Mobile CORD (M-CORD)

• Enabling 5G on CORD

SVP of R&D, Network IT Convergence

Kang-Won Lee (kangwon@sk.com)

Operator Challenges

State of the infrastructure: Built with closed proprietary boxes

• Inefficient utilization (including sub-optimal use of radio resources)
• Inability to customize for different users
• Slow in creating innovative services
• Cannot support industry-specific IoT scenarios

Mobile infrastructure needs re-architecting for 5G

 Agile and cost-efficient deployment

M-CORD Objectives

 Provide customized services and better QoE to customers  Enhance resource utilization

• On-demand deployment
• Virtualized /disaggregated RAN and EPC
• Commodity H/W and open source
• Customized service composition
• Reduced latency and increased throughput
• Differentiated QoE based on service requirements
• Real-time resource management
• Exploit multiple RATs
• Monitoring & analytics framework

Best of Mobile + CORD

Open Control Interfaces Cloud-Agile Service Customization Dynamic radio resource

• ptimization

Network Slicing Deep Observability MME, SGW, PGW Mobile Edge Services Caching, SON, Billing Disaggregated /Virtualized RAN Disaggregated /Virtualized EPC BBU, RRU front haul fabric Programmable Data Plane

SDN Control Plane

• ONOS

NFV Orchestration w/XOS

SDN Fabric Commodity servers, switches, network access

+

White Box White Box White Box White Box White Box White Box White Box White Box White Box White Box White Box White Box White Box White Box White Box White Box

Non-Local Service Central/Core DC PGW INTERNET Local Service M-CORD mobile edge M-CORD mobile edge

M-CORD mobile edge service flow

• Benefits to users
• Enhanced QoE with low latency, high-throughput and customized services
• Benefits to operators
• Optimal resource utilization, agile & scalable services, revenue opportunities
• Use cases
• Content delivery, smart cities, health care, education, industrial IoT, enterprise services

“Mobile edge, where operators can leverage their core competencies to overcome their limitations”

XOS (Service Orchestration)

Mobile Edge Services

Disaggregated/Virtualized RAN Disaggregated/Virtualized EPC

White Box White Box White Box White Box White Box White Box White Box White Box White Box White Box White Box White Box White Box White Box White Box White Box

ONOS (Networking) OpenStack

VTN Nova Ceilometer Neutron RAN/EPC Control Control APPs

[ Mobile Edge ]

Content Caching vSGW vPGW-D vBBU vBBU MME EPC Control Functions Centralized EPC MME PGW

[ Mobile Core ] RRUs

vPGW-C PCRF

M-CORD PoC Architecture

M-CORD Vision 5G Enabling Platform

• Enable virtualized/disaggregated RAN and Core
• Deploy network functions as services
• Leverage best practices of SDN, NFV, Cloud
• At mobile edge (but not limited to it!)

• 1. RAN/EPC disaggregation

– Disaggregate control-plane / user-plane of eNB and EPC

• 2. Connectionless Service

– Provide light and efficient connectivity for IoT use cases

• 3. Real-time analytics (A-CORD)

– Employ analytics framework for real-time monitoring and reacting

• 4. Mobile edge computing

– Develop customized edge service use cases for subscribers and enterprises

• 5. Network slicing

– Provide flexible logical networks that supports use cases with different requirements

M-CORD Roadmap

Thank you!

Kang-Won Lee (kangwon@sk.com)

SVP of R&D, SK Telecom
