Company Presentation May 2011 1. Company 1.1. About us Founded in Jena in 2010 as an independent engineering company Two partners with complementing skills and backgrounds in optics - Optical design - Sales of optical components - Optical

SLIDE 1

Company Presentation May 2011

SLIDE 2

1. Company

1.1. About us

Founded in Jena in 2010 as an independent engineering company Two partners with complementing skills and backgrounds in optics

B5-Optics UG (haftungsbeschränkt) | Krautgasse 26 | 07743 Jena | Germany

Optical design
Optical testing, IR/VIS system testing
Opto-mechanical design
Radiometry
Sales of optical components
Purchase of optical products
Marketing

SLIDE 3

1. Company

1.2. Services

Optical and opto-mechanical design

Design and development of new products
Analysis and optimization of existing designs

Consultancy and feasibility studies Sales of optical components and assemblies

B5-Optics UG (haftungsbeschränkt) | Krautgasse 26 | 07743 Jena | Germany

SLIDE 4

2. Design Capabilities

2.1. UV Optics

Single focal length objectives

Motorized focus
F/# < 1

Microscope objectives (NA > 1)

B5-Optics UG (haftungsbeschränkt) | Krautgasse 26 | 07743 Jena | Germany

SLIDE 5

2. Design Capabilities

2.2. Visual Optics (VIS + NIR)

Single FOV objectives Vari-focal length objectives Motorised continuous zoom Wide angle fast objectives Microscope objectives

B5-Optics UG (haftungsbeschränkt) | Krautgasse 26 | 07743 Jena | Germany

SLIDE 6

2. Design Capabilities

2.3. SWIR and MWIR Optics

Single focal length objectives

Motorized focus

Vari-focal length objectives Motorized continuous zoom Two colour beam expanders

B5-Optics UG (haftungsbeschränkt) | Krautgasse 26 | 07743 Jena | Germany

SLIDE 7

2. Design Capabilities

2.4. LWIR Optics

Single focal length objectives

Motorized focus
F/# < 1

Vari-focal length objectives Motorized continuous zoom

B5-Optics UG (haftungsbeschränkt) | Krautgasse 26 | 07743 Jena | Germany

SLIDE 8

3. Markets & Applications
3. Markets and Applications

Thermal Imaging Metrology Systems for Calibration and Inspection Life Science Medical Technology Laser Applications Aerospace

B5-Optics UG (haftungsbeschränkt) | Krautgasse 26 | 07743 Jena | Germany

SLIDE 9

4. Example Products

4.1. Example Products I

Cooled MWIR zoom objectives Multi-spectral, multi-channel VIS/NIR systems Industrial monitoring & measurement systems Multi-spectral (UV, VIS, IR) integrated objectives (common aperture)

B5-Optics UG (haftungsbeschränkt) | Krautgasse 26 | 07743 Jena | Germany

SLIDE 10

4. Example Products

4.2. Example Products II

Dual field of view IR lenses for uncooled 8-12 micron IR sensors NIR laser zoom lens Optical system calibration systems Optical measurement equipment Two-colour objectives, refractive & reflective

B5-Optics UG (haftungsbeschränkt) | Krautgasse 26 | 07743 Jena | Germany

SLIDE 11

5. Contact
5. Contact Details

B5-Optics UG (haftungsbeschränkt) Krautgasse 26 07743 Jena | Germany Tel: +49 (0) 3641 5415521 Fax: +49 (0) 3641 5431646 Web: www.b5-optics.com

B5-Optics UG (haftungsbeschränkt) | Krautgasse 26 | 07743 Jena | Germany
