Machine Learning for SAT Holger H. Hoos Department of Computer Science University of British Columbia Canada Dagstuhl Seminar on Theory and Practice of SAT Solving 2015/04/21 How can machine learning methods help to ... I build better SAT

SLIDE 1 Machine Learning for SAT Holger H. Hoos Department of Computer Science University of British Columbia Canada Dagstuhl Seminar on Theory and Practice of SAT Solving 2015/04/21

SLIDE 2 How can machine learning methods help to ... I build better SAT solvers I predict (and understand) solver performance Disclaimer: Lots of literature; no comprehensive survey, just an overview of some work in the area. Holger Hoos: Machine learning for SAT 2

SLIDE 3

1

SLIDE 4 Automatic configuration of SAT solvers Hutter, HH, St¨ utzle (2007); Hutter, HH, Leyton-Brown, St¨ utzle (2009); Hutter, Lindauer, Balint, Bayless, HH, Leyton-Brown (in preparation) Goal: Find parameter settings of a SAT solver that achieves optimised performance for specific distribution of instances. Approaches (work for arbitrary problems, solvers): I stochastic local search in configuration space (ParamILS) I sequential model-based optimisation (SMAC) Holger Hoos: Machine learning for SAT 3

SLIDE 5 Lingeling on software verification (2013 Configurable SAT Solver Competition data) average running time 3.32 → 0.16 CPU sec; rank 4 → 1 on Industrial SAT+UNSAT Holger Hoos: Machine learning for SAT 4

SLIDE 6 Clasp-3.0.4-p8 on N−Rooks (2014 Configurable SAT Solver Competition data) PAR10 705 → 5 CPU sec; rank 5 → 1 on Industrial SAT+UNSAT Holger Hoos: Machine learning for SAT 5

SLIDE 7 Knuth’s sat13 on diverse set of instances (very easy to medium; trained on very easy only) 10-3 10-2 10-1 100 101 10-3 10-2 10-1 100 101 running time optimised [gmem] running time default [gmem] mean running time 0.572 → 0.402 gmems; geometric average speedup: 1.414-fold Holger Hoos: Machine learning for SAT 6

SLIDE 8 Knuth’s sat13 on diverse set of instances (TAOCP testing instances; trained on very easy) 10-3 10-2 10-1 100 101 102 103 10-3 10-2 10-1 100 101 102 103 running time optimised [gmem] running time default [gmem] mean running time 47.4 → 36.9 gmems; geometric average speedup: 1.357-fold Holger Hoos: Machine learning for SAT 7

SLIDE 9 Citations to key publications on algorithm configuration 50 100 150 200 2 7 2 8 2 9 2 1 2 1 1 2 1 2 2 1 3 2 1 4 ParamILS (Hutter et al. 09) SMAC (Hutter et al. 11) I/F-Race (Balaprakash et al. 07) GGA (Ansotegui et al. 09) (Data from Google Scholar)

SLIDE 10

2

SLIDE 11 Automatic per-instance solver selection Xu, Hutter, HH, Leyton-Brown (2007–2012) Goal: Given a set S of SAT solvers and an instance i to be solved, find the solver from S that can be expected to work best on i. Approaches (work for arbitrary problems, solvers): I for each solver, learn a function that predicts solver performance from instance features; select solver with best predicated performance (SATzilla 2007–2009) I use cost-based classification method to select solver based on instance features (SATzilla 2011–present) Holger Hoos: Machine learning for SAT 8

SLIDE 12 2012 SAT Challenge Rank Application Hard Combinatorial Random (SAT only) 1 SATzilla2012 App SATzilla2012 COMB CCASat 2 SATzilla2012 ALL SATzilla2012 ALL SATzilla2012 RAND 3 Industrial SAT Solver ppfolio2012 SATzilla2012 ALL 4 lingeling (2011) interactSAT_c Sparrow (2011) 5 interactSAT pfolioUZK EagleUP (2011) 6 glucose aspeed-crafted sattime2012 7 SINN Clasp-crafted ppfolio2012 2/3 first, 3/3 second, 3/3 third places Holger Hoos: Machine learning for SAT 9

SLIDE 13 2012 SAT Challenge: Single best solver vs SATzilla 10 10 1 10 2 10 10 1 10 2 lingeling2011 runtime [CPU sec] SATzilla2012 APP runtime [CPU sec] Holger Hoos: Machine learning for SAT 10

SLIDE 14

3

SLIDE 15 Automatic construction of parallel solver porfolios (ACPP) Lindauer, HH, Leyton-Brown, Schaub (2012; under review) Goal: Given one or more SAT parametrised solvers, build a parallel portfolio (from solvers and configurations) with optimised performance for specific distribution of instances. Approaches (work for arbitrary problems, solvers): I configure joint parameter space I iteratively build portfolio by greedily adding components that achieve largest performance improvement Holger Hoos: Machine learning for SAT 11

SLIDE 16 Parallel portfolio based on Lingeling (v.276)

n 2012 SAT Comp. Application instances

1 10 100 1000 1 10 100 1000 runtime Greedy-MT4 [s] runtime Conf-SP [s] Holger Hoos: Machine learning for SAT 12

SLIDE 17 Parallel portfolio based on clasp (v.2.0.2)

n 2012 SAT Comp. Application instances

1 10 100 1000 1 10 100 1000 runtim Greedy-MT4 [s] runtime Conf-ST [s] Holger Hoos: Machine learning for SAT 13

SLIDE 18 Sequential vs parallel solvers

n 2012 SAT Comp. Application instances

Solver # time-outs PAR10 Sequential solvers: pfolioUZK 150 4656 glucose-2.1 55 1778 SATzilla-2012-APP 38 1289 Parallel solvers with default config: ppfolio+CS 46 1506 pfolioUZK-MP(8)+CS 35 1168 Plingeling(aqw)+CS (2013) 32 1058 ACPP solvers: Global-MP(8) 35 1172 ParHydra4-MT(8) 29 992 (ACPP solvers constructed based on solver set underlying pfolioUZK) Holger Hoos: Machine learning for SAT 14

SLIDE 19

4

SLIDE 20 Scaling of running time with instance size Mu & Hoos (IJCAI-15) Goal: Study empirical time complexity of solving phase-transition random 3-SAT instances using high-performance SAT solvers. Methodology: I fit parametric models to running time data I challenge models by extrapolation I assess models using bootstrap confidence intervals (Hoos 2009; Hoos & St¨ utzle 2014) Holger Hoos: Machine learning for SAT 15

SLIDE 21 Scaling of running time for WalkSAT/SKC 10-4 10-3 10-2 10-1 100 101 100 200 500 1000 time [CPU sec] n Support data

Exp. model: 6.89157e-04 × 1.00798n
Poly. model: 8.83962e-11 × n3.18915
Exp. model bootstrap intervals
Poly. model bootstrap intervals

Challenge data (with confidence intervals) Holger Hoos: Machine learning for SAT 16

SLIDE 22 Scaling of running time for March hi 1e-05 0.0001 0.001 0.01 0.1 1 10 100 1000 10000 100 200 300 400 500 600 CPU time [sec] n Support data for sat. instances Challenge data for sat. instances

Exp. model for sat.: 8.33113e-06 × 1.03119n
Exp. model bootstrap intervals for sat.

Support data for unsat. instances Challenge data for unsat. instances Holger Hoos: Machine learning for SAT 17

SLIDE 23 Main findings: I median running times of SLS-based solvers (WalkSAT/SKC, BalancedZ, probSAT) scale polynomially (degree ≈ 3) I median running times of complete solvers (knfcs, march hi, march br) scale exponentially (base ≈ 1.03) I scaling models for SLS-based solvers are very similar, but march-variants scale better than kcnfs Holger Hoos: Machine learning for SAT 18

SLIDE 24 Take-home message: Machine learning techniques ... I let us model & predict solver behaviour I help us build better solvers I give us interesting insights into solver performance If you care about SAT solving in practice: Use these techniques! If you only care about theorems: You may be inspired by the results thus obtained. Holger Hoos: Machine learning for SAT 19

SLIDE 25

∃∀

Holger H. Hoos

Empirical

Algorithmics

Cambridge University Press (nearing completion)

SLIDE 26 References (1): – Hoos, H. H. (2009). A bootstrap approach to analysing the scaling of empirical runtime data with problem size. Technical Report TR-2009-16, University of British Columbia, June 2009. http://www.cs.ubc.ca/hoos/Publ/Hoos09.pdf. – Hoos, H. H.; Leyton-Brown, K.; Schaub, T.; Schneider, M. (2012). Algorithm configuration for portfolio-based parallel SAT-solving. Proceedings of the First Workshop on Combining Constraint Solving with Mining and Learning (CoCoMile12). pp. 7-12. – Hoos, H. H.; & St¨ utzle, T. (2014). On the empirical scaling of run-time for finding optimal solutions to the travelling salesman problem. European Journal of Operational Research 238: 87–94. – Hutter, F.; Hoos, H.; Leyton-Brown, K.; St¨ utzle, T. (2009). ParamILS: An automatic algorithm configuration framework. Journal of Artificial Intelligence Research 36, 267306. – Hutter, F.; Hoos, H. H.; and St¨ utzle, T. (2007). Automatic algorithm configuration based on local search. Proceedings of the 22nd National Conference on Artificial Intelligence (AAAI07), pp. 1152-1157. – Hutter, F.; Lindauer, M.; Balint, A.; Bayless., S.; Hoos, H. H.; Leyton-Brown, K. (2015). The Configurable SAT Solver Challenge (CSSC). Under review. – Hutter, F.; Xu, L.; Hoos, H. H.; Leyton-Brown, K. (2014). Algorithm Runtime Prediction: Methods &

Applications. Artificial Intelligence, pp. 79–111, January 2014.

– Lindauer, M.; Hoos, H. H.; Leyton-Brown, K.; Schaub, T. (2015). Automatic Construction of Parallel Portfolios via Algorithm Configuration. Under review. – Mu, Z.; Hoos, H. H. (2015). On the Empirical Time Complexity of Random 3-SAT at the Phase

Transition. Proceedings of the 24th International Joint Conference on Artificial Intelligence (IJCAI-15), to
appear. (Preprint available at http://www.cs.ubc.ca/~hoos/Publ/MuHoo15-preprint.pdf.)

SLIDE 27 References (2): – Xu, L.; Hutter, F.; Hoos, H. H.; Leyton-Brown, K. (2007). SATzilla-07: the design and analysis of an algorithm portfolio for SAT. Proceedings of the 13th International Conference on Principles and Practice of Constraint Programming (CP07), pp. 712-727. – Xu, L.; Hutter, F.; Hoos, H. H.; Leyton-Brown, K. (2009). SATzilla2009: an automatic algorithm portfolio for SAT. SAT Competition 2009: Solver Descriptions. – Xu, L.; Hutter, F.; Hoos, H. H.; Leyton-Brown, K. (2012). Evaluating component solver contributions in portfolio-based algorithm selectors. Proceedings of the 15th International Conference on Theory and Applications of Satisfiability Testing (SAT12), pp. 228-241. – Xu, L.; Hutter, F.; Hoos, H. H.; Leyton-Brown, K. (2012). Satzilla2012: Improved algorithm selection based on cost-sensitive classification models. SAT Challenge 2012: Solver Descriptions.
