Low Impact Focus Group

Monthly Meeting September 19, 2017

Forward Together • ReliabilityFirst

Opening Comments

2

• This meeting is being recorded
• All lines are open in order to facilitate discussion
• Please mute your line when not speaking
• Please do not put this call on hold – many

systems play music on hold

• If you need to answer another call, please disconnect and

call back in

Forward Together • ReliabilityFirst

Announcements

• NERC’s Antitrust Guidelines are available at:
• http://www.nerc.com/pa/Stand/Resources/Documents/NER

C_Antitrust_Compliances_Guidelines.pdf

• This is a public call. RF cannot pre-screen the

attendees.

3

Forward Together • ReliabilityFirst

Mailing List

• ciplifg@lists.rfirst.org
• This list is intended as a discussion forum. We

will need to see how well this works with more than 150 members.

• List changes, such as additions or removals,

should be sent to: lew.folkerth@rfirst.org

4

Forward Together • ReliabilityFirst

Special Topics Meetings

• A survey is planned for the near future. A link

will be send to the CIPLIFG list.

• Possible Topics:
• CIP-101 Low Impact Introduction
• Electronic Access Controls
• Physical Access Controls
• Tips and Techniques for Compliance Documentation
• Compliance Evidence
• What Happens During an Audit?
• In-depth discussion of emerging Standards

5

Forward Together • ReliabilityFirst

Standards Update

• CIP-002-6 Draft 1
• Posted for formal comment through October 30
• Ballot pool forming through October 13
• Initial ballot October 20-30

6

Forward Together • ReliabilityFirst

Standards Update

• CIP-002-6 Draft 1 Change Summary
• Housekeeping changes

‒ “CIP-002-5.1” to “CIP-002-6” ‒ Note: The approved Interpretation has not been incorporated into this revision, so the proper designation of these Standards is “CIP-002-5.1a” and CIP-002-6a” ‒ The NERC Glossary term “Special Protection System” is

• bsolete and has been removed

‒ Applicability function 4.1.5, “Interchange Coordinator or Interchange Authority,” is obsolete and has been removed ‒ Section 5.0, “Effective Dates,” references the Implementation Plan ‒ [R1.v] “Special Protection Systems” changed to “Remedial Action Schemes” ‒ Section “E. Interpretations” added referencing Appendix 1

7

Forward Together • ReliabilityFirst

Standards Update

• CIP-002-6 Draft 1 Change Summary
• Substantive changes: Impact Rating Criterion 2.12

‒ CIP-002-5.1a

• Each Control Center or backup Control Center used to

perform the functional obligations of the Transmission Operator not included in High Impact Rating (H), above. ‒ CIP-002-6a

• Control Centers or backup Control Centers, not included in

High Impact Rating (H) above, that monitor and control BES Transmission Lines with an "aggregate weighted value" exceeding 6000 according to the table below. The "aggregate weighted value“ for a Control Center or backup Control Center is determined by summing the "weight value per line" shown in the table below for each BES Transmission Line monitored and controlled by the Control Center or backup Control Center.

8

Forward Together • ReliabilityFirst

Standards Update

• CIP-002-6 Draft 1 Change Summary

2.12. Control Centers or backup Control Centers, not included in High Impact Rating (H) above, that monitor and control BES Transmission Lines with an "aggregate weighted value" exceeding 6000 according to the table below. The "aggregate weighted value“ for a Control Center

• r backup Control Center is determined by summing the "weight value

per line" shown in the table below for each BES Transmission Line monitored and controlled by the Control Center or backup Control Center.

9

Voltage Value of a Line Weight Value per Line

less than 100 kV (not applicable) (not applicable) 100 kV to 199 kV 250 200 kV to 299 kV 700 300 kV to 499 kV 1300 500 kV and above

Forward Together • ReliabilityFirst

Standards Update

• CIP-002-6 Implementation Plan
• CIP-002-6 Effective Date: On the effective date of the
• rder approving CIP-002-6, or 60 days after BoT

approval where governmental approval is not required

• Planned Changes – Initial Performance

‒ Initial performance of periodic requirements shall occur by the end of the specified period following the update of the identification and categorization of the affected BES Cyber

• System. For example, initial performance shall be within 15

months following the update of the identification and categorization of the affected BES Cyber System for requirements that must be performed at least once every 15 calendar months.

10

Forward Together • ReliabilityFirst

Standards Update

• CIP-002-6 RSAW
• No significant changes expected

11

Forward Together • ReliabilityFirst

Future Meetings

• Next conference call (WebEx):
• Tuesday, October 24, 2017 [note date change]

at 11:00AM EDT

12

Forward Together • ReliabilityFirst

Questions & Answers

Forward Together ReliabilityFirst

13
