Foundations of Global Networked Computing: Building a Modern Computer From First Principles

IWKS 3300: NAND to Tetris Spring 2019 John K. Bennett

This course is based upon the work of Noam Nisan and Shimon Schocken. More information can be found at (www.nand2tetris.org).

Machine Language

Where we are:

Assembler

Chapter 6

H.L. Language & Operating Sys.

abstract interface

Compiler

Chapters 10 - 11

VM Translator

Chapters 7 - 8

Computer Architecture

Chapters 4 - 5

Gate Logic

Chapters 1 - 3

Electrical Engineering Physics Virtual Machine

abstract interface

Software hierarchy

Assembly Language

abstract interface

Hardware hierarchy

Machine Language

abstract interface

Hardware Platform

abstract interface

Chips & Logic Gates

abstract interface

Human Thought Abstract design

Chapters 9, 12

Assembly Language / Machine Code

Abstraction – implementation duality:  Assembly language (the instruction set architecture) can be viewed as a (sort-of) programmer-oriented abstraction of the hardware platform  The hardware platform represents a physical means for realizing the assembly language / machine code abstraction Assembly Language and Machine Code Statements are Generally One-to-One:  Symbolic assembly language statement, e.g., “D=A”  That statement translates into executable binary, e.g., “1110110000010000” Assembly Language / Machine Code:  Roughly speaking, machine code represents an agreed-upon formalism for manipulating data in memory using a processor and (usually) a set of registers.  Assembly language syntax can differ widely across different hardware platforms.

Machine Code vs. Assembly

Evolution:  Physical coding  Symbolic documentation  Symbolic coding  Translation and execution  Assembly requires translation.

1010 0001 0010 1011 ADD R1, R2, R3

Jacquard loom (1801) Augusta Ada King, Countess of Lovelace (1815-1852)

Some Typical Assembly Language Commands

// In what follows R1,R2,R3 are registers, PC is program counter, // and addr is some address in memory. ADD R1,R2,R3 // R1  R2 + R3 ADDI R1,R2,addr // R1  R2 + addr AND R1,R1,R2 // R1  R1 and R2 (bit-wise) JMP addr // PC  addr JEQ R1,R2,addr // IF R1 == R2 THEN PC  addr ELSE PC++ LOAD R1, addr // R1  RAM[addr] STORE R1, addr // RAM[addr]  R1 NOP // Do nothing // Etc. – *many* variants

Three Address Architecture

 Consider the following code fragment: X = (A-B) / (C+(D*E)) Load R1, A // R1 ← Mem[A] Load R2, B // R2 ← Mem[B] Sub R3, R2, R1 // R3 ← R2 – R1 Load R1, D // R1 ← Mem[D] Load R2, E // R2 ← Mem[E] Mpy R4, R1, R2 // R4 ← R1 * R2 Load R1, C // R1 ← Mem[C] Add R2, R1, R4 // R2 ← R1 + R4 Div R1, R3, R2 // R1 ← R3 / R2 Store X, R1 // Mem[X] ← R1

This code: 6 Memory references, code is not compact There are typically a finite number of registers,

• n the order of 16-32

Two Address Architecture

 Consider the following code fragment: X = (A-B) / (C+(D*E)) Load R1, A // R1 ← Mem[A] Load R2, B // R2 ← Mem[B] Sub R2, R1 // R2 ← R2 – R1 Load R1, D // R1 ← Mem[D] Load R3, E // R3 ← Mem[E] Mpy R1, R3 // R1 ← R1 * R3 Load R4, C // R4 ← Mem[C] Add R1, R4 // R1 ← R1 + R4 Div R2, R1 // R2 ← R2 / R1 Store X, R2 // Mem[X] ← R2

There are typically a finite number of registers,

• n the order of 16-32

This code: 6 Memory references, code is not compact

One Address Architecture

 Consider the following code fragment: X = (A-B) / (C+(D*E)) Load A // Acc ← Mem[A] Sub B // Acc ← Acc - Mem[B] Store Temp1 // Mem[Temp1] ← Acc Load D // Acc ← Mem[D] Mpy E // Acc ← Acc * Mem[E] Add C // Acc ← Acc + Mem[C] Store Temp2 // Mem[Temp2] ← Acc Load Temp1 // Acc ← Mem[Temp1] Div Temp2 // Acc ← Acc / Mem[Temp2] Store X // Mem[X] ← Acc

There is one register, called the Accumulator This code: 10 Memory references, code is more compact

Zero Address Architecture

 Consider the following code fragment: X = (A-B) / (C+(D*E)) Push D // SP = SP + 1; Mem[SP] ← Mem[D]; Push E // SP = SP + 1; Mem[SP] ← Mem[E]; Mpy // Mem[SP-1] ← Mem[SP] * Mem[SP-1]; // SP = SP -1 Push C // SP = SP + 1; Mem[SP] ← Mem[C] Add // Mem[SP-1] ← Mem[SP] + Mem[SP-1] // SP = SP -1 Push A // SP = SP + 1; Mem[SP] ← Mem[A] Push B // SP = SP + 1; Mem[SP] ← Mem[B] Sub // Mem[SP-1] ← Mem[SP] - Mem[SP-1]; // SP = SP -1 Div // Mem[SP-1] ← Mem[SP] / Mem[SP-1] Pop X // Mem[X] ← Mem[SP]; SP = SP - 1

24 Memory references, code is very compact

The Hack Computer

A 16-bit machine (this means that the ALU and memory width are 16 bits) consisting of the following elements: Data memory: RAM – an addressable sequence of registers* Instruction memory: ROM – an addressable sequence of registers* Registers: D, A, M, where M stands for RAM[A] Processing: ALU, capable of computing various functions Program counter: PC, holding an address Control: The ROM is loaded with a sequence of 16-bit instructions, one per memory location, beginning at address 0. These instructions are fetched and executed in sequence until a jump instruction is encountered, at which time the PC is set to the jump address. Simple Instruction set: Only two Instructions: A-instruction, C- instruction; A fair amount of complexity is packed into C-instructions

* Hack computer only; Recall that real memory is not implemented using registers.

The Hack CPU (no control shown)

The Hack Computer

Hack Assembly and VM Code

 Hack Assembly is a hybrid (1/2 address) code, but has only two kinds of instructions (Chapters 4, 5 & 6)  Hack VM is zero address (wait for Chapters 7 & 8)

A Hack Machine Language Example

Jack Code // Adds 1+…+100. var int i, sum; let i =1; let sum = 0; while (i < 101) { let sum = sum + 1; let i = i + 1; }

A-Instructions

value (v = 0 or 1) v v v v v v v v v v v v v v v Binary: @value // Where value is either a non-negative decimal number // or a symbol referring to such number. Symbolic:

Translation to binary:

 If value represents a non-negative number, see next slide  We will handle the case when value is a symbol in Chapter 6

(Assembler).

A Instructions @value

// A  value Where value is either a non-negative number or a symbol referring to a number.

Used for:

 Entering a constant value

( A = value)

@17 // A = 17 D = A // D = 17

Coding example:

@17 // A = 17 D = M // D = RAM[17]

 Selecting a RAM location

( register = RAM[A])

@17 // A = 17 JMP // branch to and fetch the // instruction stored in ROM[17]

 Selecting a ROM location

( PC = A )

C-Instructions - Lots Going On

jump dest comp 1 1 1

a c1 c2 c3 c4 c5 c6 d1 d2 d3 j1 j2 j3

dest=comp;jump // Either the dest or jump fields may be empty. // If dest is empty, the "=" is ommitted; // If jump is empty, the ";" is omitted. Symbolic: Binary:

The Comp Field Determines ALU Output (a and c1-c6)

The ‘a’ bit chooses ‘A’ or ‘M’ as the Y input to the ALU (the X ALU input is always D). c1-c6 of the Comp Field are identical to ALU control inputs 

The A-Register/M Multiplexor (and ALU Out Data Path)

ALU

Mux

D A/M a-bit

D register

A register A M RAM

(selected register)

ROM

(selected register)

PC

Instruction

address input address input

x y

• ut

Control Logic

Control Signals

The Hack CPU (where the control signals go)

The Hack Computer

The Dest Field A D M Each bit designates a destination (A, D, or M):

The Jump Field

The effects of j1-j3 are related to the zr and ng ALU output bits: j1 (out < 0): ng j2 (out = 0 ): zr j3 (out > 0): ng NOR zr

The C-Instruction

Exercise 1: Implement the following tasks Using Hack Assembly and Machine Code:

 Set D to A-1  Set both A and D to A + 1  Set D to 19  Set both A and D to A + D  Set RAM[5034] to D - 1  Set RAM[53] to 171  Add 1 to RAM[7],

and store the result in D.

dest = n + s dest = n - s dest = n dest = 0 dest = 1 dest = -1 n = {A, D, M} s = {A, D, M , 1} dest = {A, D, M, MD, A, AM, AD, AMD, null}

Possible Destinations

The C-Instruction

j 3012 sum 4500 q 3812 arr 20561 Symbol table: (Symbols and values are arbitrary examples)

Exercise 2: Implement the following code using Hack Assembly Language:

 sum = 0  j = j + 1  q = sum + 12 – j  arr[3] = -1  arr[j] = 0  arr[j] = 17

dest = x + y dest = x - y dest = x dest = 0 dest = 1 dest = -1 x = {A, D, M} y = {A, D, M , 1} dest = {A, D, M, MD, A, AM, AD, AMD, null}

Control (focus on the yellow chips)

ALU

Mux

D A/M a-bit

D register

A register A M RAM

(selected register)

ROM

(selected register)

PC

Instruction

In the Hack architecture:



ROM = instruction memory



Program = sequence of 16-bit numbers, starting at ROM[0]



Current instruction = ROM[PC]



To select instruction n from the ROM, we set A to n, using the instruction @n

address input address input

Handling A-Register Conflicts  The Hack programmer can use the A register to select either a data memory location for a subsequent C- instruction involving M, or an instruction memory location for a subsequent C-instruction involving a jump.  Thus, to prevent conflicting use of the A register, in well- written Hack programs, a C-instruction may contain non- zero j bits (indicating a jump), OR the d3 bit can be set (indicating a reference to M), but not both.

Coding Example

Exercise 3: Implement the following code using Hack Assembly Language:

 goto 50  if D==0 goto 112  if D<9 goto 507  if RAM[12] > 0 goto 50  if sum>0 goto END  if x[i]<=0 goto NEXT.

sum 2200 x 4000 i 15 END 50 NEXT 120

Symbol table:

(All symbols and values in are arbitrary examples)

Hack commands:

A-command: @value // set A to value C-command: dest = comp ; jump // dest = and ;jump // are optional Where: comp = 0 , 1 , -1 , D , A , !D , !A , -D , -A , D+1 , A+1 , D-1, A-1 , D+A , D-A , A-D , D&A , D|A , M , !M , -M ,M+1, M-1 , D+M , D-M , M-D , D&M , D|M dest = M , D , MD , A , AM , AD , AMD, or null jump = JGT , JEQ , JGE , JLT , JNE , JLE , JMP, or null In the command dest = comp; jump, the jump materialzes if (comp jump 0) is true. For example, in D=D+1,JLT, we jump if D+1 < 0.

Hack convention:

 True is represented by -1  False is represented by 0

if condition { code block 1} else { code block 2}

code block 3

High level: D  not condition @IF_TRUE D;JEQ code block 2 @END 0;JMP (IF_TRUE) code block 1 (END)

code block 3

Hack:

Hack If logic

Hack convention:

 True is represented by -1  False is represented by 0

Hack While Logic

while condition { code block 1 }

Code block 2

High level: (LOOP) D  not condition) @END D;JEQ code block 1 @LOOP 0;JMP (END)

code block 2

Hack: Hack convention:

 True is represented by -1  False is represented by 0

Complete program example

// Adds 1+...+100. int i = 1; int sum = 0; while (i <= 100){ sum += i; i++; }

C language code:

// Adds 1+...+100. @i // i refers to some RAM location M=1 // i=1 @sum // sum refers to some RAM location M=0 // sum=0 (LOOP) @i D=M // D = i @100 D=D-A // D = i - 100 @END D;JGT // If (i-100) > 0 goto END @i D=M // D = i @sum M=D+M // sum += i @i M=M+1 // i++ @LOOP 0;JMP // Got LOOP (END) @END 0;JMP // Infinite loop

Hack assembly code: Hack assembly convention:

 Variables: lower-case  Labels: upper-case  Commands: upper-case

add.jack

// JKB /** Computes the sum of the first 100 integers. */ class Main { function void main() { var int i, sum; let i =1; let sum = 0; while (i < 101) { let sum = sum + i; let i = i + 1; } do Output.printString("THE SUM IS: "); do Output.printInt(sum); do Output.println(); return; } }

Symbols in Hack assembly programs

Symbols created by Hack programmers and code generators:

 Label symbols: Used to label destinations of goto commands. Declared by the pseudo command (label). This directive defines the symbol label to refer to the instruction memory location holding the next command in the program (within the program, label is called “label”)  Variable symbols: Any user-defined symbol label appearing in an assembly program that is not defined elsewhere using the (label) directive is treated as a variable, and is “automatically” assigned a unique RAM address, starting at RAM address 16  By convention, Hack programmers use lower-case and upper-case letters for variable names and labels, respectively.

Predefined symbols:

 I/O pointers: The symbols SCREEN and KBD are “automatically” predefined to refer to RAM addresses 16384 and 24576, respectively (base addresses of the Hack platform’s screen and keyboard memory maps)  Virtual registers: covered in future lectures.  VM control registers: covered in future lectures.

// Typical symbolic // Hack code, meaning // not important

@R0 D=M @INFINITE_LOOP D;JLE @counter M=D @SCREEN D=A @addr M=D (LOOP) @addr A=M M=-1 @addr D=M @32 D=D+A @addr M=D @counter MD=M-1 @LOOP D;JGT (INFINITE_LOOP) @INFINITE_LOOP 0;JMP

Q: What does the assignment of symbols to RAM addresses? A: The assembler, which is the program that translates symbolic Hack programs into binary Hack program. As part of the translation process, the symbols are resolved to RAM addresses.

Perspective

 Hack is a simple machine language  User friendly syntax: D=D+A instead of ADD D,D,A  Hack is a “½-address machine”: any operation that needs to operate on the RAM must be specified using two commands: an A-command to address the RAM, and a subsequent C-command to operate on it  The Hack assembler will be discusses and developed in Chapter 6  A Macro-language could be developed

Exercise 1

Implement the following operations using both Hack Assembly and Hack Machine (binary) code :

 Set D to A-1  Set both A and D to A + 1  Set D to 19  Set both A and D to A + D  Set RAM[5034] to D - 1  Set RAM[53] to 171  Add 1 to RAM[7],

and store the result in D.

Exercise 2

Implement the following high level code snippets using Hack Assembly Language:

 sum = 0  j = j + 1  q = sum + 12 – j  arr[3] = -1  arr[j] = 0  arr[j] = 17

j 3012 sum 4500 q 3812 arr 20561 Symbol table: (Symbols and values are arbitrary examples)

Hack convention:

 True is represented by -1  False is represented by 0  R13-R15 are temps

Exercise 3

Implement the following pseudo code snippets using Hack Assembly Language:



goto 50



if (D==0) goto 112



if (D<9) goto 507



if (RAM[12] > 0) goto 50



if (sum>0) goto END



if (x[i]<=0) goto NEXT

sum 2200 x 4000 i 15 END 50 NEXT 120

Symbol table:

(All symbols and values are arbitrary examples)

Hack convention:

 True is represented by -1  False is represented by 0  R13-R15 are temps
