slide-1
SLIDE 1

Low Level RF Control System

Brian Chase MaRIE Meeting March 2016

slide-2
SLIDE 2

LLRF Experience and capabilities

  • RF systems –

– Broadband through 3.9 GHz – Copper and SRF – Triodes, Tetrodes, IOTs, Klystrons and Magnetrons – Linacs and Synchrotrons – Analog, DSP and FPGA based systems – Presently we have about 50 systems in operation

  • 3/9/16

AD/LLRF 2

slide-3
SLIDE 3

SRF LINAC Involvements

  • Tesla Test Facility
  • A0 Photo Injector
  • ILC LLRF Development team
  • NML -> FAST

– 32 cavities/klystron

  • Interactions with XFEL team
  • Project X, PIP-II, PXIE
  • CMTS-1
  • LCLS-II LLRF team

– LBNL, JLAB, FNAL, SLAC

  • 3/9/16

AD/LLRF

Helen Edwards

3

slide-4
SLIDE 4

RF Stations Diagram

PXIE Review, B.

4

PXIE LLRF DIAGRAM

M M M M M M M M M M M M M M M M

Half-wave Resonator Cryomodule (HWR)(162.5MHz.) Single-spoke Resonator Cryomodule (SSR1)(325MHz.)

RFQ

BUNCHING CAVITY1 #1 FAST CHOPPER #2 FAST CHOPPER BUNCHING CAVITY2 BUNCHING CAVITY3 ABSORBER

MEBT (162.5MHz.) LEBT

H W R BPM & Corrector coil H W R H W R H W R H W R H W R H W R H W R Corrector coil & BPM S S R 1

DUMP

(162.5MHz.)

LLRF crate 1:

  • CPU, PS
  • 2 LLRF MFC
  • Timing Distribution
SSRCavREV [1..8] SSRCavFWD [1..8] SSRCavProbe [1..8]

1……………………...8

3X LLRF crate 1:

  • CPU, PS
  • 3 LLRF MFC
  • Timing Distribution
HWRCavREV[1..8] HWRCavFWD[1..8] HWRCavProbe [1..8]

3X

1……………………...8

PA PA CHOPPER PROGRAM MODULE

BCavProbe3 BCavProbe2 BCavProbe1 RFQProbe RFQREV RFQFWD BCavREV1 BCavFWD1 BCavREV2 BCavFWD2 BCavFWD3 BCavREV3

2X

RFQProbe, BCavREV[1..3] RFQFWD, BCavFWD[1..3] RFQREV, BCavProbe[1..3] Reference Tap HWRCavREV1 HWRCavFWD1 HWRCavFWD8 HWRCavREV8 SSRCavREV1 SSRCavFWD1 SSRCavFWD8 SSRCavREV8 HWRCavProbe1 HWRCavProbe8 SSRCavProbe1 SSRCavProbe8 Reference Tap

PA PA PA PA PA PA

LLRF crate 2:

  • CPU, PS
  • Interlock Systems

LLRF crate 2:

  • CPU, PS
  • Interlock Systems

LLRF crate 3:

  • CPU, PS
  • Motor Controller
  • Resonance Controller

LLRF crate 2:

  • CPU, PS
  • Motor Controller
  • Resonance Controller

Local Oscillator Timing & Synchronization Inter-System Feedback Network/Bus MPS Network/Bus LLRF crate 2:

  • CPU, PS
  • Motor Controller
  • Resonance Controller

162.5Interlock[1..12] 325Interlocks[1..8]

162.5Interlock1 162.5Interlock5 162.5Interlock12 325Interlock1 325Interlock8 162.5Interlock2 162.5Interlock3 162.5Interlock4

162.5ResonanceCntrl[1..12] 325ResonanceCntrl[1..8] 24 36 16 24

162.5ResonanceCntrl5 162.5ResonanceCntrl12 325ResonanceCntrl1 325ResonanceCnrtl8 162.5ResonanceCntrl1 162.5ResonanceCntrl4 162.5ResonanceCntrl3 162.5ResonanceCntrl3

FAST CHOPPER

  • B. Chase, E. Cullerton, D. Klepec

1/14/13 Version 1.0

slide-5
SLIDE 5

Control system interface diagram (NML)

ADC

  • DAC
CIC Filter(D=12) Atten = 12/16

Vector Sum Down Converter Set Point Prop Gain (+/- 1024) Integral Gain Clamp FS Integrator Pole FeedForward Clamp FS Up Converter 1.29 Vpp Max (6.2 dBm) 1:2 2 Vpp FS 0.5 Vpp FS A , Amplitude Limit(0 M 0.99) Phase A , Amplitude Limit (0 M 1.99) Phase DAC 0.5 Vpp FS Iout Qout BPF 2.16 12.0 13.0 14.6 14.6 14.6 14.2 14.4 15.6 11.5 25.4 14.4 +/- 4096 2.14 1.31 15.36 16.36 15.4 Feedback ON/OFF RF ON/OFF Z-1 Clamp ½ FS 14.2 2.14 16.4 14.0 GAIN/ ATTEN 1 1.9305 1/2

16/12

m 2 CAV N 1.31 14.4 16.2 15.36 14.4 Clamp FS +/- 2048 +/- 4096 +/- 4096 +/- 1536 +/-8192 +/- 16384 +/- 8192 +/- 4096 +/- 8192 +/- 12288 +/-8192 +/- 20480 +/- 8192 +/- 8192 +/- 8192 +/-2 +/-1

LP FIR Filter Gain = 16/12

14.4 14.4 +/- 8192 +/- 8192 14.4 +/- 8192 2.16 +/-1

Variable Notch Filter(900 kHz) Unity Gain Fixed Notch Filter(2.95 MHz) Unity Gain

+/-180 +/-180 15.16

Round/ Saturate

13.3

TRUNC Dec 60 CIC Filter Fs = 1.04MHz Atten = 225/256

12.4 16.0

Dec 30 CIC Filter Fs = 2.08MHz Atten = 225/256

12.4 16.0

TRUNC

13.3

TRUNC Dec 30 CIC Filter Fs = 2.08MHz Gain = 225/256

14.2 14.2

TRUNC Dec 30 CIC Filter Fs = 2.08MHz Atten = 225/256

14.2 14.2

TRUNC

15.1

Dec 30 CIC Filter Fs = 2.08MHz Atten = 225/256

15.1 14.2

Dec 30 CIC Filter Fs = 2.08MHz Atten = 225/256 TRUNC

14.2

Dec 30 CIC Filter Fs = 2.08MHz Atten = 225/256 MULT x 4

16.0 16.0

Raw Units Primary/ Common Units

MULT x 1 MULT x 4 MULT x 2 MULT x 4 MULT x 4 MULT x 16 MULT x16

16.0 16.0 16.0 16.0 16.0

12/16

CAVITY MUX 1 MUX 2 MUX 3 MUX 4 MUX 5 VSUM

(After Filtering) FF ON/OFF 14.6 +/- 8192

MULT x 4

+/- 6144 14.6

4

FF and SP Timing (S) ()TDLY initial delay (SP only) ()TFIL fill time ()TFT flat top time ()KIGN ()IPOL ()SPA ()SPQ ()SPTu : ()FFA ()FFQ ()FFRA ratio afill/aft ()KPGN ()CUCM ()CUCQ ()NCHF ()NCHQ ()RFEN ()FFEN ()FBEN ()C[1-8]CM ()C[1-8]CQ ACNET PREFIX N:M1___ CMLLRF operational system Z:N1 ___ CMLLD development system Waveform Scaling Slot 0 Raw = input*256/225 Labview Primary = Raw/32768 Labview Common = C*Primary C = Cav_To_MV_m = Fwd_To_SQRT_kW = Rev_To_SQRT_kW

5

PXIE Review, B.

slide-6
SLIDE 6

System on Module Multi-cavity Field Controller (SOM-MFC) SOM is socketed and upgradable

3/9/16 AD/LLRF 6

slide-7
SLIDE 7

SOM-MFC LLRF Controller

3/9/16 AD/LLRF

(16) 14 bit ADCs (8)14 bit DACs System on Module

7

slide-8
SLIDE 8

VXI CPU & 3 R3MFC Controllers Master Oscillator Receivers and Up-converter Power Supplies

AD/ LLRF

NML CM1 LLRF Racks

Capable of driving 32 cavities from a single klystron

8

slide-9
SLIDE 9

LLRF Control interface

3/9/16 AD/LLRF 9

slide-10
SLIDE 10

LCLS-II and MaRIE XFEL

  • Project is very closely aligned

– 1.3 GHz 9-cell cavities – 3.9 GHz in bunch compressor section – 0.004% rms, 0.004 degree rms

  • LCLS-II LLRF collaboration team

– Larry Doolitte* (LBNL), Curt Hovater (Jefferson Lab), Brian Chase (FNAL), Sandeep Babel(SLAC) – Strong groups at each lab

  • Complete prototype system tests at Jlab and FNAL this

summer

  • Multi-lab support for a basically drop in system

*Technical lead

3/9/16 AD/LLRF 10

slide-11
SLIDE 11

RF parameters

  • 900 usec fill, 100 usec beam
  • 0.01%, 0.01 deg
  • 60 Hz operation
  • 10 MW klystrons split 26 ways
  • Ql = 2.9E6

3/9/16 AD/LLRF 11

slide-12
SLIDE 12

LLRF


 LCLS-II 1.3 GHz HPRF Penetration Layout


  • Nantista, Stewart w/ team input

SSAs

North Side

AD/LLRF

12

slide-13
SLIDE 13

Because of the XFEL style split

  • Best technical fit
  • Recommend that the XFEL LLRF system be cloned

– It is developed by a very large team, has all the firmware and software – Hardware is available from industry

  • If this is nonviable for non-technical reasons then the LCLS-II

team is very capable to complete this project

  • 3/9/16

AD/LLRF 13

slide-14
SLIDE 14

Feedforward only 300kW 2.9E6

3/9/16 AD/LLRF 14

slide-15
SLIDE 15

Closed loop with current parameters

3/9/16 AD/LLRF 15

slide-16
SLIDE 16

Optimized for power/fill/flattop/cryo

3/9/16 AD/LLRF

550usec fill 500usec flattop

16
