Monroe Avenue Complete Streets Del Ray Citizens Association Novem ber 1 2 , 2 0 1 4 Complete Streets Streets that are designed to consider the safety and Monroe Avenue Complete Streets convenience of all users of the transportation

SLIDE 1

Del Ray Citizens’ Association Novem ber 1 2 , 2 0 1 4

Monroe Avenue Complete Streets

SLIDE 2

Monroe Avenue Complete Streets

Complete Streets

“Streets that are designed to consider the safety and convenience of all users of the transportation system including pedestrians, bicyclists, transit users, freight, and motor vehicle drivers and ensure that the needs of all users shall be accommodated and balanced so that even the most vulnerable – children, elderly, and persons with disabilities – can travel safely within the public right-of way.”

SLIDE 3

Monroe Avenue Complete Streets

City Plans and Policies

City Council Goal # 3: A multimodal transportation

network that supports sustainable land use and provides internal mobility and regional connectivity for Alexandrians

Complete Streets Policy: Alexandria shall

incorporate Complete Streets infrastructure into existing public streets to improve the safety and convenience of users and construct and enhance the transportation network for all users

Transportation Master Plan: Implement a

citywide bikeway network to serve all users and trip types, provide end-of-trip facilities, improve bicycle/ transit integration, implement encouragement programs and improve safety

Pedestrian and Bicycle Mobility Plan

SLIDE 4

Monroe Avenue Complete Streets

Monroe Avenue Project Background and Civic Engagement

Spring 2013 – Community requests for traffic

calming on Monroe Ave.

September 2013 - Data collection
October 2013 - Community meeting
February 2014 – Monroe Ave. listed on

resurfacing schedule

March 2014 - Expanded project scope to include

Complete Streets design

May 2014 – Public meeting # 1
Sept 2014 – Public meeting # 2
November 2014 – Del Ray Citizen’s Association

SLIDE 5

Monroe Avenue Complete Streets

Project Limits

Section 1: Leslie Ave. to Mt. Vernon Ave.
Section 2: Mt. Vernon Ave. to Commonwealth Ave.
Section 3: Commonwealth Ave. to Stonewall Rd.

1 2 3 5

SLIDE 6

Monroe Avenue Complete Streets

Community Comments

SLIDE 7

Monroe Avenue Complete Streets

Response to Concerns

Most com m ents were incorporated

into proposal

Intersection improvements
Pedestrian crossing improvements
Speed reduction
A few com m ents will be address

through other projects

Safe Routes to School
Som e com m ents will be addressed

with redevelopment

Bury power lines
Modify curb lines

SLIDE 8

Monroe Avenue Complete Streets

Important Considerations

City Council adopted plans
Transportation Master Plan
Pedestrian and Bicycle Mobility Plan
Complete Streets Policy
Consider all street users
Accessibility requirements
Provide facilities for people with disabilities
Emergency vehicle requirements and access
Right of way constraints
Existing and future development
Cost

SLIDE 9

Monroe Avenue Complete Streets

Section 3: Commonwealth Ave. to

Stonewall Rd.

3 9

SLIDE 10

Monroe Avenue Complete Streets

Monroe Ave. at Russell Rd.

Install pedestrian countdown signals Upgrade crosswalks Install new crosswalk across Russell Rd.

N

SLIDE 11

Monroe Avenue Complete Streets

Monroe Ave. between Hancock Ave. & Russell Rd.

Add 10 parking spaces- narrow travel lanes Add cross walks across Hancock Add parking stripe along Monroe

N

SLIDE 12

Monroe Avenue Complete Streets

Section 2: Mt. Vernon Ave. to

Commonwealth Ave.

2 13

SLIDE 13

Monroe Avenue Complete Streets

Monroe Ave. at Commonwealth

Ave. - Proposed

Add 10 parking spaces- narrow eastbound travel lane Add curb extension – Relocate 1 parking spaces, shorten crossing distance & align crosswalks Install pedestrian signals

N

SLIDE 14

Monroe Avenue Complete Streets

Monroe Ave. at Wayne St. and Newton St.

Add curb extension – relocate 1 parking space, shorten crossing distance & create ADA bus stop Install concrete bus pad for ADA bus stop Install new crosswalk Provide parking stripe and edge line Install crosswalks

n side streets

Install shared bike lane symbols

N

SLIDE 15

Monroe Avenue Complete Streets

Section 1: Leslie Ave. to Mt.

Vernon Ave. - Pedestrian

1 18

SLIDE 16

Monroe Avenue Complete Streets

Mt. Vernon Ave. at Monroe
Ave. - Proposed

Upgrade crosswalks Install leading pedestrian interval for crossing north and south legs of Monroe Install “No Right Turn on Red” restrictions for EB and WB turns

N

SLIDE 17

Monroe Avenue Complete Streets

Monroe Ave. at Dewitt Ave.

Remove crosswalk Install sidewalk extension and crosswalk Install parking lane stripes Install crosswalks for side streets

N

SLIDE 18

Monroe Avenue Complete Streets

Proposed Crosswalks

N

SLIDE 19

Monroe Avenue Complete Streets

Section 1: Leslie Ave. to Mt.

Vernon Ave. – Bicycle Options

1 23

SLIDE 20

Monroe Avenue Complete Streets

Existing Conditions

24 No Parking Parking North side: 18 total spaces South side: 21 total spaces

SLIDE 21

Monroe Avenue Complete Streets

Option 1 – bike lanes between Leslie (2) and Mount Vernon

N

SLIDE 22

Monroe Avenue Complete Streets

Proposed Parking – Option 1

No Parking Existing Parking New Parking North side: 0 total spaces South side: 40 total spaces

SLIDE 23

Monroe Avenue Complete Streets

Option 2 – Eastbound bike lane to Leslie (2)

N

SLIDE 24

Monroe Avenue Complete Streets

Proposed Parking – Option 2

No Parking Existing Parking New Parking North side: 9 total spaces South side: 40 total spaces

SLIDE 25

Monroe Avenue Complete Streets

Thank You. Questions, Comments and Discussion

Hillary.Poole@AlexandriaVA.gov

SLIDE 26

Monroe Avenue Complete Streets

Next Steps

Traffic and Parking Board
Curb and gutter work Spring/ Summer

2015

Summer 2015 Implementation
