Light and clarity in KM3NeT Jordan Seneca My goal for this - - PowerPoint PPT Presentation

Jun 23, 2023 786 likes •1.34k views

Light and clarity in KM3NeT Jordan Seneca My goal for this presentation Inspire, stimulate questions and discussion 05/23/19 Jordan Seneca 2 Working towards a better ARCA res What I find exciting about my work How to convey

slide-1
SLIDE 1

Light and clarity in KM3NeT

Jordan Seneca

slide-2
SLIDE 2

05/23/19 Jordan Seneca 2

My goal for this presentation

Inspire, stimulate questions and discussion

slide-3
SLIDE 3

05/23/19 Jordan Seneca 3

 Working towards a better ARCA res  What I find exciting about my work  How to convey excitement to others

slide-4
SLIDE 4

05/23/19 Jordan Seneca 4

 Working towards a better ARCA res  What I find exciting about my work  How to convey excitement to others

slide-5
SLIDE 5

05/23/19 Jordan Seneca 5

Last year, in Dalfsen

Me

slide-6
SLIDE 6

05/23/19 Jordan Seneca 6

Current reconstruction Aanet PDFs

PMT position 1 PMT direction Reception angle

New reconstruction Jpp PDFs

PMT position 2 PMT directions Reception angle Arrival time

slide-7
SLIDE 7

05/23/19 Jordan Seneca 7

I found weird stuff.

slide-8
SLIDE 8

05/23/19 Jordan Seneca 8

I found bugs in Jpp PDFs.

slide-9
SLIDE 9

05/23/19 Jordan Seneca 9

I found bugs in Jpp PDFs.

slide-10
SLIDE 10

05/23/19 Jordan Seneca 10

Bugs have now been fixed!

Thank you Maarten MC truth New reco Old reco

slide-11
SLIDE 11

05/23/19 Jordan Seneca 11

Bugs have now been fixed!

Thank you Maarten

Sub 1 deg resolution

slide-12
SLIDE 12

05/23/19 Jordan Seneca 12

Bugs have now been fixed!

Thank you Maarten

Sub 1 deg resolution

Not t so

  • fa

fast !!! !!!

slide-13
SLIDE 13

05/23/19 Jordan Seneca 13

 Working towards a better ARCA res  What I find exciting about my work  How to convey excitement to others

slide-14
SLIDE 14

05/23/19 Jordan Seneca 14

 Why are Jpp and AAnet PDFs

different?

slide-15
SLIDE 15

05/23/19 Jordan Seneca 15

disagreement Jpp PDF: based on theoretical approximations AAnet PDF: MC interpolation

slide-16
SLIDE 16

05/23/19 Jordan Seneca 16

 Why are Jpp and AAnet PDFs

different?

 N-scattered light? Other

approximations?

slide-17
SLIDE 17

05/23/19 Jordan Seneca 17

When close, a lot of direct light

25m, PMT angle -1.0

slide-18
SLIDE 18

05/23/19 Jordan Seneca 18

When far away, mostly 1- scattered light

100m, PMT angle -1.0

slide-19
SLIDE 19

05/23/19 Jordan Seneca 19

When very far away, only 1- scattered light?

400m, PMT angle -1.0

slide-20
SLIDE 20

05/23/19 Jordan Seneca 20

 Why are Jpp and AAnet PDFs

different?

 N-scattered light? There are other

approximations we could try.

 Re-emission?

slide-21
SLIDE 21

05/23/19 Jordan Seneca 21

Less than 60% of visible light is not absorbed after 100m 63% 0.1%

slide-22
SLIDE 22

05/23/19 Jordan Seneca 22

Less than 60% of the light is not absorbed after 100m 63% 0.1% All these hard photons are absorbed. Re-emission in visible?

slide-23
SLIDE 23

05/23/19 Jordan Seneca 23

 Why are Jpp and AAnet PDFs

different?

 N-scattered light? There are other

approximations we could try.

 Re-emission?  Spread of particle shower

slide-24
SLIDE 24

05/23/19 Jordan Seneca 24

63% 0.1% At low energies, showers are small

Particle shower Cherenkov photons

Not so much at high energies How does the longitudinal and radial spread affect the light profile?

slide-25
SLIDE 25

05/23/19 Jordan Seneca 25

*dis *distant nt sni nicke ker*

slide-26
SLIDE 26

05/23/19 Jordan Seneca 26

 Working towards a better ARCA res  What I find exciting about my work  How to convey excitement to others

slide-27
SLIDE 27

05/23/19 Jordan Seneca 27

Exhibit A: The type of slides we show each

  • ther during collaboration meetings

in KM3NeT

slide-28
SLIDE 28

05/23/19 Jordan Seneca 28

slide-29
SLIDE 29

05/23/19 Jordan Seneca 29

slide-30
SLIDE 30

05/23/19 Jordan Seneca 30

slide-31
SLIDE 31

05/23/19 Jordan Seneca 31

slide-32
SLIDE 32

05/23/19 Jordan Seneca 32

slide-33
SLIDE 33

05/23/19 Jordan Seneca 33

Analysis Visibility DATA Progress status Conclusion ATel BACKUP Sensitivities

Astronomy Telegram : 17-01-2018 announcements

11184 FACT : Exceptional Flare of Mrk 421 at TeV energies

Since December 2017, Mrk 421 has been showing already some activity at TeV energies, as reported in the ATels #11077 and #11086 by the FACT and HAWC collaborations. The source was observed by FACT for a total of 5.5 hours between 1:15 UTC and 7:05 UTC (MJD 58135). At the beginning of the observation, the source showed a flux of about 6-7 times that

  • f the Crab Nebula (CU) at TeV energies, then increasing to more than 9 CU. Over the whole
  • bservation, the flux was varying between 3 and 10 CU with a decrease towards the end of

the night and an average flux of roughly 6 CU.

11186 MAXI/GSC : detection of a rapid X-ray brightening from Mrk 421 11194 HAWC : observation of Mrk421 reaching peak TeV flux in month-long enhanced activity

( 6 equivalent CU) between 2018-01-17 06:39 and 09:47 UTC. This is about 10 times the all-time averaged flux measured by HAWC and the highest one since the beginning of this enhanced period. Enhanced emission has also been reported by FACT (ATel #11086 and #11184), and MAXI/GSC (ATel #11186).

11195 Swift/BAT : finds hard X-Ray flaring activity correlated with an

  • ngoing TeV flare of Mrk421

11199 TACTIC : detection of a strong TeV flare from Mrk 421

Multi-wavelength observations of this enhanced activity of the source have also been reported by FACT ( ATels : #11184), HAWC ( ATel : #11194), MAXI/GSC ( ATel : #11186) & Swift/BAT ( ATel : #11195). An exceptional flare was reported by FACT at TeV energies between 1:15 UTC and 7:05 UTC on Jan 17 (MJD 58135) with a maximum of >10 CU and a decrease towards the end of the night. The ongoing flaring activity of Mrk421 at TeV energies was already reported since December 2017 by the FACT and HAWC collaboration (ATels #11077 and #11086).

Mukharbek Organokov Université de Strasbourg HAWC blazars analysis 25 October 2018 22 / 28

slide-34
SLIDE 34

05/23/19 Jordan Seneca 34

Why?

slide-35
SLIDE 35

05/23/19 Jordan Seneca 35

 “I need to know what to say”

 Use notes in your

PowerPoint-like program

 Do a dry run

slide-36
SLIDE 36

05/23/19 Jordan Seneca 36

 “I need to know what to say”  “Slides are used as work logs”

There are other ways of logging work:

 Elog  Wiki  Uploading .ppt with notes  Uploading .pdf with notes  Backup slides

slide-37
SLIDE 37

05/23/19 Jordan Seneca 37

 “I need to know what to say”  “Slides are used as work logs”  “It takes effort to make nice slides”

The KM3NeT template will help with that

slide-38
SLIDE 38

05/23/19 Jordan Seneca 38

The KM3NeT template

 Slide types  Predetermined fonts  Predetermined colors  Bank of logos  Bank of images

slide-39
SLIDE 39

05/23/19 Jordan Seneca 39

slide-40
SLIDE 40

23/05/19 Jordan Seneca 40

Search for

Neutrino counterparts

  • f HAWC point-sources

Michael Smith Margaret Davis

slide-41
SLIDE 41

05/23/19 Jordan Seneca 41

slide-42
SLIDE 42

23/05/19 Jordan Seneca 42

 PMT efficiency calibration update  K40 simulations comparison  K40 simulation updates

slide-43
SLIDE 43

05/23/19 Jordan Seneca 43

Data/MC comparison

Variables: tcosth > 0 (upgoing), λ >-5.6 -5.4 -5.2 -5.0 -4.8 (AAFit) or χ2 <0.9 0.8 0.7 0.6 (BBFit) estimate of angular error β < 1◦ (AAFit) With previous best cut 6466 tracks (2007-16), 5862 tracks (2007-15), 678 tracks (2017). Still processing mupage ntuples 2017 only 2007-17

3 / 12

slide-44
SLIDE 44

05/23/19 Jordan Seneca 44

Data/MC comparison

Variables: tcosth>0 (upgoing), λ > -5.6 -5.4 -5.2 -5.0 -4.8 (AAFit) or χ 2 <0.9 0.8 0.7 0.6 (BBFit) estimate of angular error β < 1 ◦ (AAFit) With previous best cut 6466 tracks (2007-16), 5862 tracks (2007-15), 678 tracks (2017). Still processing mupage ntuples

2017 only 2007 - 17

slide-45
SLIDE 45

05/23/19 Jordan Seneca 45

Data/MC comparison

Variables: tcosth>0 (upgoing), λ > -5.6 -5.4 -5.2 -5.0 -4.8 (AAFit) or χ 2 <0.9 0.8 0.7 0.6 (BBFit) estimate of angular error β < 1 ◦ (AAFit) With previous best cut 6466 tracks (2007-16), 5862 tracks (2007-15), 678 tracks (2017). Still processing mupage ntuples

2017 only 2007 - 17

slide-46
SLIDE 46

05/23/19 Jordan Seneca 46

Data/MC comparison

Variables: tcosth>0 (upgoing), λ > -5.6 -5.4 -5.2 -5.0 -4.8 (AAFit) or χ 2 <0.9 0.8 0.7 0.6 (BBFit) estimate of angular error β < 1 ◦ (AAFit) With previous best cut 6466 tracks (2007-16), 5862 tracks (2007-15), 678 tracks (2017). Still processing mupage ntuples

2017 only 2007 - 17

slide-47
SLIDE 47

05/23/19 Jordan Seneca 47

Data/MC comparison

Looking at upgoing neutrinos from GC With previous best cut 6466 tracks (2007-16), 5862 tracks (2007-15), 678 tracks (2017). Still processing mupage ntuples

slide-48
SLIDE 48

05/23/19 Jordan Seneca 48

Data/MC comparison

Looking at upgoing neutrinos from GC 2007 - 17: 7.2k tracks 2017: 0.7k tracks Muons not included in MC Is there an excess?

slide-49
SLIDE 49

05/23/19 Jordan Seneca 49

Data/MC comparison

Looking at upgoing neutrinos from GC 2007 - 17: 7.2k tracks 2017: 0.7k tracks Muons not included Is there an excess?

slide-50
SLIDE 50

05/23/19 Jordan Seneca 50

Data/MC comparison

Looking at upgoing neutrinos from GC 2007 - 17: 7.2k tracks 2017: 0.7k tracks Muons not included in MC Is there an excess?

slide-51
SLIDE 51

05/23/19 Jordan Seneca 51

Data/MC comparison

Variables: tcosth > 0 (upgoing), λ >-5.6 -5.4 -5.2 -5.0 -4.8 (AAFit) or χ2 <0.9 0.8 0.7 0.6 (BBFit) estimate of angular error β < 1◦ (AAFit) With previous best cut 6466 tracks (2007-16), 5862 tracks (2007-15), 678 tracks (2017). Still processing mupage ntuples 2017 only 2007-17

3 / 12

slide-52
SLIDE 52

05/23/19 Jordan Seneca 52

“Looks good enough to be used out

  • f the box,

is simple enough that it will rarely need cleaning up.”

~ me

slide-53
SLIDE 53

05/23/19 Jordan Seneca 53

I am working towards improving the reconstruction of showers in ARCA Light in our detector is interesting and important to think about The KM3NeT template is in the works for streamlining quality presentations
