slide-1
SLIDE 1

Nel Hydrogen Electrolyser

Company & Product Presentation

1

slide-2
SLIDE 2

Nel is a global, dedicated hydrogen company, delivering optimal solutions to produce, store and distribute hydrogen from renewable energy

2

We serve multiple industries as well as energy and gas companies with leading hydrogen technology

slide-3
SLIDE 3

NEL COMPANY HISTORY

1927 1953 1974 2003 2004 2014 2015 2016 2017 Building of the first small electrolyser, culminating with 3 large scale plants in Rjukan, Norway with more than 440 electrolysers / 60,000 Nm3/h Creation of a secondlarge- scale hydropowered electrolyser plant, for supplying hydrogen for ammonia production in Glomfjord, Norway Our renowned electrolyser technology made available for other companies and

  • ther industries

Nel opens world’s first publicly availablehydrogen fueling station inReykjavik, Iceland The first Power-to-Power demonstration projectat the island of Utsira, Norway Nel becomes the first100% dedicated hydrogen company listed on the Oslo Stock Exchange Nel acquires H2 Logic, adding world leading hydrogen fueling technology to theproduct portfolio Initiates construction of the world’s largest manufacturing plant for hydrogen fueling stations, with a capacity of 300 units per year Acquires Proton Onsite to create the world’s largest electrolyser company 2018 Decision of building new production that gives a total production capacity

  • f 360MW peryear

in electrode production

3

slide-4
SLIDE 4

NEL ASA

  • Pure-play hydrogen company listed on the Oslo Stock Exchange – facilities in Norway, Denmark and the U.S.
  • Three divisions offering hydrogen technology and solutions for industrial and energy applications
  • ~3500 hydrogen solutions delivered in ~80 countries world wide since 1927
  • World #1 on hydrogen electrolysers and hydrogen fueling – unrivalled performance and track-record
  • Financially strong company with a world-class experienced management team in place

Hydrogen Electrolysers

4

Hydrogen Fueling Hydrogen Solutions

slide-5
SLIDE 5

NEL HYDROGEN ELECTROLYSER

HYDROGEN PRODUCTION TECHNOLOGY HYDROGEN FUELING TECHNOLOGY

FUELING

SYSTEM INTEGRATION PROJECT DEVELOPMENT FINANCING & OWNERSHIP

ELECTROL YSERS SOLUTIONS

5

slide-6
SLIDE 6

NEL HYDROGEN ELECTROLYSER

  • Global leader in H2 production plants - highest uptime, lowest conversion cost, robust and reliable
  • More than 3 500 hydrogen solutions delivered in ~80 countries world wide since1927
  • Highly scalable production capacity for industrial, energy and transport applications

Containerised and turn-key

Up to 650kg/day

Large scale plant solutions

Up to any capacity size C-Series A-Series Solar Grid Wind

Alkaline and PEM electrolysers

Scalable and modular 6

slide-7
SLIDE 7

Theme/Subject Strictly private & confidential 8

8

Notodden, Norway

World leading hydrogen technology

slide-8
SLIDE 8

Engineering Procurement/ manufacturing Installation Commissioning

  • Cell stacks based Nel

technology

  • Manufactured in Nel’s

production facilities

  • Contractor

installation

  • Nel supervision
  • Replacement of cell

stack with 7-10 year intervals

  • Services & spare

parts

  • Nel assures plant
  • perates according to

requirements

  • Tailor-made plant

design Aftermarket

In-house

8

Outsourced/partners

OUR BUSINESS CONCEPT – WHAT WE DO

slide-9
SLIDE 9

INDUSTRY FUNCTION / USAGE

Edible Oils & Fats

Hydrogenation of oils and fats to raise the melting point. Widely used for i.e. production of margarine and shortenings for converting of edible oil from liquid to solidstate

Metallurgy

Used in a number of high quality special steel production processes. It is commonly used in annealing furnaces (heat treatment) that require an protective atmosphere to avoidoxidation.

Float Glass

The production of flat glass is done in a process where glass is floated in a bed of molten tin where a sheet of glass is formed by floatation. Glass is cooled in a controlled protective atmosphere of roughly 94-95% nitrogen and 5-6% hydrogen

Electronics

In the production of electronic packages (Semiconductorand integrated circuit) the presence of moisture and oxides can lead to reductions in

  • yields. Nitrogen and hydrogen are used to ensure the atmosphere is free of moisture and other impurities

Chemicals / Petrochemicals

Hydrogen is a key chemical buildingblock in many chemical processes.Apart from ammonia and methanol,hydrogen peroxide, sorbitol, PTA,

  • leochemicalsand many other chemical or petrochemical products use hydrogen in their process.

Power Plants

Friction in turbine generators produces large amounts of heat. Hydrogen has a small molecule size, giving it low viscosity. This, together with its superior heat absorptioncharacteristics makes hydrogen ideally suited as a coolingmedium for generators in power plants

Polysilicon

Polysiliconis a material consistingof small silicon crystals,and is used for silicon ingots and wafer productionfor the solar cell industry.In the productionof polysiliconused the Siemens-process,large amounts of hydrogen is used to react with thrichloresilan gas to produce silicon 9

…SERVING A WIDE RANGE OF INDUSTRIES

slide-10
SLIDE 10

H2

POWER-TO-CH3OH (GREEN METHANOL)

4

POWER-TO-CH (GREENMETHANE) CO2-FREE STEEL

Power

+ CO2

10

+ CO2

POWER-TO-X / GREEN HYDROGEN

Unlocking the potential of renewables – enables decarbonisation of industry POWER-TO-GAS POWER-TO-FUEL POWER-TO-POWER POWER-TO-LIQUID (BIOFUEL) POWER-TO-NH3 (GREEN AMMONIA)

slide-11
SLIDE 11

AWARDED MULTI—BILLION NOK ELECTROLYSER AND FUELLING STATION CONTRACT BY NIKOLA

The transformational Nikola partnership

Contract for delivery of up to 448 electrolysers / 1 GW of electrolysis

  • Contract awarded as part of Nikola’s development of a hydrogen

station infrastructure in the U.S.

  • Multi-billion NOK electrolyzer and fueling station contract, to be

deployed from 2020 – by far the largest electrolyzer contract ever awarded

  • The contract includes an initial order for an engineering package of

around USD 1.5 million

  • Electrolyzer stacks to be manufactured in Norway, fueling

equipment in Denmark - supporting components, including frames, pipes and vessels to be sourced locally in the U.S.

11

slide-12
SLIDE 12

14

PRODUCTS

slide-13
SLIDE 13

THE WORLD’S LARGEST ELECTROLYSER COMPANY

  • Concluded the acquisition of Proton OnSite on June 30, 2017
  • Enabling Nel to offer any type of electrolyser in the market

ALKALINE PRESSURIZED

✓

ALKALINE ATMOSPHERIC

✓

PEM

✓

“Nel is a one-stop-shop completely independent of technology preference, and the combined sales teams will be a global force to reckonwith”

13

slide-14
SLIDE 14

PEM PRODUCT RANGE

  • Wide range of products

sold to ~75 countries

  • Customers range from

industrial companies to laboratory institutes

  • Also offers services, incl.

installation training, service and maintenance

  • More than 1 billion hours

worth of operating experience on PEM

H-Series C-Series M Series S-Series Lab Gas Generators

Net production rate: 2-6 Nm3/hr

14

Net production rate: 0.53-1.05Nm3/hr Net production rate: 10-30Nm3/hr

1 MW solution

Net production rate: 100-200Nm3/hr

2 MW solution

Net production rate: 300-400+Nm3/h

slide-15
SLIDE 15

TAILORED & TURNKEY – BOTH SOLUTIONS

TAILORED ELECTROLYSER SOLUTION TURNKEY ELECTROLYSER SOLUTION

15

slide-16
SLIDE 16

TAILORED ELECTROLYSERS

Nel A-150

  • Small
  • 50 – 150 Nm3/hr

Tailored solutions for any customer requirement Nel A-300

  • Medium
  • 150 – 300 Nm3/hr

Nel A-485

  • Large
  • 300 – 485 Nm3/hr

16

slide-17
SLIDE 17

STANDARD LAYOUT

17

slide-18
SLIDE 18

20

NEL HYDROGEN ELECTROLYSERS

The world’s most efficient and reliable electrolyser

slide-19
SLIDE 19

SIMPLIFIED FLOW DIAGRAM

19

slide-20
SLIDE 20

20

slide-21
SLIDE 21

23

LARGE SCALE PLANTS

slide-22
SLIDE 22

~40% CAPEX reduction Mass production takes it to the next level

Scaling up smart

slide-23
SLIDE 23

25

1927 – WHEN IT ALL STARTED

  • Norsk Hydro decide to go for ammonia-based fertilizer (Haber-Bosch), rather than

existing Birkeland-Eyde process

– Starting point for huge investments in electrolyser R&D / technology

  • Two electrolyser technologies tested at Notodden; Pechkrantz-cells and Holmboe-cells.

Pechkrantz selected as best technology

  • Three plants installed in Rjukan, Norway:

1927

PLANT OPERATION # ELECTROLYSERS APPROX CAPACITY Vemork 1929 – 1971 288 37 000 NM3H Såheim 1 1929 – 1988 56 7 000 NM3H Såheim 2 1942 – 1988 96 19 000 NM3H

slide-24
SLIDE 24

RECENT REFERENCES OF LARGE SCALE PLANTS

Company: NitolSolar Industry: Polysilicon Capacity: 1 940 Nm3/h Energy: 8,8 MW Source: Hydro Power Company: Industry: Capacity: Energy: Source: Tokuyama Polysilicon 2 500 Nm3/h 3 000 Nm3/h Total 25 MW Hydro Power

24

slide-25
SLIDE 25

SCALING OF H2 PLANTS

Compressors

T r a d i t i

  • n

a l l y

25

F u t u r e

slide-26
SLIDE 26

PLANT DESIGN: 85 360 NM3/HR (184 T/DAY)

26

slide-27
SLIDE 27

32

Notodden >10x CAPACITY INCREASE

slide-28
SLIDE 28

number one by nature

37
