Willkommen Welcome Bienvenue Materials Innovation for Next-Generation Batteries Corsin Battaglia SCCER HaE Annual Symposium 2018 SCCER Heat and Electricity Storage www.sccer-hae.ch Next-generation lithium-ion batteries Cathode Anode Team
SLIDE 2
SLIDE 3
Next-generation lithium-ion batteries
State-of-the-art: 220 Wh/kg SCCER target: 275 Wh/kg
Cathode Team Battaglia Empa Anode Team Kovalenko ETH/Empa
SLIDE 4
70% after 500 cycles
Energy density on cell level
Charge 0.5 C Discharge 1.0 C Temperature 25°C Remaining capacity 70% DOD 0%-100%, 500 cycles DOD 6%-94%, 7’500 cycles DOD 8%-92%, 15’000 cycles DOD 10%-90%, 28’000 cycles DOD 20%-80%, 35’000 cycles
http://blog.evandmore.com/lets-talk-about-the-panasonic-ncr18650b/
last 10% capacity during 70 min 90% after 180 cycles
Panasonic NCR18650B LG INR MJ1 Samsung SDI INR 35E
SLIDE 5
How to reach 220 Wh/kg?
Synthesis
- Automated co-precipitation reactor
- Shape controlled synthesis
- Validation with NMC111
30 Wh/kg
SLIDE 6
How to reach 220 Wh/kg?
- Slurry formulation
- Tape casting
- Drying and calendering
- Automated co-precipitation reactor
- Shape controlled synthesis
- Validation with NMC111
Synthesis Coating
150 Wh/kg
SLIDE 7
220 Wh/kg
How to reach 220 Wh/kg?
- Slurry formulation
- Tape casting
- Drying and calendering
Stacking
- Stacking
- Automated co-precipitation reactor
- Shape controlled synthesis
- Validation with NMC111
Synthesis Coating
Team Fürst BFH
SLIDE 8
How to go beyond 220 Wh/kg?
- Increase nickel content
- Reduce cobalt content
- Gain in energy density & cost reduction
- Sacrificial electrolyte additives
- 91% capacity retention after 200 cycles
- Still suffer from impedance growth
Electrolyte Synthesis
Vidal Laveda et al. in preparation
275 Wh/kg
SLIDE 9
Non-flammable electrolytes
- Stability window of water 1.23 V
- High salt concentration to reach 2.6 V
- 77% capacity retention after 500 cycles
Kühnel et al. Chem. Comm. 2016 Kühnel et al. ACS Energy Express 2017 Reber et al. ACS Sust. Energy Fuels 2017 Reber et al. submitted
SLIDE 10
Non-flammable electrolytes
- Stability window of water 1.23 V
- High salt concentration to reach 2.6 V
- 77% capacity retention after 500 cycles
Kühnel et al. Chem. Comm. 2016 Kühnel et al. ACS Energy Express 2017 Reber et al. ACS Sust. Energy Fuels 2017 Reber et al. submitted
SLIDE 11
Non-flammable electrolytes
- Stability window of water 1.23 V
- High salt concentration to reach 2.6 V
- 77% capacity retention after 500 cycles
Kühnel et al. Chem. Comm. 2016 Kühnel et al. ACS Energy Express 2017 Reber et al. ACS Sust. Energy Fuels 2017 Reber et al. submitted
SLIDE 12
B12H12
2-
B10H10
2-
Na+
Solid-state electrolytes
Duchêne et al. Chem. Comm. 2017 Yan et al. Adv. Energy Mater. 2017 Roedern et al. Sci. Reports 2017 SNF Sinergia w/ UniGe & PSI
- Closoborate salts
- Suppression of transition by 1:1 anion mixing
- Thermally stable up to at least 300 °C
- ~1 mS/cm at room temperature
SLIDE 13
- 3 V stability window
- Compatible with sodium metal anode
- Low overpotential for sodium plating/stripping
3.0 V plating
Solid-state electrolytes
Duchêne et al. Energy and Environ. Sci. 2017 Patent application submitted SNF Sinergia w/ UniGe & PSI
SLIDE 14
Solid-state electrolytes
Duchêne et al. Energy and Environ. Sci. 2017 Patent application submitted SNF Sinergia w/ UniGe & PSI 3.0 V plating
- 3 V stability window
- Compatible with sodium metal anode
- Low overpotential for sodium plating/stripping
- Candidate cathode material NaCrO2
- 85% capacity retention after 250 cycles
SLIDE 15
L i - I o n N a N i C l N a - I o n
3
4
1
2
