Applications of SMT to Test Generation Patrice Godefroid Microsoft - - PowerPoint PPT Presentation

Page 1 June 2012 SAT/SMT Summer School 2012

Applications of SMT to Test Generation

Patrice Godefroid Microsoft Research

Page 2 June 2012 SAT/SMT Summer School 2012

Test Generation is Big Business

• #1 application for SMT solvers today (CPU usage)
• SAGE @ Microsoft:

– 1st whitebox fuzzer for security testing – 400+ machine years (since 2008)  – 3.4+ Billion constraints – 100s of apps, 100s of security bugs – Example: Win7 file fuzzing ~1/3 of all fuzzing bugs found by SAGE  (missed by everything else…) – Bug fixes shipped (quietly) to 1 Billion+ PCs – Millions of dollars saved

• for Microsoft + time/energy for the world

Blackbox Fuzzing + Regression All Others SAGE How fuzzing bugs were found (Win7, 2006-2009) :

Page 3 June 2012 SAT/SMT Summer School 2012

Agenda

• 1. Why Test Generation?
• 2. What kind of SMT constraints ?
• 3. New: test generation from validity proofs

Disclaimer: here, focus on test generation for software using SMT (not hardware using SAT)

Page 4 June 2012 SAT/SMT Summer School 2012

Part 1: Why Test Generation ?

Whitebox Fuzzing for Security Testing (The Killer App)

Page 5 June 2012 SAT/SMT Summer School 2012

Security is Critical (to Microsoft)

• Software security bugs can be very expensive:

– Cost of each Microsoft Security Bulletin: $Millions – Cost due to worms (Slammer, CodeRed, Blaster, etc.): $Billions

• Many security exploits are initiated via files or packets

– Ex: MS Windows includes parsers for hundreds of file formats

• Security testing: “hunting for million-dollar bugs”

– Write A/V (always exploitable), Read A/V (sometimes exploitable), NULL-pointer dereference, division-by-zero (harder to exploit but still DOS attacks), etc.

Page 6 June 2012 SAT/SMT Summer School 2012

Hunting for Security Bugs

• Main techniques used by “black hats”:

– Code inspection (of binaries) and – Blackbox fuzz testing

• Blackbox fuzz testing:

– A form of blackbox random testing [Miller+90] – Randomly fuzz (=modify) a well-formed input – Grammar-based fuzzing: rules that encode “well-formed”ness + heuristics about how to fuzz (e.g., using probabilistic weights)

• Heavily used in security testing

– Simple yet effective: many bugs found this way… – At Microsoft, fuzzing is mandated by the SDL 

I am from Belgium too!

Page 7 June 2012 SAT/SMT Summer School 2012

Introducing Whitebox Fuzzing

• Idea: mix fuzz testing with dynamic test generation

– Dynamic symbolic execution – Collect constraints on inputs – Negate those, solve with constraint solver, generate new inputs –  do “systematic dynamic test generation” (=DART)

• Whitebox Fuzzing = “DART meets Fuzz”

Two Parts: 1. Foundation: DART (Directed Automated Random Testing)

• 2. Key extensions (“Whitebox Fuzzing”), implemented in SAGE

Page 8 June 2012 SAT/SMT Summer School 2012

Automatic Code-Driven Test Generation

Problem: Given a sequential program with a set of input parameters, generate a set of inputs that maximizes code coverage = “automate test generation using program analysis” This is not “model-based testing” (= generate tests from an FSM spec)

Page 9 June 2012 SAT/SMT Summer School 2012

How? (1) Static Test Generation

• Static analysis to partition the program’s input space

[King76,…]

• Ineffective whenever symbolic reasoning is not possible

– which is frequent in practice… (pointer manipulations, complex arithmetic, calls to complex OS or library functions, etc.) Example:

int obscure(int x, int y) { if (x==hash(y)) error(); return 0; }

Can’t statically generate values for x and y that satisfy “x==hash(y)” !

Page 10 June 2012 SAT/SMT Summer School 2012

How? (2) Dynamic Test Generation

• Run the program (starting with some random inputs),

gather constraints on inputs at conditional statements, use a constraint solver to generate new test inputs

• Repeat until a specific program statement is reached

[Korel90,…]

• Or repeat to try to cover ALL feasible program paths:

DART = Directed Automated Random Testing = systematic dynamic test generation [PLDI’05,…]

– detect crashes, assertion violations, use runtime checkers (Purify,…)

Page 11 June 2012 SAT/SMT Summer School 2012

DART = Directed Automated Random Testing

Example:

int obscure(int x, int y) { if (x==hash(y)) error(); return 0; }

• start with (random) x=33, y=42

Run 1 :

• solve: x==567  solution: x=567
• execute concretely and symbolically:

if (33 != 567) | if (x != hash(y)) constraint too complex  simplify it: x != 567

• new test input: x=567, y=42

Run 2 : the other branch is executed All program paths are now covered !

• Observations:

– Dynamic test generation extends static test generation with additional runtime information: it is more powerful

– see [DART in PLDI’05], [PLDI’11]

– The number of program paths can be infinite: may not terminate! – Still, DART works well for small programs (1,000s LOC) – Significantly improves code coverage vs. random testing

Page 12 June 2012 SAT/SMT Summer School 2012

DART Implementations

• Defined by symbolic execution, constraint generation and solving

– Languages: C, Java, x86, .NET,… – Theories: linear arith., bit-vectors, arrays, uninterpreted functions,… – Solvers: lp_solve, CVCLite, STP, Disolver, Z3,…

• Examples of tools/systems implementing DART:

– EXE/EGT (Stanford): independent [’05-’06] closely related work – CUTE = same as first DART implementation done at Bell Labs – SAGE (CSE/MSR) for x86 binaries and merges it with “fuzz” testing for finding security bugs (more later) – PEX (MSR) for .NET binaries in conjunction with “parameterized-unit tests” for unit testing of .NET programs – YOGI (MSR) for checking the feasibility of program paths generated statically using a SLAM-like tool – Vigilante (MSR) for generating worm filters – BitScope (CMU/Berkeley) for malware analysis – CatchConv (Berkeley) focus on integer overflows – Splat (UCLA) focus on fast detection of buffer overflows – Apollo (MIT/IBM) for testing web applications …and more!

Page 13 June 2012 SAT/SMT Summer School 2012

Whitebox Fuzzing [NDSS’08]

• Whitebox Fuzzing = “DART meets Fuzz”
• Apply DART to large applications (not unit)
• Start with a well-formed input (not random)
• Combine with a generational search (not DFS)

– Negate 1-by-1 each constraint in a path constraint – Generate many children for each parent run – Challenge all the layers of the application sooner – Leverage expensive symbolic execution

• Search spaces are huge, the search is partial…

yet effective at finding bugs !

Gen 1 parent

Page 14 June 2012 SAT/SMT Summer School 2012

Example

void top(char input[4]) { int cnt = 0; if (input[0] == ‘b’) cnt++; if (input[1] == ‘a’) cnt++; if (input[2] == ‘d’) cnt++; if (input[3] == ‘!’) cnt++; if (cnt >= 4) crash(); } input = “good” I0!=‘b’ I1!=‘a’ I2!=‘d’ I3!=‘!’

Negate each constraint in path constraint Solve new constraint  new input

Path constraint: good goo! bood gaod godd  I0=‘b’  I1=‘a’  I2=‘d’  I3=‘!’ Gen 1

 SAT

SMT solver

Page 15 June 2012 SAT/SMT Summer School 2012

The Search Space

void top(char input[4]) { int cnt = 0; if (input[0] == ‘b’) cnt++; if (input[1] == ‘a’) cnt++; if (input[2] == ‘d’) cnt++; if (input[3] == ‘!’) cnt++; if (cnt >= 4) crash(); }

If symbolic execution is perfect and search space is small, this is verification !

Page 16 June 2012 SAT/SMT Summer School 2012

SAGE (Scalable Automated Guided Execution)

• Generational search introduced in SAGE
• Performs symbolic execution of x86 execution traces

– Builds on Nirvana, iDNA and TruScan for x86 analysis – Don’t care about language or build process – Easy to test new applications, no interference possible

• Can analyse any file-reading Windows applications
• Several optimizations to handle huge execution traces

– Constraint caching and common subexpression elimination – Unrelated constraint optimization – Constraint subsumption for constraints from input-bound loops – “Flip-count” limit (to prevent endless loop expansions)

Page 17 June 2012 SAT/SMT Summer School 2012

Check for Crashes (AppVerifier) Code Coverage (Nirvana) Generate Constraints (TruScan) Solve Constraints (Z3) Input0 Coverage Data Constraints Input1 Input2 … InputN

SAGE Architecture

MSR algorithms & code inside (2006-2012) SAGE was mostly developed by CSE (2006-2008)

Page 18 June 2012 SAT/SMT Summer School 2012

Some Experiments

• Seven applications – 10 hours search each

App Tested #Tests Mean Depth Mean #Instr. Mean Input Size ANI 11468 178 2,066,087 5,400 Media1 6890 73 3,409,376 65,536 Media2 1045 1100 271,432,489 27,335 Media3 2266 608 54,644,652 30,833 Media4 909 883 133,685,240 22,209 Compressed File Format 1527 65 480,435 634 OfficeApp 3008 6502 923,731,248 45,064

Most much (100x) bigger than ever tried before!

Page 19 June 2012 SAT/SMT Summer School 2012

Generational Search Leverages Symbolic Execution

• Each symbolic execution is expensive
• Yet, symbolic execution does not dominate search time

SymbolicExecutor Testing/Tracing/Coverage 5 10 15 20 25 30 SymbolicExecutor TestTask

25m30s

10 hours X1,000

Page 20 June 2012 SAT/SMT Summer School 2012

Since April’07 1st release: many new security bugs found (missed by blackbox fuzzers, static analysis)

– Apps: image processors, media players, file decoders,… – Bugs: Write A/Vs, Read A/Vs, Crashes,… – Many triaged as “security critical, severity 1, priority 1” (would trigger Microsoft security bulletin if known outside MS) – Example: WEX Security team for Win7

• Dedicated fuzzing lab with 100s machines 
• 100s apps (deployed on 1billion+ computers)
• ~1/3 of all fuzzing bugs found by SAGE !

– SAGE = gold medal at Fuzzing Olympics

• rganized by SWI at BlueHat’08 (Oct’08)

– Credit due to entire SAGE team + users !

SAGE Results

Page 21 June 2012 SAT/SMT Summer School 2012

WEX Fuzzing Lab Bug Yield for Win7

• 100s of apps, total number of

fuzzing bugs is confidential

• But SAGE didn’t exist in 2006
• Since 2007 (SAGE 1st release),

~1/3 bugs found by SAGE

• But SAGE was then deployed
• n only ~2/3 of those apps
• Normalizing the data by 2/3,

SAGE found ~1/2 bugs

• SAGE was run last in the lab,

so all SAGE bugs were missed by everything else!

Default Blackbox Fuzzer + Regression All Others SAGE

How fuzzing bugs found (2006-2009) : SAGE is running 24/7 on 100s machines: “the largest usage ever of any SMT solver”

• N. Bjorner + L. de Moura (MSR, Z3 authors)

Page 22 June 2012 SAT/SMT Summer School 2012

SAGE Summary

• SAGE is so effective at finding bugs that, for the first

time, we face “bug triage” issues with dynamic test generation

• What makes it so effective?

– Works on large applications (not unit test, like DART, EXE, etc.) – Can detect bugs due to problems across components – Fully automated (focus on file fuzzing) – Easy to deploy (x86 analysis – any language or build process !)

• 1st tool for whole-program dynamic symbolic execution at x86 level

– Now, used daily in various groups at Microsoft

Page 23 June 2012 SAT/SMT Summer School 2012

Part 2: What kind of SMT constraints ?

(Tests from Satisfiability Models)

Page 24 June 2012 SAT/SMT Summer School 2012

Types of Constraints

Roughly speaking:

• Long conjunctions !
• Bit vector constraints
• Bounded arrays (for pointer reasoning)

– No unbounded quantifiers

• See (anonimysed) SAGE benchmarks part of “SMT comp”

– (for more, contact Nikolaj Bjorner or Leonardo de Moura)

• Sometimes:

– Axiomatization for type systems (e.g., PEX) – String constraints, etc. (e.g., HAMPI) – uninterpreted functions (for summaries)

Page 25 June 2012 SAT/SMT Summer School 2012

The Art of Constraint Generation

More On the Research Behind SAGE : – How to recover from imprecision in symbolic exec.? PLDI’05, PLDI’11

• Must under-approximations

– How to scale symbolic exec. to billions of instructions? NDSS’08

• Techniques to deal with large path constraints

– How to check efficiently many properties together? EMSOFT’08

• Active property checking

– How to leverage grammars for complex input formats? PLDI’08

• Lift input constraints to the level of symbolic terminals in an input grammar

– How to deal with path explosion ? POPL’07, TACAS’08, POPL’10, SAS’11

• Symbolic test summaries (more later)

– How to reason precisely about pointers? ISSTA’09

• New memory models leveraging concrete memory addresses and regions

– How to deal with floating-point instructions? ISSTA’10

• Prove “non-interference” with memory accesses

– How to deal with input-dependent loops? ISSTA’11

• Automatic dynamic loop-invariant generation and summarization

Page 26 June 2012 SAT/SMT Summer School 2012

SAGAN: Fuzzing in the (Virtual) Cloud

• Since June 2010, new centralized server collecting stats

from all SAGE runs !

– 200+ machine-years of SAGE data (since June 2010)

• Track results (bugs, concrete & symbolic test coverage),

incompleteness (unhandled tainted x86 instructions, Z3 timeouts, divergences, etc.)

• Help troubleshooting (SAGE has 100+ options…)
• Tell us what works and what does not

Page 27 June 2012 SAT/SMT Summer School 2012

Picking and Choosing

• Typical SAGE run can fill up 300 GB in 1 week
• Problem: 100s of machines * 300+ GB = lots of data
• Solution: pick and choose what to ship up

– Configuration files – Counters from each SAGE execution – Run “heartbeats” at random intervals – Crashing test information

• Key principles

– Enough information to repro SAGE run results – Support key analyses for improving SAGE

Page 28 June 2012 SAT/SMT Summer School 2012

Are we hitting known problems in symbolic execution?

Page 29 June 2012 SAT/SMT Summer School 2012

“Incompleteness”

• 100s of instructions in x86
• Some of them we handle perfectly
• Some we do not handle perfectly – and we know it
• Which instructions should we prioritize?

SAGAN tells us!

Page 30 June 2012 SAT/SMT Summer School 2012

How to Automate These Steps?

• Automated Synthesis of Symbolic Instruction Encodings

from I/O Samples (to appear at [PLDI’2012]) :

– 6 abstract instruction templates – building blocks are bit-vector constraints (SMT-lib format) – for 534 x86 ALU instructions (8/16/32bits, outputs, EFLAGS) – new “smart sampling” synthesis algorithm takes <2 hours with Z3 – synthesis against specific x86 processor as I/O oracle :

Page 31 June 2012 SAT/SMT Summer School 2012

How long do we spend in constraint generation and constraint solving?

Page 32 June 2012 SAT/SMT Summer School 2012

Most solver queries are fast…

Page 33 June 2012 SAT/SMT Summer School 2012

…but solving time often dominates

Page 34 June 2012 SAT/SMT Summer School 2012

We can cut off outlying tasks!

Solver time

Page 35 June 2012 SAT/SMT Summer School 2012

SAT UNSAT / timeout

Most Constraints are UNSAT…

Page 36 June 2012 SAT/SMT Summer School 2012

Why are these constraints (usually) fast to solve?

90.18% of Z3 queries solved in 0.1 seconds or less!

Page 37 June 2012 SAT/SMT Summer School 2012

Key Optimizations

• Sound

– Common subexpression elimination on every new constraint

• Crucial for memory usage

– “Related Constraint Optimization”

• Unsound

– Constraint subsumption

• Syntactic check for implication, take strongest constraint

– Drop constraints at same instruction pointer after threshold

• This is the “art of constraint generation” !

– So that the constraint solver is not the bottleneck – Predictability is key to good business !

• Nobody wants an NP-hard problem in the way !

Page 38 June 2012 SAT/SMT Summer School 2012

What Next? Towards “Verification”

• When can we safely stop testing?

– When we know that there are no more bugs ! = “Verification” – “Testing can only prove the existence of bugs, not their absence.” – Unless it is exhaustive! This is the “model checking thesis” – “Model Checking” = exhaustive testing (state-space exploration) – Two main approaches to software model checking:

Modeling languages Programming languages Model checking Systematic testing

state-space exploration state-space exploration

abstraction adaptation (SLAM, Bandera, FeaVer, BLAST,…) Concurrency: VeriSoft, JPF, CMC, Bogor, CHESS,… Data inputs: DART, EXE, SAGE,… [Dijkstra]

Page 39 June 2012 SAT/SMT Summer School 2012

Exhaustive Testing ?

• Model checking is always “up to some bound”

– Limited (often finite) input domain, for specific properties, under some environment assumptions

• Ex: exhaustive testing of Win7 JPEG parser up to 1,000 input bytes

– 8000 bits  2^8000 possibilities  if 1 test per sec, 2^8000 secs – FYI, 15 billion years = 473040000000000000 secs = 2^60 secs!  MUST be “symbolic” !  How far can we go?

• Practical goals: (easier?)

– Eradicate all remaining buffer overflows in all Windows parsers – Reduce costs & risks for Microsoft: when to stop fuzzing? – Increase costs & risks for Black Hats !

• Many have probably moved to greener pastures already… (Ex: Adobe)
• Ex: <5 security bulletins in all the SAGE-cleaned Win7 parsers
• If noone can find bugs in P, P is observationally equivalent to “verified”!

Page 40 June 2012 SAT/SMT Summer School 2012

How to Get There?

1. Identify and patch holes in symbolic execution + constraint solving

• 2. Tackle “path explosion” with compositional testing and

symbolic test summaries [POPL’07,TACAS’08,POPL’10]

Page 41 June 2012 SAT/SMT Summer School 2012

The Art of Constraint Generation

• Static analysis: abstract away “irrelevant” details

– Good for focused search, can be combined with DART (Ex: [POPL’10]) – But for bit-precise analysis of low-level code (function pointers, in-lined assembly,...) ? In a non-property-guided setting? Open problem…

• Bit-precise VC-gen: statically generate 1 formula from a program

– Good to prove complex properties of small programs (units) – Does not scale (huge formula encodings), asks too much of the user

• SAT/SMT-based “Bounded Model Checking”: stripped-down VC-gen

– Emphasis on automation – Unrolling all loops is naïve, does not scale

• “DART”: the only option today for large programs (Ex: Excel)

– Path-by-path exploration is slow, but “whitebox fuzzing” can scale it to large executions + zero false alarms ! – But suffers from “path explosion”…

Page 42 June 2012 SAT/SMT Summer School 2012

DART is Beautiful

• Generates formulas where the only “free” symbolic

variables are whole-program inputs

– When generating tests, one can only control inputs !

• Strength: scalability to large programs

– Only tracks “direct” input dependencies (i.e., tests on inputs); the rest of the execution is handled with the best constant- propagation engine ever: running the code on the computer ! – (The size of) path constraints only depend on (the number of) program tests on inputs, not on the size of the program = the right metric: complexity only depends on nondeterminism!

• Price to pay: “path explosion” [POPL’07]

– Solution = symbolic test summaries

Page 43 June 2012 SAT/SMT Summer School 2012

Example

void top(char input[4]) { int cnt = 0; if (input[0] == ‘b’) cnt++; if (input[1] == ‘a’) cnt++; if (input[2] == ‘d’) cnt++; if (input[3] == ‘!’) cnt++; if (cnt >= 3) crash(); } input = “good” I0!=‘b’ I1!=‘a’ I2!=‘d’ I3!=‘!’ Path constraint:

Page 44 June 2012 SAT/SMT Summer School 2012

Compositionality = Key to Scalability

• Idea: compositional dynamic test generation [POPL’07]

– use summaries of individual functions (or program blocks, etc.)

• like in interprocedural static analysis
• but here “must” formulas generated dynamically

– If f calls g, test g, summarize the results, and use g’s summary when testing f – A summary φ(g) is a disjunction of path constraints expressed in terms of g’s input preconditions and g’s output postconditions: φ(g) =  φ(w) with φ(w) = pre(w)  post(w) – g’s outputs are treated as fresh symbolic inputs to f, all bound to prior inputs and can be “eliminated” (for test generation)

• Can provide same path coverage exponentially faster !
• See details and refinements in [POPL’07,TACAS’08,POPL’10]

Page 45 June 2012 SAT/SMT Summer School 2012

SAGAN tracks branch flipped

2000 4000 6000 8000 10000 12000 14000 16000 18000 20000 1 4 7 10 13 16 19 22 25 28 31 34 37 40 43 46 49 52 55 58 61 64 67 70 73 76 79 82 85 88 91 94 97 100

Sampled runs on Windows, many different file-reading applications Max frequency 17761, min frequency 592 Total of 290430 branches flipped, 3360 distinct branches

Summarize this !

Page 46 June 2012 SAT/SMT Summer School 2012

• Across different program paths
• Across different program versions

– “Incremental Compositional Dynamic Test Generation” [SAS’11]

• Across different applications 
• Summaries avoid unnecessary work
• What if central server of

summaries for all code?...

Summaries Cure Search Redundancy

IF…THEN…ELSE

Page 47 June 2012 SAT/SMT Summer School 2012

The Engineering of Test Summaries

• Systematically summarizing everywhere is foolish

– Very expensive and not necessary (costs outweigh benefits) – Not scalable without user help (see work on VC-gen and BMC)

• Summarization on-demand: (100% algorithmic)

– When? At search bottlenecks (with dynamic feedback loop) – Where? At simple interfaces (with simple data types) – How? With limited side-effects (to be manageable and “sound”)

• Goal: use summaries intelligently

– THE KEY to scalable bit-precise whole-program analysis ?

• Necessary, but sufficient? In what form(s)?

– Computed statically? [POPL’10, ISSTA’10]

• Stay tuned…

Page 48 June 2012 SAT/SMT Summer School 2012

Part 3:

Tests from Validity Proofs

(Higher-Order Test Generation) [PLDI’2011]

Page 49 June 2012 SAT/SMT Summer School 2012

Why Dynamic Test Gen.? Most Precise !

Example:

int obscure(int x, int y) { if (x==hash(y)) error(); return 0; }

• start with (random) x=33, y=42

Run 1 :

• solve: x==567  solution: x=567
• execute concretely and symbolically:

if (33 != 567) | if (x != hash(y)) constraint too complex  simplify it: x != 567

• new test input: x=567, y=42

Run 2 : the other branch is executed All program paths are now covered !

Observations:

– “Unknown/complex symbolic expressions can be simplified using concrete runtime values” [DART, PLDI’05] – Let’s call this step “concretization” (ex: hash(y)  567) – Dynamic test generation extends static test generation with additional runtime information: it is more powerful How often? When exactly? Why?  this work!

Page 50 June 2012 SAT/SMT Summer School 2012

Unsound and Sound Concretization

• Concretization is not always sound

int foo(int x, int y) { if (x==hash(y)) { if (y==10) error(); } … }

• Definition: A path constraint pc for a path w is sound if

every input satisfying pc defines an execution following w

• Sound concretization: add concretization constraints
• Theorem: path constraint is now always sound. Is this better? No

– Forces us to detect all sources of imprecision (expensive/impossible…) – Can prevent test generation and “good” divergences Run: x=567, y=42 pc: x==567 and y!=10 New pc: x==567 and y==10 New inputs: x=567, y=10 Divergence! pc and new pc are unsound ! pc: y==42 and x==567 and y!=10 (sound) New pc: y==42 and x==567 and y==10 (sound)

Page 51 June 2012 SAT/SMT Summer School 2012

Idea: Using Uninterpreted Functions

• Modeling imprecision with uninterpreted functions

int obscure(int x, int y) { if (x==hash(y)) error(); return 0; }

• How to generate tests?

– Is (∃x,y,h:) x=h(y) SAT? Yes, but so what? (ex: x=y=0, h(0)=0) – Need universal quantification ! (∀h:) ∃x,y: x=h(y) is this first-order logic formula valid?

• Yes. Solution (strategy): “fix y, set x to the value of h(y)”
• Test generation from validity proofs ! (not SAT models)

– Necessary but not sufficient: what “value of h(y)”?

Run: x=33, y=42 pc: x != h(y) New pc: x == h(y)

Page 52 June 2012 SAT/SMT Summer School 2012

Need for Uninterpreted Function Samples

• Record I/O UF samples

int obscure(int x, int y) { if (x==hash(y)) error(); return 0; }

• Use UF samples to interpret a validity proof/strategy

– “fix y, set x to the value of h(y)”  set y=42, x=567

• Or new pc: (∀h:) ∃x,y: (567=h(42)) => (x=h(y)) is valid?
• Higher-order test generation =

– models imprecision using Uninterpreted Functions – records UF samples as concrete input/output value pairs – generates tests from validity proofs of FOL formulas Key: a “higher-order” logic representation of path constraints

Run: x=33, y=42 Record: 567 == h(42) pc: x!=h(y)

Page 53 June 2012 SAT/SMT Summer School 2012

Higher-Order Test Generation is Powerful

• Theorem: HOTG is as powerful as sound concretization

– Can simulate it (both UFs and UF samples are needed for this)

• Higher-Order Test Generation is more powerful

Ex 1: (∀h:) ∃x,y: h(x)=h(y) is valid (solution: set x=y) Ex 2: (∀h:) ∃x,y: h(x)=h(y)+1 is invalid But (∀h:) ∃x,y: (h(0)=0 ∧ h(1)=1) => h(x)=h(y)+1 is valid (solution: set x=1, y=0) Ex 3:

int foo(int x, int y) { if (x==hash(y)) { if (y==10) error(); } … }

Run: x=567, y=42 pc: x==h(y) and y!=10 New pc: (∀h:)∃x,y: (h(42)=567) => x=h(y) ∧ y=10 is valid. Solution: set y=10, set x=h(10) 2-step test generation:

• run1 with y=10, x=567 to learn h(10) =66
• run2 with y=10, x=66 !

Page 54 June 2012 SAT/SMT Summer School 2012

Implementability Issues

• Tracking all sources of imprecision is problematic

– Excel on a 45K input bytes executes 1 billion x86 instructions

• Imprecision cannot always be represented by UFs

– Unknown input/output signatures, nondeterminism,…

• Capturing all input/output pairs can be very expensive
• Limited support from current SMT solvers

– ∃X:Ф(F,X) is valid iff ∀X:¬Ф(F,X) is UNSAT – little support for generating+parsing UNSAT ‘saturation’ proofs

• In practice, HOTG can be used for targeted reasoning

about specific user-defined complex/unknown functions

Page 55 June 2012 SAT/SMT Summer School 2012

Application: Lexers with Hash Functions

• Parsers with input lexers using hash functions for fast

keyword recognition

Initially, forall language keywords: addsym(keyword, hashtable) When parsing the input: X=findsym(inputChunk, hashtable); // is inputChunk in hashtable? if (x==52) … // how to get here?

• With higher-order test generation:

– Represent hashfunct by one UF h – Capture all pairs (hashvalue,h(keyword)) – If “h(inputChunk)==52” and “(52,h(‘while’))” -> inputChunk=‘while’ – This effectively inverses hashfunct only for all keywords – Sufficient to drive executions through the lexer ! – See [PLDI’2011] for details

Page 56 June 2012 SAT/SMT Summer School 2012

Other Related Work

• Modeling imprecision with UFs is well-known in program

verification of universal properties

– “may” abstractions, universal quantifiers only, validity checks – Here, novelty is for existential properties

• Test generation is only one way to verify existential

properties of programs

– More generally, one can build “must” abstractions – Alternation ∀∃ is also used then

• Test generation as a game is not new

– in model-based testing, testing for reactive systems, etc. – but from validity proofs of FOL formulas with UFs is new

Page 57 June 2012 SAT/SMT Summer School 2012

Summary (see [PLDI’2011])

• Higher-order test generation = UFs + UF samples +

test generation from validity checks of FOL formulas

• A new powerful form of test generation
• Tracking all sources of incompleteness is unrealistic,

targeted use of UFs is more practical (ex: lexer with h)

• A formal tool to define the limits of test generation
• Explains in what sense dynamic test generation

is more powerful than static test generation

– only in its ability to record concrete values in path constraints – concrete values are ultimately needed for test generation

Page 58 June 2012 SAT/SMT Summer School 2012

General Summary

• 1. Why Test Generation?
• 2. What kind of SMT constraints ?
• 3. New: test generation from validity proofs

Page 59 June 2012 SAT/SMT Summer School 2012

Conclusion: Impact of SAGE (In Numbers)

• 400+ machine-years

– Runs in the largest dedicated fuzzing lab in the world

• 3.4 Billion+ constraints

– Largest computational usage ever for any SMT solver

• 100s of apps, 100s of bugs (missed by everything else)
• Bug fixes shipped quietly (no MSRCs) to 1 Billion+ PCs
• Millions of dollars saved

– for Microsoft + time/energy savings for the world

• DART, Whitebox fuzzing now adopted by (many) others

(10s tools, 100s citations)

Page 60 June 2012 SAT/SMT Summer School 2012

Conclusion: Blackbox vs. Whitebox Fuzzing

• Different cost/precision tradeoffs

– Blackbox is lightweight, easy and fast, but poor coverage – Whitebox is smarter, but complex and slower – Note: other recent “semi-whitebox” approaches

• Less smart (no symbolic exec, constr. solving) but more lightweight:

Bunny-the-fuzzer (taint-flow, source-based, fuzz heuristics from input usage), Flayer (fault injection, not necessarily feasible), etc.

• Which is more effective at finding bugs? It depends…

– Many apps are so buggy, any form of fuzzing find bugs in those ! – Once low-hanging bugs are gone, fuzzing must become smarter: use whitebox and/or user-provided guidance (grammars, etc.)

• Bottom-line: in practice, use both! (We do at Microsoft)

Page 61 June 2012 SAT/SMT Summer School 2012

What Next? Towards Verification

• Tracking all(?) sources of incompleteness

– Possibly using UFs and Higher-Order Test Generation

• Summaries (on-demand…) against path explosion
• How far can we go?

– Reduce costs & risks for Microsoft: when to stop fuzzing? – Increase costs & risks for Black Hats (goal already achieved?)

• For history books !?

2000 2005 2010 2015 Blackbox Fuzzing Whitebox Fuzzing Verification

Page 62 June 2012 SAT/SMT Summer School 2012

Acknowledgments

• SAGE is joint work with:

– MSR: Ella Bounimova, David Molnar, … – CSE: Michael Levin, Chris Marsh, Lei Fang, Stuart de Jong,… – Interns Dennis Jeffries (06), David Molnar (07), Adam Kiezun (07), Bassem Elkarablieh (08), Marius Nita (08), Cindy Rubio-Gonzalez (08,09), Johannes Kinder (09), Daniel Luchaup (10), Nathan Rittenhouse (10), Mehdi Bouaziz (11), Ankur Taly (11)…

• Thanks to the entire SAGE team and users !

– Z3 (MSR): Nikolaj Bjorner, Leonardo de Moura,… – Windows: Nick Bartmon, Eric Douglas, Dustin Duran, Elmar Langholz, Isaac Sheldon, Dave Weston,…

• TruScan support: Evan Tice, David Grant,…

– Office: Tom Gallagher, Eric Jarvi, Octavian Timofte,… – SAGE users all across Microsoft!

• References: see http://research.microsoft.com/users/pg
