Norco College Facilities Master Plan Update Workshop 05 Final Presentation May 13 - 17, 2019 DLR Group NORCO COLLEGE FACILITIES MASTER PLAN Campus and Community Engagement 50+ meetings with Campus, Community, and District DLR Group NORCO

slide-1
SLIDE 1

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Norco College

Workshop 05 Final Presentation May 13 - 17, 2019

Facilities Master Plan Update

slide-2
SLIDE 2

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Campus and Community Engagement

50+ meetings with Campus, Community, and District

slide-3
SLIDE 3

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Norco College will build a comprehensive and inspiring campus integrated into the region that serves as a destination for education, commerce, life, and the arts.

slide-4
SLIDE 4

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Facilities Master Plan Key Drivers

College Transformation: Create a comprehensive campus environment Student Transformation: Promote student success through academic growth and guided pathways framework Regional Transformation: Establish a distinct regional identity by hosting initiatives that impact regional development

slide-5
SLIDE 5

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Space Needs Analysis

slide-6
SLIDE 6

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Enrollment Growth (FTES) 7,400 9,600

30%

INCREASE

12,700+

72%

INCREASE

2018 FTES 2025 FTES 2030 FTES

slide-7
SLIDE 7

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

168,870

(today’s deficit - 107,262) 2018 asf

Physical Space Growth 467,800

177%

INCREASE

2030 asf

368,600

118%

INCREASE

2025 asf 84% CAP LOAD 120% CAP LOAD 120% CAP LOAD 120% CAP LOAD

slide-8
SLIDE 8

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Space Needs Analysis – Fall 2018

168,870

(today’s deficit - 107,262)

(52,610) asf

CAP Load

(54,652) asf

Other

slide-9
SLIDE 9

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Space Needs Analysis – 2025 368,600

Deficit (199,763)

(116,706) asf

CAP Load

(83,057) asf

Other

slide-10
SLIDE 10

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Space Needs Analysis – 2030 467,800

Deficit (298,973)

(170,146) asf

CAP Load

(119,827) asf

Other

slide-11
SLIDE 11

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Guided Pathways Space Allocation

Student Services, Study, General Use (meeting, hangout, dining, etc.) distributed as follows:

  • Centralize 60% of generated need in

campus core/front-door

  • Distribute 30% across the four Schools

pro-rated by WSCH contribution

  • Allocate 10% of generated need for

underrepresented groups (Veterans, Foster Youth, DACA, LGBTQ+, Umoja, etc.)

slide-12
SLIDE 12

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Site Plan Development

slide-13
SLIDE 13

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

The Campus Today

slide-14
SLIDE 14

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Proposed Site Plan

Existing Building to remain Major Building Reconstruction New Construction

slide-15
SLIDE 15

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Project Type

Existing Building to remain Major Building Reconstruction New Construction Demolition

slide-16
SLIDE 16

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Guided Pathways Clusters

slide-17
SLIDE 17

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Instruction and Academic Admin/Student Services Student Life and Dining Housing Recreation and Athletics Facility Support Community and Corporate Partners GP Node

Primary Building Use

slide-18
SLIDE 18

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Open Space Improvements

AG AG

SOFT BALL

Hardscape/ Sidewalks Enhanced Ped. Crossing Campus Lawn Sports Field Parking Lot/ Roadway Agriculture

slide-19
SLIDE 19

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Pedestrian Circulation

Promenade Pedestrian Circulation Multi-purpose Trail

slide-20
SLIDE 20

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Vehicular Circulation

Existing Roadway New Roadway Parking (Lot and Structure) Demolished Roadway

slide-21
SLIDE 21

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Parking

Today: 2,010 2025 Deficit: (330) 2030 Deficit: (1,090) 2025 Total: 2,340 2030 Total: 3,100

5 LEVELS 920 5 LEVELS 833 5 LEVELS 841

Parking Garage Surface Lot Stall Count

slide-22
SLIDE 22

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Implementation and Phasing

slide-23
SLIDE 23

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Phase I: 2020-2023

Existing Building to remain Major Building Reconstruction New Construction

slide-24
SLIDE 24

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

STEM Phase I

PROJECT DETAILS Prior to Phase 1 – place 22,800 asf of portables to ease campus deficit (labs, classrooms, offices) Phase 1 STEM Building 42,000 asf or 80,000 GSF

  • Relocate programs from ATEC and IT
  • Grow and expand Science and

Engineering Programs

  • Shared space with Navy

(offices/meetings)

slide-25
SLIDE 25

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Kinesiology Phase I/Softball Complex

PROJECT DETAILS Kinesiology/Athletics: 39,000 asf or 71,000 GSF

  • Kinesiology Classrooms
  • Class Labs
  • Offices/Conference Rooms
  • Gymnasium
  • Locker Rooms
  • Lounge

Softball Complex:

  • Regulation Collegiate Softball Fields
  • Small Building for Support Space

(2,700 GSF) - Storage, Restrooms, Concessions, Satellite Training Room

slide-26
SLIDE 26

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Front-Door Student-Services

PROJECT DETAILS Front-Door Student Services 30,178 asf or 48,250 GSF

  • Welcome Center - one-stop

shop for student services

  • Cultural Center - support for

underrepresented groups Parking Structure with Liner Building

  • 31,200 asf or 52,000 GSF
  • Includes one-level for campus

needs (bookstore, campus police, parking services, dining) and three-stories of partnership space

slide-27
SLIDE 27

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Library/LRC Expansion (Learning Commons)

PROJECT DETAILS New Construction: 45,000 asf or 70,000 GSF

  • Demolition of College Resource Center

and Student Services (functions relocated into STEM, Front-Door Student Services, and Liner Building (Parking Structure A) Reconstruction of existing LRC into Student Focused Spaces (19,559 asf)

  • Complex includes Library, Academic

Support space, and Student-Focused Space, such as dining, meeting rooms, informal collaboration spaces

slide-28
SLIDE 28

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Phase I: 2020-2023

Existing Building to remain Major Building Reconstruction New Construction

slide-29
SLIDE 29

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Phase II: 2023-2027

Existing Building to remain Major Building Reconstruction New Construction

slide-30
SLIDE 30

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Arts and Humanities Phase I + II

PROJECT DETAILS Reconstruction of existing facilities 43,147 asf (ATEC, IT)

  • Occur over three-phases as programs

are relocated into new structures Includes Fine and Performing Arts spaces:

  • Embedded student services and study

space

  • Instructional Studios
  • Fine Arts High School
  • Partnership with Orange County

School of the Arts

  • 750-students
slide-31
SLIDE 31

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

STEM Phase II

PROJECT DETAILS Phase 2 STEM Building 37,440 asf or 62,400 GSF

  • Embedded student services and study

space

  • Relocate programs from ATEC and IT,

STEM 100-300

  • Relocate programs from portables
  • Grow and expand Science and

Engineering Programs

slide-32
SLIDE 32

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Social and Behavioral Sciences Ph. I

PROJECT DETAILS Social and Behavioral Sciences Phase 1 19,000 asf or 38,200 GSF

  • Building dedicated to Social and

Behavioral Sciences

  • Embedded student services and study

space

  • General Classrooms and Open Labs

located in campus core for multidisciplinary use

  • Partnership with CRC through Social

Justice Center (long-term location near CRC)

slide-33
SLIDE 33

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Business and Management

PROJECT DETAILS Business and Management 21,927 asf or 41,400 GSF

  • Building dedicated to Business and

Management

  • Embedded student services and study

space

  • General Classrooms and Open Labs

located in campus core for multidisciplinary use

  • Incubator/Start-up Space – connected

to STEM program

  • Adjacent to STEM for enhanced

interdisciplinary programming

slide-34
SLIDE 34

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Phase III: 2027-2030+

Existing Building to remain Major Building Reconstruction New Construction

slide-35
SLIDE 35

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Arts and Humanities Phase III

PROJECT DETAILS Performing Arts Center 32,482 asf or 54,000 GSF

  • 500-seats theater
  • Art Gallery
  • Meeting Space

Parking Structure with Liner Buildings 64,800 asf or 108,000 GSF

  • Arts and Humanities instructional

space

  • Academic/Performing Arts Partners

Outdoor Amphitheater overlooking Lake Norconian and the Norconian Hotel (future Regional Arts Center)

slide-36
SLIDE 36

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

STEM/Photonics Phase III

PROJECT DETAILS Phase 3 STEM Building 44,820 asf or 74,700 GSF

  • Photonics* Center
  • Photonics* Museum
  • Shared Space with Navy

(offices/meetings)

  • Embedded student services and study

space

  • Grow and expand Science and

Engineering Programs * Pending feasibility study and Board approval

slide-37
SLIDE 37

DLR Group NORCO COLLEGE FACILITIES MASTER PLAN

Questions
