key constraints.

n Key: unique identifier n Constraint: rule governing attribute values n Domain: set of values of the same data type

Referential integrity

n Property of data which, when satisfied, requires every

value of one attribute of a relation to exist as a value of another attribute in a different (or the same) relation (table).

n Foreign Key constraint

Data modeling and normalization

n Trick: look for invalid relationships:

¨ Expressed as 1:1 or single entity, when relationship is 1:m ¨ 1:m when relationship is m:m

n Data modeling is often an easier path to good database

design

n A high-fidelity data model will be of high normal form n 5NF is likely to create the most problems

¨ Check for special rules

Key points

n Normalization is one approach to data modeling. n Based on eliminating redundancies.

¨ Note: eliminating redundancies can increase the number of table

joins which can reduce performance.

n Use normalization to complement relational modeling. n A data model can have multiple representations. n Learning to model is difficult. n Learning to represent a model is relatively easy.
