@MagnusHyttsten Meet Robin Guinea Pig Meet Robin An Awkward - - PowerPoint PPT Presentation

@MagnusHyttsten

Meet Robin

Guinea Pig

Meet Robin

An Awkward Social Experiment (that I'm afraid you need to be part of...)

Super ROCKS!

Examples (Train & Test Data) Model (Your Brain) Output Input Data

"QCon"

<Awkward Silence>

Examples (Train & Test Data) Model (Your Brain) Loss function Output Input Data Labels (Correct Answers) Optimizer

"QCon" "Super Rocks"

Examples (Train & Test Data) Model (Your Brain) Loss function Output Input Data Labels (Correct Answers) Optimizer

"QCon" "Super Rocks" "Super Rocks"

Agenda

Intro to Machine Learning Frontiers of Machine Learning Creating a TensorFlow Model Why are TPUs Great for Machine Learning Workloads Distributed TensorFlow Training

Agenda

Intro to Machine Learning Frontiers of Machine Learning Creating a TensorFlow Model Why are TPUs Great for Machine Learning Workloads Distributed TensorFlow Training

Agenda

Intro to Machine Learning Frontiers of Machine Learning Creating a TensorFlow Model Why are TPUs Great for Machine Learning Workloads Distributed TensorFlow Training

“The network performed similarly to senior orthopedic surgeons when presented with images at the same resolution as the network.”

www.tandfonline.com/doi/full/10.1080/17453674.2017.1344459

Radiology Ophthalmology

0.95

Algorithm Ophthalmologist (median)

0.91

Pathology

https://research.googleblog.com/2017/03/assisting-pathologists-in-detecting.html

ImageNet

Alaskan Malamute Siberian Husky

http://news.stanford.edu/2017/01/25/artificial-intelligence-used-identify-skin-cancer

Input Saturation Defocus

Data, Data, Data Compute, Compute, Compute

Data, Data, Data Compute, Compute, Compute Humans, Humans, Humans

How long did it take for a Human to construct this?

AM!!!

Current: Solution = ML expertise + data + computation

Current: Solution = ML expertise + data + computation Can we turn this into: Solution = data + 100X computation

Current: Solution = ML expertise + data + computation Can we turn this into: Solution = data + 100X computation

??? Can We Learn How To Teach Machines To Learn

CIFAR-10

Learning Transferable Architectures for Scalable Image Recognition, Barret Zoph, Vijay Vasudevan, Jonathon Shlens and Quoc Le, https://arxiv.org/abs/1707.07012

ImageNet

Agenda

Intro to Machine Learning Frontiers of Machine Learning Creating a TensorFlow Model Why are TPUs Great for Machine Learning Workloads Distributed TensorFlow Training

TensorFlow Distributed Execution Engine CPU GPU Android iOS ... Java Python Frontend C++ Estimator tf.keras.layers tf.keras Premade Estimators Datasets

input_fn (Datasets, tf.data) Estimator (tf.estimator) calls

TensorFlow Estimator Architecture

input_fn (Datasets, tf.data) Estimator (tf.estimator) subclass calls

Premade Estimators

DNNClassifier DNNRegressor LinearClassifier LinearRegressor DNNLinearCombinedClassifier DNNLinearCombinedRegressor

Premade Estimators

BaselineClassifier BaselineRegressor

estimator = # Train locally

estimator.train (input_fn=..., ... estimator.evaluate(input_fn=..., ...) estimator.predict (input_fn=..., ...)

Premade Estimators

Datasets Premade Estimators

LinearRegressor(...) LinearClassifier(...) DNNRegressor(...) DNNClassifier(...) DNNLinearCombinedRegressor(...) DNNLinearCombinedClassifier(...) BaselineRegressor(...) BaselineClassifier(...)

Datasets

input_fn (Datasets, tf.data) Estimator (tf.estimator) subclass calls

Custom Models #1 - model_fn

DNNClassifier DNNRegressor LinearClassifier LinearRegressor DNNLinearCombinedClassifier DNNLinearCombinedRegressor

Premade Estimators

BaselineClassifier BaselineRegressor model_fn calls Keras Layers (tf.keras.layer) use

# Imports yada yada ... def model_fn(input, ...): Conv2D(32, kernel_size=(3, 3), activation='relu') MaxPooling2D(l1, pool_size=(2, 2) Flatten(l2) Dense(l3, 128, activation='relu') Dropout(0.2)) Dense(10, activation='softmax') model.compile(loss='categorical_crossentropy', optimizer='adam', metrics=['accuracy'])

tf.keras.layers tf.Estimator

Custom Models

tf.keras.layers

# Convert a Keras model to tf.estimator.Estimator ...

estimator = keras.estimator.model_to_estimator(model, ...)

# Train locally

estimator.train (input_fn=..., ... estimator.evaluate(input_fn=..., ...) estimator.predict (input_fn=..., ...)

Train/Evaluate Model

Estimator Datasets Datasets

Summary - Use Estimators, Datasets, and Keras

• Premade Estimators (tf.estimator): When possible
• Custom Models

a. model_fn in Estimator & tf.keras.layers

• Datasets (tf.data) for the input pipeline

Agenda

Intro to Machine Learning Frontiers of Machine Learning Creating a TensorFlow Model Why are TPUs Great for Machine Learning Workloads Distributed TensorFlow Training

• We may have a huge number of layers
• Each layer can have huge number of neurons
• -> There may be 100s millions or even billions * and + ops

All knobs are W values that we need to tune So that given a certain input, they generate the correct output

"Matrix Multiplication is EATING (the computing resources of) THE WORLD"

hi_j = [X0, X1, X2, ...] * [W0, W1, W2, ...] hi_j = X0*W0 + X1*W1 + X2*W2 + ...

X = [1.0, 2.0, ..., 256.0] # Let's say we have 256 input values W = [0.1, 0.1, ..., 0.1] # Then we need to have 256 weight values h0,0 = X * W # [1*0.1 + 2*0.1 + ... + 256*0.1] == 32389.6

Matmul

Single-threaded Execution

X 1 2 . . . 256

[ [

W 0.1 0.1 . . . 0.1

[ [

*

Single-threaded Execution

X = [1.0, 2.0, ..., 256.0] # Let's say we have 256 input values W = [0.1, 0.1, ..., 0.1] # Then we need to have 256 weight values h0,0 = X * W # [1*0.1 + 2*0.1 + ... + 256*0.1] == 32389.6

X 1 2 . . . 256

[ [

W 0.1 0.1 . . . 0.1 1*0.1 = 0.1

[ [

*

Single-threaded Execution

X = [1.0, 2.0, ..., 256.0] # Let's say we have 256 input values W = [0.1, 0.1, ..., 0.1] # Then we need to have 256 weight values h0,0 = X * W # [1*0.1 + 2*0.1 + ... + 256*0.1] == 32389.6

X 1 2 . . . 256

[ [

W 0.1 0.1 . . . 0.1 Prev 1*0.1 = 0.1 0.1

[ [

*

Single-threaded Execution

X = [1.0, 2.0, ..., 256.0] # Let's say we have 256 input values W = [0.1, 0.1, ..., 0.1] # Then we need to have 256 weight values h0,0 = X * W # [1*0.1 + 2*0.1 + ... + 256*0.1] == 32389.6

X 1 2 . . . 256

[ [

W 0.1 0.1 . . . 0.1 Prev 1*0.1 = 0.1 0.1 + 2*0.1 = 0.3

[ [

*

Single-threaded Execution

X = [1.0, 2.0, ..., 256.0] # Let's say we have 256 input values W = [0.1, 0.1, ..., 0.1] # Then we need to have 256 weight values h0,0 = X * W # [1*0.1 + 2*0.1 + ... + 256*0.1] == 32389.6

X 1 2 . . . 256

[ [

W 0.1 0.1 . . . 0.1 Prev 1*0.1 = 0.1 0.1 + 2*0.1 = 0.3 . . 3238.5+255*0.1 = 3264 3264 + 256*0.1 = 3289.6

[ [

*

Single-threaded Execution

X = [1.0, 2.0, ..., 256.0] # Let's say we have 256 input values W = [0.1, 0.1, ..., 0.1] # Then we need to have 256 weight values h0,0 = X * W # [1*0.1 + 2*0.1 + ... + 256*0.1] == 32389.6

X 1 2 . . . 256

[ [

W 0.1 0.1 . . . 0.1 Prev 1*0.1 = 0.1 0.1 + 2*0.1 = 0.3 . . 3238.5+255*0.1 = 3264 3264 + 256*0.1 = 3289.6

[ [

*

Single-threaded Execution

256 * t

Single-threaded Execution

X = [1.0, 2.0, ..., 256.0] # Let's say we have 256 input values W = [0.1, 0.1, ..., 0.1] # Then we need to have 256 weight values h0,0 = X * W # [1*0.1 + 2*0.1 + ... + 256*0.1] == 32389.6

Tensor Processing Unit (TPU) v2

Matrix Unit (MXU)

Matrix Unit Systolic Array

W11 W12 W13 W21 W22 W23 W31 W32 W33 X11 X12

Computing y = Wx

3x3 systolic array W = 3x3 matrix Batch-size(x) = 3

X13 X21 X22 X23 X31 X32 X33

inputs weights

accumulation

Matrix Unit (MXU)

W11 X11 W12 W13 W21 W22 W23 W31 W32 W33 X12 X13 X21 X22 X23 X31 X32 X33

inputs weights

Matrix Unit Systolic Array

Computing y = Wx

with W = 3x3, batch-size(x) = 3

accumulation

Matrix Unit (MXU)

W11 X21

W13 W21 X11 W22 W23 W31 W32 W33 X13 X22 X23 X31 X32 X33

inputs weights

Matrix Unit Systolic Array

Computing y = Wx

with W = 3x3, batch-size(x) = 3

accumulation

Matrix Unit (MXU)

W11 X31

W21 X21

W23 W31 X11 W32 W33 X23 X32 X33

inputs weights

Matrix Unit Systolic Array

Computing y = Wx

with W = 3x3, batch-size(x) = 3

accumulation

Matrix Unit (MXU)

W11

W21 X31

W31 X21

W33 X33

inputs weights

Matrix Unit Systolic Array

Computing y = Wx

with W = 3x3, batch-size(x) = 3

Y11 = W11X11 + W12X12 + W13X13

• utputs

accumulation

Matrix Unit (MXU)

W11 W12

W21

W31 X31

inputs weights

Matrix Unit Systolic Array

Computing y = Wx

with W = 3x3, batch-size(x) = 3

Y21 = W11X21 + W12X22 + W13X23 Y11 = W11X11 + W12X12 + W13X13 Y12 = W21X11 + W22X12 + W23X13

• utputs

accumulation

Matrix Unit (MXU)

W11 W12 W13 W21 W22

W31

inputs weights

Matrix Unit Systolic Array

Computing y = Wx

with W = 3x3, batch-size(x) = 3

• utputs

Y31 = W11X31 + W12X32 + W13X33 Y22 = W21X21 + W22X22 + W23X23 Y11 = W11X11 + W12X12 + W13X13 Y12 = W21X11 + W22X12 + W23X13 Y21 = W11X21 + W12X22 + W13X23 Y13 = W31X11 + W32X12 + W33X13

accumulation

Matrix Unit (MXU)

W11 W12 W13 W21 W22 W23 W31 W32

inputs weights

Matrix Unit Systolic Array

Computing y = Wx

with W = 3x3, batch-size(x) = 3

• utputs

Y31 = W11X11 + W12X12 + W13X13 Y22 = W21X21 + W22X22 + W23X23 Y12 = W21X11 + W22X12 + W23X13 Y21 = W11X21 + W12X22 + W13X23 Y13 = W31X11 + W32X12 + W33X13 Y32 = W21X31 + W22X32 + W23X33 Y23 = W31X21 + W32X22 + W33X23

accumulation

Matrix Unit (MXU)

W11 W12 W13 W21 W22 W23 W31 W32 W33

inputs weights

Matrix Unit Systolic Array

Computing y = Wx

with W = 3x3, batch-size(x) = 3

• utputs

Y31 = W11X11 + W12X12 + W13X13 Y22 = W21X21 + W22X22 + W23X23 Y13 = W31X11 + W32X12 + W33X13 Y32 = W21X31 + W22X32 + W23X33 Y23 = W31X21 + W32X22 + W33X23 Y33 = W31X31 + W32X32 + W33X33

accumulation

TPU V1

• 256 X 256 Systolic Array @ 700MHz
• 64K * 2 * 700M = 92 TOPS

Inference Only

Tensor Processing Unit (aka TPU) v2

Designed for neural net training and inference

• 180 teraflops of computation
• Designed to be connected together

TPU Pod - 11.5 petaflops

Many Knobs to Tune TPUs Were Built to Perform these Operations (and no other) Optimally

Agenda

Intro to Machine Learning Frontiers of Machine Learning Creating a TensorFlow Model Why are TPUs Great for Machine Learning Workloads Distributed TensorFlow Training

Different Services

"Between-Graph & Asynchronous Training"

Services, typically distributed to different hardware nodes

• Workers: ALL the processing (1 or more)
• Parameter Servers: Stores all weights (1 or more, why more?)
• Chief: Makes sure everything runs synchronized (1)

Distributed Training - Between-Graph/A-sync

Operation Execution Chief & Worker #1 CPU & TPU Variable Storage Parameter Server #1 CPU Variable Storage Parameter Server #2 CPU Operation Execution Worker #2 CPU & TPU Operation Execution Worker #3 CPU & TPU PS sends variables to WS WS sends gradient updates to PS Shared Storage Checkpoint Storage Training Data Storage

PS & Chief Writes & Reads Checkpoint Data

WS Read Training Data

Distributed Training - Between-Graph/A-sync

Operation Execution Chief & Worker #1 CPU & TPU Variable Storage Parameter Server #1 CPU Variable Storage Parameter Server #2 CPU Operation Execution Worker #2 CPU & TPU Operation Execution Worker #3 CPU & TPU PS sends variables to WS WS sends gradient updates to PS Shared Storage Checkpoint Storage Training Data Storage

PS & Chief Writes & Reads Checkpoint Data

WS Read Training Data

# Convert a Keras model to tf.estimator.Estimator ...

estimator = keras.estimator.model_to_estimator(model, ...)

# Train locally

estimator.train (input_fn=..., ... estimator.evaluate(input_fn=..., ...) estimator.predict (input_fn=..., ...)

Train/Evaluate Model

Estimator Datasets Datasets

# Convert a Keras model to tf.estimator.Estimator ...

estimator = keras.estimator.model_to_estimator(model, ...)

# Train locally & distributed

tf.estimator.train_and_evaluate( estimator, train_spec, eval_spec)

Train/Evaluate Model

Estimator Datasets

# Convert a Keras model to tf.estimator.Estimator ...

estimator = keras.estimator.model_to_estimator(model, ...)

# Train locally & distributed

tf.estimator.train_and_evaluate( estimator, train_spec, eval_spec)

Train/Evaluate Model

Estimator Datasets

Specifying input data How long to train & evaluate Evaluation metrics

# Convert a Keras model to tf.estimator.Estimator ...

estimator = keras.estimator.model_to_estimator(model, ...)

# Train locally & distributed

tf.estimator.train_and_evaluate( estimator, train_spec, eval_spec)

Train/Evaluate Model

Estimator Datasets

TF_CONFIG

Environment Variable

Specifying input data How long to train & evaluate Evaluation metrics

TF_CONFIG='{

"cluster": { "chief": ["host1:2222"], "worker": ["host1:2222", "host2:2222", "host3:2222"], "ps": ["host4:2222", "host5:2222"] }, # To start Parameter Server #1 "task": {"type": "ps", "index": 0} } '

Starting Parameter Server #1

Estimator

TF_CONFIG='{

"cluster": { "chief": ["host1:2222"], "worker": ["host1:2222", "host2:2222", "host3:2222"], "ps": ["host4:2222", "host5:2222"] }, # To start Parameter Server #1 "task": {"type": "ps", "index": 0} } ' $(host4) python <YourProgram.py>

Starting Parameter Server #1

Estimator

• Workers are Stateless - Easy to add new ones
• >=1 Parameter Servers - Supports large variables (e.g. embeddings)
• Shared Storage: Makes Cloud a great place (GCS, S3, ...)

Summary

HEY! Stop there, not so fast!

HEY! Stop there, not so fast! What about

with tf.device('/gpu:0'): a = tf.constant([1.0, 2.0, 3.0, 4.0, 5.0, 6.0], shape=[2, 3]) b = tf.constant([1.0, 2.0, 3.0, 4.0, 5.0, 6.0], shape=[3, 2]) c = tf.matmul(a, b)

Getting Started With TensorFlow & TPUs == void

Getting Started With TensorFlow & TPUs == void

(at least in the future)

Kubeflow

https://goo.gl/2vfHcm

Summary

• Use tf.estimator, tf.data, tf.keras to define & train your models

Summary

• Use tf.estimator, tf.data, tf.keras to define & train your models
• TPUs are great for ML Workloads

Summary

• Use tf.estimator, tf.data, tf.keras to define & train your models
• TPUs are great for ML Workloads
• Estimators support Between-graph, Asynchronous Training

■ Chief ■ Parameter Server ■ Workers

Summary

• Use tf.estimator, tf.data, tf.keras to define & train your models
• TPUs are great for ML Workloads
• Estimators support Between-graph, Asynchronous Training

■ Chief ■ Parameter Server ■ Workers

<<<STAY TUNED>>>

@MagnusHyttsten

Thank You
