May 2014 Network Policy Mohammad Banikazemi Sumit Naiksatam Abstractions in Neutron Stephen Wong Outline Introduction Neutron Abstractions Group Policy Extension PoC Implementation and Demo

slide-1
SLIDE 1

May 2014

Network Policy

Abstractions in Neutron

Mohammad Banikazemi Sumit Naiksatam Stephen Wong

slide-2
SLIDE 2

Outline

❖ Introduction ❖ Neutron Abstractions ❖ Group Policy Extension ❖ PoC Implementation and Demo ❖ Future Directions ❖ Q&A

slide-3
SLIDE 3

Networking in the Cloud

❖ Current API: network centric ❖ Need a more application centric set of abstractions

as well

❖ More easily understood/utilized by higher layers ❖ Declarative model ❖ Separation of concerns

slide-4
SLIDE 4

Desired Features

❖ Provide policy-based connectivity between

application tiers

❖ Support dynamic application of policies ❖ Redirection to Network services and chains ❖ Policies defined by administrators and users

slide-5
SLIDE 5

Current Neutron API

❖ Network centric, close to physical devices ❖ Network: isolated layer-2 broadcast domain; private/shared ❖ Subnet: CIDR IP address block associated with a network;

  • ptionally associated with gateway, DNS/DHCP servers

❖ Port: virtual switch port on a network; has MAC and IP

address properties

❖ Router: connects networks, supports SNAT

slide-6
SLIDE 6

Example: Multi Tier Apps

Q Web Application DB Firewall Load Balancer QoS External Network (Internet)

slide-7
SLIDE 7

Neutron Representation

Q Network/ subnet Network/ subnet Network/ subnet Router External Network

Port

Q

neutron net-create web_tier neutron subnet-create web_tier 10.0.0.0/24 neutron router-create router1 neutron router-add-interface router1 web_subnet

. . .

slide-8
SLIDE 8

Group Policy

e x t e n s i o n

slide-9
SLIDE 9

The Basic Idea

❖ Endpoint (EP): Lowest unit of

abstraction where policy is applied

❖ Endpoint Group (EPG): Logical

grouping of endpoints

❖ Policy Rule: Network policies to

access EPGs

❖ Contract: Collection of policy rules

slide-10
SLIDE 10

EPG-Contract Relationship

❖ An EPG may provide one or more contracts ❖ An EPG may consume one or more contracts

Endpoint Group

Contract

❖ Application deployer focused

slide-11
SLIDE 11

Policy Rules

❖ Action is applied to traffic specified by Classifier

Policy Rule

Classifier Protocol Ports Direction Action Type Value

Action

Type

Allow

Redirect

QoS Log Copy

Mark

Value

None Service/ Chain QoS args Log args Copy args Mark args

slide-12
SLIDE 12

Group Policy - Workflow

neutron classifier-create Insecure-Web-Access --port 80 --protocol TCP --direction IN neutron policy-rule insecure-web --policy-classifier Insecure-Web-Access --actions ALLOW neutron contract-create Web-Server-Contract --policy-rule insecure-web

❖ Create contract ❖ Create EPGs and provide/consume contracts

neutron epg-create Web-Server-EPG --provides-contract Web-Server-Contract neutron ep-create --endpoint-group Web-Server-EPG neutron epg-create Outside-EPG --consumes-contract Web-Server-Contract

slide-13
SLIDE 13

Putting It All Together – 3 Tier App

Web Application DB Firewall Load Balancer External Network (Internet)

slide-14
SLIDE 14

Group Policy Realization

EPG Web EPG Application EPG DB

Firewall Firewall

EPG External Network (Internet)

Contract Protocol:TCP Port:80 Action:Redirect To FW_LB_CHAIN Provides Consumes Protocol:TCP Port:3306 Action:ALLOW Protocol:TCP Port:9080 Action:ALLOW EPG EPG

slide-15
SLIDE 15

Optional Constructs in Model

❖ Scopes: put constraints around how provider and consumer

EPGs are matched

❖ Policy Rule Filters: allow for tagging Policy Rules with Labels

such that subsets can be created in a Contract

❖ Contract hierarchy: infra admin constraints can be achieved

by Contract hierarchical composition

❖ Endpoint labels: policies get triggered automatically when

labels are added or removed

slide-16
SLIDE 16

Proof of Concept

i m p l e m e n t a t i o n

slide-17
SLIDE 17

PoC Implementation

❖ Team has worked on a PoC

implementation

❖ Considering various model and

implementation alternatives

❖ Using legacy driver ❖ CLI, Horizon, and Heat

CLI

  • Neutron
  • Heat
  • Horizon
  • Policy Manager
  • Legacy
  • Policy Driver
  • ODL
  • Policy Driver
  • thers
slide-18
SLIDE 18

The Group Policy PoC Team

❖ Sumit Naiksatam, Robert Kukura, Mandeep Dhami (Cisco) ❖ Mohammad Banikazemi (IBM) ❖ Stephen Wong (Midokura) ❖ Ronak Shah (Nuage Networks) ❖ Hemanth Ravi, Susaant Kondapaneni, Prasad Vellanki (One

Convergence)

❖ Rudra Rugge (Juniper)

slide-19
SLIDE 19

State of Implementation

❖ The blueprint for Group Policy has been reviewed/

approved

❖ Working PoC available (install from: https://github.com/

noironetworks/devstack/tree/group-policy-poc)

❖ Neutron reference implementation for Group Policy is in

progress

❖ Complementary work on network services framework is in

progress

slide-20
SLIDE 20

More Information

❖ Neutron Group-based Policy design session

  • May 16 • 10:50am - 11:30am • B304

❖ Wiki page:

  • https://wiki.openstack.org/wiki/Neutron/GroupPolicy

❖ Neutron Group Policy Sub-Team Meeting IRC weekly meetings:

  • https://wiki.openstack.org/wiki/Meetings/Neutron_Group_Policy
