Market areas

• Marine
• Refrigeration
• Sanitary
• Process (Heavy Duty)

Marine

• Customers

– Oem’s like MAN, Ellehammer, Alfa Laval tank equipment – Ship owners like APM, J. Lauritzen, Torm, Evergreen – Spare part distributors

Marine

• Products

– Standard pressure gauges – Thermometers – Mechatronic thermometers – Proximity switches – Pressure transmitters – Pressure switches

Marine

Refrigeration

• Customers

– OEM’s like, JCI, Hansen Technologies, Gea refrigeration – Distributors like Frigotechnik, Antilhue, Beijer group – End users for spare parts – Service companies

Refrigeration

• Products
• Pressure gauges
• Standard, duplex & differential
• PT100 sensors
• Thermometers
• Pressure transmitters All SS
• For ammonia

Refrigeration

Sanitary

• Customers

– Oem’s like SPX (APV), GEA, Alfa Laval, Tetra pak – Distributors – End users like Arla, Novo

– Food & Pharmaceutical

– Food = high volume, many batches, much cleanig between bathces – Pharma: injectable & oral drugs = less volume, fewer batches, high cleaning demands before each batch

Sanitary

• Products
• Sanitary pressure gauges and

transmitters

• Diaphragm seals acc. To standards
• Sanitary thermometers and pockets
• Documentation
• Material traceability, conformity

declarations

Sanitary

• Products

– Homogenizer gauges – SwipGuard Safety switch – Rota check tank cleaning system – Oxygen gauges

Sanitary

Process/Heavy Duty

• Customers

– Power stations – Oil and gas, off-shore – Hydraulic systems – Chemical factories

Process/Heavy Duty

• Products
• Pressure gauges

– With diaphragm seal, alarm contacts and 4-20 mA out put

• Pressure transmitters

– With diaphragm seals

• OPF angle transmitter
• Proximity swithches
• Thermometers

Process/Heavy Duty

Product training - gauges

Movement System

• Bourdon tube
• Shank (joint, studs)

Glass Needle Bezel (front ring) Process connection Blow-out / temperature compenstaion House (case)

Product training - gauges

For correct delivery we need to know: Dimension of house DN63/80/100/160 Bottom (horizontal) or Rear (vertical) connection Process pressure or max pressue Media – corrosive or not Temperature of media and ambinet environment Process connection: Threaded e.g. ¼” ½” ¾” etc. Parallel/Tapered or is diaphragm seal necessary.

Product training - gauges

Mounting accessories for gauges Bottom connetion Rear conncetin Threaded Nipples/connectors Back flange/Front flange/U-Clamp

Product training - gauges

Diaphragm seal Seal (body or foot or nippel) Diaphragm (membrane) 0,1 0,05 0,04 mm thickness Diaphragm seal = seal and diaphragm welded together

Product training - gauges

Diaphragm seals are available in many designs. Typically are they designed and manufactured according to international standards e.g. ISO, DIN, ANSI, ASME, BS, JIS SMS......

Product training – thermometers

House Spring Compensator Shank Stem (sensor)

Product training – thermometers

For correct delivery we need to know: Dimension of house DN63/80/100/160 Bottom (horizontal) or Rear (vertical) connection Temperature range Length of stem: Immersion length and total length Process connection: Threaded e.g. ¼” ½” ¾” etc. Parallel/Tapered or is Clamp

• r other flanged seal necessary.

Product training – thermometers

Accessories for thermometers: Sanitary/Hygenic pockets Adjustable pockets Adjustable nipples

Product training – Pressure transmitters

Electrical connection: Plug or cable House Print board Pressure element

Product training – Pressure transmitters

For corrrect delivery we need to know: Measuring range Out put signal: 4-20 mA standard, Hart protokol, mV, V, 0-20 mA etc. Electrical connection: Plug or cable Process connection: Threaded or diaphragm seal Display ? Media and ambient temperature

Product training – SwipGuard PED cat. IV

Safety Switch

1 set 2 pcs to avoid redundancy Can replace emergency stop, sanitary safety valves and spring plates Used in sanitary/hygienic installations where users do not want to get an

• pening from the process to the

ambient environment. Used on UHT process units, Heated oil units

Product training – Temperature sensors

Electrical connection Exchangeble Insert Plug Cable Inner sheath with RTD or TC element inside Other sheath/Pocket

Product training – Temperature sensors

For corrrect delivery we need to know:

Electrical connection: plug or cable Process conncecion Pressure element: RTD (PT100/500/1000 or T/C Type K NiCrNi etc.) Nech Length Immesion Length With or without transmitter for signal out e.g. 4-20 mA

Product training – Temperature sensores

Temperature sensors: Mechanically/physically are there many desgins Internally do they all consist of a sensor element (RTD or T/C) with a plug, head or cable on top for eletrical supply.

Product training – OPF

Optical potentio meter: (Opto potentionmetrisch ferngeber) Angel positioning 0-290° No mechanical tear and wear 4-20 mA out put ATEX approved Resistant to vibrations Long life cyclus For valve positioning systems e.g. Actuators and for installin with gauges for signal out

http://actuators.schiebel.com/

Product training – Indupec

Reliable in all environments Increased operation safety Less downtime Extremely precise detection ”Plug and Play” function Mobile sensor “head” Programmable distance No adjustment Resistant to pressure, temperature, strokes and corrosion.
