[PPT] - @MagnusHyttsten Meet Robin Guinea Pig Meet Robin An Awkward PowerPoint Presentation

SLIDE 1

@MagnusHyttsten

SLIDE 2

Meet Robin

SLIDE 3

Guinea Pig

Meet Robin

SLIDE 4

SLIDE 5

An Awkward Social Experiment (that I'm afraid you need to be part of...)

SLIDE 6

SLIDE 7

ROCKS!

SLIDE 8

Examples (Train & Test Data) Model (Your Brain) Output Input Data

"GTC"

SLIDE 9

Examples (Train & Test Data) Model (Your Brain) Loss function Output Input Data Labels (Correct Answers) Optimizer

"GTC" "Rocks"

SLIDE 10

Examples (Train & Test Data) Model (Your Brain) Loss function Output Input Data Labels (Correct Answers) Optimizer

"GTC" "Rocks" "Rocks"

SLIDE 11

SLIDE 12

SLIDE 13

Agenda

Intro to Machine Learning Creating a TensorFlow Model Why are GPUs Great for Machine Learning Workloads Distributed TensorFlow Training

SLIDE 14

Agenda

Intro to Machine Learning Creating a TensorFlow Model Why are GPUs Great for Machine Learning Workloads Distributed TensorFlow Training

SLIDE 15

Agenda

Intro to Machine Learning Creating a TensorFlow Model Why are GPUs Great for Machine Learning Workloads Distributed TensorFlow Training

SLIDE 16

TensorFlow Distributed Execution Engine CPU GPU Android iOS ... Java Python Frontend C++ Estimator tf.keras.layers tf.keras Premade Estimators Datasets

SLIDE 17

input_fn (Datasets, tf.data) Estimator (tf.estimator) calls

TensorFlow Estimator Architecture

SLIDE 18

input_fn (Datasets, tf.data) Estimator (tf.estimator) subclass calls

Premade Estimators

DNNClassifier DNNRegressor LinearClassifier LinearRegressor DNNLinearCombinedClassifier DNNLinearCombinedRegressor

Premade Estimators

BaselineClassifier BaselineRegressor

SLIDE 19

estimator = # Train locally

estimator.train (input_fn=..., ... estimator.evaluate(input_fn=..., ...) estimator.predict (input_fn=..., ...)

Premade Estimators

Datasets Premade Estimators

LinearRegressor(...) LinearClassifier(...) DNNRegressor(...) DNNClassifier(...) DNNLinearCombinedRegressor(...) DNNLinearCombinedClassifier(...) BaselineRegressor(...) BaselineClassifier(...)

Datasets

SLIDE 20

input_fn (Datasets, tf.data) Estimator (tf.estimator) subclass calls

Custom Models #1 - model_fn

DNNClassifier DNNRegressor LinearClassifier LinearRegressor DNNLinearCombinedClassifier DNNLinearCombinedRegressor

Premade Estimators

BaselineClassifier BaselineRegressor model_fn calls Keras Layers (tf.keras.layer) use

SLIDE 21

input_fn (Datasets, tf.data) Estimator (tf.estimator) subclass calls

Custom Models #2 - Keras Model

DNNClassifier DNNRegressor LinearClassifier LinearRegressor DNNLinearCombinedClassifier DNNLinearCombinedRegressor

Premade Estimators

BaselineClassifier BaselineRegressor model_fn calls Keras Layers (tf.keras.layer) use model_to_estimator Keras (tf.keras)

SLIDE 22

# Imports yada yada ... model = Sequential() model.add(Conv2D(32, kernel_size=(3, 3), activation='relu')) model.add(MaxPooling2D(pool_size=(2, 2))) model.add(Flatten()) model.add(Dense(128, activation='relu')) model.add(Dropout(0.2)) model.add(Dense(10, activation='softmax')) model.compile(loss='categorical_crossentropy', optimizer='adam', metrics=['accuracy'])

tf.keras.layers tf.keras

Custom Models

SLIDE 23

# Convert a Keras model to tf.estimator.Estimator ...

estimator = keras.estimator.model_to_estimator(model, ...)

# Train locally

estimator.train (input_fn=..., ... estimator.evaluate(input_fn=..., ...) estimator.predict (input_fn=..., ...)

Train/Evaluate Model

Estimator Datasets Datasets

SLIDE 24

Summary - Use Estimators, Datasets, and Keras

Premade Estimators (tf.estimator): When possible
Custom Models

a. model_fn in Estimator & tf.keras.layers b. Keras Models (tf.keras) ■ estimator = keras.model_to_estimator(...)

Datasets (tf.data) for the input pipeline

SLIDE 25

Agenda

Intro to Machine Learning Creating a TensorFlow Model Why are GPUs Great for Machine Learning Workloads Distributed TensorFlow Training

SLIDE 26

Disclaimer...

High-Level - We look at only parts of the power of GPUs
Simple Overview - More optimal designs exist
Reduced Scope - Only considering fully-connected layers, etc

SLIDE 27

Strengths of V100 GPU

Built for Massively Parallel Computations
Hardware & software suitable to manage

Deep Learning Workloads (Tensor Cores, mixed-precision execution, etc)

SLIDE 28

Strengths of V100 GPU

Built for Massively Parallel Computations
Specific hardware / software to manage

Deep Learning Workloads (Tensor Cores, mixed-precision execution, etc)

Tesla SXM V100

5376 cores (FP32)

SLIDE 29

Strengths of V100 GPU

What are we going to do with 5376 FP32 cores?

SLIDE 30

Strengths of V100 GPU

What are we going to do with 5376 FP32 cores? "Execute things in parallel"!

SLIDE 31

Strengths of V100 GPU

What are we going to do with 5376 FP32 cores? "Execute things in parallel"! Yes, but how can we exactly do that for ML Workloads?

SLIDE 32

Strengths of V100 GPU

What are we going to do with 5376 FP32 cores? "Execute things in parallel"! Yes, but how can we exactly do that for ML Workloads? "Hey, that's your job - That's why we're here listening"!

SLIDE 33

Strengths of V100 GPU

What are we going to do with 5376 FP32 cores? "Execute things in parallel"! Yes, but how can we exactly do that for ML Workloads? "Hey, that's your job - That's why we're here listening"!

Alright, let's talk about that then

SLIDE 34

SLIDE 35

SLIDE 36

We may have a huge number of layers
Each layer can have huge number of neurons
-> There may be 100s millions or even billions * and + ops

All knobs are W values that we need to tune So that given a certain input, they generate the correct output

SLIDE 37

"Matrix Multiplication is EATING (the computing resources of) THE WORLD"

hi_j = [X0, X1, X2, ...] * [W0, W1, W2, ...] hi_j = X0*W0 + X1*W1 + X2*W2 + ...

SLIDE 38

X = [1.0, 2.0, ..., 256.0] # Let's say we have 256 input values W = [0.1, 0.1, ..., 0.1] # Then we need to have 256 weight values h0,0 = X * W # [1*0.1 + 2*0.1 + ... + 256*0.1] == 32389.6

*

Single-threaded Execution

256 * t

Single-threaded Execution

X = [1.0, 2.0, ..., 256.0] # Let's say we have 256 input values W = [0.1, 0.1, ..., 0.1] # Then we need to have 256 weight values h0,0 = X * W # [1*0.1 + 2*0.1 + ... + 256*0.1] == 32389.6

SLIDE 55

Comparing - Order of Magnitude (sequences)

Single-Threaded Execution GPU Multi-Threaded Execution

1 * t + 7 * t = 256 * t 8 * t

SLIDE 56

Many Knobs to Tune But the type of calculation we perform is very suited for GPUs

SLIDE 57

Summary

GPUs == Many Threads == Great for ML Workloads
And now you know how this works
Fortunately, you don't need to worry about implementation details

SLIDE 58

Agenda

Intro to Machine Learning Creating a TensorFlow Model Why are GPUs Great for Machine Learning Workloads Distributed TensorFlow Training

SLIDE 59

Different Services

"Between-Graph & Asynchronous Training"

Services, typically distributed to different hardware nodes

Workers: ALL the processing (1 or more)
Parameter Servers: Stores all weights (1 or more, why more?)
Chief: Makes sure everything runs synchronized (1)

SLIDE 60

Distributed Training - Between-Graph/A-sync

Operation Execution Chief & Worker #1 CPU & GPU Variable Storage Parameter Server #1 CPU Variable Storage Parameter Server #2 CPU Operation Execution Worker #2 CPU & GPU Operation Execution Worker #3 CPU & GPU PS sends variables to WS WS sends gradient updates to PS Shared Storage Checkpoint Storage Training Data Storage

PS & Chief Writes & Reads Checkpoint Data

WS Read Training Data

SLIDE 61

Distributed Training - Between-Graph/A-sync

Operation Execution Chief & Worker #1 CPU & GPU Variable Storage Parameter Server #1 CPU Variable Storage Parameter Server #2 CPU Operation Execution Worker #2 CPU & GPU Operation Execution Worker #3 CPU & GPU PS sends variables to WS WS sends gradient updates to PS Shared Storage Checkpoint Storage Training Data Storage

PS & Chief Writes & Reads Checkpoint Data

WS Read Training Data

SLIDE 62

# Convert a Keras model to tf.estimator.Estimator ...

estimator = keras.estimator.model_to_estimator(model, ...)

# Train locally

estimator.train (input_fn=..., ... estimator.evaluate(input_fn=..., ...) estimator.predict (input_fn=..., ...)

Train/Evaluate Model

Estimator Datasets Datasets

SLIDE 63

# Convert a Keras model to tf.estimator.Estimator ...

estimator = keras.estimator.model_to_estimator(model, ...)

# Train locally & distributed

tf.estimator.train_and_evaluate( estimator, train_spec, eval_spec)

Train/Evaluate Model

Estimator Datasets

SLIDE 64

# Convert a Keras model to tf.estimator.Estimator ...

estimator = keras.estimator.model_to_estimator(model, ...)

# Train locally & distributed

tf.estimator.train_and_evaluate( estimator, train_spec, eval_spec)

Train/Evaluate Model

Estimator Datasets

Specifying input data How long to train & evaluate Evaluation metrics

SLIDE 65

# Convert a Keras model to tf.estimator.Estimator ...

estimator = keras.estimator.model_to_estimator(model, ...)

# Train locally & distributed

tf.estimator.train_and_evaluate( estimator, train_spec, eval_spec)

Train/Evaluate Model

Estimator Datasets

TF_CONFIG

Environment Variable

Specifying input data How long to train & evaluate Evaluation metrics

SLIDE 66

TF_CONFIG='{

"cluster": { "chief": ["host1:2222"], "worker": ["host1:2222", "host2:2222", "host3:2222"], "ps": ["host4:2222", "host5:2222"] }, # To start Parameter Server #1 "task": {"type": "ps", "index": 0} } '

Starting Parameter Server #1

Estimator

SLIDE 67

TF_CONFIG='{

"cluster": { "chief": ["host1:2222"], "worker": ["host1:2222", "host2:2222", "host3:2222"], "ps": ["host4:2222", "host5:2222"] }, # To start Parameter Server #1 "task": {"type": "ps", "index": 0} } ' $(host4) python <YourProgram.py>

Starting Parameter Server #1

Estimator

SLIDE 68

Different Modes of Distribution

Work Distribution Mode

Between-graph Replication - Individual processes

Each Worker runs its own process (of the same program) Variable Update Mode

Asynchronous: Updates are applied across Workers in parallel

SLIDE 69

Different Modes of Distribution

Work Distribution Mode

Between-graph Replication - Individual processes

Each Worker runs its own process (of the same program)

In-graph Replication - Single program/process

Ops or variables are distributed to different nodes (or GPU cards) Variable Update Mode

Asynchronous: Updates are applied across Workers in parallel
Synchronous: Update values are co-ordinated across Ops

SLIDE 70

Workers are Stateless - Easy to add new ones
>=1 Parameter Servers - Supports large variables (e.g. embeddings)
Shared Storage: Makes Cloud a great place (GCS, S3, ...)

Summary

SLIDE 71

HEY! Stop there, not so fast!

SLIDE 72

HEY! Stop there, not so fast! What about

with tf.device('/gpu:0'): a = tf.constant([1.0, 2.0, 3.0, 4.0, 5.0, 6.0], shape=[2, 3]) b = tf.constant([1.0, 2.0, 3.0, 4.0, 5.0, 6.0], shape=[3, 2]) c = tf.matmul(a, b)

SLIDE 73

Getting Started With TensorFlow & GPUs == void

SLIDE 74

Getting Started With TensorFlow & GPUs == void

(at least in the future)

SLIDE 75

Kubeflow

https://goo.gl/2vfHcm

SLIDE 76

Summary

Use tf.estimator, tf.data, tf.keras to define & train your models

SLIDE 77

Summary

Use tf.estimator, tf.data, tf.keras to define & train your models
GPUs are great for ML Workloads

SLIDE 78

Summary

Use tf.estimator, tf.data, tf.keras to define & train your models
GPUs are great for ML Workloads
Estimators support Between-graph, Asynchronous Training

■ Chief ■ Parameter Server ■ Workers

SLIDE 79

Summary

Use tf.estimator, tf.data, tf.keras to define & train your models
GPUs are great for ML Workloads
Estimators support Between-graph, Asynchronous Training

■ Chief ■ Parameter Server ■ Workers

<<<STAY TUNED>>>

SLIDE 80

SLIDE 81

@MagnusHyttsten

Thank You
