Mental Models

CMSC 691R - Human-Robot Interaction March 7th, 2019 Luke Richards

What is a Mental Model?

• What do you see?
• What are some descriptive words you

would use to describe this object?

What is a Mental Model?

• “Mental models generally describe a

person's representation of what the external world might be or how it might work” - Hwang 2005

• Internal Representation
• Human ‘expectations’ of the world around them
• In HRI, this is ‘projectioning’ this mental model
• nto the robot’s capabilities

What is a Mental Model?

• What do you see?
• What are some descriptive words you

would use to describe this object?

Which would you ask to make you dinner?

Types of Mental Models

Shared Grounds Robot’s Mental Model Human’s Mental Model

Why Consider Mental Models?

• Usability
• Efficiency of Interaction
• Capability understanding
• Information Transfer
• Advantage of Previous Mental Models in

Design

• Familiar symbols
• Physical morphology that relates to job
• Emotional/cognitive support with

nostalgic influences

Changing Someone’s Mental Model

• Hard or easy?
• The proposed solution must offer

significant value

• Redefining what a phone is (iPhone)
• Clashing mental models between designer

and user

Double-loop learning

Hard

Robot’s “Mental” Model

• How?
• Static programming
• Dynamic: Machine Learning
• For?
• Environmental understanding
• Emotional understanding
• Various other tasks of

comphrenedening the world around it

Paper #1:

‘The role of mental model and shared grounds in human-robot interaction’ Jung-Hoon Hwang, KangWoo Lee, and Dong-Soo Kwon , 2005

• Overview of Mental Models in HRI
• Multimodal Icon Language Interface
• User Study

Multimodal Icon Language Interface

Experiment

• 6 subjects with no experience operating a robot. Only one had

experience programming in general

• Phases:
• Pre-interaction
• Interaction
• Post-interaction

Results

• Measured the change of the user’s

perceived difficulty of operating the robot

• Interaction can lead to assumptions

about the robot that aren’t true

• Robot being able to move a

table

Paper #1 Discussion

• What did we like?
• What did we dislike?
• Thoughts on technical system?
• Discussion:
• Did the work achieve what it set out to do?
• Did they measure enough using the metric(s)?
• Would this concept be more effective in with technologies from 2019
• pposed to 2005?

Paper #2

‘Situated Language Understanding with Human-like and Visualization-Based Transparency’ Leah Perlmutter, Eric Kernfeld and Maya Cakmak, 2016

• LUCIT System
• Grounded Language System
• Transparency
• Video

Situated Language Understanding

• Used Bayesian Network to model

environment, language and gesture

• Action Context model
• Parameterization model
• Gesture model
• Language model

Types of Interaction

• Human-like transparency
• Speech
• Poining
• Gaze

Types of Media Used

• Screen
• Virtual Reality (VR)

Hypotheses

• H1: Adding visualization-based transparency after natural

transparency will positively impact communication.

• H2: By improving the user’s mental model, visualization based

transparency will improve communication even after it is removed.

• H3: The medium in which visualizations are provided will not

impact communication.

User Study

• Mostly fluid interactions
• No pointing/pointing
• Changing transparency

medium

• Removing medium after in

Phase 2

Qualitative Results

• “... I learned the way that the system sees my pointing. I found it

was accurate on the right side of the room but it was difficult [..] on the left side of the room..”

• “Based on my observation from this round, I see that [the robot] has

a much richer perception of the environment around her, and is probably much less controlled by a human during the experiment than I had initially thought.”

• “... understood in this round what went wrong when [it] did not

understand me: for instance, mis-translating ‘dust’ as ‘does’ and thereby not recognizing the action word in the command.”

Results

Results

Paper #2 Discussion

• What did we like?
• What did we dislike?
• Thoughts on technical system?
• Discussion:
• Did the work achieve what it set out to do?
• Did they measure enough using the metric(s)?
• When should a transparency method be present?
• How does this work compare to Paper 1? 2005 to 2016?
• Programming language design and HRI/HCI?
