NETWORK COOPERATION FOR ENERGY SAVING IN GREEN RADIO COMMUNICATIONS

Muhammad Ismail and Weihua Zhuang IEEE Wireless Communications – Oct. 2011

Outline

Introduction Energy Saving at the Network Level The Potentials of Network Cooperation Network Cooperation for Energy Saving System Model The Proposed Strategy Performance Evaluation Conclusion

2

Outline

Introduction Energy Saving at the Network Level The Potentials of Network Cooperation Network Cooperation for Energy Saving System Model The Proposed Strategy Performance Evaluation Conclusion

3

Introduction

• Green Communications Network Design Objectives:
• 1. Reduce the amount of energy consumption by

the networks’ BSs

• 2. Maintain a satisfactory QoS for the users

4

Introduction Cont.

Motivations for Green Radio Communications

Service Provider’s Financial Considerations Environmental Considerations

• Half of annual operating

expenses are energy costs

• Currently, 2% of CO2

emissions from telecom.

• By 2020, 4% of CO2

emissions

5

Outline

Introduction Energy Saving at the Network Level The Potentials of Network Cooperation Network Cooperation for Energy Saving System Model The Proposed Strategy Performance Evaluation Conclusion

6

Energy Saving at Network Level

Solutions for Energy Aware Infrastructure

Renewable Energy Sources Heterogeneous Cell Sizes Dynamic Planning

• Reduce CO2

emissions by using renewable energy

• Reliability issues
• Macro-cells 

Femto-cells

• Balance of

different cell sizes is required

• Exploit traffic

load fluctuations

• Switch off

available resources at light traffic load

7

Dynamic Planning

• Temporal fluctuations in traffic load

Resources on-off Switching

Radio transceivers of active BSs Entire BS switch-off

8

Dynamic Planning Cont.

• Dynamic planning challenges

Service Provision Guarantee Increase cell radii Relaying mechanism Network cooperation

• Increase

transmission power

• Unreliable for

delay sensitive applications

• Alternately

switch on-off resources

9

Outline

Introduction Energy Saving at the Network Level The Potentials of Network Cooperation Network Cooperation for Energy Saving System Model The Proposed Strategy Performance Evaluation Conclusion

10

Heterogeneous Medium

11

Heterogeneous wireless communication network

Heterogeneous Medium Cont.

Potential Benefits of Cooperative Networking

Mobile Users Networks

• Always best

connection

• Multi-homing
• Relaying
• Load balance
• Energy saving

12

Proposal

• In this article:
• Employ cooperative networking to achieve energy

saving and avoid dynamic planning shortcomings

• Networks with overlapped coverage alternately

switch on-off: 1. BSs, 2. radio transceivers of active BSs according to call traffic load conditions

13

Proposal Cont.

• Develop an optimal resource on-off switching

framework:

• 1. Captures the stochastic nature of call traffic load
• 2. Adapts to temporal fluctuations in the call traffic

load

• 3. Maximize the amount of energy saving under

service quality constraints in a cooperative networking environment

14

Outline

Introduction Energy Saving at the Network Level The Potentials of Network Cooperation Network Cooperation for Energy Saving System Model The Proposed Strategy Performance Evaluation Conclusion

15

System Model

• Cellular/ WiMAX system
• cellular network cells

covered by WiMAX BS

N

• Vector of BSs working modes

in the overlapped coverage area

1 2 1

[ , ,..., , ]

N N

X x x x x





• channels available in

cellular network BS  active channels

C

cn

k

• channels available in

WiMAX network BS  active channels

M

wn

k

16

System Model Cont.

• Power Consumption model

Total power consumption of WiMAX(Cellular) BS

( )

w c

P P ( )

wo co

P P

Fixed component

( )

wv cv

P P

Variable component

( )

wf cf

P P

Power consumption of inactive BS

( )

wo co

P P  

Switching cost

17

System Model Cont.

• Call traffic and mobility

Assumptions:

• A1. New call arrivals to cell 

Poisson process with mean arrival rate

n

n



• A2. Handoff call arrivals to cell

 Poisson process with mean arrival rate

n

n



• A3. MT dwell time  exponential

distribution with mean

1/

• A4. Call duration  exponential

distribution with mean 1/ 

18

The Proposed Energy Saving Strategy

Call Traffic Load Fluctuations

Large Scale Fluctuations Small Scale Fluctuations

{ 1,2,.., } T   24/ T   D { 1,2,.., } D  / D   

19

The Proposed Energy Saving Strategy

20

The Proposed Energy Saving Strategy

• Decision on BS Working Mode:
• Maximize energy saving
• Minimize the frequency at which BS changes its

working mode from inactive to active

• Achieve acceptable service quality (call blocking

probability)

• Ensure radio coverage in the overlapped area

21

1 1 0, , 1 1 1 1 1 1

max ( ) ( ) (1 ) ( / ) / ! . . (( / ) / !) 1, , = 0,

• therwise

, =

n n n

N N c n w N n N S J X n n S n u n S S n u s n N N N n n

P P P P P P S s t n N S S C n N x N x x       

        

                                   

   

1 1

, 1,

N N n n

J x S M JC

 

       



The Proposed Energy Saving Strategy

• Large Scale Optimization Problem:

22

The Proposed Energy Saving Strategy

   

 

1 1

max . ( ) . ( ) ( / ) / ! . . (( / ) / !)

n n n

n c co cn cv N w wo wn wv S S n u n S S n u s

x P P k P x P P k P S s t n N S     

  

       



• Small Scale Optimization Problem:

23

Performance Evaluation

24

Performance Evaluation Cont.

25

Performance Evaluation Cont.

WiMAX Cellular 3 Cellular 2 Cellular 1 BS 24.5% 73.13% 48.75% 44.68% % Saving

Table 3. Percentage energy saving without small scale optimization

WiMAX Cellular 3 Cellular 2 Cellular 1 BS 34.45% 74.06% 50.31% 46.33% % Saving

Table 4. Percentage energy saving with small scale optimization

26

Performance Evaluation Cont.

27

Outline

Introduction Energy Saving at the Network Level The Potentials of Network Cooperation Network Cooperation for Energy Saving System Model The Proposed Strategy Performance Evaluation Conclusion

28

Conclusion

• Network cooperation for energy saving on two scales:
• Large scale: networks with overlapped coverage alternately

switch their BSs according to long-term traffic load fluctuations

• Small scale: active BSs switches its channels according to short-

term traffic load fluctuations

• Satisfactory service quality in terms of call blocking and large

percentage of energy saving, ensure radio coverage

• Service quality constraints can be extended to: minimum

achieved throughput for data applications and delay and delay- jitter for video streaming applications

• Incurred cost: synchronization overhead required

29

30

THANK YOU !

For more information please refer to: M.Ismail and W.Zhuang, “Network cooperation for energy saving in green radio communications,” IEEE Wireless Communications, Vol. 18, No. 5, Oct. 2011.
