MULTI LINE E The modular connection system for electrical and electronic connections MINIMISED SETUP TIMES FLEXIBLE CONFIGURATION For automation, plant engineering and ELECTRONIC control technology AND ELECTRIC CONNECTIONS FLEXIBLE
SLIDE 2
SLIDE 3
MULTILINE E combines different interfaces. The adaptive inserts can be equipped as needed with M12 round connectors or other connector types for bus systems, control technology and power supply. In addition, hose connections can be integrated.
FLEXIBLE CONFIGURATION
www.eisele.eu
SLIDE 4
Diverse combinations of different connector types and media result in a genuine modular kit system. Later modifications or conversions of the modular system are easy to implement. The replacement of entire functional groups or tools with a flick of the wrist minimises machine setup times.
MINIMISED SETUP TIMES
www.eisele.eu
SLIDE 5
The highly reliable multiple connector MULTILINE E combines multiple electrical or electronic connections. The E-connector line with the widely used and standardised M12 round connectors is available in different versions: A-coding, Cube6, Profibus, Ethernet and three to twelve pins.
ELECTRONIC AND ELECTRIC CONNECTIONS
www.eisele.eu
SLIDE 6
The M12 power connector in accordance with IEC 61076-2-111 is the smallest and most compact connector for cables with wires up to 2.5 mm2. The adaptive insert with five power contacts supplies up to 16 A per pin. The power connector is protected against reverse polarity, vibrations and shock.
M12 POWER CONNECTOR
www.eisele.eu
SLIDE 7
- Fast, connection and disconnection without tools
- Frequent mounting and removal possible
- Individual pre-configured connection cable
- Minimum installation space
- Unproblematic combination with gases, pneumatics and fluids
- Best quality material, durable and robust
- Very high flexibility
WORLD INNOVATION: MULTILINE E
www.eisele.eu
SLIDE 8
Diversity of variants Saves time and space High-quality workmanship MULTILINE E with union nut
SLIDE 9
tool-free mounting & dismounting MULTILINE E with locking lever coding patterns prevent incorrect connections Optimized coupling & uncoupling
SLIDE 10
Design of the MULTILINE E/ADAPTIVE
www.eisele.eu
MULTILINE E Modular connections for electronics, electric power, pneumatics, gases and fluids
SLIDE 11
Combinable with adaptive inserts Mounting bracket for easy fixation Compatible with standard industrial connectors MULTILINE Industrial connector
SLIDE 12
“From the design through to delivery and beyond we guarantee the premium quality of Eisele products” Klaus Harsch, Design Engineer
- 100 % Made in Germany
- Solid metal connections
- Durable and robust
- Maximum reliability
EISELE quality
www.eisele.eu
SLIDE 13
Robust and durable Base body of stainless steel / anodised aluminium Countless possible variations Easy installation and handling
CHECKLIST MULTILINE E
www.eisele.eu
SLIDE 14
Reduced machine setup times Flexible configuration Compact installation space Anti-twist and reverse polarity protection
www.eisele.eu
CHECKLIST MULTILINE E
SLIDE 15
Eisele Pneumatics GmbH & Co. KG High-quality connection components for compressed air, gases and fluids Hermann-Hess-Str. 14–16 D-71332 Waiblingen Phone +49 (0)7151-1719-0 Fax +49 (0)7151-1719-17 info@eisele.eu
Do you still have questions? We will be glad to advise you!
