MODUS Light ACOUSTIC PANELS MODUS Light Sound absorbing wall and ceiling panels with different depths improve office acoustics and create an inspiring and functional interior solution. Panel structure Fabric Velcro stripe HDF (3 mm)

SLIDE 1

MODUS Light

ACOUSTIC PANELS

SLIDE 2

MODUS Light

Sound absorbing wall and ceiling panels with different depths improve office acoustics and create an inspiring and functional interior solution.

SLIDE 3

Panel structure

Fabric Acoustic foam (40/60 mm) Velcro stripe HDF (3 mm)

SLIDE 4

Sound absorption class

f acoustic foam according to DIN EN ISO 354 standard

Panel thickness – 48 mm Panel thickness – 68 mm Improves acoustic comfort by efficiently absorbing a wide range of frequencies. A superior absorber of low frequencies compared to C class. Tunes the room in the range of high and midfrequencies, therefore creates a more pleasant ambient sound experience.

SLIDE 5

Sound absorption

f acoustic foam according to DIN EN ISO 354 standard

SLIDE 6

Range

Acoustic panels for Armstrong ceiling from 600x600 mm modules Wall and ceiling acoustic panels

48 or 68 mm thickness available for all acoustic panels.

300x300 mm 600x300 mm 600x600 mm 575x575 mm

SLIDE 7

Wall and ceiling Armstrong ceiling Wire rope for ceiling pendant Metal fittings for ceiling (fixing included)* Adhesive fittings Screwed fittings Ceiling pendant Wire rope

Fixing types

* For Armstrong ceiling from 600x600 mm modules

SLIDE 8

MODUS Light

SLIDE 9

Elsworth House Herries Road South Sheffield S6 1QS t: 0114 232 7402 e: sales@hyphensales.co.uk w: www.hyphensales.co.uk
