Fieldbus : : Fieldbus Industrial Network Industrial Network Real Time Network Real Time Network Jean-Pierre Thomesse Institut National Polytechnique de Lorraine Nancy, France ETR 2005 - Fieldbus - Industrial Network - Real Time Network

slide-1
SLIDE 1

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

Fieldbus Fieldbus : : Industrial Network Industrial Network Real Time Network Real Time Network

Jean-Pierre Thomesse Institut National Polytechnique de Lorraine Nancy, France

slide-2
SLIDE 2

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

Who’s who Who’s who

EthernetWorldFIP

TTP Profibus-PA IEC 61158 Sercos BacNET Seriplex Unitelway P-NET CSMA-DCR Batibus EiBUS Interbus DeviceNet SDS ControlNet CiA CANOpen Profibus-FMS FieldBus Foundation Profibus-DP DWF Modbus TTP-A TTP-C EN 50170 EN 50254 TCP-IP MMS SNMP M-PCCN TASE2 IEC CASM FDDI ISO 8802.3 ISO 8802.4 ISO 8802.5 Sinec FIPIO FIPWay ControlFIP WDPF JBUS ASI PLAN Mini-MAP LON EHS CAN UCA ICCP CSMA-CA CSMA-BA CSMA-CD Hart Digital Hart Bitbus MAP TOP F8000 ARINC Profisafe UIC 556 IEC 6375 CIP M-Bus WITBUS Sycoway GENIUS VAN OPTOBUS Euridis J1850 LocaFIP FTT-CAN BlueTooth Anubis AFDX LIN IEEE 802.11 FlexRay TT-CAN FireWire EtherLink Ethercat EPA ModBus-RTPS Vnet/IP UWB PROFInet IEC 61784 ARCNET CAMAC MIL 1553B IEC 61 499

EN 50 295

Sensoplex Proway

slide-3
SLIDE 3

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

content content

1st part : history and state of the art

– fieldbus origins

– development of fieldbus and standards

2nd part : technical aspects

– application relationships – Medium Access Control – Data Link Layer – architectures

slide-4
SLIDE 4

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

prehistory prehistory

60s : CAMAC in nuclear experiments 70s :

– MODBUS (PLC network) – WDPF (continuous process) – ARCNET (office communication and data acquisition) – Mil Std 1553B

Data HighWay (Allen Bradley), TiWay (Texas

Instr)…

needs for standards

slide-5
SLIDE 5

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

MAP and TOP (1980) MAP and TOP (1980)

Manufacturing Automation Protocol

– General Motors – communication between design offices and factories – communication between machine tools and robots

Technical and Office Protocol

– Boeing – communication between business and technical offices

slide-6
SLIDE 6

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

CIM architecture CIM architecture

instrumentation machine cell plant Inc enterprise management factory control cell control machine instrumentation TOP MAP miniMAP fieldbus

slide-7
SLIDE 7

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

enabling technologies enabling technologies

OSI reference model (1980)

– communication model and concepts

LANs (Ethernet, Token…)

– deterministic protocols – nondeterministic protocols

microelectronics and integrated circuits

slide-8
SLIDE 8

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

enabling technologies enabling technologies

OSI reference model “reduced models”

Application layer Data Link layer+MAC Physical layer Application layer Data Link layer Physical layer Network layer Transport layer Session layer Presentation layer

slide-9
SLIDE 9

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

enabling technologies enabling technologies

LANs (Ethernet, Token, TDMA…) development

– deterministic protocols – nondeterministic protocols – centralized access or not

DCS

– Digital Control System vs. Distributed Control System

slide-10
SLIDE 10

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

enabling technologies enabling technologies

microelectronics and integrated circuits

– full and semi-custom – micro processors – micro controllers – DSP – communication dedicated ICs (I2C- Inter IC network) – “intelligence” embedded in ICs

slide-11
SLIDE 11

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

roles of a roles of a fieldbus fieldbus

connection of field devices and field controllers

– sensors, actuators, drives controllers, PLCs…

system considerations

– simplification of wiring – standardization of communication between devices – development of smart devices

real time communication system

– with different services and various qualities of service – multiple domains of application

slide-12
SLIDE 12

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

fieldbus fieldbus

backbone of distributed and real time systems

slide-13
SLIDE 13

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

fieldbus fieldbus

backbone of distributed and real time systems

but also

bone of contention between automation companies

beginning of the fieldbus saga

slide-14
SLIDE 14

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

content content

1st part : history and state of the art – fieldbus origins

– development of fieldbus and standards

2nd part : technical aspects

– application relationships – Medium Access Control – Data Link Layer – architectures

slide-15
SLIDE 15

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

first development first development

1982 - FIP - WorldFIP 1983 - PROFIBUS and CAN 1984 - P-Net 1985 - IEC NWI TC65C/WG6 1985 - ISA SP50

slide-16
SLIDE 16

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

IEC std contenders IEC std contenders

1st group existing systems

– Mil Std 1553B – IEEE P1118 (Bitbus) – Foxboro – Rosemount – …

2nd group paper proposals

– FIP – PROFIBUS

discussion draft and questionnaire for functional requirements (ISA)

slide-17
SLIDE 17

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

questionnaire questionnaire

benefits of fieldbus

– lowering cost, ease of adding devices, accuracy of information, enhancing the maintainability, remote access to data, advanced control strategies

describing field devices

– max response time and message frequency

information flows

– grouping of devices, topology, number of stations, redundancy

application environment

– power, wires type, insulation, flammable atmosphere

slide-18
SLIDE 18

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

two two fieldbuses fieldbuses H1 and H2 H1 and H2

H1

– low data rate – a few sensors – small distances – continuous process

H2

– high data rate – manufacturing process – connection of several H1

slide-19
SLIDE 19

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

requirements requirements -

  • application

application

definition of Application Protocol Data Units

– process (real time traffic)

measurement alarm setting status

– installation (non real time traffic)

tag number manufacturer’s data additional maintenance

name value status

slide-20
SLIDE 20

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

requirements requirements -

  • application

application

definition of other services

– control access – configuration services

types of data polled and unsolicited messages full logical connectivity architectures (distributed or centralized) time coherences (of data, of actions) space consistency

slide-21
SLIDE 21

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

requirements requirements

environment

– medium – insulation – power – flammable atmosphere – topologies

performances

– number of stations – length – data rate – response time – integrity of data – addressing

slide-22
SLIDE 22

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

IEC 61158 IEC 61158

8 types for data link layer

– Type 1 : compromise (Technical Report) – Type 2 : ControlNet – Type 3 : Profibus – Type 4 : P-Net – Type 5 : Foundation fieldbus – Type 6 : Swiftnet – Type 7 : WorldFIP – Type 8 : Interbus

slide-23
SLIDE 23

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

IEC 61158 IEC 61158

10 types for application layer

– Type 1 : compromise (Technical Report) – Type 2 : ControlNet – Type 3 : Profibus – Type 4 : P-Net – Type 5 : Foundation fieldbus – Type 6 : Swiftnet – Type 7 : WorldFIP – Type 8 : Interbus – Type 9 : Foundation fieldbus H1 – Type 10 : Profinet

slide-24
SLIDE 24

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

IEC 61 784 IEC 61 784

Communication Profile Family - CPF IEC 61 784-1

– 18 profiles

IEC 61 784 -2 under specification (based on

Ethernet)

– VNET/IP, – TCNet, – EtherCAT, – EtherNet PowerLink, – EPA : Ethernet for Plant Automation – ModBus RTPS : Real Time Publish - Subscribe

slide-25
SLIDE 25

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

Who’s who Who’s who

EthernetWorldFIP

TTP Profibus-PA IEC 61158 Sercos BacNET Seriplex Unitelway P-NET CSMA-DCR Batibus EiBUS Interbus DeviceNet SDS ControlNet CiA CANOpen Profibus-FMS FieldBus Foundation Profibus-DP DWF Modbus TTP-A TTP-C EN 50170 EN 50254 TCP-IP MMS SNMP M-PCCN TASE2 IEC CASM FDDI ISO 8802.3 ISO 8802.4 ISO 8802.5 Sinec FIPIO FIPWay ControlFIP WDPF JBUS ASI PLAN Mini-MAP LON EHS CAN UCA ICCP CSMA-CA CSMA-BA CSMA-CD Hart Digital Hart Bitbus MAP TOP F8000 ARINC Profisafe UIC 556 IEC 6375 CIP M-Bus WITBUS Sycoway GENIUS VAN OPTOBUS Euridis J1850 LocaFIP FTT-CAN BlueTooth Anubis AFDX LIN IEEE 802.11 FlexRay TT-CAN FireWire EtherLink Ethercat EPA ModBus-RTPS Vnet/IP UWB PROFInet IEC 61784 ARCNET CAMAC MIL 1553B IEC 61 499

EN 50 295

Sensoplex Proway

slide-26
SLIDE 26

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

content content

1st part : history and state of the art – fieldbus origins – development of fieldbus and standards

2nd part : technical aspects

– application relationships

– Medium Access Control – Data Link Layer – architectures

slide-27
SLIDE 27

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

requirements requirements -

  • application

application

definition of Application Protocol Data Units

– process (real time traffic)

measurement alarm setting status

– installation (non real time traffic)

tag number manufacturer’s data additional maintenance

name value status

identified data

messages

slide-28
SLIDE 28

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

fieldbus fieldbus traffic traffic

application exchanges messages identified data

real time periodic aperiodic non real time (management, configuration) real time periodic aperiodic non real time (management, configuration)

slide-29
SLIDE 29

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

periodic traffic periodic traffic

F E D C B A A D C A D C A D C A A E B A

periodic traffic of identified data

slide-30
SLIDE 30

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

aperiodic aperiodic traffic traffic

F E D C B A A D C A D C A D C A A E B A

Aperiodic traffic M 1 M 2

slide-31
SLIDE 31

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

application layer application layer

two main classes of relationships client - server

– and variants

publisher - subscriber

– and variants

slide-32
SLIDE 32

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

client client-

  • server

server

Request Indication Response Confirmation X-Request X-Indication Y-Request Y-Indication quality of service: safety : confirmed service response time : transport delay + local server response time RT

slide-33
SLIDE 33

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

publisher publisher -

  • subscriber models

subscriber models

Pull Publishing Manager Pull Publisher Pull Subscriber Pull Subscriber

Confirmed service request Confirmed service response containing published information

Push Subscriber Push Subscriber

Confirmed service request/response

Push Subscriber Push Publisher

Unconfirmed service containing published information

Push subscriber Push subscriber Push subscriber

slide-34
SLIDE 34

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

content content

1st part : history and state of the art – fieldbus origins – development of fieldbus and standards

2nd part : technical aspects

– application relationships

– Medium Access Control

– Data Link Layer – architectures

slide-35
SLIDE 35

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

fieldbus fieldbus traffic traffic

periodic traffic decentralized centralized token TDMA polling CSMA

TTP SERCOS INTERBUS CONTROLNET WORLDFIP PROFIBUS-DP PROFIBUS-PA FF P-NET PROFIBUS FMS + polling CAN DEVICENET SDS CANOPEN LON

slide-36
SLIDE 36

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

fieldbus fieldbus traffic traffic

aperiodic traffic decentralized (as periodic) periodic server when token periodic time slot special frame on demand CSMA

CONTROLNET P-NET INTERBUS WORLDFIP PROFIBUS-PA FF CAN SDS DeviceNet

slide-37
SLIDE 37

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

Profibus Profibus -

  • 1

1

M1 M2 M3 M4 Slave3 Slave2 Slave1 Slave4 Slave5 TOKEN passing

POLLING ANSWER

slide-38
SLIDE 38

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

Profibus Profibus -

  • 2

2

role of a Profibus master

– receive the token – perform high priority messages first – perform the exchanges specified in the Poll List – perform low priority messages – perform station registration (live list) – send the token

slide-39
SLIDE 39

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

WorldFIP WorldFIP -

  • 1

1

75

Speed value

Local Write

Speed “copy”

Local Read

52

Speed “copy”

Local Read

Speed

Bus arbitrator polling table

52

slide-40
SLIDE 40

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

WorldFIP WorldFIP -

  • 2

2

75

Speed

Local Write

Speed “copy”

Local Read

52

Speed “copy”

Local Read

Speed

Bus arbitrator Speed

52

slide-41
SLIDE 41

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

WorldFIP WorldFIP -

  • 3

3

75

Speed

Local Write

Speed “copy”

Local Read

Speed “copy”

Local Read

Speed

Bus arbitrator v(Speed)=75

slide-42
SLIDE 42

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

WorldFIP WorldFIP -

  • 4

4

75

Speed

Local Write

Speed “copy”

Local Read

Speed “copy”

Local Read

Speed

Bus arbitrator

75 75

slide-43
SLIDE 43

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

ControlNet ControlNet -

  • 1

1

based on a fixed repetitive time cycle

– Network Update Time (NUT) – close synchronism – each node - a clock synchronised to the NUT – access to the medium in sequential order based

  • n the MAC ID of the node

– implicit token passing

at the end of a frame, comparison of the received

MAC ID +1 with the own address

slide-44
SLIDE 44

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

ControlNet ControlNet -

  • 2

2

Scheduled part

NUT i NUT I+1

Unscheduled part Guard Band

station K station K+1

slide-45
SLIDE 45

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

ControlNet ControlNet -

  • 3

3

in a NUT, three time windows

– scheduled – unscheduled – Guard Band

  • ne MAC Frame by node in scheduled part

predictable and deterministic manner Round Robin in the unscheduled part

slide-46
SLIDE 46

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

Interbus Interbus -

  • 1

1

Station K periodic data Station K aperiodic data start K+1 K+2

slide-47
SLIDE 47

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

arbitrator arbitrator

NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE ARBITRATOR DISTRIBUTE COMPEL

slide-48
SLIDE 48

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

token token

NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE TOKEN Message Message Reply TOKEN

slide-49
SLIDE 49

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

L.A.S. L.A.S.

NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE L.A.S. DISTRIBUTE COMPEL

slide-50
SLIDE 50

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

L.A.S. L.A.S.

NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE L.A.S. TOKEN MSG MSG REPLY

slide-51
SLIDE 51

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

L.A.S. L.A.S.

NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE NODE L.A.S. TOKEN

slide-52
SLIDE 52

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

content content

1st part : history and state of the art – fieldbus origins – development of fieldbus and standards

2nd part : technical aspects

– application relationships – Medium Access Control

– Data Link Layer

– architectures

slide-53
SLIDE 53

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

quality of service quality of service

QoS transport

– reliability of transmission – storing methods

queues buffers (retentive or

not)

– connections

with or without peer to peer, multipeer

QoS timeliness

– time stamping – timeliness attributes

residence time update time synchronous

slide-54
SLIDE 54

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

buffers and queues buffers and queues

14 12 12 16 12 12 16 16 16 12 14 16 16 14 12

slide-55
SLIDE 55

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

QoS QoS in in fieldbus fieldbus -

  • transport

transport

connections

– four qualities related to frames ordering

classical (queues…) disordered without loss

  • rdered (but with possible loss)

unordered (as received)

slide-56
SLIDE 56

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

QoS QoS in in fieldbus fieldbus -

  • timeliness

timeliness

production transmission reception consumption production consumption reception transmission

slide-57
SLIDE 57

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

residence attribute residence attribute

assessment based upon the time that a data

unit has been resident in a buffer.

Write-date Read-date Residence Time End of time window

slide-58
SLIDE 58

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

update attribute update attribute

assessment based upon the time interval

between a synchronising event and the moment the buffer is written

Update-Time Synchro-event Writing-date End of time window

slide-59
SLIDE 59

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

synchronous attribute synchronous attribute

assessment based upon the time intervals and

timing relationships between

– a synchronising event – the moment when the buffer is written – the moment the buffer is read Synchro-event Writing-date End of time window Read-date

slide-60
SLIDE 60

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

time coherence time coherence

time coherence of actions, of events simultaneity of events

  • ccurrences in a given time window

time coherence of

– productions – consumptions – other actions

slide-61
SLIDE 61

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

time coherence time coherence

control of time coherence

– data received indication – allows, in multi peer connections, the synchronization of subscribers

usable to control any actions simultaneity verification of time coherence

– by timeliness attributes

slide-62
SLIDE 62

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

space space -

  • time consistency

time consistency

“reliable broadcasting” management of lists of variables (copies)

– produced by different publishers – consumed by several subscribers

verification and correction to obtain identical lists by the

subscribers

kind of global acknowledgement for different transmitters hypothesis:

– two remote copies are considered identical if they are received without error and correct timeliness attributes

slide-63
SLIDE 63

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

space space -

  • time consistency

time consistency

NODE NODE NODE NODE NODE NODE NODE 7 NODE NODE 9 NODE NODE 8 NODE NODE NODE 6 NODE L.A.S. COMPEL (A) value(A) value(A) value(A) value(A) COMPEL (B) DISTRIBUTE B value(B) value(B) value(B) value(B) DISTRIBUTE A COMPEL L6 DISTRIBUTE L6 L6=OK L8=OK L9=OK L7=not OK, B

slide-64
SLIDE 64

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

content content

1st part : history and state of the art – fieldbus origins – development of fieldbus and standards

2nd part : technical aspects

– application relationships – Medium Access Control – Data Link Layer

– architectures

slide-65
SLIDE 65

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

two stacks architectures two stacks architectures

Physical layer Fieldbus Link layer LLI (glue) FMS Physical layer Time critical DP or PA Physical layer Time critical Data Link layer MCS Transport layer (glue) SUB-MMS Physical layer Time critical MPS Profibus Architecture WorldFIP Architecture

slide-66
SLIDE 66

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

Internet and Internet and fieldbus fieldbus

Physical layer Time Critical Data Link layer TCP IP HTTP Time critical Time Critical Data Link layer TCP IP HTTP Physical layer Time critical IP Encapsulation Based architecture TCP IP HTTP DLL Ph L Station 1 Station 2 Outside

slide-67
SLIDE 67

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

Ethernet based architectures Ethernet based architectures

Physical layer TC-DLL layer TCP/ UDP IP HTTP Physical layer Time critical Application layer Physical layer Ethernet Data Link layer TCP UDP IP HTTP Physical layer Time critical Application layer Time critical mechanisms Ethernet Ethernet A Ethernet B

slide-68
SLIDE 68

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

time critical architecture time critical architecture

Physical layer Time critical Data Link layer Network layer Transport layer OSI Session layer OSI Presentation layer OSI Application layer Physical layer Physical layer Fieldbus Application and Presentation layer

slide-69
SLIDE 69

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

conclusion conclusion -

  • fieldbus

fieldbus technology? technology?

real time communication system and distributed data base new paradigms of cooperation between agents new views on quality of service impact on several computer science domains

– protocol modeling and validation – performance evaluation – scheduling (joint scheduling of messages and tasks) – and now joint modeling of application and communication for proving distributed applications

slide-70
SLIDE 70

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

fieldbus fieldbus technology? technology?

future

– which Ethernet ? – Internet and Web technologies – wireless – real intelligent devices and equipment – interoperability

standards as in general purpose computing

– one or two operating systems – a common communication architecture

reference: Proceedings of IEEE, Vol 93, N°6, June 2005, pp 1073-1101

slide-71
SLIDE 71

ETR 2005 - Fieldbus - Industrial Network - Real Time Network

Fieldbus Fieldbus : : Industrial Network Industrial Network Real Time Network Real Time Network

Jean-Pierre Thomesse Institut National Polytechnique de Lorraine Nancy, France
