SLIDE 1

Loophole

Timing Attacks on Shared Event Loops in Chrome Pepe Vila November 22, 2016

Pepe Vila Loophole November 22, 2016 1 / 22

SLIDE 2

Introduction

Event-driven programming Event loops A timing side-channel on event loops

Pepe Vila Loophole November 22, 2016 2 / 22

SLIDE 3

Introduction: Event-driven programming

EDP is a programming paradigm for GUI, web clients, networks and server-side

1https://html.spec.whatwg.org/#event-loop Pepe Vila Loophole November 22, 2016 3 / 22

SLIDE 4

Introduction: Event-driven programming

EDP is a programming paradigm for GUI, web clients, networks and server-side The flow of the program is determined by events or messages

1https://html.spec.whatwg.org/#event-loop Pepe Vila Loophole November 22, 2016 3 / 22

SLIDE 5

Introduction: Event-driven programming

EDP is a programming paradigm for GUI, web clients, networks and server-side The flow of the program is determined by events or messages Examples: Nginx, Node.js or memcached Used for message passing: inter-(thread | process) communication HTML5 standard 1 mandates user agents to use EDP:

1https://html.spec.whatwg.org/#event-loop Pepe Vila Loophole November 22, 2016 3 / 22

SLIDE 6

Introduction: Event loops

Event loop, message dispatcher, message loop, or run loop

Pepe Vila Loophole November 22, 2016 4 / 22

SLIDE 7

Introduction: Event loops

Event loop, message dispatcher, message loop, or run loop FIFO queue & dispatcher:

Q = []; while (true) { M = Q.shift (); // dequeue process(M); }

Pepe Vila Loophole November 22, 2016 4 / 22

SLIDE 8

Introduction: Event loops

Event loop, message dispatcher, message loop, or run loop FIFO queue & dispatcher:

Q = []; while (true) { M = Q.shift (); // dequeue process(M); }

If queue is empty, waits until an event arrives

Pepe Vila Loophole November 22, 2016 4 / 22

SLIDE 9

Introduction: Event loops

Event loop, message dispatcher, message loop, or run loop FIFO queue & dispatcher:

Q = []; while (true) { M = Q.shift (); // dequeue process(M); }

If queue is empty, waits until an event arrives Blocking operations (e.g., database and network requests) are dealt with asynchronously

Pepe Vila Loophole November 22, 2016 4 / 22

SLIDE 10

Introduction: Event loops

Event loop, message dispatcher, message loop, or run loop FIFO queue & dispatcher:

Q = []; while (true) { M = Q.shift (); // dequeue process(M); }

If queue is empty, waits until an event arrives Blocking operations (e.g., database and network requests) are dealt with asynchronously Simple concurrency model for programmers

Pepe Vila Loophole November 22, 2016 4 / 22

SLIDE 11

Introduction: A timing side-channel on event loops

Event loops are susceptible to timing side-channel attacks:

Pepe Vila Loophole November 22, 2016 5 / 22

SLIDE 12

Introduction: A timing side-channel on event loops

Event loops are susceptible to timing side-channel attacks: when shared between mutually distrusting programs

Pepe Vila Loophole November 22, 2016 5 / 22

SLIDE 13

Our work (in poetry)

“Loophole” Exploit a timing side-channel in the Chrome web browser to break user privacy using machine learning techniques

Abraham Lincoln

Pepe Vila Loophole November 22, 2016 6 / 22

SLIDE 14

Chrome’s architecture

Same Origin Policy (SOP) Multi-process Shared event loops

Pepe Vila Loophole November 22, 2016 7 / 22

SLIDE 15

Chrome’s architecture: Same Origin Policy (SOP)

Central concept in the web security model Script from a site A can not access data from site V if origins differ: Origin := (scheme, domain, port )

Pepe Vila Loophole November 22, 2016 8 / 22

SLIDE 16

Chrome’s architecture: Same Origin Policy (SOP)

Central concept in the web security model Script from a site A can not access data from site V if origins differ: Origin := (scheme, domain, port ) Origin 1 Origin 2 http://example.com:8080 http://example.com http://mail.example.com http://app.example.com https://foo.example.com https://foo.example.com https://example.com http://example.com

Pepe Vila Loophole November 22, 2016 8 / 22

SLIDE 17

Chrome’s architecture: Multi-process

Multi-process: 1 privileged host — N sandboxed renderers

2Chrome’s implementation of an event loop Pepe Vila Loophole November 22, 2016 9 / 22

SLIDE 18

Chrome’s architecture: Multi-process

Multi-process: 1 privileged host — N sandboxed renderers Each process has multiple threads. Each thread one message loop 2

2Chrome’s implementation of an event loop Pepe Vila Loophole November 22, 2016 9 / 22

SLIDE 19

Chrome’s architecture: Multi-process

Multi-process: 1 privileged host — N sandboxed renderers Each process has multiple threads. Each thread one message loop 2 DEMO: Chrome’s task manager

2Chrome’s implementation of an event loop Pepe Vila Loophole November 22, 2016 9 / 22

SLIDE 20

Chrome’s architecture: Shared event loops

Different policies for mapping applications into renderer processes (default: process-per-site-instance) A Site is a registered domain plus a scheme

Pepe Vila Loophole November 22, 2016 10 / 22

SLIDE 21

Chrome’s architecture: Shared event loops

Different policies for mapping applications into renderer processes (default: process-per-site-instance) A Site is a registered domain plus a scheme (different than SOP)

Pepe Vila Loophole November 22, 2016 10 / 22

SLIDE 22

Chrome’s architecture: Shared event loops

Different policies for mapping applications into renderer processes (default: process-per-site-instance) A Site is a registered domain plus a scheme (different than SOP) Sharing the renderer

◮ When using iframes, linked nagivation or |processes| > T ◮ T = 32 for 4 GB of RAM, and T = 70 for 8 GB or more Pepe Vila Loophole November 22, 2016 10 / 22

SLIDE 23

Chrome’s architecture: Shared event loops

Different policies for mapping applications into renderer processes (default: process-per-site-instance) A Site is a registered domain plus a scheme (different than SOP) Sharing the renderer

◮ When using iframes, linked nagivation or |processes| > T ◮ T = 32 for 4 GB of RAM, and T = 70 for 8 GB or more

Sharing the host process

◮ One for all renderers ◮ IPC through I/O thread Pepe Vila Loophole November 22, 2016 10 / 22

SLIDE 24

Spying on shared event loops

Main thread of a renderer I/O thread of the host process

Pepe Vila Loophole November 22, 2016 11 / 22

SLIDE 25

Spying on shared event loops

Main thread of renderer processes

Pepe Vila Loophole November 22, 2016 12 / 22

SLIDE 26

Spying on shared event loops

Main thread of renderer processes

◮ runs resource parsing, style calculation, layout, painting and Javascript ◮ each task blocks the event loop for a while ◮ when 2 pages share the process, the main thread’s event loop is shared ◮ A can eavesdrop information from V ’s tasks Pepe Vila Loophole November 22, 2016 12 / 22

SLIDE 27

Spying on shared event loops

Main thread of renderer processes

◮ runs resource parsing, style calculation, layout, painting and Javascript ◮ each task blocks the event loop for a while ◮ when 2 pages share the process, the main thread’s event loop is shared ◮ A can eavesdrop information from V ’s tasks

I/O thread of the host process

◮ manages IPC with all children renderers ◮ demultiplexes all UI events to each corresponding renderer ◮ multiplexes all network requests from renderers ◮ each task/message/event also blocks the event loop Pepe Vila Loophole November 22, 2016 12 / 22

SLIDE 28

Spying on shared event loops

Main thread of renderer processes

◮ runs resource parsing, style calculation, layout, painting and Javascript ◮ each task blocks the event loop for a while ◮ when 2 pages share the process, the main thread’s event loop is shared ◮ A can eavesdrop information from V ’s tasks

I/O thread of the host process

◮ manages IPC with all children renderers ◮ demultiplexes all UI events to each corresponding renderer ◮ multiplexes all network requests from renderers ◮ each task/message/event also blocks the event loop

Some tasks are very fast (<< 0.1 ms). We need high timing resolution.

Pepe Vila Loophole November 22, 2016 12 / 22

SLIDE 29

Spying on shared event loops: renderer’s main thread

Monitor the event loop from an arbitrary HTML page running Javascript:

function loop () { save( performance .now ()); // high -resolution timestamp

self. postMessage (0,’*’); //

recursive invocation } self.onmessage = loop; // set event handler

self. postMessage (0,’*’); // post

first async task

Pepe Vila Loophole November 22, 2016 13 / 22

SLIDE 30

Spying on shared event loops: renderer’s main thread

Monitor the event loop from an arbitrary HTML page running Javascript:

function loop () { save( performance .now ()); // high -resolution timestamp

self. postMessage (0,’*’); //

recursive invocation } self.onmessage = loop; // set event handler

self. postMessage (0,’*’); // post

first async task

1 Generates a trace of timing measurements 2 Resolution ≈ 25 µs Pepe Vila Loophole November 22, 2016 13 / 22

SLIDE 31

Spying on shared event loops: host’s I/O thread

Monitor the loop from any HTML page running Javascript:

function loop () { save( performance .now ()); fetch(new Request(’http ://0.0.0.0 ’)).catch(loop); } loop ();

Pepe Vila Loophole November 22, 2016 14 / 22

SLIDE 32

Spying on shared event loops: host’s I/O thread

Monitor the loop from any HTML page running Javascript:

function loop () { save( performance .now ()); fetch(new Request(’http ://0.0.0.0 ’)).catch(loop); } loop ();

Performs an invalid network request. Task is posted into the I/O event to be processed asynchronously. Fails quick and triggers our “catch” callback.

1 Resolution ≈ 0.5 ms Pepe Vila Loophole November 22, 2016 14 / 22

SLIDE 33

Spying on shared event loops: host’s I/O thread

Monitor the loop from any HTML page running Javascript:

function loop () { save( performance .now ()); fetch(new Request(’http ://0.0.0.0 ’)).catch(loop); } loop ();

Performs an invalid network request. Task is posted into the I/O event to be processed asynchronously. Fails quick and triggers our “catch” callback.

1 Resolution ≈ 0.5 ms 2 NEW METHOD: We obtain a resolution of < 0.1 ms! :D Pepe Vila Loophole November 22, 2016 14 / 22

SLIDE 34

Attacks

Covert channel Web page fingerprinting User action detection

Pepe Vila Loophole November 22, 2016 15 / 22

SLIDE 35

Attacks: covert channel

Covert-channel using timing differences bandwidth of 200 bit/s on same renderer, and 5 bit/s across processes VIDEO: https://www.youtube.com/watch?v=IlndCZmRDmI

Pepe Vila Loophole November 22, 2016 16 / 22

SLIDE 36

Attacks: web page fingerprinting

Pepe Vila Loophole November 22, 2016 17 / 22

SLIDE 37

Attacks: web page fingerprinting

Dynamic Time Warping Distance metric for time series: X = (x1, ..., xn) and Y = (y1, ..., ym) Robust to horizontal compressions and streches (warping)

Pepe Vila Loophole November 22, 2016 17 / 22

SLIDE 38

Attacks: web page fingerprinting

Dynamic Time Warping Distance metric for time series: X = (x1, ..., xn) and Y = (y1, ..., ym) Robust to horizontal compressions and streches (warping) Computes cross-distance matrix: M(i, j) = f (xi, yj) ≥ 0

Pepe Vila Loophole November 22, 2016 17 / 22

SLIDE 39

Attacks: web page fingerprinting

Dynamic Time Warping Distance metric for time series: X = (x1, ..., xn) and Y = (y1, ..., ym) Robust to horizontal compressions and streches (warping) Computes cross-distance matrix: M(i, j) = f (xi, yj) ≥ 0 Find optimal alignment φ such that: DTW (X, Y ) = min

φ dφ(X, Y )

Pepe Vila Loophole November 22, 2016 17 / 22

SLIDE 40

Attacks: web page fingerprinting

Dynamic Time Warping Distance metric for time series: X = (x1, ..., xn) and Y = (y1, ..., ym) Robust to horizontal compressions and streches (warping) Computes cross-distance matrix: M(i, j) = f (xi, yj) ≥ 0 Find optimal alignment φ such that: DTW (X, Y ) = min

φ dφ(X, Y )

Cost O(n · m) → We use Lemire’s lower bound.

Pepe Vila Loophole November 22, 2016 17 / 22

SLIDE 41

Attacks: web page fingerprinting

Figure: Warping matrix with optimal alignment between two time series

Pepe Vila Loophole November 22, 2016 18 / 22
