SLIDE 1
Multi-modal Reasoning: Bridging Vision and Language
Heming Zhang
Media Communications Lab University of Southern California
2
Multi-modal Reasoning: Bridging Vision and Language Heming Zhang - - PowerPoint PPT Presentation
Multi-modal Reasoning: Bridging Vision and Language Heming Zhang - - PowerPoint PPT Presentation
Multi-modal Reasoning: Bridging Vision and Language Heming Zhang Media Communications Lab University of Southern California Personal Assistant AI Touchstone 2 The mass of an electron is approximately 9.109 10 -31 kg. 3 Has Personal
SLIDE 2
SLIDE 3
3
The mass of an electron is approximately 9.109×10-31 kg.
SLIDE 4
4
Has Personal Assistant Come True?
Illustration by Fiona Carswell
SLIDE 5
5
Vision & Language in MCL
Vision
- Object detection
- Semantic segmentation
- Video segmentation
Language
- Text classification
- Language graph learning
Vision & Language
- Visual dialogue
- Vision & Language
navigation
- Multi-modal machine
translation
SLIDE 6
6
- Dialogue that is grounded in vision
What is Visual Dialogue?
A man wearing leather jacket standing next to a motorcycle Is it colored leather? What color is his leather? Yes, it is.
SLIDE 7
7
- Aiding visually impaired users
- Aiding analysts
Why Visual Dialogue?
Daisy just sent you some pictures of her new house. Yes, there is a large living room with fireplace Great, is the living room large? Did anyone pass the gate yesterday? Were any of them carrying a cardboard box? Yes, 45 instances logged on camera.
SLIDE 8
8
From Information Point of View
Image Text
SLIDE 9
9
- Encoder-decoder framework
(Das et al., 2017, Lu et al., 2017, Wu et al., 2018, etc.)
– Encoder
- Embeds image, question and dialogue history
– Decoder
- Decodes the embedding to answers in natural language
Previous Work
Embedding Et Ât Qt , I , Ht
Encoder Decoder
SLIDE 10
10
- Lu et al., 2017, Wu et al., 2018, etc.
– Use one input as guidance to compute attention
- n another input
Previous multi-modal encoders
SLIDE 11
11
- Weighted-sum over features
Attention
Weights
c w h c
SLIDE 12
12
Attention with Guidance
𝒈 Weights
c w h c
SLIDE 13
13
- Lu et al., 2017, Wu et al., 2018, etc.
– Use one input as guidance to compute attention
- n another input
– Process inputs sequentially in pre-defined orders
Previous multi-modal encoders
SLIDE 14
14
- Lu et al. 2017
Encoders with Sequential Attention
What color is his leather? A man wearing leather jacket standing next to a motorcycle Is it colored leather? Yes, it is.
SLIDE 15
15
- Wu et al., 2018
Encoders with Sequential Attention
What color is his leather? A man wearing leather jacket standing next to a motorcycle Is it colored leather? Yes, it is.
SLIDE 16
16
- Cannot accommodate to different scenario’s
- How many people are there in the image?
- Is there anything else on the table?
Previous multi-modal encoders
SLIDE 17
17 E FI FQ FH
Adaptive reasoning
FI FQ FH Reasoning RNN fg, i i = imax ? No Yes Guided Attention Guided Attention Guided Attention fI, i fH, i fQ, i fQIH, i Comprehension Exploration
SLIDE 18
18
Attention Visualization
Is the little boy on a beach? How old does he look?
SLIDE 19
19
Attention Visualization
How old does he look? What color hair does he have?
SLIDE 20
20
Attention Visualization
What color hair does he have? Is he dressed for summer?
SLIDE 21
21
Attention Visualization
What color is the airplane? Time step i=1
SLIDE 22
22
Attention Visualization
What color is the airplane? Time step i=2
SLIDE 23
23
Qualitative results
4 ducks are in a grassy island of a parking lot with their heads down
SLIDE 24
24
Qualitative results
4 ducks are in a grassy island of a parking lot with their heads down Questions Human Ours Any grass? Yes Yes, a lot of grass What color grass? It is green with brownish dead spots Green and brown
SLIDE 25
25
Qualitative results
4 ducks are in a grassy island of a parking lot with their heads down Questions Human Ours Any vehicles on the lot? Yes Yes, there are a lot of cars Do they look new or old? They look new They look new
SLIDE 26
26
Generative Visual Dialogue System via Weighted Likelihood Estimation
Heming Zhang, Shalini Ghosh, Larry Heck, Stephen Walsh, Junting Zhang, Jie Zhang, C.-C. Jay Kuo
Thursday Aug. 15th 09:30 - 10:30 AM CV|LV - Language and Vision 2 (2501-2502)
IJCAI 2019
SLIDE 27
27
- What is visual dialogue?
- Dialogue that grounded in vision
Vision-grounded Problems Revisited
A man wearing leather jacket standing next to a motorcycle Is it colored leather? What color is his leather? Yes, it is.
SLIDE 28
28
- From information point of view
Vision-grounded Problems Revisited
Image Text
SLIDE 29
29
Vision-grounded Problems Revisited
- No alignment between image & text manifolds
Image Text
SIFT BoW CNN … RNN Transformer …
SLIDE 30
30
Bridging Vision & Language
Image Text
?
SLIDE 31
31
Bridging Vision & Language
Image Text Joint
- Manifold alignment
SLIDE 32
32
- Usually one-to-one mapping in other
manifold alignment problems
– E.g. machine translation
Bridging Vision & Language
English Dutch Joint I like you I take you with me Ik hou van jou Ik neem je mee
SLIDE 33
33
- Alignment between vision and language
– No one-to-one mapping
Bridging Vision & Language
Image Text Joint
SLIDE 34
34
- Weighted-sum over features
Attention Revisited
Weights
c w h c
SLIDE 35
35
- Alignment by attention
– Joint learning of attention and alignment
Bridging Vision & Language
Image Text Joint
SLIDE 36
36
Related Research in MCL
Vision
- Object detection
- Semantic segmentation
- Video segmentation
Language
- Text classification
- Language graph learning
Vision & Language
- Visual dialogue
- Vision & Language
navigation
- Multi-modal machine
translation
SLIDE 37
37
- Instructions in natural language
– Walk down and turn right.
- Surrounding environment in vision
Vision-and-language Navigation
SLIDE 38
38
- Leave the room into the hall and go straight.
- Head towards the stairs.
- Stop on the round rug next to the flowers.
Co-attention between Vision & Language
SLIDE 39
39
Unsupervised Multi-modal Neural Machine Translation
SLIDE 40
40
- Lab director: Prof. C.-C. Jay Kuo
- Visiting scholars
- PhD students
- Master students
Media Communication Lab
