Network Kernel Architectures and Implementation (01204423) Node Programming

Chaiporn Jaikaeo chaiporn.j@ku.ac.th Department of Computer Engineering Kasetsart University

2

Outline



Microcontroller programming

• Software development cycle



Hardware platforms

• IWING-MRF
• IWING-JN



IWING's MoteLib

3

IWING-MRF Mote

Radio transceiver 8-bit AVR Microcontroller USB Connector (for reprogramming and power) Analog/Digital sensor connectors External battery connector UART connectors Morakot Saravanee, Chaiporn Jaikaeo, 2010. Intelligent Wireless Network Group (IWING), KU

IWING-JN Mote

Analog/Digital sensor connectors UART connectors Wireless microcontroller module with PCB antenna

5

Microcontroller

flash memory

BSL

Typical Development Process



For microcontrollers with bootstrap loader (BSL) installed

Source code (C/Asm) Cross Compiler/Assembler Machine code Serial/USB

6

Build Simple App



Let's build a simple application



How to know whether our program is running?

• Make mote output something
• What can be used as output?

7

IWING-MRF Schematic



Available on course's homepage

8

IWING-MRF – Blinking LED



Task: turn a LED on and off repeatedly



Idea

• Configure Port D's Pin 5 (PD5) for output
• Repeatedly set the pin logic level to 0 and 1
• Add some delay before toggling pin level

9

IWING-MRF C Code – blink.c



How to add delay?



Can the code be made shorter?

#include <avr/io.h> main() { DDRD |= (1 << 5); // Make PD5 output while (1) { // Set pin logic to low PORTD &= ~(1 << 5); // Add some delay // Set pin logic to high PORTD |= (1 << 5); } }

10

Compiling



Make an ELF binary by running cross compiler

Note: blink.elf is not a Windows or Linux executable!



Translate the object file into ihex format

$ avr-gcc -mmcu=atmega328p –o blink.elf blink.c

$ avr-objcopy -j .text -j .data –O ihex blink.elf blink.hex

11

Flashing Code Into Mote



Plug mote into a USB port



Activate boot-loader

• Press and release RESET while holding USER/B.L.



Make sure it is recognized by your PC



Invoke chip programmer

$ avrdude -p atmega328p -c usbasp -U flash:w:blink.hex $ lsusb Bus 003 Device 049: ID 16c0:05dc Bus 001 Device 003: ID 046d:c03d Logitech, Inc.

12

IWING-MRF's Boot Loader

13

Creating Makefile



To compile



To download program to flash (will compile if needed)

make make flash

Tab character

14

IWING's MoteLib

Software Hardware

Morakot Saravanee, Patra Poome, Chaiporn Jaikaeo, 2009. Intelligent Wireless Network Group (IWING), KU

15

Hardware Abstraction

IWING-MRF Hardware IWING-MRF API Implementation

16

Hardware Abstraction

IWING-JN Hardware IWING-JN API Implementation

17

Mote and Network Emulator

Virtual Mote

18

Programming Model



MoteLib provides event-based programming environment

Idle loop

Radio event handler Sensor event handler Timer event handler Boot event handler

Handled by MoteLib Handled by developer

19

Example



Turn red LED on and off repeatedly every 500 ms

#include <motelib/system.h> #include <motelib/led.h> #include <motelib/timer.h> Timer t; void fired(Timer *t) { ledToggle(0); } void boot() { timerCreate(&t); timerStart(&t, TIMER_PERIODIC, 500, fired); }

20

Example: Creating Makefile

# Platform to build the code for PLATFORM = iwing-mrf # Required target without extension TARGET = blink # Include MoteLib's main make rules include $(MOTELIB_DIR)/Makerules

21

Example: Build and Flash App



Build your application



Program the mote with

make make flash

22

MoteLib API



Residing in $(MOTELIB_DIR)/include

• motelib/system.h
• motelib/led.h
• motelib/timer.h
• motelib/button.h
• motelib/sensor.h
• motelib/actor.h
• motelib/radio.h
• motelib/uart.h



Complete API documentation can be found here

• http://www.cpe.ku.ac.th/~cpj/motelib/

23

System API (motelib/system.h)



Provides boot() function signature



Provides various function declarations for node ID and network ID inquiry



Should be included in every MoteLib application

24

LED API (motelib/led.h)



Turn LED#2 on



Turn LED#1 off



Toggle LED#0



Use LEDs to display binary value

ledSet(2,1); ledSet(1,0); ledToggle(0); ledSetValue(5);

25

Timer API (motelib/timer.h)



Define and initialize a timer



Start the timer with 1-second timeout; trigger only

• nce; call function fired when triggered



Start the timer with 1-second timeout; trigger periodically

Timer t; timerCreate(&t); timerStart(&t, TIMER_ONESHOT, 1000, fired); timerStart(&t, TIMER_PERIODIC, 1000, fired);

26

Timer API (cont'd)



Defining callback

void fired(Timer *t) { // do something }

27

Button API (motelib/button.h)



Set handler to monitor button event

• Usually called in boot()



Handler example

buttonSetHandler(handler); void handler(ButtonStatus s) { if (s == BUTTON_PRESSED) // do something if (s == BUTTON_RELEASED) // do something }

28

Programming Practice



button-count.c

• Counts how many times the USER button has

been pressed

• Then shows the number (only 3 LSBs) on the

LEDs

• Count to 7 and wrap around to 0

29

Se Sens nsor

• r API (motelib/sensor.h)



Read digital input from input#0



Request analog reading (asynchronous) from input#3

uint16_t x = sensorReadDigital(SENSOR_0); sensorRequestAnalog(SENSOR_3, dataReady); : void dataReady(uint16_t value) { // value stores sensor reading }

30

Ac Actor tor AP API I (motelib/actor.h)



Activate output #2 (set logic to High)



Deactivate output #3 (set logic to Low)

actorSetState(ACTOR_2,1); actorSetState(ACTOR_3,0);

31



Measures light and temperature

Sensor Board

Sensor Power Supply

Light Sensor

Temperature Sensor

IWING-MRF Schematic

32

33

IWING-JN Schematic

34

Sensor Reading Procedure



Step 1: Turn on sensor power



Step 2: Request analog reading



Step 3: Wait until value is available



Step 4: Turn off sensor power

Split-Phase Operations

Request Data Blocking Sensor Controller

Synchronous Operation Asynchronous Operation

Sensor Controller Request Ready Ack Read Data

36

Example: sense-light.c



Every 100 ms, measure light and display the value on LEDs

• Light value is in range 0 – 1023
• Need to scale down to 0 – 7

37

Example

#include <motelib/system.h> #include <motelib/led.h> #include <motelib/timer.h> #include <motelib/sensor.h> #include <motelib/actor.h> Timer t; void readDone(uint16_t value); void readLight(Timer *t); void boot() { timerCreate(&t); timerStart(&t, TIMER_PERIODIC, 100, readLight); } void readLight(Timer *t) { actorSetState(ACTOR_0, 1); sensorRequestAnalog(SENSOR_1, readDone); } void readDone(uint16_t value) { ledSetValue(value/128); actorSetState(ACTOR_0, 0); }

38

Programming Practice



Modify sense-light.c so that light is sampled 4 times in each measurement

• Average value is displayed on LEDs

39

Creating a Reading Task



Event-based code can be difficult to read and maintain



Idea

• Make a reading task

that runs forever

• Other tasks can also

be added to run concurrently

Start timer Wait until timer expired Create timer Turn on sensors Request reading Wait until data ready Complete 4 samples? Compute and display average Turn off sensors

40

Synchronous Operations



MoteLib provides various checks to support synchronous operation



E.g.,

• timerExpired(t)
• Determines whether timer t has already expired
• Only works for one-shot timer
• sensorAnalogWaiting(s)
• Returns true if the system still waits for sensor s
• sensorAnalogResult(s)
• Returns the most recent value of sensor s

41

First Attempt

#include <motelib/system.h> #include <motelib/led.h> #include <motelib/timer.h> #include <motelib/sensor.h> #include <motelib/actor.h> Timer t; void readLightTask(); void boot() { readLightTask(); } void readLightTask() { uint8_t i; uint16_t sum = 0; timerCreate(&t); while (1) { timerStart(&t, TIMER_ONESHOT, 100, NULL); while (!timerExpired(&t)) ; actorSetState(ACTOR_0, 1); for (i = 0; i < 4; i++) { sensorRequestAnalog(SENSOR_1, NULL); while (sensorAnalogWaiting(SENSOR_1)) ; sum += sensorAnalogResult(SENSOR_1); } ledSetValue(sum/4/128); actorSetState(ACTOR_0, 0); } }

Will this work?

Problem with Event-based Model

Threads: sequential code flow Events: unstructured code flow

Very much like programming with GOTOs

42

Events Require One Stack



Four event handlers, one stack

Eventhandler 1 Eventhandler 2 Eventhandler 3

Stack is reused for every event handler

Eventhandler 4

43

Problem with Multithreading



Four threads, each with its own stack

Thread 1 Thread 2 Thread 3 Thread 4

44

45

Emulating Concurrency



Previous example wouldn't work because of the blocking while-loop

• Other parts of the system will be unresponsive



Must return to MoteLib inside of the while- loops



During MoteLib's idle loop, keep jumping into the while-loops

Coroutines



Generalized subroutines

• Allow multiple entry points for suspending and

resuming execution at certain locations



Can be used to implement:

• Cooperative multitasking
• Actor model of concurrency

46

Routine 2

Subroutines vs. Coroutines

Routine 1

Subroutines

Routine 2 Routine 1

Coroutines

call call return return yield yield yield yield

47

“Subroutines are a special case of coroutines.”

• -Donald Knuth

Fundamental Algorithms. The Art of Computer Programming

48

Programming Model

MoteLib's Idle loop

Task 2 Event handler2 Task 1 Event handler1

Handled by MoteLib Handled by developer

call return call return continue yield yield continue

49

Implementation Details



How to ask MoteLib to call our tasks?

• MoteLib provides setLoopRoutine(), allowing a

function to be called every idle loop



How to have a task yield and correctly come back to where it left?

void myroutine() { // something to be executed continuously } void boot() { : setLoopRoutine(myroutine); }

Implementing Continuation



Each coroutine must be able to continue from where it last yielded

Routine 1

50

Main Loop

continue yield continue yield

51

Duff's Device



Invented to optimize data transfer by means of loop unwinding



Switch cases are used like GOTO labels

do { *to = *from++; } while(--count > 0); register n = (count + 7) / 8; switch(count % 8) { case 0: do { *to = *from++; case 7: *to = *from++; case 6: *to = *from++; case 5: *to = *from++; case 4: *to = *from++; case 3: *to = *from++; case 2: *to = *from++; case 1: *to = *from++; } while(--n > 0); }

52

Protothreads



Invented by Adam Dunkels and Oliver Schmidt

• Used in the Contiki OS



Provides light-weight mechanism for concurrent programming using standard C macros and switch-case statements



Heavily inspired by Duff's Device and Simon Tatham's Coroutines in C



See

• http://dunkels.com/adam/pt/expansion.html

Protothreads



Protothreads require only one stack



E.g, four protothreads, each with its own stack

Events require one stack

Protothread 1 Protothread 2 Protothread 3 Protothread 4

Just like events

53

Six-line implementation



Protothreads implemented using the C switch statement



Heavily inspired by Duff's Device and Simon Tatham's Coroutines in C

struct pt { unsigned short lc; }; #define PT_INIT(pt) pt->lc = 0 #define PT_BEGIN(pt) switch(pt->lc) { case 0: #define PT_EXIT(pt) pt->lc = 0; return 2 #define PT_WAIT_UNTIL(pt, c) pt->lc = __LINE__; case __LINE__: \ if(!(c)) return 0 #define PT_END(pt) } pt->lc = 0; return 1

54

55

Revised sense-light.c

////////////////////////////// PT_THREAD(readLightTask(struct pt *pt)) { static uint8_t i; static uint16_t sum = 0; PT_BEGIN(pt); timerCreate(&t); while (1) { timerStart(&t, TIMER_ONESHOT, 100, NULL); PT_WAIT_UNTIL(pt, timerExpired(&t)); actorSetState(ACTOR_0, 1); for (i = 0; i < 4; i++) { sensorRequestAnalog(SENSOR_1, NULL); PT_WAIT_WHILE(pt, sensorAnalogWaiting(SENSOR_1)); sum += sensorAnalogResult(SENSOR_1); } ledSetValue(sum/4/128); actorSetState(ACTOR_0, 0); } PT_END(pt); } #include <motelib/system.h> #include <motelib/led.h> #include <motelib/timer.h> #include <motelib/sensor.h> #include <motelib/actor.h> #include <pt/pt.h> struct pt readLight_pt; PT_THREAD(readLightTask(struct pt *pt)); Timer t; ////////////////////////////// void scheduleTasks() { readLightTask(&readLight_pt); } ////////////////////////////// void boot() { setLoopRoutine(scheduleTasks); }

56

Protothreads Limitations



Local variables must be manually preserved

• Local variables are created on stack
• They are destroyed when function returns
• So they should be stored in an explicit state
• bject
• Or declared static, if reentrancy is not required



switch-case statements are not allowed



Cannot take advantage of multi-processing
