SLIDE 1
Frank Reinartz Product Manager
M. CS/Z.CS Frank Reinartz Product Manager M.CS/Z.CS WEIGHT - - PowerPoint PPT Presentation
M. CS/Z.CS Frank Reinartz Product Manager M.CS/Z.CS WEIGHT - - PowerPoint PPT Presentation
M. CS/Z.CS Frank Reinartz Product Manager M.CS/Z.CS WEIGHT REDUCTION FOR ALL VARIANTS Huge weight savings for the entire vehicle train M.CS+Z.CS MEGA approx. 500 kg lighter than the previous model Z.CS MEGA unladen weight
SLIDE 2
SLIDE 3
- Huge weight savings for the entire vehicle train
- M.CS+Z.CS MEGA approx. 500 kg lighter than
the previous model
- Z.CS MEGA unladen weight begins at 4,400 kg
- Adaptation of the proven S.CS body
(certified to DIN EN 12642 XL) 500 kg more payload with proven quality Optimised cost efficiency Reduced total cost of ownership
M.CS/Z.CS
WEIGHT REDUCTION FOR ALL VARIANTS
SLIDE 4
- Approx. 100 kg weight saving for the M.CS
- Approx. 400 kg weight saving for the Z.CS
- Corrosion protection through hot-dip galvanised chassis
500 kg more payload with the proven quality of our M.CS/Z.CS frame constructions Corrosion protection including 10-year warranty against rust-through on hot-dip galvanised parts High value retention Loading height reduced by 20 mm
M.CS/Z.CS
THE WEIGHT-OPTIMISED CHASSIS WITH HOT-DIP GALVANISED DESIGN
SLIDE 5
- S.CS body on the M.CS/Z.CS MEGA
- Body certified to DIN EN 12642 Code XL
- Sturdy design
- Use of synergy effects
- Standardisation of spare parts
High-quality body with an outstanding price/performance ratio Uniform vehicle design for fleet with semi-trailers and articulated trains
M.CS/Z.CS
ADAPTATION OF THE PROVEN S.CS BODY
SLIDE 6
- S.CS body on the M.CS/Z.CS MEGA
- Robust bulkhead and rear portal with galvanised
steel corner supports for optimal stability
- Lifting roof with manual stanchion lifts as standard
- Clear interior height can be set to
2900/2950/3000 mm Proven quality Maximum volume High flexibility Easy, safe and standardised handling
M.CS/Z.CS
ADAPTATION OF THE PROVEN S.CS BODY
SLIDE 7
- Full-length, easily accessible lashing
holes in the outer frame
- Lashing-holes in the inner frame
- Certified body (DIN EN 12642 XL)
- Additional load securing certificates
available (Beverages, Daimler 9.5) Diverse and flexible load-securing options for every application Safe, fast and easy load securing Load securing elements easily accessible
M.CS/Z.CS
IMPROVED LOAD SECURING
SLIDE 8
- Enclosed hinge mountings on the corner
stanchions (S.CS rear portal)
- Winch-version spare wheel holder
- Weight-optimised support on the Z.CS with
central support leg at the front Protects the hinges against damage Easier handling of the spare wheel and increased ground clearance Increased payload
M.CS/Z.CS
ADDITIONAL FEATURES OF THE M.CS/Z.CS MEGA
