Nano-satellites and IoT applications M. Maris INAF OATS S. - - PowerPoint PPT Presentation
SPIN-OFF UNIVERSIT DI TRIESTE INCUBATION AREA SCIENCE PARK Nano-satellites and IoT applications M. Maris INAF OATS S. Seriani UNITS E. Slejko UNITS & PICOSATS A. Gregorio UNITS & PICOSATS www.picosats.eu OVERVIEW
www.picosats.eu
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
² SMALL SATELLITES ² PICOSATS ² IoT WITH SMALL SATELLITES ² CONCLUSIONS
2
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
“Nano satellites”: 1-50 kg
0 kg 1 kg 10 kg 100 kg 1000 kg
Source: SpaceWork report 2019
Pico-satellite Nano-satellite Micro-satellite Small/medium satellite
3
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
TEXT
Small satellites (1-50 kg) are increasing their launches because of their are increasing their launches because of their reduced cost, mass, fast development time, and increased reliability
The total space industry presents 1123 M€ final sales
Example of a nano satellite (CubeSat)
310 361 400 457 513 430 515 538 643 745 100 200 300 400 500 600 700 800 2013 2014 2015 2016 2017 2018 2019 2020 2021 2022 2023 Number of satellites Number of satellites Year ear
Small Medium Satellite (1-50 kg) Small Medium Satellite (1-50 kg)
Historical Launches Forecast Full Market Potential
Source: SpaceWork report 2019
4
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
5
Source: Spaceworks
Source: SpaceWork report 2019 Earth Observation/ Remote Sensing
mur-2 2 (Spire) pire)
Communications
PP (Kep eple ler Comm.) mm.)
Scientific
Ex
CO-A/Wa /Wall ll-E E (JPL)
Technology
ngchua huan1 n1 (Space Spacety ty)
Novel Applications
ch (LACMA) ACMA)
–
5
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
6
Source: Spaceworks
Source: E. Slejko
6
Mobile Calls Weather Forecast GPS Surveillance/Defense Sat TV Science Internet
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
7
Source: Nanosats.eu 2017
7
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
8
Source: Spaceworks
41% 10% 20% 27% 2% 57% 10% 27% 6% 1%
Historical (2014 – 2018)
Communica cations EO EO/RS Sc Scientific
Future (2019 – 2023)
Tech chnol
Novel Applica cations EO EO/RS Sc Scientific Tech chnol
Communica cations
–
Novel Applica cation
13
Source: SpaceWork report 2019
8
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
“As expected, 2018 was a record year for the emerging satellite internet-of- things market. Seven different commercial operators launched their first satellite(s) last year, and five of the seven launched more than one! Growth in this segment is surpassing even our initial predictions and promises to be a major driver of market growth in the future.”
Source: Spaceworks, 2019
“Satellite IoT is expected to be the largest driver of market growth in the future, and may be coming sooner rather than later ▪ Initial growth in the communications segment is greater than was seen in the early years of the Earth Observation & Remote Sensing segment.”
9
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
Telecommunications ² Telephone ² Internet ² Maritime ² Internet of Things Earth Observation ² Agriculture ² Disaster mitigation ² Transportation Science
Global space economy 339 B€
Source: SIA
111 82 286 327 430 100 200 300 400 500 2016 2017 2018 2019 2020
M €
Telecommunication elecommunication
Source:
10
Non-satellite industry, Ground equipment, Manufacturing and Launch Services
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
11
Design flexibility Low mission overall cost
Reduced mass
kg
In-orbit assembly Fast development time Poor data transmission Weak radio coverage
Space debris
Limited science capabilities
“We see the space as a resource for our community, hence our mission is to bring to the market reliable, cost-efficient and sustainable solutions to strengthen a European independent access to space” PICOSATS Founders
11
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
Italian Space Start-up developing an innovative miniaturized radio for a tele-communication system dedicated to small satellites for (near) future Internet of Things and 5G
Source: ESA
Superior data rate for small satellites First on the market 1st client already acquired (ESA)
Radio Modem Power Management Modular and customizable Reduced mission
€
Reduced mass
k g
Improve radio radio performances Improve radio coverage
12
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
Team di 12 people, mix di ingegneri elettronici, telecomunicazioni, meccanici e astrofisici 5 ingegneri R&S 1 Business Development 1 Company Development 1 Marketing consultant Co-fondatori: Anna Gregorio Mario Fragiacomo Alessandro Cuttin Mauro Messerotti CEO CTO PM Fondatore
PACINNO Granted as one of “Best Idea Winners” Winner Start-Cup FVG 2015 ESA contract for RADIOSAT H2020 – SME Instrument ph.1 grant Bando Premiale SPINAREA 2014” Space Exploration Master
13
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
14
Satellite Internet of Things and 5G services through satellite constellation
PICOSATS now
Miniaturized superior data transmission radio Novel high speed satellite transmitter Global earth coverage Modular polymeric satellite structure Modular rovers for planetary exploration
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
IoT is already used in our daily life, with a number of services providing information and data related to health and fitness, home-automation, security, smart cities, transportation, connected vehicles, industrial activities
² Ground infrastructures: hardly capable of affording these numbers; unable of providing global coverage, especially for what regards Earth remote regions (Arctic and Antarctic, Islands…) or even servicing large shipping company (fishing, cruising, cargo…) ² Providing such a service from Space, so called “Internet of Space” (IoS), would
Raman, Weigel, Lee, 2016
15
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
There is the perception of a sizeable gap between the demand of sats services in the maritime sector, the quality requirement of data, apart from the obvious integration with any available GNSS service on a worldwide scale, and the actual capacity of the offer
access area (Sentinels), from the big data networks, in situ, historical series… ² Services: security and remote medical care services necessary for all types of vessels and in particular the cruisers (medical diagnostics and emergency intervention from Ground service points), advanced meteorological parameters, salinity, temperature, pollution degree, surface wind of the water through in situ sensors networks and archive material, optimal routing assistance according to meteo and currents, etc.)
Source: Sciortino et al., 2017
16
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
The IoS system: the “ecosystem leveraging a satellite backbone in parallel with the existing wireline infrastructure”
Source: The Internet of Space (IoS): Raman, Weigel, Lee, 2016
17
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
Key elements ▪ Telecommunication system ▪ Modular mechanical structure ▪ Actuation System
Source: Cassini Huygens
18
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
In the IoT-scenario the spacecraft has to handle challenging link requirements ▪ Towards sensors and actuators spread around on the Earth’s surface,
collection tasks despite the significant orbit dynamics, ▪ Passing in almost real-time collected information towards a ground station .
Source: Proposal IOSmall
19
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
Key elements ▪ Directional telecommunication systems must be pointed to the relevant antenna during operations (ground station or other sat) ▪ This makes it hard to point at other targets ▪ Usual pan-tilt Actuation Systems for the antennae are complex and massive ▪ Our solution: a single degree of freedom actuation that, in tandem with the ADC system, allows pointing two targets at once .
Source: Proposal IOSmall
20
Actuation module
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
DVB-S2 modem
generation System-on-Chip
Performance
can be tuned independently Accomodation
Interfaces
K-2.92mm
(BBFRAMES) over LVDS Applications
Innovative miniaturized Ka Band transceiver designed for CubeSat and Small Satellites in LEO Frequencies:
MHz
Supported by
21
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
Reduced Mass
the complete structure for a 1U CS has mass lower than 100g In-orbit assembly
technologies Space debris mitigation
material Structural solution for building small satellites (CubeSats) with highly modular design by means of 3D printing technique. Modular and Customizable
can be combined in a highly unlimited way, meeting different payload-related volume requirements
Supported by
Fast delivery time
manufacturing and fast production processes
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
Thermal requirements
heat while functioning continuously at an output speed
Performance
electronics, cabling, flywheel system, structure): 1 kg
Performance
Interfaces
between side A and side B
Applications
node
Single degree of freedom actuation system for small satellites, designed to work in tandem with the ADC Speed:
rotational speed to effectively track ground objects at LEO.
23
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
Actuation system ▪ An An electrical electrical motor motor that drives the relative motion of the satellite sides ▪ Compensation Compensation system system: counter-rotating flywheel that compensate for the rotation
▪ This way we avoid overloading the ADC
24
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
BRICSAT • SME INSTRUMENT FASE 1 AREA SCIENCE PARK • 10 MAGGIO 2018
www.picosats.eu
“Added Value of Space ▪ IoT services may need remote or global interconnectivity, robust communication, positioning, precision timing, remote control, in-situ and remote sensors, technology for harsh environments, geo-information etc. Space assets, such as satellite communication, satellite navigation, Earth observation, or human spaceflight, can enable these capabilities”
Source: ESA
European Space Agency artes-apps.esa.int
→ FUNDING & SUPPORT FOR SPACE BASED SERVICES INTEGRATING THE ‘INTERNET OF THINGS’
Funding up to € 150 000 per Feasibility Study
Deadline 13 April 2017
25
Added Value of Nano satellites ▪ Nano satellites are market reliable, cost- efficient and sustainable solutions ▪ Nano satellites can quickly become ready as IoS solutions
SPIN-OFF UNIVERSITÀ DI TRIESTE INCUBATION AREA SCIENCE PARK
