SLIDE 1
MOTOR LEARNING IMAGINARY TRAINING NATALIE MRACHACZ-KERSTING USING - - PowerPoint PPT Presentation
MOTOR LEARNING IMAGINARY TRAINING NATALIE MRACHACZ-KERSTING USING - - PowerPoint PPT Presentation
MOTOR LEARNING IMAGINARY TRAINING NATALIE MRACHACZ-KERSTING USING A BRAIN-COMPUTER-INTERFACE FOR MOTOR LEARNING NATALIE MRACHACZ-KERSTING Motor Learning involves neuroplasticity The ability of the nervous system to reorganize neural
SLIDE 2
SLIDE 3
Motor Learning involves neuroplasticity
The ability of the nervous system to reorganize neural pathways based on:
learning new skills recovery from injury artificial induction
SLIDE 4
Mechanisms of neuroplasticity
- Persistent changes in synaptic efficacy
proposed by Hebb, 1949; review refer to Sanes & Donoghue, 2000; Cook & Bliss, 2006
- D.O. Hebb and synaptic plasticity:
- Synaptic terminals strengthened by
correlated activity will be retained or sprout new branches.
- Synaptic terminals that are
persistently weakened by non- correlated activity will eventually loose their hold on the post-synaptic cell.
SLIDE 5
Paired Associative Stimulation (PAS) in humans
- Effects following PAS are:
- dependent on the timing
between the two stimuli
- specific to the target muscle
- rapidly evolving
- persist upon cessation of the
stimulation period
For a comprehensive review refer to Ziemann et al. (2008) Stefan et al. (2000)
SLIDE 6
Paired Associative Stimulation (PAS) in humans
Professor Janne Avela Dr Susanne Kumpulainen
SLIDE 7
PAS requires two artificial stimuli: TMS and ES
SLIDE 8
The movement related cortical potential as part of PAS
Professor Dario Farina Goettingen, DE Canada Denmark
- Dr. Ning Jiang
- Dr. Kim Dremstrup
SLIDE 9
Brain Computer Interfaces (BCI)
Applications:
- Communication
- Gaming
- Rehabilitation
Signal Acquisition:
- Invasive (ECoG, intra-
cortical, etc.)
- Non-invasive (EEG)
Modes:
- Synchronous/cued
- Asynchronous/self-paced
Control Brain Signals:
- ERD/ERS, P300
- MRCP (CNV or
Bereitschaftspotential)
- etc.
[* adapted from Wolpaw et al., 2012]
SLIDE 10
The movement related cortical potential as part of PAS
SLIDE 11
Real movements Imaginary movements
do Nascimento et al. 2005
The movement related cortical potential
SLIDE 12
The movement related cortical potential as part of PAS
SLIDE 13
Associativit y
Mrachacz-Kersting et al. (2012) J Physiol
SLIDE 14
Associativity and Specificity
Mrachacz-Kersting et al. (2012) J Physiol
SLIDE 15
Chronic stroke patients
Mrachacz-Kersting et al. J Neurophysiol (2016)
SLIDE 16
Chronic stroke patients – BCIassociative intervention
TMS intensity [%S.O.]
45 50 55 60 65 70
TA p-p MEP amplitude [V]
200 400 600 800 1000 1200 pre-intervetion post-intervention 30 min post-intervention
Mrachacz-Kersting et al. (2016) J Neurophysiol
SLIDE 17
Chronic stroke patients - BCIassociative intervention
TMS intensity [%S.O.]
45 50 55 60 65 70
TA p-p MEP amplitude [V]
200 400 600 800 1000 1200 pre-intervetion post-intervention 30 min post-intervention
10 m walk test: Pre: 15.5 s Post 10.5 s Foot Tap Frequ: Pre: 2.31 Hz Post: 3.42 Hz Finger Tap Frequ: Pre: 3.17 Hz Post: 3.18 Hz
Mrachacz-Kersting et al. (2016) J Neurophysiol
SLIDE 18
Chronic stroke patients – BCInon-associative intervention
TMS intensity [%S.O.]
40 45 50 55 60 65 70 75
TA p-p MEP amplitude [V]
200 400 600 800 1000 1200 1400 1600
pre-intervetion post-intervention 30 min post-intervention Mrachacz-Kersting et al. (2016) J Neurophysiol
SLIDE 19
Chronic stroke patients - BCInon-associative intervention
TMS intensity [%S.O.]
40 45 50 55 60 65 70 75
TA p-p MEP amplitude [V]
200 400 600 800 1000 1200 1400 1600
pre-intervetion post-intervention 30 min post-intervention
10 m walk test: Pre: 8.03 s Post 8.05 s Foot Tap Frequ: Pre: 4.03 Hz Post: 3.8 Hz Finger Tap Frequ: Pre: 0.53 Hz Post: 0.53 Hz
Mrachacz-Kersting et al. (2016) J Neurophysiol
SLIDE 20
Acute stroke patients
TMS intensity [%S.O.]
40 45 50 55 60 65 70
TA p-p MEP amplitude [V]
200 400 600 800 1000
Day 1
pre-intervetion post-intervention 30 min post-intervention
SLIDE 21
Acute stroke patients
MRCP
Day 6
TMS intensity [%S.O.]
35 40 45 50 55 60 65
TA p-p MEP amplitude [V]
200 400 600 800 1000 pre-intervetion post-intervention 30 min post-intervention
SLIDE 22
Acute stroke patients
MRCP
TMS intensity [%S.O.]
35 40 45 50 55 60 65
TA p-p MEP amplitude [V]
200 400 600 800 1000
Day 12
pre-intervetion post-intervention 30 min post-intervention
SLIDE 23
Acute stroke patients
TMS intensity [%S.O.]
35 40 45 50 55 60 65
TA p-p MEP amplitude [V]
200 400 600 800 1000
Day 12
pre-intervetion post-intervention 30 min post-intervention
10 m walk test: Pre: 8.47 s Post 5.52 s LE-FM: Pre: 24/34 Post: 33/34
SLIDE 24
Acute stroke patients
TMS intensity [%S.O.]
30 35 40 45 50 55 60
TA p-p MEP amplitude [V]
200 400 600 800 1000 pre-intervetion post-intervention 30 min post-intervention
TMS intensity [%S.O.]
84 86 88 90 92 94 96 98 100
TA p-p MEP amplitude [V]
50 100 150 200 250 300 pre-intervetion post-intervention 30 min post-intervention
SLIDE 25
HIGH LEVEL ATHLETES
Other applications for the MRCP in motor learning
SLIDE 26
Improving athletic performance using real-time neurofeedback
Susan Aliakbaryhosseinabadi Fabiano Landi Xuxian Yin Professor Uwe G. Kersting
SLIDE 27
BCI for improving athletic performance using real-time neurofeedback
Susan Aliakbaryhosseinabadi Fabiano Landi Xuxian Yin Uwe G. Kersting
SLIDE 28
Special Thanks!
The Chronic study team:
- Vladimir Kostic
- Sasa Radovanovic
- Aleksandra Pavlovic
- Ning Jiang
- Dario Farina
- The patients
The Acute study team:
- Andrew JT Stevenson
- Helle Jørgensen
- Margherita Castronovo
- Kåre E Severinsen
- Jakob Blicher
- Anna C Lundgaard
- Margherita Castronovo
- Fabiano Landi
- Susan
Aliakbaryhosseinabadi
- The patients
The athletic team:
- Uwe G Kersting
- Susan
Aliakbaryhosseinabadi
- Fabiano Landi
- Xu Xian
- The participants
The funders:
- The Obels Family
Foundation
- Spar Nord Fonden
- Lundbeck Fonden
- EU – SEP-210192113
