MAST BOLOGNA, 25-26 OCTOBER, 2016 DEP DEPArray rray User Meeting Disse ssect cting G g Gen eneti tic and and Epigenetic Heter erog ogen enei eity y in Malignant B Brain Tumors Matija Snuderl, MD Director of Molecular

slide-1
SLIDE 1

MAST • BOLOGNA, 25-26 OCTOBER, 2016

slide-2
SLIDE 2

MAST • BOLOGNA, 25-26 OCTOBER, 2016

DEP DEPArray rray™ User Meeting

Disse ssect cting G g Gen eneti tic and and Epigenetic Heter erog

  • gen

enei eity y in Malignant B Brain Tumors

Matija Snuderl, MD Director of Molecular Pathology and Diagnostics Department of Pathology New York University, NY, USA

slide-3
SLIDE 3

MAST • BOLOGNA, 25-26 OCTOBER, 2016

Precision Medicine: Tailoring the treatment for the patient based on underlying molecular biology

Modified from - McDermott U, Settleman J: Personalized cancer therapy with selective kinase inhibitors: an emerging paradigm in medical oncology. J Clin Oncol 27:2009; 5650-9

Tumour Biopsy Histological pathology Genomic pathology Glioma Therapy Mutation A Mutation B Mutation C

IDH1 EGFRvIII STAT3

slide-4
SLIDE 4

MAST • BOLOGNA, 25-26 OCTOBER, 2016

Molecular changes underlying recurrence and treatment failure: molecular progression and intratumoral heterogeneity

Initial diagnosis Recurrence Surgery, XTR+TMZ

WHO II – astrocytoma WHO III – anaplastic astrocytoma WHO IV– glioblastoma

p53 mut PDGFR 5-10 year 11p/19q loss CDK4/6 amp RB mut 2-3 year 10q loss PTEN mut 1 year

slide-5
SLIDE 5

MAST • BOLOGNA, 25-26 OCTOBER, 2016

Glioblastoma, WHO Grade IV

  • The most common primary malignant brain tumor of adults,

~12% of all intracranial tumors

  • Incidence = 3-4/100,000/yr (Eur, USA)
  • Peak age of Incidence: 45-75ys
  • One of the deadliest tumors, with a median survival of 1 yr
  • GBMs arise de novo or from lower grade lesions
  • Common genetic alterations:
  • Receptor tyrosine kinase gene amplification or overexpression

(~ 50% of primary GBMs: EGFR, PDGFRA/KIT/VEGFR2, MET)

  • TP53 gene mutations (~ 60% of secondary GBMs)
  • Homozygous CDKN2A deletion (~40% of GBMs)
slide-6
SLIDE 6

MAST • BOLOGNA, 25-26 OCTOBER, 2016

Glioblastoma, WHO Grade IV, histological criteria

Hypercellularity, atypia, mitosis Microvascular proliferation Pseudopallisading necrosis Tumor microenvironment

slide-7
SLIDE 7

MAST • BOLOGNA, 25-26 OCTOBER, 2016

Molecular Glioblastoma Subtypes

Sturm et al, Cancer Cell, 2012

slide-8
SLIDE 8

MAST • BOLOGNA, 25-26 OCTOBER, 2016

Co-amplification of Receptor Tyrosine Kinase genes in GBM

slide-9
SLIDE 9

MAST • BOLOGNA, 25-26 OCTOBER, 2016

PDGFRA MET EGFR MET

Co-amplification of Receptor Tyrosine Kinase genes in GBM: Mosaic heterogeneity

Snuderl et al, Cancer Cell, 2011

slide-10
SLIDE 10

MAST • BOLOGNA, 25-26 OCTOBER, 2016

In GBM, each subclone is proliferating and gene amplification leads to protein overexpression

EGFR MET MET (protein) EGFR MET pHH3 (M phase marker) Snuderl et al, Cancer Cell, 2011

slide-11
SLIDE 11

MAST • BOLOGNA, 25-26 OCTOBER, 2016

Mosaic heterogeneity subclones in GBM share early genetic mutations

EGFR MET P53 EGFR CDKN2A MET CDKN2A PDGFRA CDKN2A Snuderl et al, Cancer Cell, 2011

slide-12
SLIDE 12

MAST • BOLOGNA, 25-26 OCTOBER, 2016

The size of glioma subclones varies from tumor to tumor

slide-13
SLIDE 13

MAST • BOLOGNA, 25-26 OCTOBER, 2016

Mosaic heterogeneity in GBM: Collaboration or Competition?

Darwinian model of tumor evolution

slide-14
SLIDE 14

MAST • BOLOGNA, 25-26 OCTOBER, 2016

Functional implications of GBM heterogeneity

PDGFRA EGFR

Snuderl et al, Cancer Cell, 2011

slide-15
SLIDE 15

MAST • BOLOGNA, 25-26 OCTOBER, 2016

Extreme mosaic heterogeneity

EGFR MET PDGFRA Up to four DISTINCT subclones present in a single GBM: three mutually exclusive populations with RTK amplifications plus one GBM subclone without amplification

slide-16
SLIDE 16

MAST • BOLOGNA, 25-26 OCTOBER, 2016

Or is this really the most extreme…?

slide-17
SLIDE 17

MAST • BOLOGNA, 25-26 OCTOBER, 2016

Deeper (and deeper) insights into genetic heterogeneity of GBM

PDGFRA

Same, or different subclones….?

slide-18
SLIDE 18

MAST • BOLOGNA, 25-26 OCTOBER, 2016

Can DEPArray help us dissect mosaic heterogeneity in GBM (and other tumors)?

Goals:

  • Identify & isolate glioma subclones using predicted targets from

whole tumor profiling such as overexpressed RTKs and mutation specific markers (FFPE)

  • Identify cells with functional overexpressed RTK (FFPE/Fresh)
  • Unbiased single cell profiling of glioma cells to identify the true

extent of heterogeneity missed by whole genome profiling (FFPE)

  • Identify and isolate stromal cells in malignant gliomas and

correlate their profile with underlying GBM genetic features (FFPE/Fresh)

slide-19
SLIDE 19

MAST • BOLOGNA, 25-26 OCTOBER, 2016

Some notes for DEPArray users from the NYU experience:

Brain (tumor) requires different approach than other tissues

  • Optimizing digestion enzymes and timing for optimal cell suspension
  • Clusters vs debris (too little vs too much digestion)
  • High in fat and low in collagen (collagenase might not be the best enzymes for

dissociation of brain tissues)

  • Necrosis (?) -> debris that creates obstacles
  • Size of the cells, multinucleation, cells within the cells

Single cell Single cell

slide-20
SLIDE 20

MAST • BOLOGNA, 25-26 OCTOBER, 2016

Current workflow

1 ) Whole genome methylation/CNV profiling and targeted mutation profiling to identify targets 2) Cell suspension 3) IF for presumed markers 4) Inspection of the suspension quantity/quality and quality of the staining 5) DEPArray run, subclone selection and isolation 6) Molecular studies

slide-21
SLIDE 21

MAST • BOLOGNA, 25-26 OCTOBER, 2016

Identifying expression of proteins predicted by the whole genome profiling

(Illumina Methylation 450k BeadChip Array)

CDK4 EGFR

slide-22
SLIDE 22

MAST • BOLOGNA, 25-26 OCTOBER, 2016

Identifying mosaic heterogeneity subclones in GBM by DEPArray

EGFR CDK4 CDK4 EGFR

slide-23
SLIDE 23

MAST • BOLOGNA, 25-26 OCTOBER, 2016

EGFR CDK4 CDK4 EGFR

Identifying mosaic heterogeneity subclones in GBM by DEPArray

slide-24
SLIDE 24

MAST • BOLOGNA, 25-26 OCTOBER, 2016

pPDGFRA pEGFR

Identifying expression of functional proteins predicted by the CNV analysis

slide-25
SLIDE 25

MAST • BOLOGNA, 25-26 OCTOBER, 2016

pPDGFRA pEGFR

Identifying cancer cells with phosphorylated Receptor Tyrosine Kinases by DEPArray

pEGFR pPDGFRA

slide-26
SLIDE 26

MAST • BOLOGNA, 25-26 OCTOBER, 2016

Glioblastoma: Critical role of tumor microenvironment

DEPArray:

Next steps: isolating metabolically different glioma subclones by DEPArray

slide-27
SLIDE 27

MAST • BOLOGNA, 25-26 OCTOBER, 2016

Goals for DEPArray at NYU Neuropathology

  • Become the leader for DEPArray technology in brain

disorders (tumor and non-tumor)

  • Establish DEPArray protocols for extracting cancer cell

subclones and tumor associated stromal cells (macrophages, endothelial cells) from brain tumors

  • Establish protocols for studying tumor-stroma

interaction of live cells

  • Establish CTC protocols to correlate with our current

cfDNA workflow

slide-28
SLIDE 28

MAST • BOLOGNA, 25-26 OCTOBER, 2016

Acknowledgements

Jonathan Serrano Briana Zeck Luis Chiriboga, PhD John G. Golfinos, MD

Others: Andrew Chi, MD Peter Wu, MD, PhD Kasthuri Kannan, PhD Adriana Heguy, PhD Dimitris Placantonakis, MD, PhD

Matthias Karajannis, MD

Funding:

  • The Friedberg Charitable Foundation
  • The Making Headway Foundation
  • Alice and Thomas J. Tisch Brain Tumor Research Fund
