NETWORK ANALYSIS: PEOPLE AND OPEN SOURCE COMMUNITIES

Dawn M. Foster

@geekygirldawn ¡ dawn@dawnfoster.com ¡ fastwonderblog.com PhD ¡Student ¡ University ¡of ¡Greenwich ¡ London, ¡UK

WHOAMI

• Geek, traveler, reader
• 20 year tech career. Past 15

years doing community &

• pen source (Intel, Jive,

Puppet Labs, etc.)

• PhD student at University of

Greenwich researching Linux kernel

Photos by Josh Bancroft, Don Park

WHAT IS NETWORK ANALYSIS?

Studies relationships between units and looks for patterns and structure in those relationships

Image from ANAMIA Project

AGENDA AND INFO

• Gathering your data
• Data manipulation for

network analysis

• Visualization
• What else can you do?

Image from a Northern Marina Islands Network

Scripts, Data, and More:
 github.com/geekygirldawn/linuxcon_2015

I 💗 METRICS GRIMOIRE

MailingListStats aka MLStats CVSAnalY - repos Bicho - bugs More

Photo by Bitergia

http://metricsgrimoire.github.io/

MLSTATS

a) Install mlstats

$ python setup.py install

b) Create database

mysql> create database mlstats;

c) Import data by running mlstats

$ mlstats --db-user=USERNAME --db-password=PASS http://URLOFYOURLIST

MLSTATS: EXTRACT DATA

SELECT mp.email_address AS sender,
 (SELECT mp2.email_address FROM
 messages m2, messages_people mp2 WHERE m2.is_response_of=m.is_response_of
 AND mp2.message_id=m2.is_response_of limit 1) AS receiver FROM messages_people mp, messages m WHERE YEAR(m.first_date)=2015 AND MONTH(m.first_date)=1 AND mp.message_id=m.message_id;

people sending emails subquery: who they replied to limit time for manageable data

Network Analysis Output for R / Visone: sender@example.com in_reply_to@example.com sender1@example.com in_reply_to1@example.com sender2@example.com in_reply_to2@example.com ...

EXTRACT DATA: SCRIPTS

Reformat / clean up data Reproducible Reduce human error linuxcon.py script

Image from Mark Grealish

github.com/geekygirldawn/linuxcon_2015

R / VISONE

Convert data for better use with network analysis Visualize data using
 RStudio and Visone

Image from WebOps.com

GOURCE

Visualize data using Gource

GOURCE CUSTOM FORMAT

Pipe Separated File

timestamp - A unix timestamp of when the update occured.
 username - The name of the user who made the update.
 type - Update type - (A)dded, (M)odified or (D)eleted.
 file - Path of the file.
 color - Color for the file in hex (FFFFFF) format (Optional)

Examples:

1275543595|andrew|A|src/main.cpp
 1275543700|bob|M|src/main.cpp

https://github.com/acaudwell/Gource/wiki/Custom-Log-Format

EXAMPLE:

a) Extract data using mlstats / database queries b) Generate Gource custom format (pipe sep file)

unixtime|user-email_sender|A|new
 unixtime|user-email_sender|M|user-in_response_to

OR) Run linuxcon.py from my linuxcon_2015 repo (a & b) c) Run Gource

$ gource -i 10 --max-user-speed 100 -a 1 --highlight-users
 gource_output.log

github.com/geekygirldawn/linuxcon_2015

OTHER OPTIONS

Bug data Wikis Other stuff

https://github.com/acaudwell/Gource/wiki/Custom-Log-Format

Photo by Bitergia

Image from WebOps.com

WHAT ELSE?

So many visualization tools Python network packages Network analysis is more than just pretty pictures!

Dawn Foster University of Greenwich Centre for Business Network Analysis www2.gre.ac.uk/about/faculty/business/research/centres/cbna/home @geekygirldawn, dawn@dawnfoster.com fastwonderblog.com

THANK YOU
