Z3: an efficient SAT/SMT solver SAT Problem SAT problem is translate in propositional formula that is composed by boolean variables connected by boolean operators: Not, And, Or, ->, <->. If the formula is satisfiable , there is an

slide-1
SLIDE 1

Z3: an efficient SAT/SMT solver

slide-2
SLIDE 2

SAT Problem

  • SAT problem is translate in propositional formula that is composed by boolean variables

connected by boolean operators: Not, And, Or, ->, <->.

  • If the formula is satisfiable, there is an assignment that make the results true, otherwise the

formula in unsat.

  • The solution of the formula are based on the Truth table. The solution on Truth table is exponential

in the number of variables. SAT is NP-Complete Problem.

  • SAT solvers are successful for a big formula and a lot of practical problems.
slide-3
SLIDE 3

SMT Theories

  • SMT is Satisfiability Modulo Theories is about SAT extended with other theories
  • SMT can add other abstract layers to handle more complicate expressions.
  • SMT include the theory of integers, the theory of reals, the theory of arrays, the theory of data

types, the theory of bit vectors and the theory of the pointers.

  • SMT can be view a language of first order logic.
slide-4
SLIDE 4

Z3 SAT/SMT Solver (Microsoft Research)

slide-5
SLIDE 5

Z3 SMT/SAT Syntax

  • set-logic and/or set-options (often redundant)
  • declarations: declare-constant, declare-func
  • ( assert…. ) containing the actual formula.
  • ( check-sat ) to do the actual sat solving.
  • ( get model ) to show the satisfying assignment.
slide-6
SLIDE 6

Z3 SMT/SAT Variable Example

(declare-const a Int) (declare-const b Int) (declare-const c Int) (declare-const d Int) (assert (and (> (* 2 a) (+ b c)) (> (* 2 b) (+ c d)) (> (* 2 c) (* 3 d)) (> (* 3 d) (+ a c)))) (check-sat) (get-model)

slide-7
SLIDE 7

Z3 SMT/SAT Functions Example

(declare-fun f (Int) Int) (assert (and (> (* 2 (f 1)) (+ (f 2) (f 3))) (> (* 2 (f 2)) (+ (f 3) (f 4))) (> (* 2 (f 3)) (* 3 (f 4))) (> (* 3 (f 4)) (+ (f 1) (f 3))))) (check-sat) (get-model)

slide-8
SLIDE 8

Z3 SMT/SAT Big Number Example

(declare-const A Int) (declare-const B Int) (declare-const C Int) (assert (and (= A 98798798987987987987987923423) (= B 763429999988888888887364578645) (= (+ (* 87 A) (* 93 B)) (+ C C)))) (check-sat) (get-model)

slide-9
SLIDE 9

Z3 SMT/SAT If Statement Example

(ite ( < a b ) 13 ( * 3 a )) If a < b return 13 Else return 3 * a
