NBI Overview

• NBI is committed to future-proofing internet access in rural Ireland, using fibre technologies to enable

a truly limitless connected society and economy for generations to come.

• Fibre broadband uses fibre optics cables to deliver data to businesses and homes. Fibre-to-the-home

(FTTH) connections that can deliver lighting fast speeds of up to 1,000Mbps (1GB).

• Eliminating Ireland’s digital divide, promising to deliver life-changing infrastructure that will be the

platform to empower nearly 1.1million people who have remained underserved in the provision of full modern telecommunication services.

• Making its services available to 100% of the NBP’s Intervention Area, which accounts for 23% of the

population – in about approximately 536,000 homes, farms, schools and businesses. The intervention

• r rollout area only applies in places which are deemed ‘Amber’ in DCCAEs broadband.gov.ie map
• Building and operating its ultrafast network on an independent wholesale open-access basis

NBI Overview

• NBP’s comparable effect will be equivalent to

rural electrification

• Key role in sustaining rural Ireland and more

remote communities

• Enabling remote working, e-health initiatives,
• nline education, job creation, agri-tech, access

to e-government facilities, tourism benefits

• Growth in SMEs, new start-ups &

entrepreneurship

• Increased social inclusion and digital literacy

through community hub

• NBP is part of Ireland’s Climate Action Plan –

helping reduce fossil fuel consumption

NBP – Critical Infrastructure

4

• NBI will deploy the latest fibre to the home technology

known as XGS-PON technology.

• Minimum broadband speeds of 150Mbps available from

year 1

• NBI have committed to increase the minimum

broadband speeds for customers over the life of the contract

• Minimum speeds of 300Mbps by Year 5 and 500Mbsp by Year 10
• Business customers can avail of symmetrical products

e.g. 200Mbps, 1Gbps, 5Gbps and 10Gbps available from year 1

Technology overview

150Mb 300Mb 1,000Mb (1Gbps) Bitstream/VUA 1Gbps 5Gbps 10Gbps Symmetric Ethernet Services Year 1 Product Catalogue

5

Point of Hand-off locations OLT locations

• We will deploy 74,000km of new fibre during our

deployment phase, passing the premises

• We estimate 90% of our network deployment will

be overhead and 10% underground

• Our Network will be rolled out by utilising existing

eir & enet infrastructure (existing poles & ducts)

• This will reduce the amount of new construction

required in each county

• Only 12% of deployment of the network will

involve new construction (of poles and ducts)

Broadband Deployment

• The picture above gives a high level design view of the quantity of routes and fibre required to

connect all 21,024 premises in Limerick. This equates to over a fifth of all premises in the county. While the NBI network will traverse through all the county, it will only connect in the rollout area.

High-level design for Limerick county

2 3 1

• Limerick county has 21,024 premises in the Intervention area – representing 22% of all premises in the county
• These are serviced from 9 network nodes (yellow dots) – 5 of which are based in Limerick county (yellow dots)
• Core hub sites (green) will be deployed first and the other network nodes are linked with fibre back to these (orange)

High-level design for Limerick county

• The first deployment area in Limerick will be surveyed in the coming weeks & built in Q3/Q4 2020.
• 4Site and Enet – both Limerick based companies – will carry out surveying works on behalf of NBI
• The other deployment areas to follow will be designed/started once all the surveying results are collated

High-level design for Limerick county

High-level design for Limerick

First surveying area in the coming weeks will cover 3,425 premises in the townlands around Limerick city includareas such as Clarina, Parteen, Lisnagry & Mungret

Nine Broadband Connection Points (BCPs) will be accessible to the public for free high speed internet access in 2020. These will all be in the roll-out area & includes locations in Mungret, Bruff, Abbeyfeale & Cappamore. BCP locations include schools, GAA halls, community centres & enterprise hubs. Those who live in the rollout area can use these facilities for many of their digital needs

• inc. remote working, making online payments
• r online applications, contacting family or

friends and partaking in new courses etc These locations are all available online at

• www. nbi.ie/broadband-connections-points

Broadband Connection Points

• Engagement with the local communities and stakeholders is a key focus for NBI
• Advertising in local press and radio will be complimented by engaging directly with the

community via town hall events, roadshows and interaction with local associations

Engaging with the Community Local Authorities

• BBOs
• County managers
• Planners
• Council members
• Local Enterprise Offices
• An Garda Síochána

Communities

• Town Hall Events
• Roadshows
• Public Participation

Networks

• Sporting & other

associations (GAA, Soccer, Bridge Clubs)

• Broadband Champions

& Ambassadors

Stakeholders

• IFA
• ICA
• Age Action
• Macra na Feirme
• IBEC
• Regional development

bodies

• Chambers of Commerce
• Muintir na Tíre
• An Post

Limerick erick City y & Co County: unty: 2019 19-Q3 Q3 Br Broad

• adband

band Statistics atistics

• 97,887 Premises Total (City + County)
• 76,019 Commercial (78%, blue)
• 844 Planned Commercial (1%, eir, light-blue)
• 21,024 NBP Intervention (21%)

78% Overall Coverage in 2019

93%/58% Coverage City/County

1. Mihai Bilauca, Digital Services (chair) 2. Jim Dore, ICT 3. Stephane Duclot, Planning 4. Tom Cassidy, Heritage 5. Hugh McGrath, Service Operations 6. Gerrard Doherty, Environment 7. Tom Tarpey, Water 8. Laura Ryan, Communications 9. Mike Cantwell, Innovation 10. Damien Brady, Libraries 11. Rob Lowth, Community Supp. 12. Seamus O’Connor, Social Dev 13. Shay Riordan, WLR 14. Padraig Casey, Ballyhoura Dev. 15. Joe Leddin, MW Jobs

NBP BP St Stee eering ing Gr Group up in Limerick

14

Thank You – Questions
